engine RENAULT ESPACE 2000 J66 / 3.G Technical Note 3426A Owner's Manual

Downloaded from www.Manualslib.com manuals search engine TOP AND FRONT OF ENGINE
Timing belt
11
11 - 7
Tighten:
–bolt (8) of the tension wheel to a torque of 2.5 daN.m,
–the camshaft timing sprocket bolts (9) to a torque of
1 daN.m.Remove the camshaft timing tools Mot. 1534 and
Mot. 1537 and the TDC pin Mot. 1536.
Refit the cap in the TDC pin opening applying
RHODORSEAL 5661 to the thread and by tightening
to a torque of 2.2 daN.m.
Refitting is the reverse of removal.
To refit the right-hand suspended mounting, you must
consult section 19 "Suspended mountings".
17553M4
15854M

Downloaded from www.Manualslib.com manuals search engine TOP AND FRONT OF ENGINE
Cylinder head gasket
11
11 - 8
Cylinder head gasket
Consult manual Mot. G9 for the details of this
operation.You must remove the engine and transmission
assembly to remove the cylinder head

Downloaded from www.Manualslib.com manuals search engine TURBOCHARGING
Turbocharger
12
112TURBOCHARGING
Turbocharger
THE TURBOCHARGING PRESSURE ON THE
TURBOCHARGER FITTED ON THE G9T 710
ENGINE IS NOT ADJUSTABLE.
In operation, the pressure should stabilise at
210 ± 3.5 mbar.
REMOVAL
Removal or refitting of the turbocharger requires the
removal of the engine and transmission assembly.TIGHTENING TORQUES (in daN.m)
Turbocharger mounting nuts 2.6
Oil inlet union bolt 2
Oil return union bolt 0.9
Turbo mounting nut on the intermediate
exhaust downpipe 2.6
12-1

Downloaded from www.Manualslib.com manuals search engine TURBOCHARGING
Turbocharger
12
12-2
IMPORTANT: Never attempt to remove the
turbocharger with the engine in place; you will not be
able to follow the recommendations for refitting the oil
supply pipe (1) and the constraints created by blind
tightening the connection (3) will lead to the pipe (1)
rupturing in service.
Fit:
–the pipe (1) to the turbocharger by tightening the
union (3) by hand,
–the turbocharger, by holding the union (4) and
tightening it manually. Tighten the turbocharger
mountings on the manifold to a torque of 2.7 daN.m.
Tighten the unions (4), then (3).
IMPORTANT: It is essential to change the special seal
at the turbocharger oil inlet union (3).
Before running the engine, disconnect the pressure
rail sensor connector (5).
Then run the starter motor until the oil pressure
warning light goes out (persist for a few seconds).
Reconnect the sensor, preheat and start the engine.Run the engine at idling speed and check that there
are no leaks at the oil connections.
Using the fault finding tool, erase the fault as a result
of the sensor being disconnected.
Special precautions
●Ensure that no foreign bodies enter the turbine or
compressor during the refitting operation.
●If there has been a fault in the turbocharger, check
that the air-air exchanger is not full of oil.
If the air-air exchanger is full of oil, it must be
removed, flushed with a cleaning agent and then
left to drain properly.
●Check that the turbocharger oil return pipe is not
partially or completely blocked by scale. Check
also that it is perfectly tight. If not, replace it.

Downloaded from www.Manualslib.com manuals search engine FUEL MIXTURE
Air intake
12
12-3
FUEL MIXTURE
Air intake
AIR INTAKE CIRCUIT DIAGRAM
1Air-air exchanger
2Air filter
3Damper unit
4Inlet manifold
5Turbocharger
6Air inlet

Downloaded from www.Manualslib.com manuals search engine FUEL MIXTURE
Air intake
12
12-4
DAMPER UNIT
This unit, controlled by the injection computer, comprises a throttle placed in
the air inlet flow which closes when the ignition is switched of f to ensure that
the engine stops cleanly.
It also includes the exhaust gas recirculation solenoid valve.TIGHTENING TORQUES (in daN.m)
Clip nuts 5.5

Downloaded from www.Manualslib.com manuals search engine FUEL MIXTURE
Air intake
12
12-5
REMOVAL
Put the vehicle on a two post lift.
Disconnect the battery.
Remove:
–the lower engine cover,
–the air exchanger/damper unit pipe after
disconnecting the electrics.
Place hose pliers on the oil tank/power assisted
steering pump return pipe and disconnect the pump.
Separate the power steering reservoir without
disconnecting the pump and move it on the side
member.Remove:
–the turbocharger/exchanger air pipe mounting bolts
from the cylinder head,
–the stiffening bracket (1) between the damper unit
and the power assisted steering pump mounting,
–the exhaust gas recirculation pipe (2) and the seals.
Plan for the replacement of the pipe and the seals
when refitting.
Disconnect the exhaust gas recirculation control
solenoid valve connector.
15853M1

Downloaded from www.Manualslib.com manuals search engine FUEL MIXTURE
Air intake
12
12-6
Remove:
–the mounting bolt from the low pressure air
conditioning pipe bracket (3),
–the mounting bolts (4) from the throttle body on the
engine housing. Use a 13 mm dowel, a cardan joint
and small extension. If necessary, remove the pipes
to access the bolts.
WARNING: avoid loosening the four self-tapping bolts
(A) which attach the top to the unit body.Remove the connection pipe (5) between the throttle
body and the inlet manifold,
If necessary, unclip the electrical wiring in front of the
damper unit to ease the downwards release of this
unit.
REFITTING
Proceed in the reverse order from removal.
Tighten the mounting clips to 5.5 daN.m.
Check that there are no stored faults using a fault
finding tool. Erase them if necessary.

Downloaded from www.Manualslib.com manuals search engine FUEL MIXTURE
Exhaust manifold
12
12-7
Exhaust manifold
REMOVAL
Removal of the exhaust manifold requires removal of the engine and
transmission assembly (see section 10 "Removing/refitting engine and
transmission assembly"), and the removal of the turbocharger (see
section 12 "Removing/refitting turbocharger").
REFITTING
Refit the manifold bolts in the order recommended above.
Refitting is the reverse of removal.TIGHTENING TORQUES (in daN.m)
Manifold mounting nut 0.8±0.2
Manifold mounting nut 2.7±0.4
EGR valve mounting bolt 1.5
Turbocharger clamp mounting bolt 2.7

Downloaded from www.Manualslib.com manuals search engine FUEL MIXTURE
Inlet manifold
12
12-8
Inlet manifold
REMOVAL
The removal of the inlet manifold/cylinder head cover
requires the removal of the injectors and injection
harnesses. (See section 13 "Removing/refitting the
high pressure injection section").
Insert the mounting tool Mot. 1390 under the engine
and transmission assembly, positioning the right-hand
pads only beneath the engine. Lower the two unused
left-hand pads.Remove the right-hand suspended engine mounting
cover.
Undo the two clips on the connection hose (1)
between the inlet manifold and the damper unit.
Remove the pad (2). SPECIAL TOOLING REQUIRED
Mot. 1390 Engine and transmission
assembly mounting tool
TIGHTENING TORQUES (in daN.m)
Heater plugs 1.1
Manifold mounting stud 1
"Common-Rail" high pressure unions 2.5
15855M2
