SUBARU SOLTERRA 2023 Owners Manual

3715-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
■Function description
A smartphone can be used to
remotely operate the parking
functions and exit functions.
Also, assistance can be pro-
vided to remotely move the vehi-
cle forward or backward into a
garage, etc.
■Parking using Remote con-
trol function
A smartphone can be used to
remotely operate the parking
function if the target parking
space can be detected when the
vehicle is stopped close and
perpendicular to the center of
the parking space. Also,
depending on the condition of
the parking space, etc., if it is
necessary to change the direc-
tion of travel of the vehicle, the
shift position can be changed by
assistance control.
1 Stop the vehicle with it
aligned near the center of the
target parking space.
( P.356)
2 Press the Advanced Park
main switch and check that a
possible parking space is dis-
played on the Multimedia dis-
play. ( P.356)
3 Select the button and
then select [Perpendicu-
lar/parallel].
4 Select [OK] button.
5 Exit the vehicle while carrying
the electronic key and smart-
phone, and then start the
Remote Park app on the
smartphone.
The detection area of the electronic
key is within approximately 9.8 ft. (3
m) around the vehicle.
If there is an obstruction in the path
of the vehicle, move it before park-
NOTICE
• When accessories which
obstruct the view of the camera
are installed
If assistance is ended during reg-
istration, perform registration
again.
●When registering a parking
space to the memory function, if
the road surface cannot be
detected “No available parking
space to registe r” will be dis-
played.
●When using the memory func-
tion, make sure to stop immedi-
ately in front of the stop
position. Otherwise the parking
space may not be able to be
detected correctly or assis-
tance may not be provided to
the point that the vehicle is fully
parked.
●Do not use the memory function
if a camera has been subjected
to a strong impact or images of
the panoramic view monitor are
misaligned.
●If a camera has been replaced,
as the installation angle of the
camera will have changed, it will
be necessary to reregister park-
ing spaces of the memory func-
tion.
Remote control function

3725-4. Using the driving support systems
Owners Manual_USA_M42C01_ening the vehicle. A traffic cone can
also be moved after exit the vehi-
cle.
6
From outside of the vehicle,
confirm the parking space on
the screen of the smartphone
and then select the start but-
ton.
Start operation of Remote control
function while standing approxi-
mately 1.6 ft. (50 cm) or more from
the vehicle and out of the path of
the vehicle.
7 Checking the safety of the
area around the vehicle,
trace the operation area on
the screen of the smartphone
continuously, the vehicle will
move and parking assis-
tance will be performed.
If operation of the screen of the
smartphone is stopped, assistance
can be suspended and the vehicle
can be stopped. T he doors are
automatically locked before the
vehicle starts moving.
8 When the parking space is
reached, after the vehicle is
stopped by the parking
brake, the shift position will
be changed to P, the power
switch will be turned off, and
the doors will be locked.
A completion screen will be dis-
played on the smartphone
■The parking function can be
used even if obs tructions exist
if
●When using the parking functions
at a parking space made of white
lines, even if an obstruction exists
in the parking space, the space
can be set as th e target parking
space. This allows for assistance to continue after setting a parking
space from inside the vehicle and
then exiting the
vehicle to move
an obstruction, su ch as a traffic
cone placed in a handicapped
parking space.
●When perpendicular parking using
Advanced Park, 3 parking spaces
on each side of the vehicle (up to
6 total) can be detected. However,
when using Remot e control func-
tion, only 1 parking space on each
side of the vehicle can be
detected
After the vehicle is stopped,
assistance can be provided to
move the vehicle into a garage,
etc., by using the forward and
backward movement function.
1 Stop the vehicle at the loca-
tion you would like to start
assistance.
2 Press the Advanced Park
main switch. ( P.354)
3 Select and then select
[Forward/reverse].
4 Select [OK].Moving the vehicle for-
ward and backward using
Remote control function

3735-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
5 Exit the vehicle while carrying
the electronic key and smart-
phone, and then start the
Remote Park app on the
smartphone.
The detection area of the electronic
key is within approximately 9.8 ft. (3
m) around the vehicle.
6From outside of the vehicle,
confirm the direction of travel
on the screen of the smart-
phone and then select the
start button.
Start operation of Remote control
function while standing approxi-
mately 1.6 ft. (50 cm) or more from
the vehicle and out of the path of
the vehicle. The d etection area of
the electronic key is within approxi-
mately 9.8 ft. (3 m) around the vehi-
cle.
7 Checking the safety of the
area around the vehicle,
trace the operation area on
the screen of the smartphone
continuously, the vehicle will
move and parking assis-
tance will be performed.
If operation of the screen of the
smartphone is stopped, assistance
can be suspended and the vehicle
can be stopped. After assistance
has been started, it can be stopped
part way or the direction of travel of
the vehicle can be changed.
8 Select the power button on
the screen of the smart-
phone. The power switch will
then turn OFF and the doors
will lock automatically.
■Changing the direction of travel
While assistance is being per- formed, the directio
n of travel of the
vehicle can be changed by the for-
ward and reverse movement func-
tion. When there is a wall behind the
vehicle, etc., by operating the direc-
tion of travel changing button on the
screen of the smartphone, the vehi-
cle can be slightly moved forward to
allow loading of items and then
moved back to its original position.
Assistance can be provided to
exit from a perpendicular or par-
allel parking space when the
power switch OFF. When for-
ward and backward movement
is selected, the maximum dis-
tance the vehicle can move is
23.0 ft. (7 m) from the starting
point and possible to change the
direction of travel.
1 While near the parked vehi-
cle, unlock the doors using
the electronic key, and then
start the Remote Park app on
the smartphone.
If the smartphone cannot connect
to the vehicle, using the electronic
key, unlock the doors again.
2 Select the start button on the
screen of the smartphone.Exiting using Remote con-
trol function

3745-4. Using the driving support systems
Owners Manual_USA_M42C01_enThe power switch
will change to
ON.
3 Check that a possible exit
direction is displayed, select
the exit direction.
4 Checking the safety of the
area around the vehicle,
trace the operation area on
the screen of the smartphone
continuously, the vehicle will
move and parking assis-
tance will be performed.
If operation of the screen of the
smartphone is stopped, assistance
can be suspended and the vehicle
can be stopped. After assistance
has been started, it can be stopped
part way or the direction of travel of
the vehicle can be changed.
5 Move the vehicle to the posi-
tion where assistance ends
and enter the vehicle while
carrying the electronic key.
To stop assistance part way, stop
operating the smartphone or enter
the vehicle.
■While using the remote air con-
ditioner
●Exit assist can be done even
when using remote air condition-
ing.
●When Remote cont rol function is
started while the remote air condi-
tioning is operating, if tracing
operations are not performed on a
smartphone, assistance can be
canceled by entering the vehicle
and depressing th e brake pedal.
A smartphone can be used to
remotely operate the memory
function if the target parking
space can be detected when the
vehicle is stopped close to a
parking space which was previ-
ously registered to the memory
function. Also, depending on the
condition of the parking space,
etc., if it is necessary to change
the direction of travel of the
vehicle, the shift position can be
changed by assistance control.
1Stop the vehicle with it
aligned near the center of the
target parking space.
( P.366)
2 Press the Advanced Park
main switch, check that a
possible parking space is dis-
played on the Multimedia dis-
play. ( P.366)
3 Select the button and
then select [Perpendicu-
lar/parallel].
4 [OK].
If the [MODE] button is displayed,
the button can be selected to
change between t he memory func-
tion, perpendicular parking (for-
ward/reverse) function and parallel
parking function.
5 Exit the vehicle while carrying
the electronic key and smart-
phone, and then start the Parking using the Remote
control function and mem-
ory function

3755-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
Remote Park app on the
smartphone.
The detection area of the electronic
key is within approximately 9.8 ft. (3
m) around the vehicle. If there is a
cone or other obstruction in the
path of the vehicle, move it after
exiting the vehicle.
6 From outside of the vehicle,
confirm the parking space on
the screen of the smartphone
and then select the start but-
ton.
Start operation of Remote control
function while standing approxi-
mately 1.6 ft. (50 cm) or more from
the vehicle and out of the path of
the vehicle.
7 Checking the safety of the
area around the vehicle,
trace the operation area on
the screen of the smartphone
continuously, the vehicle will
move and parking assis-
tance will be performed.
If operation of the screen of the
smartphone is stopped, assistance
can be suspended and the vehicle
can be stopped. T he doors are
automatically locked before the
vehicle starts moving.
8 When the parking space is
reached, after the vehicle is
stopped by the parking
brake, the shift position will
be changed to P, the power
switch will be turned off, the
doors will be locked and the
mirrors will be closed.
A completion screen will then be
displayed on the smartphone.
Make sure to perform the follow-
ing before using Remote control
function:
1Download the Remote Park
app from the app store.
2 Turn the power switch to ON
and register the smartphone
as a Bluetooth device to the
multimedia system. For
details on registering a Blue-
tooth device, refer to the
“MULTIMEDIA OWNER’S
MANUAL”.
3 Setup the Remote Park app
and register the vehicle.
4 The registered vehicle will be
displayed on the screen of
the smartphone.
Select the vehicle.
The name and image of the vehicle
can be changed on the new vehicle
registration screen.
Vehicles can be added through the
menu screen.
1Select and then select
“Advanced Park” on the Mul-
timedia display.
2 Select “Remote Park” to turn
it on/off. (The default setting
is on.)Preparation before using
Remote control function
Preparation before using
Remote control function
on/off

3765-4. Using the driving support systems
Owners Manual_USA_M42C01_en
3Press the Advanced Park
main switch.
If the switch is pressed while assis-
tance is being performed, the assis-
tance will be canceled.
4Select the button dis-
played on the multimedia dis-
p l a y.
NOTICE
●When using Remote control
function, make sure carry an
electronic key in your pocket,
etc.
●If an electronic key is held
together with a smartphone,
etc., the electronic key may not
be able to be detected.
●Remote control function cannot
be used when carrying only a
digital key. The driver should
always carry the electronic key.
●When entering the vehicle after
using Remote control function,
make sure that the electronic
key is brought i nto the vehicle
and all of the doors are closed.
●If the power switch is turned off
when Remote control function
operation has finished or been
canceled, the doors will be
locked automatica lly. However,
if a door is open , it may not be
locked. Check the vehicle con-
dition after Remote control func-
tion operation has finished.
●When the doors are locked after
Remote control function opera-
tion has finished or been can-
celed, an alarm may sound if
someone is detected inside the
vehicle.
■Situations in which the func-
tion may not operate cor-
rectly
●When the functions of the smart
entry & start system may not
operate correctly: P. 1 9 0
●When the vehicle is near fluo-
rescent lights
■Radio wave interference
 P. 1 9 1
■Electronic key battery con-
sumption
●When Remote control function
is being used, the electronic key
battery will be used as the elec-
tronic key will continuously send
and receive radio waves.
●If the electronic key battery is
depleted: P. 4 9 7
■Situations in which the sen-
sors may not operate prop-
erly
 P. 3 1 4
●When using Remote control
function, visibility of the area
around the vehicle may be lim-
ited. Make sure to check the fol-
lowing when using Remote
control function:

3775-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving■Assistance will be can-
celed when
In situations such as the follow-
ing, Advanced Park operation
will be canceled.
As system operation has been can-
celed, begin the operation again or
continue parking manually, using
the steering wheel.
 The Advanced Park main
switch is pushed
 The shift position has been
changed to P
 The parking brake is engaged
 A door or back door is opened
 The driver’s seat belt is unfas-
tened
 The outside rear view mirrors are folded
 The TRAC or VSC is turned
off
 The TRAC, VSC or ABS oper-
ates
 The power switch is pushed
 The system determines assis-
tance cannot be continued in
the current parking environ-
ment
 The system malfunctions
 While the vehicle was
stopped, “Cancel” was
selected on the multimedia
display
■Assistance will be sus-
pended when
In situations such as the follow-
ing, Advanced Park operation
will be suspended.
Assistance can be started again by
following the directions displayed
on the multimedia display.
Also, when assistance is sus-
pended, if the shift position is
changed twice with the brake pedal
depressed, assistance will be can-
celed in tha t shift position. How-
ever, if assistance is suspended by
changing the shift position, assis-
tance will be canceled if the shift
position is changed once.
 The steering wheel is oper-
ated
 The accelerator pedal is
depressed
 The shift position has been
NOTICE
• The vehicle and area around
the vehicle are clearly visible
• There are no people, animals, or objects in the path of the
vehicle
• An appropriate distance from the vehicle can be maintained
and the safety of yourself and
others can be ensured
• Caution for the area around the vehicle is always maintained
and there is no potential for
danger
• You can cancel Remote control function immediately if neces-
sary
Advanced Park cancel-
ation/suspension

3785-4. Using the driving support systems
Owners Manual_USA_M42C01_en
changed
 Brake control operates
 Camera switch is pressed
 The PKSB (Parking Support
Brake) PCS (Pre-Collision
System) has operates
■Remote control function
assistance will be canceled
when
In situations such as the follow-
ing, Remote control function
operation will be canceled.
As system operation has been
canceled, while carrying an
electronic key, enter the vehicle
and park the vehicle manually,
using the steering wheel.
 When a condition for stopping
Advanced Park assistance is
met, with the exception sus-
pension due to a door being
opened or the driver’s seat
belt being released
 When Remote control func-
tion is operated while the
remote air conditioning is
operating and the power
switch is changed to ON
before remote air conditioning
has ended
 When 5 minutes have
elapsed since Remote con-
trol function operation was
started
 When 3 minutes have
elapsed since any operation
was performed 
When 30 seconds have
elapsed with the vehicle not
being able to be driven, even
though the screen of the
smartphone is being operated
to drive the vehicle
 When the power button on the
screen of the smartphone is
selected
 When the Remote Park app is
force closed
 When the vehicle is on a
steep slope
 When an electronic key is
detected inside the vehicle
while Remote control function
operation is suspended
 When the ambient tempera-
ture is 14°F (-10°C) or less
■Remote control function
assistance will be sus-
pended when
In situations such as the follow-
ing, assistance will be sus-
pended.
 When the Bluetooth commu-
nication between the smart-
phone and multimedia system
get lost
 When smartphone continuous
operation is suspended
 When the Remote Park app is
pushed to the background (a
call is received, the home but-
ton is pressed, etc.)
 When electronic key does not
detected

3795-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
 When there is an obstruction
in the movement direction of
the vehicle
 When the vehicle is operated
while it is being driven by
assistance
 When the smart key is oper-
ated while it is being driven by
assistance
 When the door is unlocked
while it is being driven by
assistance
 When a door is opened while
the vehicle is being driven
Select on the multimedia
display, and then select
“Advanced Park”.
■Remote Park
Remote control function can be
turned on/off.
■Speed Profile
The vehicle speed for when
assistance is performed can be
set.
This setting cannot be changed
when registering a parking space to
the memory function.
■Detect. range
The distance from which obsta-
cles will be avoided while assis-
tance is being performed can be
set.
■Prk. Method
The preferred parking direction
displayed when at a parking
space which perpendicular (for-
ward/reverse) or parallel parking
is possible can be set.
■Prk. direction
The preferred parking direction
displayed when it is possible to
pull perpendicular forward or
reverse into a parking space can
be selected.
■Exit dir .: Per.
The preferred exit direction dis-
played when it is possible to pull
forward or reverse to the left or
right out of a parking space can
be selected.
■Exit dir .: Par.
The preferred exit direction dis-
played when it is possible to exit
to the left or right from a parallel
parking space can be selected.
■Parking view
The display angle of the camera
image when using the perpen-
dicular parking (for-
ward/reverse) function or
parallel parking function can be
set.
■Exit view
The display angle of the camera
image when using the perpen-
dicular exiting (forward/reverse)
function or parallel parking exit
function can be set.
Changing the Advanced
Park settings

3805-4. Using the driving support systems
Owners Manual_USA_M42C01_en
■Parking Path Adjustment
The course for when parking
assistance is operating can be
adjusted inward or outward.
If the tires are worn, the path of
vehicle may be offset from the cen-
ter of the parking space. In this
case, use this setting to adjust the
parking course.
■Road Width Adjustment
When parking assistance is
started, the amount of lateral
movement while the vehicle is
moving forward can be
adjusted.
■Park Position Adjustment
(fwd.)
The position at which perpendic-
ular parking (forward/reverse) is
completed can be adjusted.
(Except when using the memory
function.)
■Park Position Adjustment
(rev.)
The position at which perpendic-
ular parking (forward/reverse) is
completed can be adjusted.
(Except when using the memory
function.)
■Rear Accessory Setting
If an accessory, such as a trailer
hitch, has been installed to the
rear of the vehicle, the length of
the rear of the vehicle can be
adjusted to help avoid colliding
with objects to the rear of the
vehicle.
■Clear Registered Parking
Space
The parking spaces registered
to the memory function can be
deleted. Parking space informa-
tion cannot be deleted when
assistance is being performed
or when registering parking
space information to the mem-
ory function.
■Intuitive parking assist-sen-
sor warning sound ON/OFF
(Smartphone setting)
The warning sounds of the intui-
tive parking assist-sensor from
smartphone application can be
turned on/off using the Remote
Park app.
■Intuitive parking assist-sen-
sor warning sound volume
adjustment (Smartphone
setting)
The volume of the warning
sounds of the intuitive parking
assist-sensor from smartphone
application can be adjusted
using the Remote Park app.
The operating state, assistance
operation, etc. of the Advanced
Park is displayed on the multi-
media display. If a message is
Changing the Remote
Park app settings
Advanced Park Displayed
messages
