make your selection, touch the “+” or “–” soft-keys to
adjust the minutes up or down. Touch the back arrow
soft-key to return to the previous menu or touch the “X”
soft-key to close out of the settings screen.
•Time Format
When in this display, you may select the time format
display setting. Touch the “Time Format” soft-key until a
check-mark appears next to the 12hrs or 24hrs setting,
showing that setting has been selected. Touch the back
arrow soft-key to return to the previous menu.
Safety & Driving Assistance
After pressing the “Safety & Driving Assistance” soft-key
the following settings will be available.
• Park Assist
The Rear Park Assist system will scan for objects behind
the vehicle when the transmission shift lever is in RE-
VERSE and the vehicle speed is less than 11 mph (18 km/h). The system can be enabled with Sound Only
or Sound and Display. To change the Park Assist status,
touch and release the “Sound Only” or the “Sounds and
Display” soft-key. Then touch the back arrow soft-key.
Refer to “ParkSense® Rear Park Assist” in “Understand-
ing The Features Of Your Vehicle” for system function
and operating information.
•
Tilt Mirrors In Reverse
When this feature is selected, the outside sideview mir-
rors will tilt downward when the ignition is in the RUN
position and the transmission shift lever is in the RE-
VERSE position. The mirrors will move back to their
previous position when the transmission is shifted out of
REVERSE. To make your selection, touch the “Tilt Mir-
rors In Reverse” soft-key, until a check-mark appears next
to setting, showing that setting has been selected. Touch
the back arrow soft-key to return to the previous menu.
338 UNDERSTANDING YOUR INSTRUMENT PANEL

CAUTION!
Do not use Alcohol and Alcohol-based and/or Keton
based cleaning products to clean leather seats, as
damage to the seat may result.
Cleaning Headlights
Your vehicle is equipped with plastic headlights and fog
lights that are lighter and less susceptible to stone break-
age than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MOPAR® Glass Cleaner, or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning the inside rear win-
dow equipped with electric defrosters or the right rear
quarter window equipped with the radio antenna. Do
not use scrapers or other sharp instrument that may
scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
7
MAINTAINING YOUR VEHICLE 717

Grocery Bag Retainer...................... .236
Gross Axle Weight Rating ...................582
Gross Vehicle Weight Rating ..................582
Guide, Body Builders ........................6
GVWR ................................ .579
Hazard Driving Through Flowing, Rising, or Shallow
Standing Water ........................ .486
Hazard Warning Flasher ....................617
Headlights ............................. .732
Automatic ........................... .163
Cleaning ............................ .717
High Beam ........................... .173
High Beam/Low Beam Select Switch .........173
Passing ............................. .173
Switch .............................. .163
Head Restraints ......................... .154
Heated Mirrors .......................... .139
Heater ................................ .356Heater, Engine Block
...................... .393
High Beam/Low Beam Select (Dimmer) Switch . . . .173
Hitches Trailer Towing ........................ .585
Hoisting ............................... .659
HomeLink® (Garage Door Opener) ............207
Hood Release ........................... .160
Hub Caps .............................. .657
Ignition .................................16
Key..................................12
Ignition Key Removal .......................16
Illuminated Entry ..........................22
Immobilizer (Sentry Key) ....................18
Infant Restraint ...........................82
Inflation Pressure Tires .....................551
Inside Rearview Mirror .....................128
Instrument Cluster ....................... .278
Instrument Panel and Controls ................275
Instrument Panel Lens Cleaning ...............717
776 INDEX

Malfunction Indicator Light (Check Engine).......682
Manual, Service ......................... .766
Manual Transmission Fluid Level Check ...................... .708
Lubricant Selection ..................... .746
Memory Seat ........................... .156
Methanol .............................. .569
Mirrors ............................... .128
Electric Powered ....................... .137
Heated .............................. .139
Memory ............................. .156
Outside ............................. .135
Rearview ............................ .128
Trailer Towing ........................ .141
Modifications/Alterations, Vehicle ...............7
Monitor, Tire Pressure System ................557
Mopar Parts ............................ .683
MTBE/ETBE ........................... .569
Multi-Function Control Lever .................172Navigation System (Uconnect® gps)
............202
New Vehicle Break-In Period .................114
Occupant Restraints ........................49
Occupant Restraints (Sedan) ..................70
Octane Rating, Gasoline (Fuel) ................568
Off-Pavement Driving (Off-Road) ..............466
Off-Road Driving (Off-Pavement) ..............466
Oil, Engine ............................. .685
Capacity ............................ .742
Change Interval ....................... .686
Dipstick ............................. .685
Disposal ............................. .688
Filter ............................... .688
Filter Disposal ........................ .688
Identification Logo ..................... .686
Recommendation ...................... .686
Synthetic ............................ .688
V

iscosity ............................ .687
Oil Filter, Selection ....................... .688
10
INDEX 779

Onboard Diagnostic System..................681
Operating Precautions ..................... .681
Operator Manual (Owner’s Manual) .............4
Outside Rearview Mirrors ...................135
Overdrive .............................. .415
Overdrive OFF Switch ..................... .415
Overhead Console ........................ .205
Overheating, Engine ...................... .287
Owner’s Manual (Operator Manual) .............4
Paint Care ............................. .712
Panic Alarm ..............................27
Parking Brake ........................... .512
ParkSense System, Rear .....................185
Passing Light ........................... .173
Pedals, Adjustable ........................ .180
Personal Settings ......................... .323
Pets ...................................114
Pets, Transporting .........................114
Pickup Box ............................. .240Placard, Tire and Loading Information
..........536
Power Distribution Center (Fuses) ................721
Door Locks ............................38
Mirrors ............................. .137
Outlet (Auxiliary Electrical Outlet) ...........219
Seats ............................... .142
Sliding Rear Window ....................237
Steering ............................. .509
Sunroof ............................. .216
Windows ..............................45
Power Steering Fluid ...................... .746
Pregnant Women and Seat Belts ................66
Pretensioners Seat Belts ..............................64
Programmable Electronic Features .............323
Programming Transmitters (Remote Keyless Entry) . .23
Radial Ply Tires ......................... .543
Radiator Cap (Coolant Pressure Cap) ...........697
780 INDEX
