SUBARU CROSSTREK 2018 Owners Manual

(248,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
Antenna&Roof antenna (for Rod type)
CAUTION
.Be sure to remove the antenna
rod before entering garages,
parking towers and other loca-
tions with low ceilings.
.Remove the antenna rod before
washing your car at a car wash. If
the antenna rod remains at-
tached, it may scratch the roof.
.When reinstalling the removed
antenna rod, be sure to fully
tighten it.
1) Unscrew
2) RemoveThe roof antenna is installed on the roof.
The antenna rod can be removed by
unscrewing it from its base.
&Roof antenna (for Shark fin
type)The roof antenna is installed on the roof.
Audio/Antenna
5-2

(249,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
Audio setIf your vehicle is equipped with a genuine
SUBARU navigation system or audio
system, refer to the separate navigation/
audio Owner’s Manual for details.
Audio/Audio set
5-3
5

Black plate (2,1)
Model "ALL_MODEL_MEMO" EDITED: 2007/ 6/ 22
Left Page————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————
————————————————————————————————————————

(251,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
Interior lights...........................................................6-2
Map lights.............................................................. 6-2
Dome light............................................................. 6-2
Cargo area light..................................................... 6-3
OFF delay timer..................................................... 6-3
Sun visors...............................................................6-3
Sun visor extension plate (if equipped) .................. 6-4
Vanity mirror.......................................................... 6-4
Vanity mirror with light (if equipped)...................... 6-5
Storage compartment.............................................6-5
Glove box.............................................................. 6-5
Center console...................................................... 6-6
Cup holders........................................................... 6-6
Bottle holders........................................................ 6-6
Accessory power outlets.......................................6-7
Use with a cigarette lighter (dealer option) ..............6-8
Ashtray (dealer option)..........................................6-9
Floor mat...............................................................6-10
Coat hook..............................................................6-10
Shopping bag hook...............................................6-11
Cargo area cover (ifequipped).............................6-11
Using the cover.................................................... 6-11
To remove the cover housing................................6-12
Stowage of the cargo area cover...........................6-12
To install the cover housing..................................6-13
Cargo tie-down hooks (ifequipped)...................6-13
Interior equipment
6

(252,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
Interior lights
CAUTION
When leaving your vehicle, make
sure the lights are turned off to
avoid battery discharge.&Map lights1) Door interlock switchTo turn on the map light, push the lens.
To turn it off, push the lens again.!Automatic illumination
When the door interlock switch is in the
“DOOR”position, the map lights illuminate
automatically in the following cases.
.Any of the doors other than the rear
gate (if equipped) is opened.
.The doors are unlocked using the
keyless access function (if equipped).
Refer to“Locking and unlocking by holding
the access key fob”F2-6.
.The doors are unlocked using the
remote keyless entry system. Refer to
“Remote keyless entry system”F2-17.
.The ignition switch is turned from the
“ACC”position to the“LOCK”/“OFF”posi-
tion.
&Dome light1) ON
2) DOOR
3) OFFThe dome light switch has the following
positions.
ON:The light remains on continuously.
OFF:The light remains off.
DOOR:The dome light illuminates auto-
matically in the following cases.
.Any of the doors or the rear gate is
opened.
.The doors or the rear gate are unlocked
using the keyless access function (if
equipped). Refer to“Locking and unlock-
ing by holding the access key fob”F2-6.
.The doors or the rear gate are unlocked
Interior equipment/Interior lights
6-2

(253,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
using the remote keyless entry transmitter.
Refer to“Remote keyless entry system”
F2-17.
.The ignition switch is turned from the
“ACC”position to the“LOCK”/“OFF”posi-
tion.&Cargo area light1) DOOR
2) OFFDOOR: The light illuminates when the rear
gate is opened. The light remains illumi-
nated for several seconds and gradually
turns off after the rear gate is closed.
OFF: The light remains off.
&OFF delay timerThe following lights have an automatic
illumination function.
.dome light
.map light
.cargo area light
When the interior light switch is set to the
“DOOR”position, the light will automati-
cally turn on and turn off depending on the
locking and unlocking of the doors, the
opening and closing of the doors, as well
as the position of the ignition switch.NOTEThe setting for the period of time in
which the lights remain on (OFF delay
timer) can be changed by a SUBARU
dealer. Contact your SUBARU dealer
for details. For models with the combi-
nation meter display (color LCD), the
setting can also be changed by operat-
ing the combination meter display
(color LCD). For details, refer to“Vehi-
cle Setting”F3-41.
Sun visorsTo block out glare, swing down the visors.
To use the sun visor at a side window,
swing it down and move it sideways.
–CONTINUED–
Interior equipment/Sun visors
6-3
6

(254,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
&Sun visor extension plate (if
equipped)With the sun visor positioned over the side
window, you can use the sun visor exten-
sion plate to prevent glare through the gap
between the sun visor and center pillar. To
use the extension plate, pull it toward the
rear of the vehicle. When you have
finished using it, stow it by pushing it
toward the front of the vehicle.
CAUTION
Do not pull out the extension plate
with the sun visor positioned over
the windshield. The extension plate
would obstruct your view of the
rearview mirror.
&Vanity mirror
CAUTION
Keep the vanity mirror cover closed
while the car is being driven to avoid
being temporarily blinded by the
glare of bright light.To use the vanity mirror, swing down the
sun visor and open the vanity mirror cover.
Interior equipment/Sun visors
6-4

(255,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
&Vanity mirror with light (if
equipped)
CAUTION
Keep the vanity mirror cover closed
while the car is being driven to avoid
being distracted by the light.To use the vanity mirror, swing down the
sun visor and open the vanity mirror cover.
The light beside the vanity mirror illumi-
nates when the mirror cover is opened.NOTEUse of the vanity mirror light for a long
period of time while the engine is not
running can cause battery discharge.
Storage compartment
CAUTION
.Always keep the storage com-
partment closed while driving to
reduce the risk of injury in the
event of a sudden stop or an
accident.
.Do not store spray cans, contain-
ers with flammable or corrosive
liquids or any other dangerous
items in the storage compart-
ment.
&Glove box1) Rotate the key clockwise to lock.
2) Rotate the key counterclockwise to un-
lock.To open the glove box, pull the handle.
To close it, push the lid firmly upward.NOTE.The emergency key is directional. If
the key cannot be inserted, change the
direction that the grooved side is facing
and insert it again.
.For models with the“keyless access
with push-button start system”, use the
emergency key to lock or unlock the
glove box.
–CONTINUED–
Interior equipment/Storage compartment
6-5
6

(256,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
&Center consoleThe center console box provides a storage
space.1) Card holderThe top of the console can be used as an
armrest.&Cup holders
CAUTION
.Do not pick up a cup from the cup
holder or put a cup in the holder
while you are driving, as this may
distract you and lead to an acci-
dent.
.Take care to avoid spills. Bev-
erages, if hot, might scald youand/or your passengers. Spilled
beverages may also damage up-
holstery or carpets.
.When a cup in the rear passen-
ger’s cup holder contains a bev-
erage, do not fold down the rear
seatback. Otherwise, the bever-
age could spill and, if the bev-
erage is hot, it could scald you
and/or your passengers.
Front passenger’s cup holderA dual cup holder is built into the center
console.
Rear passenger’s cup holder (if equipped)A dual cup holder is built into the armrest.&Bottle holders
CAUTION
.Do not pick up a bottle from the
bottle holder or put a bottle in the
holder while you are driving, as
this may distract you and lead to
an accident.
.When placing a beverage in a
bottle holder, make sure it is
capped. Otherwise, the beverage
could spill when opening/closing
the door or while driving and, if
the beverage is hot, it could scald
you and/or your passengers.
Interior equipment/Storage compartment
6-6

(257,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
The bottle holder equipped on each door
trim can be used to hold beverage bottles
and other items.
Accessory power outletsElectrical power (12V DC) is available at
any of the accessory power outlets when
the ignition switch is in either the“ACC”or
“ON”position. Accessory power outlets
are located in the following places.Power outlet below the climate control
dials
Power outlet in the center consoleYou can use an in-vehicle electrical appli-
ance by connecting it to an outlet.
The maximum power rating of an appli-
ance that can be connected is120W.
CAUTION
.Do not attempt to use a cigarette
lighter in the accessory power
outlets.
.Do not place any foreign objects,
especially metal ones such as
coins or aluminum foil, into the
accessory power outlet. That
could cause a short circuit. Al-
ways put the cap on the acces-
sory power outlet when it is not in
use.
–CONTINUED–
Interior equipment/Accessory power outlets
6-7
6
