SUBARU BAJA 2005 1.G Owners Manual

6-8
Interior and exterior equipments
„
Rear passenger’s cup holder
A dual cup holder is built in the rear center console.Accessory power outlet
The accessory power outlet is located at the rear of the
center console.
Electrical power (12V DC) from the battery is available
at the socket when the ignition switch is either in the
“ACC” or “ON” position.
You can use an in-car use electrical appliance by con-
necting it to the accessory power outlet.
y Do not attempt to use a cigarette lighter in the
accessory power outlet.
UB6029BAUB6057BA

6-9
Interior and exterior equipments
– CONTINUED –
yDo not place any foreign objects, especially
metal ones such as coins or aluminum foil, into
the accessory power outlet. That could cause a
short circuit. Always put the cap on the acces-
sory power outlet when it is not in use.y Use only electrical appliances which are de-
signed for 12V DC and which consume less
than 120W. Overloading the accessory power
outlet can cause a short circuit. Do not use dou-
ble adapters or more than one electrical appli-
ance.y If the plug on your electric appliance is either
too loose or too tight for the accessory power
outlet, this can result in a poor contact or cause
the plug to get stuck. Only use plugs that fit
properly. y Use of an electric appliance in the accessory
power outlet for a long period of time while the
engine is not running can cause battery dis-
charge.y Do not raise the rear seat cushion while an
electric appliance is plugged into the accessory
power outlet. The rear seat cushion would hit
the electric appliance, possibly damaging the
accessory power outlet and the electric appli-
ance.
Cigarette lighter socket
y The electrical power socket located on the
lower part of the instrument panel is originally
designed to use a genuine SUBARU cigarette
lighter plug. Do not use non-genuine cigarette
lighter plugs in the socket. Doing so may cause
a short-circuit and overheating, resulting in a fire. y If the socket is ever used for a plug-in acces-
sory such as a mobile phone, they may damage
the portion of the socket’s internal mechanism
that causes a cigarette lighter plug to “pop out”
after its lighter element is heated. Therefore, do
not place a cigarette lighter plug in a socket
that has been used, even once, to power a plug-
in accessory. Doing so may cause the plug to
stick and overheat, creating a potential fire haz-
ard.y Do not place any foreign objects, especially
metal ones such as coins or aluminum foil, into
the socket. That could cause a short circuit.

6-10
Interior and exterior equipments
The electrical power socket located on the lower part
of the instrument panel can be used as cigarette light-
er socket. A cigarette lighter plug is an optional acces-
sory. It is available from your SUBARU dealer.
The cigarette lighter socket may also be used as a
power source for an in-car use electrical appliance. „
Use with a cigarette lighter
To avoid being burned, never grasp the lighter
by the end with the heating element. Doing so
could result in injury and could also damage
the heating element.
Do not hold the lighter pushed in, because it
will overheat.
The cigarette lighter operates only when the ignition
switch is in the “ON” and “ACC” positions.
To use the cigarette lighter, push in the knob and wait
a few moments. It will automatically spring up when
ready for use.
UB6011BA
UB6011DA

6-11
Interior and exterior equipments
– CONTINUED –
„Using as an accessory power outlet
Electrical power (12V DC) from the battery is available
at the socket when the ignition switch is either in the
“ACC” or “ON” position.
If you use the socket as an accessory power outlet,
take the following precautions.
When the socket is not in use, always put the cap on
the socket to prevent any foreign object from entering
it.
y Use only in-car use electrical appliances
which are designed for 12V DC and which con-
sume less than 120W. Overloading the socket
can cause a short circuit. Do not use double
adapters or more than one electrical appliance. y If the plug on your electric appliance is either
too loose or too tight for the socket, this can re-
sult in a poor contact or cause the plug to get
stuck. Only use plugs that fit properly. y Use of an electric appliance in the socket for
a long period of time while the engine is not
running can cause battery discharge. y Before driving your vehicle, make sure that
the plug and the cord on your electrical appli- ance will not interfere with your shifting gears and operating the accelerator and brake pedals.
If they do, do not use the electrical appliance
while driving.
If the socket has been used for electrical appliances,
damage may have been done to the internal mecha-
nism that cause a cigarette lighter to “pop-out” after its
element has been heated. For that reason, a cigarette
lighter, even if it is a genuine part, should not be used
in the socket. If you want to use the socket for a ciga-
rette lighter again, or to protect your purchaser before
you sell your vehicle, have your SUBARU dealer re-
place the socket with a new one.

6-12
Interior and exterior equipments
Ashtray
Do not use ashtrays as waste receptacles or
leave a lighted cigarette in an ashtray. This
could cause a fire.
Fully close the ashtray after using it to help reduce re-
sidual smoke.
To open the ashtray, pull the lid out.
To remove the ashtray for cleaning, open it and pull it out while pushing the inner plate down.
UB6011CA

6-13
Interior and exterior equipments
– CONTINUED –
Convenience hook „Coat hook
Never hang anything on the coat hook that
might obstruct the driver’s view or that could
cause injury in sudden stops or in a collision.
And do not hang items on the coat hook that
weigh 2.2 lbs (1 kg) or more.
The coat hook is attached to each rear passenger’s hand grip. „
Cargo net hooks
HS6040BA
UB6031BA

6-14
Interior and exterior equipments
There are four hooks on the back panel behind the
rear seatback.
These hooks can be used for installing a cargo net so
that small and light items can be held next to the back
panel when the rear seatback is in the down position.
Fold the rear seatback forward by pulling the release
knob up for access to the hooks.
There are two hooks on the back of the rear seatback.
Using these hooks and the two hooks at the bottom of
the back panel, it is possible to use a cargo net to re-
tain luggage on the folded-down rear seatback.
After returning the seatback to its original posi-
tion, make sure that the rear seatback has been
securely locked. When securely locked, the red
marks on the locking knobs are no longer visi-
ble.
UB6054BA

6-15
Interior and exterior equipments
– CONTINUED –
Floor mat (if equipped)
Make sure the driver’s floor mat is placed back
in its proper location and correctly secured on
its retaining pin. If the floor mat slips forward
and interferes with the movement of the pedals
during driving, it could cause an accident.
A retaining pin is located on the driver’s side of the ve-
hicle. The floor mat is secured using the built-in grom-
met, by placing the grommet over the pin and pushing
downward.
HS6039BA
HS6038BA

6-16
Interior and exterior equipments
Cargo bed
y
Never fill gasoline containers on the cargo
bed. Static electricity may ignite gasoline vapor
when filling portable containers. Approved
containers must be removed from the vehicle
and placed on the ground when filling.
Do not fill any portable container on a vehicle.y Never allow anyone to ride in the cargo bed.
It is not designed for passengers. They should
ride in the seats with the seatbelts securely fas-
tened. Otherwise they are much more likely to suffer serious injury or death in a sudden brak-
ing or in a collision.
y
Do not exceed the cargo load rating of your
vehicle. Refer to the “Loading your vehicle”
section in Chapter 8.y Be sure cargo is secured properly. Unse-
cured cargo in the cargo bed can be thrown
around during sudden braking, in a sharp turn
or during rapid acceleration, which could cre-
ate a dangerous road hazard. y To avoid creating a dangerous road hazard or
causing personal injury, cargo must not stick
out beyond the tailgate. y Never drive the vehicle with the tailgate open
unless the optional SUBARU Bed Extender is
used.
Cargo should be placed in the cargo bed. Make sure
all items are secured in place.
Be careful to keep the vehicle balanced. Locating the
weight as low and far forward as possible helps main-
tain balance.
There are two water drain holes at both sides of the
UB1149BA

6-17
Interior and exterior equipments
– CONTINUED –
front end of the cargo bed. Keep those holes clear and
free from obstructions. „Cargo tie-down hooks
The cargo bed is equipped with four tie-down hooks so
that cargo can be secured with a luggage net or ropes.Bed extender (if equipped)
The bed extender is designed to increase the usable
cargo area of the bed.
y When the tailgate and bed extender are in the
“open/outward” position, the license plate
bracket must be lowered and locked into posi-
tion before the vehicle is driven (see section
“License plate bracket” under the heading of
“Tailgate” in Chapter 2 for more information on
the function of the license plate bracket). In or-
der to avoid damaging the license plate bracket
or the bumper, make certain that the license
plate bracket is in its fully lowered/open posi-
tion before the tailgate is lowered. y Do not exceed the cargo load rating of your
vehicle. Refer to “Loading your vehicle” sec-
tion in Chapter 8. y Locking buckles must be engaged into the
tailgate latch while the vehicle is in motion. y When the bed extender is not in use, the tail-
gate should be closed. y Do not use the bed extender or tailgate to se-
cure cargo.
