3-38 INSTRUMENT PANEL
78J00-03E
Choose one of the available settings and
press the set/reset button while it is dis-
played on the DIC to select it.
APPROACH LIGHTING
This feature allows you to select whether
or not to have the exterior lights turn on
briefly during low light periods after unlock-
ing the vehicle using the RKE transmitter.
Press the vehicle information button until
APPROACH LIGHTING appears on the
DIC display. Press the set/reset button to
access the settings for this feature. Then
press the vehicle information button to
scroll through the following settings:
OFF:
The exterior lights will not turn on when
you unlock the vehicle with the RKE
transmitter.
 ON (default):
If it is dark enough outside, the exterior
lights will turn on briefly when you unlock
the vehicle with the RKE transmitter.
The lights will remain on for 20 seconds
or until the lock button on the RKE trans-
mitter is pressed, or the vehicle is no
longer off. Refer to “Remote Keyless
Entry (RKE) System Operation” in
“Keys” in the “Features and Controls”
section for more information.
 NO CHANGE:
No change will be made to this feature.
The current setting will remain.Choose one of the available settings and
press the set/reset button while it is dis-
played on the DIC to select it.
CHIME VOLUME
This feature allows you to select the vol-
ume level of the chime.
Press the vehicle information button until
CHIME VOLUME appears on the DIC dis-
play. Press the set/reset button to access
the settings for this feature. Then press the
vehicle information button to scroll through
the following settings:
 NORMAL (default):
The chime volume will be set to a normal
level.
 LOUD:
The chime volume will be set to a loud
level.
 NO CHANGE:
No change will be made to this feature.
The current setting will remain.
Choose one of the available settings and
press the set/reset button while it is dis-
played on the DIC to select it.
REMOTE START
If your vehicle has this feature, it allows
you to turn the remote start off or on. The
remote start feature allows you to start the
engine from outside of the vehicle using
your RKE transmitter. Refer to “Remote
Vehicle Start” under “Remote Keyless
Entry (RKE) System Operation” in “Keys”in the “Features and Controls” section for
more information.
Press the vehicle information button until
REMOTE START appears on the DIC dis-
play. Press the set/reset button to access
the settings for this feature. Then press the
vehicle information button to scroll through
the following settings:
OFF:
The remote start feature will be disabled.
 ON (default):
The remote start feature will be enabled.
 NO CHANGE:
No change will be made to this feature.
The current setting will remain.
Choose one of the available settings and
press the set/reset button while it is dis-
played on the DIC to select it.
FACTORY SETTINGS
This feature allows you to set all of the per-
sonalization features back to their factory
default settings.
Press the vehicle information button until
FACTORY SETTINGS appears on the DIC
display. Press the set/reset button to
access the settings for this feature. Then
press the vehicle information button to
scroll through the following settings:
 RESTORE ALL (default):
The personalization features will be set
to their factory default settings.

3-57 INSTRUMENT PANEL
78J00-03E
There is not any type of notification for the
customer to see through the radio display,
but VSM has a text field that shows audio
stream changing.
Inserting a Disc
To play a disc, gently insert the disc, with
the label side up, into the loading slot. The
DVD player might not accept some paper
labeled media. The player starts loading
the disc into the system and show “Load-
ing Disc” on the radio display. At the same
time, the radio displays a softkey menu of
option(s). Some discs automatically play
the movie while others default to the soft-
key menu display, which requires the Play,
Enter, or Navigation softkeys to be
pressed; either by softkey or by the rear
seat passenger using the remote control.
Loading a disc into the system, depending
on media type and format, ranges from
5 to 20 seconds for a CD, and up to 30
seconds for a DVD.
Stopping and Resuming Playback
To stop playing a DVD without turning off
the system, press the stop button on the
remote control, or press the pushbutton
located under the stop or the play/pause
symbol tags displayed on the radio. If the
radio head is sourced to something other
than DVD-V, press the DVD/CD AUX but-
ton to make DVD-V the active source. To
resume DVD playback, press the play/
pause button on the remote control, or
press the pushbutton located under theplay/pause symbol tag displayed on the
radio. The DVD should resume play from
where it last stopped if the disc has not
been ejected and the stop button has not
been pressed twice on the remote control.
If the disc has been ejected or the stop but-
ton has been pressed twice on the remote
control, the disc resumes playing at the
beginning of the disc.
Ejecting a Disc
Press the eject button on the radio to eject
the disc. If a disc is ejected from the radio,
but not removed, the radio reloads the disc
after a short period of time. The disc is
stored in the radio. The radio does not
resume play of the disc automatically. In
case loading and reading of a DVD or CD
cannot be completed (unknown format,
etc.), and the disc fails to eject, press and
hold the DVD Eject button more than five
seconds to force the disc to eject.
DVD Radio Error Messages
Player Error:
This message displays when there are disc
load or eject problems.Disc Format Error:
This message displays, if the disc is
inserted with the disc label wrong side up,
or if the disc is damaged.
Disc Region Error:
This message displays, if the disc is not
from a correct region.
No Disc Inserted:
This message displays, if no disc is
present when the EJECT or DVD/CD AUX
button is pressed on the radio.
Using the Auxiliary Input Jack(s)
The radio system has an auxiliary input
jack located on the lower right side of the
faceplate. This is not an audio output; do
not plug the headphone set into the front
auxiliary input jack. However, an external
audio device such as an iPod, laptop com-
puter, MP3 player, CD player, or cassette
tape player, etc. can be connected to the
auxiliary input jack for use as another
source for audio listening.
Drivers are encouraged to set up any auxil-
iary device while the vehicle is in PARK
(P). Refer to “Defensive Driving” in “Your
Driving, the Road, and Your Vehicle” in the
“Driving Your Vehicle” section for more
information on driver distraction.
To use a portable audio player, connect a
1/8 inch (3.5 mm) cable to the radio’s front
auxiliary input jack. While a device is con-
nected, the radio automatically begins
playing audio from the device over the
vehicle speakers.

3-62 INSTRUMENT PANEL
78J00-03E
length of the file, folder, or playlist name.
Long names also take up more space on
the display, potentially getting cut off.
 Finalize the audio disc before you burn it.
Trying to add music to an existing disc
may cause the disc not to function in the
player.
Root Directory
The root directory of the CD-R is treated
as a folder. If the root directory has com-
pressed audio files, the directory is dis-
played as F1 ROOT. All files contained
directly under the root directory are
accessed prior to any root directory fold-
ers. However, playlists (Px) are always
accessed before root folders or files.
Empty Directory or Folder
If a root directory or a folder exists some-
where in the file structure that contains
only folders/subfolders and no compressed
files directly beneath them, the player
advances to the next folder in the file struc-
ture that contains compressed audio files.
The empty folder does not display.
No Folder
When the CD-R contains only compressed
files, the files are located under the root
folder. The next and previous folder func-
tion does not function on a CD-R that was
recorded without folders or playlists. When
displaying the name of the folder the radio
displays ROOT.
When the CD-R contains only playlists and
compressed audio files, but no folders, allfiles are located under the root folder. The
folder down and the folder up buttons
search playlists (Px) first and then goes to
the root folder. When the radio displays the
name of the folder the radio displays
ROOT.
Order of Play
Tracks recorded to the CD-R are played in
the following order:
 Play begins from the first track in the first
playlist and continues sequentially
through all tracks in each playlist. When
the last track of the last playlist has
played, play continues from the first track
of the first playlist.
 Play begins from the first track in the first
folder and continues sequentially
through all tracks in each folder. When
the last track of the last folder has
played, play continues from the first track
of the first folder.
When play enters a new folder, the display
does not automatically show the new folder
name unless the folder mode was chosen
as the default display. The new track name
displays.
File System and Naming
The song name that is displayed is the
song name that is contained in the ID3 tag.
If the song name is not present in the ID3
tag, then the radio displays the file name
without the extension (such as .mp3) as
the track name.Track names longer than 32 characters or
four pages are shortened. Parts of words
on the last page of text and the extension
of the filename displays.
Preprogrammed Playlists
Preprogrammed playlists that were created
using WinAmp
TM, MusicMatch
TM, or Real
Jukebox
TM software can be accessed,
however, they cannot be edited using the
radio. These playlists are treated as spe-
cial folders containing compressed audio
song files.
Playing an MP3
(in either the DVD or CD slot)
Insert a CD-R partway into either the top or
bottom slot, label side up. The player pulls
it in, and the CD-R should begin playing.
Depending on the format of the disc, a
softkey menu appears and allows naviga-
tion of the disc. The menu reads left to
right as RDM (Randomize song play
order), a Folder icon with left and right
arrows (to move up or down through avail-
able folders), a PL tag if the disc has a
Playlist available, and a Music Navigator
tag. If a Playlist tag is shown, toggling this
key brings up a Folder softkey only or the
menu as previously described.
If the ignition or radio is turned off with a
CD-R in the player, it stays in the player.
When the ignition or radio is turned on, the
CD-R starts to play where it stopped, if it
was the last selected audio source.

3-71 INSTRUMENT PANEL
78J00-03E
tinue playing in a slow play mode. You
may also, depending on the radio, perform
reverse slow play by pressing the pause
button and then pressing the fast reverse
button. To cancel slow play mode, press
the play/pause button.
(Previous Track/Chapter):
Press this button to return to the start of
the current track or chapter. Press this but-
ton again to go to the previous track or
chapter. This button may not work when
the DVD is playing the copyright informa-
tion or the previews.
(Next Track/Chapter):
Press this button to go to the beginning of
the next chapter or track. This button may
not work when the DVD is playing the
copyright information or the previews.
(Fast Reverse):
Press this button to fast reverse the DVD
or CD. To stop fast reversing a DVD video,
press the play button. To stop fast revers-
ing a DVD audio or CD, release the fast
reverse button. This button may not work
when the DVD is playing the copyright
information or the previews.
(Fast Forward):
Press this button to fast forward the DVD
or CD. To stop fast forwarding a DVD
video, press the play button. To stop fast
forwarding a DVD audio or CD, release the
fast forward button. This button may not
work when the DVD is playing the copy-
right information or the previews. (Audio):
Press this button to change audio tracks
on DVDs that have this feature when the
DVD is playing. The format and content of
this function will vary for each disc.
(Subtitles):
Press this button to turn ON/OFF subtitles
and to move through subtitle options when
a DVD is playing. The format and content
of this function will vary for each disc.
AUX (Auxiliary):
Press this button to switch the system
between the DVD player and an auxiliary
source.
(Camera):
Press this button to change camera angles
on DVDs that have this feature when a
DVD is playing. The format and content of
this function will vary for each disc.
1 through 0 (Numeric Keypad):
The numeric keypad provides the capabil-
ity of direct chapter or track number selec-
tion.
(Clear):
Press this button within three seconds
after entering a numeric selection, to clear
all numeric inputs.
(Double Digit Entries):
Press this button to select chapter or track
numbers greater than nine. Press this but-
ton before entering the number.Battery Replacement
To change the remote control batteries, do
the following:
1) Remove the battery compartment door
located on the bottom of the remote
control.
2) Replace the two batteries in the com-
partment. Make sure that they are
installed correctly, using the diagram on
the inside of the battery compartment.
3) Close the battery door securely.
If the remote control is to be stored for a
long period of time, remove the batteries
and keep them in a cool, dry place.

4-2 DRIVING YOUR VEHICLE
78J00-03E
many might think. Although it depends on
each person and situation, here is some
general information on the problem.
The Blood Alcohol Concentration (BAC) of
someone who is drinking depends upon
four things:
 The amount of alcohol consumed
 The drinker’s body weight
 The amount of food that is consumed
before and during drinking
 The length of time it has taken the
drinker to consume the alcohol
According to the American Medical Associ-
ation, a 180 lbs (82 kg) person who drinks
three 12 ounce (355 ml) bottles of beer in
an hour will end up with a BAC of about
0.06 percent. The person would reach the
same BAC by drinking three 4 ounce (120
ml) glasses of wine or three mixed drinks if
each had 1-1/2 ounces (45 ml) of liquors
like whiskey, gin, or vodka.
1527211
It is the amount of alcohol that counts. For
example, if the same person drank three
double martinis (3 ounces or 90 ml of
liquor each) within an hour, the person’s
BAC would be close to 0.12 percent. A per-
son who consumes food just before or dur-
ing drinking will have a somewhat lower
BAC level.
There is a gender difference, too. Women
generally have a lower relative percentage
of body water than men. Since alcohol is
carried in body water, this means that a
woman generally will reach a higher BAC
level than a man of her same body weight
will when each has the same number of
drinks.
The law in most U.S. states, and through-
out Canada, sets the legal limit at 0.08 per-
cent. In some other countries, the limit is
even lower. For example, it is 0.05 percentin both France and Germany. The BAC
limit for all commercial drivers in the United
States is 0.04 percent.
The BAC will be over 0.10 percent after
three to six drinks (in one hour). Of course,
as we have seen, it depends on how much
alcohol is in the drinks, and how quickly the
person drinks them.
But the ability to drive is affected well
below a BAC of 0.10 percent. Research
shows that the driving skills of many peo-
ple are impaired at a BAC approaching
0.05 percent, and that the effects are
worse at night. All drivers are impaired at
BAC levels above 0.05 percent. Statistics
show that the chance of being in a collision
increases sharply for drivers who have a
BAC of 0.05 percent or above. A driver with
a BAC level of 0.06 percent has doubled
his or her chance of having a collision. At a
BAC level of 0.10 percent, the chance of
this driver having a collision is 12 times
greater; at a level of 0.15 percent, the
chance is 25 times greater!
The body takes about an hour to rid itself
of the alcohol in one drink. No amount of
coffee or number of cold showers will
speed that up. “I will be careful” is not the
right answer. What if there is an emer-
gency, a need to take sudden action, as
when a child darts into the street? A per-
son with even a moderate BAC might not
be able to react quickly enough to avoid
the collision.

4-20 DRIVING YOUR VEHICLE
78J00-03E
TowingTowing Your VehicleConsult your dealer or a professional tow-
ing service if you need to have your dis-
abled vehicle towed.
If you want to tow your vehicle behind
another vehicle for recreational purposes
(such as behind a motorhome), refer to
“Recreational Vehicle Towing” following.Recreational Vehicle TowingRecreational vehicle towing means towing
your vehicle behind another vehicle – such
as behind a motorhome. The two most
common types of recreational vehicle tow-
ing are known as “dinghy towing” (towing
your vehicle with all four wheels on the
ground) and “dolly towing” (towing your
vehicle with two wheels on the ground and
two wheels up on a device known as a
“dolly”).
With the proper preparation and equip-
ment, many vehicles can be towed in these
ways. See “Dinghy Towing” and “Dolly Tow-
ing”, following.
Here are some important things to con-
sider before you do recreational vehicle
towing:
 What’s the towing capacity of the towing
vehicle? Be sure you read the tow vehi-
cle manufacturer’s recommendations. How far will you tow? Some vehicles
have restrictions on how far and how
long they can tow.
 Do you have the proper towing equip-
ment? See your dealer or trailering pro-
fessional for additional advice and
equipment recommendations.
 Is your vehicle ready to be towed? Just
as you would prepare your vehicle for a
long trip, you’ll want to make sure your
vehicle is prepared to be towed. Refer to
“Before Leaving on a Long Trip” in this
section.
Dinghy Towing
If you have an all-wheel-drive vehicle or a
front-wheel-drive vehicle, it was not
designed to be towed with all of its wheels
on the ground. It can be towed with car
carrier equipment. If you have a front-wheel-drive vehicle, it can be towed with its
two front wheels off the ground. See “Dolly
Towing” following.
Dolly Towing
If you have a front-wheel-drive vehicle, it
can be towed with the two front wheels off
the ground. To dolly tow your vehicle, do
the following:
1) Put the front wheels on a dolly.
2) Put the vehicle in PARK (P).
3) Set the parking brake and then remove
the key.
4) Clamp the steering wheel in a straight-
ahead position with a clamping device
designed for towing.
5) Release the parking brake.
If you have an all-wheel-drive vehicle, it
cannot be towed with any of its wheels on
CAUTION
Towing an all-wheel-drive vehicle
with all four wheels or even only two
wheels on the ground will damage
drivetrain or transmission compo-
nents. Towing a front-wheel-drive
vehicle with all four wheels on the
ground will damage drivetrain or
transmission components. Do not
tow an all-wheel-drive vehicle with
two or four wheels on the ground or a
front-wheel-drive vehicle if all four
wheels will be on the ground.
CAUTION
Towing an all-wheel-drive vehicle
with all four wheels or even only two
wheels on the ground will damage
drivetrain or transmission compo-
nents. Towing a front-wheel-drive
vehicle with all four wheels on the
ground will damage drivetrain or
transmission components. Do not
tow an all-wheel-drive vehicle with
two or four wheels on the ground or a
front-wheel-drive vehicle if all four
wheels will be on the ground.

5-9 SERVICE AND APPEARANCE CARE
78J00-03E
system to work properly, you must reset
the system every time the oil is changed.
When the system has calculated that oil
life has been diminished, it will indicate
that an oil change is necessary. A change
engine oil light and a CHANGE ENGINE
OIL SOON message will come on. Refer to
“Change Engine Oil Light” in “Warning
Lights, Gages, and Indicators” in the
“Instrument Panel” section and “DIC Warn-
ings and Messages” in “Driver Information
Center (DIC)” in the “Instrument Panel”
section. Change your oil as soon as possi-
ble within the next 600 miles (1000 km). It
is possible that, if you are driving under the
best conditions, the oil life system may not
indicate that an oil change is necessary for
over a year. However, your engine oil and
filter must be changed at least once a year
and at this time the system must be reset.
Your dealer has trained service people
who will perform this work and reset the
system. It is also important to check your
oil regularly and keep it at the proper level.
If the system is ever reset accidentally, you
must change your oil at 3000 miles (5000
km) since your last oil change. Remember
to reset the oil life system whenever the oil
is changed.
How to Reset the Engine Oil Life Sys-
tem
The Engine Oil Life System calculates
when to change your engine oil and filter
based on vehicle use. Anytime your oil ischanged, reset the system so it can calcu-
late when the next oil change is required. If
a situation occurs where you change your
oil prior to a change engine oil light or
CHANGE ENGINE OIL SOON message
being turned on, reset the system.
1) Turn the ignition key to RUN with the
engine off.
2) Fully press and release the accelerator
pedal three times within five seconds.
The change engine oil light will flash
while the system is resetting.
3) When the light stops flashing, turn the
key to LOCK.
If the light or message comes back on and
stays on when you start your vehicle, the
engine oil life system has not reset.
Repeat the procedure.
What to Do with Used Oil
Used engine oil contains certain elements
that may be unhealthy for your skin and
could even cause cancer. Do not let used
oil stay on your skin for very long. Clean
your skin and nails with soap and water, or
a good hand cleaner. Wash or properly
dispose of clothing or rags containing used
engine oil. See the manufacturer’s warn-
ings about the use and disposal of oil prod-
ucts.
Used oil can be a threat to the environ-
ment. If you change your own oil, be sure
to drain all the oil from the filter before dis-
posal. Never dispose of oil by putting it inthe trash, pouring it on the ground, into
sewers, or into streams or bodies of water.
Instead, recycle it by taking it to a place
that collects used oil. If you have a prob-
lem properly disposing of your used oil,
ask your dealer, a service station, or a
local recycling center for help.
Engine Air Cleaner/FilterThe engine air cleaner/filter is located in
the engine compartment on the passen-
ger’s side of the vehicle. Refer to “Engine
Compartment Overview” in this section for
more information on location.
When to Inspect the Engine Air Cleaner/
Filter
Inspect the air cleaner/filter at the Mainte-
nance II intervals and replace it at the first
oil change after each 50000 mile (83000
km) interval. Refer to “Scheduled Mainte-
nance” in “Maintenance Schedule” in the
“Maintenance Schedule” section for more
information. If you are driving in dusty/dirty
conditions, inspect the filter at each engine
oil change.
How to Inspect the Engine Air Cleaner/
Filter
To inspect the air cleaner/filter remove the
filter from the vehicle and lightly shake the
filter to release loose dust and dirt. If the fil-
ter remains caked with dirt, a new filter is
required.

5-16 SERVICE AND APPEARANCE CARE
78J00-03E
6) Reinstall the coolant recovery tank cap
and the pressure cap.
7) If the coolant in the recovery tank is
constantly low, you should have your
dealership service department inspect
the vehicle for leaks.Power Steering Fluid
812554
Refer to “Engine Compartment Overview”
in this section for reservoir location.
When to Check Power Steering Fluid
It is not necessary to regularly check
power steering fluid unless you suspect
there is a leak in the system or you hear an
unusual noise. A fluid loss in this system
could indicate a problem. Have the system
inspected and repaired.How to Check Power Steering Fluid
To check the power steering fluid, do the
following:
1) Turn the key off and let the engine com-
partment cool down.
2) Wipe the cap and the top of the reser-
voir clean.
3) Unscrew the cap and wipe the dipstick
with a clean rag.
4) Replace the cap and completely tighten
it.
5) Remove the cap again and look at the
fluid level on the dipstick.
The fluid level should be between the Min
(Minimum) and Max (Maximum) marks
when the engine is cold, and at the Max
mark when the engine is hot. If the fluid is
at the Min mark when the engine is cold or
hot, power steering fluid should be added.
What to Use
To determine what kind of fluid to use,
refer to “Recommended Fluids and Lubri-
cants” in “Maintenance Schedule” in the
“Maintenance Schedule” section. Always
use the proper fluid. Failure to use the
proper fluid can cause leaks and damage
hoses and seals.
Windshield Washer FluidWhat to Use
When you need windshield washer fluid,
be sure to read the manufacturer’s instruc-
tions before use. If you will be operating
your vehicle in an area where the tempera-
ture may fall below freezing, use a fluid
that has sufficient protection against freez-
ing.
Adding Washer Fluid
809177
Open the cap with the washer symbol on it.
Add washer fluid until the tank is full. Refer
to “Engine Compartment Overview” in this
section for reservoir location.

5-19 SERVICE AND APPEARANCE CARE
78J00-03E
For battery replacement, see your dealer
or the service manual.
Vehicle Storage
If you are not going to drive your vehicle
for 25 days or more, remove the black,
negative (–) cable from the battery. This
will help keep your battery from running
down.
You must close all doors and the liftgate
before reconnecting the battery. After
reconnecting the battery, you must press
the unlock button on the key transmitter.
Failure to follow this procedure may result
in sounding an alarm. Pressing unlock on
the key transmitter would stop the alarm.
Jump StartingIf your vehicle’s battery has run down, you
may want to use another vehicle and some
jumper cables to start your vehicle. Be
sure to use the following steps to do it
safely.
1) Check the other vehicle. It must have a
12-volt battery with a negative ground
system.2) Get the vehicles close enough so the
jumper cables can reach, but be sure
the vehicles are not touching each
other. If they are, it could cause a
ground connection you do not want.
You would not be able to start your
vehicle, and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles
rolling, set the parking brake firmly on
both vehicles involved in the jump start
procedure. Put an automatic transaxle
in PARK (P) or a manual transaxle in
NEUTRAL before setting the parking
brake.
WARNING
Battery posts, terminals, and related
accessories contain lead and lead
compounds, chemicals known to the
State of California to cause cancer
and reproductive harm. Wash hands
after handling.
WARNING
Batteries have acid that can burn you
and gas that can explode. You can be
badly hurt if you are not careful.
Refer to “Jump Starting” in this sec-
tion for tips on working around a bat-
tery without getting hurt.
WARNING
Batteries can hurt you. They can be
dangerous because:
 They contain acid that can burn
you.
 They contain gas that can explode
or ignite.
 They contain enough electricity to
burn you.
If you do not follow these steps
exactly, some or all of these things
can hurt you.
CAUTION
Ignoring these steps could result in
costly damage to your vehicle that
would not be covered by your war-
ranty.
Trying to start your vehicle by push-
ing or pulling it will not work, and it
could damage your vehicle.
CAUTION
If the other vehicle’s system is not a
12-volt system with a negative
ground, both vehicles can be dam-
aged. Only use vehicles with 12-volt
systems with negative grounds to
jump start your vehicle.
CAUTION
If you leave your radio or other
accessories on during the jump start-
ing procedure, they could be dam-
aged. The repairs would not be
covered by your warranty. Always
turn off your radio and other acces-
sories when jump starting your vehi-
cle.

5-33 SERVICE AND APPEARANCE CARE
78J00-03E
The TPMS system is ready for the sen-
sor matching process to begin.
5) Start with the driver side front tire.
6) Remove the valve cap from the tire’s
valve stem. Activate the TPMS sensor
by increasing or decreasing the tire’s
air pressure for five seconds, or until a
horn chirp sounds. The horn chirp,
which may take up to 30 seconds to
sound, confirms that the sensor identifi-
cation code has been matched to the
tire/wheel position. To decrease the
tire’s air-pressure use the pointed end
of the valve cap, a pencil-style air pres-
sure gage, or a key.
7) Proceed to the passenger side front
tire, and repeat the procedure in Step 6.
8) Proceed to the passenger side rear tire,
and repeat the procedure in Step 6.
9) Proceed to the driver side rear tire, and
repeat the procedure in Step 6.
10)After hearing the confirming horn chirp
for the driver side rear tire, the tire
learning process ends. Turn the ignition
switch to LOCK.
11)Set all four tires to the recommended
air pressure level as indicated on the
tire and loading information label.
12)Put the valve caps back on the valve
stems.
Federal Communications Commission
(FCC) and Industry and Science Canada
The Tire Pressure Monitor System (TPMS)
operates on a radio frequency and com-
plies with Part 15 of the FCC Rules. Oper-ation is subject to the following two
conditions:
1) This device may not cause harmful
interference.
2) This device must accept any interfer-
ence received, including interference
that may cause undesired operation.
The Tire Pressure Monitor System (TPMS)
operates on a radio frequency and com-
plies with RSS-210 of Industry and Sci-
ence Canada. Operation is subject to the
following two conditions:
1) This device may not cause interfer-
ence.
2) This device must accept any interfer-
ence received, including interference
that may cause undesired operation of
the device.
Changes or modifications to this system by
other than an authorized service facility
could void authorization to use this equip-
ment.
Tire Inspection and RotationTires should be rotated every 5000 to 8000
miles (8000 to 13000 km).
Any time you notice unusual wear, rotate
your tires as soon as possible and check
wheel alignment. Also check for damaged
tires or wheels. Refer to “When It Is Time
for New Tires” and “Wheel Replacement”
in this section for more information.The purpose of regular rotation is to
achieve more uniform wear for all tires on
the vehicle. The first rotation is the most
important. Refer to “Scheduled Mainte-
nance” in “Maintenance Schedule” in the
“Maintenance Schedule” section for sched-
uled rotation intervals.
811106
When rotating your tires, always use the
correct rotation pattern shown here.
Do not include the compact spare tire in
your tire rotation.
After the tires have been rotated, adjust
the front and rear inflation pressures as
shown on the Tire and Loading Information
label. Refer to “Inflation -Tire Pressure” in
this section and “Loading Your Vehicle” in
“Your Driving, the Road, and Your Vehicle”
in the “Driving Your Vehicle” section.
