SUZUKI ALTO 2007 6.G Owner's Manual

Downloaded from www.Manualslib.com manuals search engine 22
76G-74E
3-9BEFORE DRIVINGFRONT SEAT ADJUSTMENT
76G-03-018
TYPE-1 (ALTO)
76G-03-018A
TYPE-2 (ALTO K10)
ADJUSTING SEAT POSITION
76G-03-019A76G-03-019B
TYPE-1 (ALTO)TYPE-2 (ALTO K10) Never attempt to adjust the driver’s
seat or seatback while driving. The
seat or seatback could move
unexpectedly, causing loss of control.
Make sure that the driver’s seat and
seatback are properly adjusted before
you start driving.
w ww w
w WARNING

Downloaded from www.Manualslib.com manuals search engine 2376G-74E
BEFORE DRIVING
3-10
The adjustment lever for each front seat is
located under the front of the seat. To
adjust the seat position, pull up on the
adjustment lever and slide the seat forward
or rearward. After adjustment, try to move
the seat forward and rearward to ensure
that it is securely latched.
w ww w
w WARNING
To avoid excessive seat belt slack,
which reduces the effectiveness of the
seat belts as a safety device, make
sure that the seats are adjusted
before the seat belts are fastened.
Seatbacks should always be in an
upright position when driving, or seat
belt effectiveness may be reduced.
Seat belts are designed to offer
maximum protection when seatbacks
are in the fully upright position.
Front Seats
The seatbacks can be adjusted to different
angles. To adjust the seatback angle, pull
up the lever on the outboard side of the
seat, move the seatback to the desired
position, and release the lever to lock the
seatback in place.
w ww w
w WARNING
76G-03-022
76G-03-023
TYPE-1 (ALTO)
TYPE-2 (ALTO K10)ADJUSTING SEATBACKS

Downloaded from www.Manualslib.com manuals search engine 24
76G-74E
BEFORE DRIVING3-11Seat belts are good help to protect
occupants from injury or death in the
event of accidents. We urge you to
wear seat belts at all times if the belts
are equipped. If seat belts are not
equipped at the rear seating positions,
we recommend you to install optional
or after market high quality seat belts
to increase occupant's safety.SEAT BELTS
w ww w
w WARNING
76G-03-026
Never allow persons to ride in the
cargo area of a vehicle. In the event
of an accident, there is a much
greater risk of injury for persons
who are not riding in a seat with
their seat belt securely fastened.
Seat belts should always be
adjusted so the lap portion of the
belt is worn low across the pelvis,
not across the waist. Shoulder
straps should be worn on the
outside shoulder only, and never
under the arm. Seat belts should
never be worn with the straps
twisted and should be adjusted as
w ww w
w WARNING
V VV V
V
76G-03-027
tightly as is comfortable to provide
the protection for which they have
been designed. A slack belt will
provide less protection than one
which is snug.
Make sure that each seat belt buckle
is inserted into the proper buckle
catch.
Do not wear your seat belt over
hard or breakable objects in your
pockets or on your clothing. If an
accident occurs, objects such as
glasses, pens, etc. under the seat
belt can cause injury.
w ww w
w WARNING
V VV V
V
V VV V
V
76G-03-028

Downloaded from www.Manualslib.com manuals search engine 2576G-74E
BEFORE DRIVING
3-12
Never use the same seat belt on
more than one occupant and never
attach a seat belt over an infant or
child being held on an occupant’s
lap. Such seat belt use could cause
serious injury in the event of an
accident.
Pregnant women should use seat
belts, although specific recommen-
dations about restraint use should
be made by the woman’s medical
advisor. Remember that the lap
portion of the belt should be worn
as low as possible across the hips,
as shown in the diagram.
w ww w
w WARNING
V VV V
V
V VV V
V
76G-03-029
Periodically inspect seat belt
assemblies for excessive wear and
damage. Seat belts should be
replaced if webbing becomes frayed,
contaminated, or damaged in any
way. It is essential to replace the
entire seat belt assembly after it has
been stressed in an impact, even if
damage to the assembly is not
obvious.
Infants and small children should
never be transported unless they are
properly restrained. Restraint
systems for infants and small
children can be purchased locally
and should be used. Make sure that
the system you purchase meets
applicable safety standards. Read
and follow all the directions
provided by the manufacturer.
Avoid contamination of seat belt
webbing by polishes, oils,
chemicals, and particularly battery
acid. Cleaning may safely be carried
out using mild soap and water.
For children, if the shoulder belt
irritates the neck or face, move the
child closer to the center of the
vehicle.
w ww w
w WARNING
V VV V
V
V VV V
V
Be sure to inspect all seat belt
assemblies after any collision. Any
seat belt assembly which was in use
during a collision (other than a very
minor one) should be replaced, even
if damage to the assembly is not
obvious. Any seat belt assembly
which was not in use during a
collision should be replaced if it does
not function properly or is damaged
in any way.
w ww w
w WARNING
V VV V
V

Downloaded from www.Manualslib.com manuals search engine 26
76G-74E
BEFORE DRIVING3-13
76G-03-031
76G-03-032
To reduce the risk of sliding under the belt
during a collision, position the lap portion
of the belt across your lap as low on your
hips as possible and adjust the belt to a
snug fit using the proper method for each
type of the belt as described below. Make
sure that the belt is not twisted.
76G-03-033
To fasten the seat belt, sit up straight and
well back in the seat, pull the buckle tongue
attached to the seat belt across your body
and slide it into the buckle catch on the
opposite side until you hear a “click”.
76G-03-030

Downloaded from www.Manualslib.com manuals search engine 2776G-74E
BEFORE DRIVING
3-14
w ww w
w WARNING
To Adjust the Belt
Pull the shoulder portion of the belt
upwards through the tongue plate.
The length of the diagonal shoulder strap
adjusts itself to allow freedom of movement.
The seat belt has an emergency locking
retractor (ELR), which is designed to lock
the seat belt only during a sudden stop or
impact.
No modifications or additions of any
sort should be made to the seat belt
or its operating mechanism.
76G-03-035
Seat Belt Inspection
Periodically inspect the seat belts to make
sure they work properly and are not
damaged. Check the webbing, buckles, latch
plates, retractors, anchorages and guide
loops. Replace any seat belts which do not
work properly or are damaged.
76G-03-036
To unfasten the belt, press the release
button on the buckle catch.
76G-03-034

Downloaded from www.Manualslib.com manuals search engine 28
76G-74E
BEFORE DRIVING3-15
To lengthen, release the tounge from the
buckle unit, pull the tounge (adjuster) in
the direction of the arrow, at right angles
to the belt. The tounge should then be
refitted into the buckle unit and the belt
tightened as previously described.
76G-03-038
NOTE:
To identify the center seat belt buckle catch
and tongue in the rear seat, "CENTER" is
moulded on the buckle catch and tongue of
the center lap belt. The buckle catches are
designed so a buckle tongue can not be
inserted into the wrong buckle catch.
76G-03-039
On this belt the adjuster is incorporated in
the tounge unit.
To tighten the belt, pull the free end of
the belt across alongside the lap strap
until it is adjusted to a snug comfortable
position.LAP BELT (if equipped)
76G-03-037

Downloaded from www.Manualslib.com manuals search engine 2976G-74E
4
STEERING COLUMN CONTROLS
STEERING COLUMN CONTROLS
Ignition Switch.................................................................................................... 4-1
Lighting/Turn Signal Control Lever................................................................ 4-2
Hazard Warning Switch.................................................................................... 4-5
Windscreen Wiper and Washer Lever.......................................................... 4-5
Horn....................................................................................................................... 4-6
Electrical Power Steering (if equipped)........................................................ 4-7

Downloaded from www.Manualslib.com manuals search engine 30
76G-74E
IGNITION SWITCHThe ignition switch has the following four
positions:
Do not use any locally made key.
Should you require duplicate key,
place your order with MARUTI
SUZUKI dealer only.LOCK
This is the normal parking position. It is the
only position in which the key can be
removed.
The “LOCK” position locks the ignition, and
prevents normal use of the steering wheel
after the key is removed.
To release the steering lock, fully insert the
key and turn it clockwise to one of the other
positions. If you have trouble turning the
key to unlock the steering, try turning the
steering wheel slightly to the right or left
while turning the key. To avoid possible injury, do not operate
controls by reaching through the steering
wheel.
STEERING COLUMN CONTROLS
w ww w
w WARNING
w ww w
w WARNING
4-1
76G-04-00176G-04-003 76G-04-002

Downloaded from www.Manualslib.com manuals search engine 3176G-74E
Do not use the starter motor for
more than 15 seconds at a time. If
the engine does not start; wait 15
seconds before trying again. If the
engine does not start after several
attempts, check the fuel and ignition
systems or consult your MARUTI
SUZUKI dealer.
Do not leave the ignition switch in
the “ON” position if the engine is
not running as the battery will
discharge.
LIGHTING/TURN SIGNAL
CONTROL LEVERSTEERING COLUMN CONTROLS
ACC
Accessories such as the radio can operate,
but the engine is off.
ON
This is the normal operating position. All
electrical systems are on.
START
This is the position for starting the engine
using the starter motor. The key should be
released from this position as soon as the
engine starts.
Never remove the ignition key while
the vehicle is moving. The steering
wheel will lock and you will not be
able to steer the vehicle.
Do not leave children alone in a
parked vehicle. Unattended children
could cause accidental movement of
the vehicle, which could result in
severe personal injury.
Always remove the key when parked
to prevent unintentional operation of
the vehicle and to improve security.
w ww w
w WARNING
CAUTION
4-2
76G-04-005 76G-04-004
ALTO
76G-04-005A
ALTO K10 TYPE-1
