312 STARTING AND OPERATING
NOTE:
Do not attempt to make a shift while only the front or rear
wheels are spinning. This could cause damage to driveline
components.
When operating your vehicle in 4WD LOW, the engine
speed is approximately three times that of the 2WD or 4WD
HIGH positions at a given road speed. Take care not to over-
speed the engine and do not exceed 25 mph (40 km/h).
Proper operation of four-wheel drive vehicles depends on
tires of equal size, type and circumference on each wheel.
Any difference in tire size can cause damage to the drive -
train.
Because four-wheel drive provides improved traction, there
is a tendency to exceed safe turning and stopping speeds. Do
not go faster than road conditions permit. Shifting Procedure
NOTE:
• If any of the requirements to select a new transfer case
position have not been met, the transfer case will not shift.
The position indicator light for the previous position will
remain ON and the newly selected position indicator light
will continue to flash until all the requirements for the
selected position have been met.
• If all the requirements to select a new transfer case position have been met, the current position indicator light will
turn OFF, the selected position indicator light will flash
until the transfer case completes the shift. When the shift is
complete, the position indicator light for the selected posi -
tion will stop flashing and remain ON.
2WD To 4WD HIGH
Push the desired position on the 4WD control switch to shift
the transfercase. Shifts between 2WD and 4WD HIGH can be
done with the vehicle stopped or in motion. With the vehicle
in motion, the transfer case will engage/disengage faster if
you momentarily release the accelerator pedal after turning
the control switch. If the vehicle is stopped, the ignition
switch must be in the ON position with the engine either
running or off. This shift cannot be completed if the ignition
switch is in the ACC position.
WARNING!

Always engage the parking brake when powering down the
vehicle if the “SVC 4WD Warning Light” is illuminated.
Not engaging the parking brake may allow the vehicle to
roll which may cause personal injury or death.

STARTING AND OPERATING 315
The “Transfer Case Position Indicator Light” in the instru-
ment cluster will alert the driver that the vehicle is in
four-wheel drive and that the front and rear driveshafts are
locked together. This light will illuminate when the transfer
case is shifted into either the 4H or 4L position. There is no
light for the 2H or NEUTRAL positions on some models.
When operating your vehicle in 4L, the engine speed is
approximately three times that of the 2H or 4H positions at a
given road speed. Take care not to overspeed the engine and
do not exceed 25 mph (40 km/h).
Proper operation of four-wheel drive vehicles depends on
tires of equal size, type and circumference on each wheel.
Any difference will adversely affect shifting and can cause
damage to the drivetrain.
NOTE:
Do not attempt to make a shift while only the front or rear
wheels are spinning, as this can cause damage to driveline
components.
Because four-wheel drive provides improved traction, there
is a tendency to exceed safe turning and stopping speeds. Do
not go faster than road conditions permit.NOTE:
Delayed shifts out of four-wheel drive may be experienced
due to uneven tire wear, low or uneven tire pressures, exces
-
sive vehicle loading, or cold temperatures.
Two-Wheel Drive High Range (2H)
Rear-Wheel Drive High Range — This range is for normal
street and highway driving on dry hard surfaced roads.
Four-Wheel Drive High Range (4H)
Four-Wheel Drive High Range — This range locks the front
and rear driveshafts together forcing the front and rear
wheels to rotate at the same speed. Additional traction for
loose, slippery road surfaces only.
WARNING!
You or others could be injured or killed if you leave the
vehicle unattended with the transfer case in the
NEUTRAL position without first fully engaging the
parking brake. The transfer case NEUTRAL position
disengages both the front and rear drive shafts from the
powertrain and will allow the vehicle to roll, even if the
transmission is in PARK. The parking brake should
always be applied when the driver is not in the vehicle.
5

322 STARTING AND OPERATING
To lock the rear axle, place the vehicle in 4LO. Refer to “Four
Wheel Drive Operation” in “Starting And Operating” for
further information. Push the REAR LOCK button while
traveling less than 3 mph (5 km/h). The RR indicator light
will remain on when the rear axle is locked.
NOTE:
Left to right wheel speed difference may be necessary to
allow the axle to fully lock. If the indicator light is flashing
after placing the switch in the REAR LOCK or FRONT/
REAR LOCK position, drive the vehicle in a turn or on loose
gravel to expedite the locking action.
To lock the front axle; push the FRONT/REAR LOCK button
while traveling less than 3 mph (5 km/h). The indicator light
will be solid when the front axle is locked.
NOTE:
The rear axle must be locked before the front axle will lock. To unlock the front axle; push the REAR LOCK button. The
FRONT/REAR LOCK indicator light will go out when the
axle is unlocked.
NOTE:
The axle lockers could be torque locked due to side to side
loads on the axle. Driving slowly while turning the steering
wheel from a left hand turn to a right hand turn or driving in
REVERSE for a short distance may be required to release the
torque lock and unlock the axles.
To unlock the rear axle; push the AXLE UNLOCK button.
The REAR LOCK indicator light will go out when the rear
axle is unlocked.
STABILIZER/SWAY BAR SYSTEM — POWER WAGON
ONLY
Your vehicle is equipped with an electronic disconnecting
stabilizer/sway bar. This system allows greater front
suspension travel in off-road situations.
Due to the use of taller springs, this vehicle has an increased
ride height of approximately 1.9 in (48.3 mm) in the front
and 1.5 in (38.1 mm) in the rear. A major advantage to
increasing ride height is the positive effect it has on
approach/departure and break over angles.
WARNING!
Do not use the locked axle position for normal driving. A
locked front axle is intended for off-road driving only.
Locking the front axle during on-road driving will
reduce the steering ability. This could cause a collision
and you may be seriously injured.

STARTING AND OPERATING 323
This system is controlled by the electronic control sway bar
switch located below the instrument panel.Sway Bar Disconnect Button
Push the SWAY BAR switch to activate the system. Push the
switch again to deactivate the system. The “Sway Bar Indi -
cator Light” (located in the instrument cluster) will illumi -
nate when the bar is disconnected. The “Sway Bar Indicator
Light” will flash during activation transition, or when activa -
tion conditions are not met. The stabilizer/sway bar should
remain in on-road mode during normal driving conditions. To disconnect the stabilizer/sway bar, shift to either 4HI or
4LO and push the SWAY BAR button to obtain the Off-Road
position. Refer to “Four Wheel Drive Operation” in “Starting
And Operating” for further information. The “Sway Bar
Indicator Light” will flash until the stabilizer/sway bar has
been fully disconnected.
NOTE:
The stabilizer/sway bar may be torque locked due to left and
right suspension height differences. This condition is due to
driving surface differences or vehicle loading. In order for
the Stabilizer/Sway Bar to disconnect/reconnect, the rightWARNING!
Do not disconnect the stabilizer bar and drive on hard
surfaced roads or at speeds above 18 mph (29 km/h), you
may lose control of the vehicle, which could result in
serious injury or death. The front stabilizer bar enhances
vehicle stability and assists in maintaining control of the
vehicle. The system monitors vehicle speed and will
attempt to reconnect the stabilizer bar at speeds over
18 mph (29 km/h). This is indicated by a flashing off road
light and solid on road light. Once vehicle speed is
reduced below 14 mph (22 km/h), the system will
attempt to return to the Off-Road mode.
5

324 STARTING AND OPERATING
and left halves of the bar must be aligned. This alignment
may require that the vehicle be driven onto level ground or
rocked from side to side.
To return to the On-Road mode; push the SWAY BAR button
again.
SAFE OFF-ROAD DRIVING — POWER WAGON ONLY
Off-Road Driving Tips And Vehicle Characteristics
Your vehicle has excellent on and off-road capabilities. These
off-road capabilities will allow you to explore those wilder-
ness trails where few travel, providing a source of exciting
and satisfying recreation. Before you venture out, you
should contact your local governmental agency to determine
the designated off-road vehicle (ORV) trails or recreation areas. You should always tread lightly and only use estab
-
lished roads, trails or ORV recreational areas.
The National Forest Service, Bureau of Land Management,
or local Department of Natural Resources are a wealth of
information and usually have maps with marked trails.
Skid Plates And Underbody Protection
Steel skid plates protect the major driveline components of
the truck including the fuel tank, transfer case and steering
damper. In addition, this vehicle is equipped with boxed
cross members and fore/aft rails. This additional protection
allows the vehicle to be utilized in severe off-road situations
that would be considered impassable by a normal truck.
Ramp Travel Index (RTI)
The ramp travel index is the distance, in inches, that you can
drive your vehicle with one wheel on a 20-degree ramp
without lifting any other wheel off the ground. This distance
up the ramp divided by the wheelbase of the vehicle and
multiplied by 1,000 is the RTI. This vehicle has an RTI of 510,
which means you can articulate one front wheel 26 inches (66
cm) in the air while the other three wheels remain in contact
with the ground.
WARNING!
If the stabilizer/sway bar will not return to On-Road
mode, vehicle stability is reduced. Do not attempt to
drive the vehicle over 18 mph (29 km/h). Driving faster
than 18 mph (29 km/h) may cause loss of control of the
vehicle, which could result in serious injury or death.
Contact your local service center for assistance.

STARTING AND OPERATING 325
Water Fording Characteristics
Water fording characteristic is the vehicle's ability to cross a
body of still water, where the powertrain and drivetrain are
safe from water ingestion. This vehicle has high water
fording characteristics with the ability to cross a pool of
water, without stopping, 24 inches (60 cm) deep at a
maximum speed of 10 mph (16 km/h) and a pool of water
30 inches (76 cm) deep at a maximum speed of 5 mph (8 km/
h), both with an entrance ramp angle of 1.3 degrees.
Simultaneous Brake And Throttle Operation
Many off-road driving conditions require the simultaneous
use of the brake and throttle (two footed driving). When
climbing rocks, logs, or other stepped objects, using light
brake pressure with light throttle will keep the vehicle from
jerking or lurching. This technique is also used when you
need to stop and restart a vehicle on a steep incline.The Basics Of Off-Road Driving
You will encounter many types of terrain driving off-road.
You should be familiar with the terrain and area before
proceeding. There are many types of surface conditions:
hard packed dirt, gravel, rocks, grass, sand, mud, snow and
ice. Every surface has a different effect on your vehicle's
steering, handling and traction. Controlling your vehicle is
one of the keys to successful off-road driving, so always keep
a firm grip on the steering wheel and maintain a good
driving posture. Avoid sudden accelerations, turns or
braking. In most cases there are no road signs, posted speed
limits or signal lights. Therefore you will need to use your
own good judgment on what is safe and what isn't. When on
a trail you should always be looking ahead for surface obsta
-
cles and changes in terrain. The key is to plan your future
driving route while remembering what you are currently
driving over.
CAUTION!
The door sill height is 25 inches (63.5 cm). Water may
intrude into the interior of the vehicle at greater depths.
WARNING!
Always wear your seat belt and firmly tie down cargo.
Unsecured cargo can become projectiles in an off-road
situation.
5

STARTING AND OPERATING 327
entering any mud hole, get out and determine how deep it
is, if there are any hidden obstacles and if the vehicle can
be safely recovered if stuck.
• Sand – Soft sand is very difficult to travel through with full
tire pressure. When crossing soft sandy spots in a trail
maintain your vehicle's momentum and do not stop. The
key to driving in soft sand using the appropriate tire pres -
sure, accelerating slowly, avoiding abrupt maneuvers and
maintaining the vehicle's momentum. If you are going to
be driving on large soft sandy areas or dunes, reduce your
tire pressure to a minimum of 15 psi (103 kPa) to allow for
a greater tire surface area. Reduced tire pressure will dras -
tically improve your traction and handling, while driving
on the soft sand, but you must return the tires to normal air
pressure before driving on pavement or other hard
surfaces. Be sure you have a way to air the tires back up
prior to reducing the pressure.Crossing Obstacles (Rocks And Other High Points)

While driving off road, you will encounter many types of
terrain. These varying types of terrain bring different types of
obstacles. Before proceeding review the path ahead to deter -
mine the correct approach and your ability to safely recover the
vehicle if something goes wrong. Keeping a firm grip on the
steering wheel, bring the vehicle to a complete stop and then
inch the vehicle forward until it makes contact with the object.
Apply the throttle lightly while holding a light brake pressure
and ease the vehicle up and over the object.

Using A Spotter
There are many times where it is hard to see the obstacle or
determine the correct path. Determining the correct path can
be extremely difficult when you are confronting many obsta -
cles. In these cases have someone guide you over, through, or
around the obstacle. Have the person stand a safe distance in
front of you where they can see the obstacle, watch your tires
and undercarriage, and guide you through.
CAUTION!
Reduced tire pressures may cause tire unseating and
total loss of air pressure. To reduce the risk of tire
unseating, while at a reduced tire pressure, reduce your
speed and avoid sharp turns or abrupt maneuvers.
WARNING!
Crossing obstacles can cause abrupt steering system
loading which could cause you to loose control of your
vehicle.
5

328 STARTING AND OPERATING
Crossing Large Rocks
When approaching large rocks, choose a path which ensures
you drive over the largest with your tires. This will lift your
undercarriage over the obstacle. The tread of the tire is
tougher and thicker than the side wall and is designed to
take the abuse. Always look ahead and make every effort to
cross the large rocks with your tires.
Crossing A Ravine, Gully, Ditch, Washout Or Rut
When crossing a ravine, gully, ditch, washout or a large rut,
the angled approach is the key to maintaining your vehicle's
mobility. Approach these obstacles at a 45-degree angle and
let each tire go through the obstacle independently. You
need to use caution when crossing large obstacles with steep
sides. Do not attempt to cross any large obstacle with steep
sides at an angle great enough to put the vehicle at risk of a
rollover. If you get caught in a rut, dig a small trench to the
right or left at a 45-degree angle ahead of the front tires. Usethe removed dirt to fill the rut ahead of the turnout you just
created. You should now be able to drive out following the
trench you just created at a 45-degree angle.
Crossing Logs
To cross a log, approach it at a slight angle (approximately 10
to 15 degrees). This allows one front tire to be on top of the
log while the other just starts to climb the log. While climbing
the log, modulate your brake and accelerator to avoid spin
-
ning the log out from under your tires. Then ease the vehicle
off the log using your brakes.
CAUTION!
• Never attempt to straddle a rock that is large enough to strike your axles or undercarriage.
• Never attempt to drive over a rock which is large enough to contact the door sills.
WARNING!
There is an increased risk of rollover when crossing an
obstacle, at any angle, with steep sides.
CAUTION!
Do not attempt to cross a log with a greater diameter than
the running ground clearance or the vehicle will become
high centered.

330 STARTING AND OPERATING
provide enough traction to complete the climb. If you do
not make it to the top, place the vehicle in REVERSE and
back straight down the grade using engine resistance
along with the vehicle brakes.
• Driving Down Hill – Before driving down a steep hill you
need to determine if it is too steep for a safe descent. What
is the surface traction? Is the grade too steep to maintain a
slow controlled descent? Are there obstacles? Is it a
straight descent? Is there plenty of distance at the base of
the hill to regain control if the vehicle descends too fast? If
you feel confident in your ability to proceed then make
sure you are in 4LO (Low Range) with the transmission in
first gear (manually select first gear on automatic transmis -
sions) and proceed with caution. Allow engine braking to
control the descent and apply your brakes if necessary, but
do not allow the tires to lock. •
Driving Across An Incline – If at all possible avoid
driving across an incline. If it is necessary, know your
vehicle's abilities. Driving across an incline places more
weight on the down hill wheels, which increases the possi -
bilities of a down hill slide or rollover. Make sure the
surface has good traction with firm and stable soils. If
possible transverse the incline at an angle heading slightly
up or down.
• If You Stall Or Begin To Lose Headway – If you stall or
begin to lose headway while climbing a steep hill, allow
your vehicle to come to a stop and immediately apply the
brake. Restart the engine and shift into REVERSE. Back
slowly down the hill allowing the compression braking of
the engine and transmission to help regulate your speed. If
WARNING!
Never attempt to climb a hill at an angle or turn around
on a steep grade. Driving across an incline increases the
risk of a roll over, which may result in severe injury or
death.
WARNING!
Do not descend a steep grade in NEUTRAL. Use vehicle
brakes in conjunction with engine braking. Descending
a grade too fast could cause you to lose control and be
seriously injured or killed.
WARNING!
Driving across an incline increases the risk of a rollover,
which may result in severe injury.

STARTING AND OPERATING 331
the brakes are required to control vehicle speed, apply
them lightly and avoid locking or skidding the tires.
Driving Through Water
Extreme care should be taken crossing any type of water.
Water crossings should be avoided if possible and only be
attempted when necessary, in a safe responsible manner.
You should only drive through areas which are designated
and approved. You should tread lightly and avoid damage
to the environment. You should know your vehicle's abilities
and be able to recover it if something goes wrong. You
should never stop or shut a vehicle off when crossing deep
water unless you ingested water into the engine air intake. If
the engine stalls do not attempt to restart it. Determine if it
has ingested water first. The key to any crossing is low andslow. You want to use first gear in 4L (Low Range) and
proceed very slowly with a constant slow speed (3-5 mph
[5–8 km/h] maximum) and light throttle. Keep the vehicle
moving; do not try to accelerate through the crossing. After
crossing any water higher than the bottom of the axle differ
-
entials, you should inspect all of the vehicle fluids for signs
of water ingestion.
• Before You Cross Any Type Of Water – As you approach
any type of water you need to determine if you can cross it
safely and responsibly. If necessary, get out and walk
through the water or probe it with a stick. You need to be
sure of its depth, approach angle, current and bottom
condition. Be careful of murky or muddy waters, check for
hidden obstacles. Make sure you will not be intruding on
any wildlife and you can recover the vehicle if necessary.
The key to a safe crossing is the water depth, current and
bottom conditions. On soft bottoms the vehicle will sink in,
WARNING!
If the engine stalls or you lose headway or cannot make
it to the top of a steep hill or grade, never attempt to turn
around. To do so may result in tipping and rolling the
vehicle, which may result in severe injury. Always back
carefully straight down a hill in REVERSE. Never back
down a hill in NEUTRAL using only the vehicle brakes.
Never drive diagonally across a hill, always drive
straight up or down.
CAUTION!
Water ingestion into the axles, transmission, transfer
case, engine or vehicle interior can occur if you drive too
fast or through too deep of water. Water can cause
permanent damage to engine, driveline or other vehicle
components and your brakes will be less effective once
wet and/or muddy.
5
