steering wheel adjustment TOYOTA AVALON 2021 Owners Manual (in English)

1423-3. Adjusting the seats
Seat position adjustment switch
Seatback angle adjustment
switch
Seat cushion (front) angle
adjustment switch
Vertical height adjustment
switch
Lumbar support firmness
adjustment switch (if equipped)
Lumbar support height adjust-
ment switch (if equipped)
■Power easy access system (vehicles with driving position memory)
The driver’s seat and steering wheel move in accordance with engine switch
mode and the driver’s seat belt condition. (P. 146)
Front seats
Adjustment procedure
1
2
3
4
5
6

1483-3. Adjusting the seats
■To stop the position recall operation part-way through
Perform any of the following operations:
●Press the “SET” button.
●Press button “1” or “2”.
●Operate any of the seat adjustment switches (only cancels seat position
recall).
●Operate the tilt and telescopic steering control switch (only cancels steering
wheel position recall).
■Seat positions that can be memorized (P. 142)
The adjusted positions other than the position adjusted by lumbar support
switch can be recorded.
■Operating the driving position memory after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.
■In order to correctly use the driving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be slightly different
when it is recalled.

1503-3. Adjusting the seats
■Cancelation procedure
Carry only the key you want to cancel and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
canceled properly.
Turn the engine switch to IGNITION ON mode.
While pressing the “SET” button, press and hold the door lock
switch (either lock or unlock) until the buzzer sounds twice.
If it button could not be canceled, the buzzer sounds continuously for
approximately 3 seconds.
■Recalling the driving position using the memory recall function
●Different driving positions can be registered for each electronic key. There-
fore, the driving position that is recalled may be different depending on the
key being carried.
●If a door other than the driver’s door is unlocked with the smart key system,
the driving position cannot be recalled. In this case, press the driving posi-
tion button which has been set.
■Customization
Some functions can be customized. (P. 505)
WARNING
■Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear
passenger or squeeze your body against the steering wheel.
1
2

153
3
Operation of each component
3-4. Adjusting the steering wheel and mirrors
Manual type
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
Power type
Operating the switch moves the steering wheel in the following direc-
tions:
Up
Down
Toward the driver
Away from the driver
Steering wheel
Adjustment procedure
1
2
1
2
3
4

1543-4. Adjusting the steering wheel and mirrors
To sound the horn, press on or
close to the mark.
■The steering wheel can be adjusted when (power type)
The engine switch is in ACCESSORY or IGNITION ON mode.
■Automatic adjustment of the steering position (vehicles with driving
position memory)
A desired steering position can be entered to memory and recalled automati-
cally by the driving position memory system. (P. 146)
■Power easy access system (vehicles with driving position memory)
The steering wheel and driver’s seat move in accordance with engine switch
mode and the driver’s seat belt condition. (P. 505)
Horn
WARNING
■Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.
■After adjusting the steering wheel (manual type)
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident, and resulting in death or serious injury. Also, the horn may not
sound if the steering wheel is not securely locked.

1573-4. Adjusting the steering wheel and mirrors
3
Operation of each component
To select a mirror to adjust, turn
the switch.
Left
Right
To adjust the mirror, operate the
switch.
Up
Right
Down
Left
Push the mirror back in the direc-
tion of the vehicle’s rear.
Outside rear view mirrors
Adjustment procedure
1
1
2
2
1
2
3
4
Folding the mirrors

1583-4. Adjusting the steering wheel and mirrors
When the mirror select switch is in the “L” or “R” position, the outside
rear view mirrors will automatically angle downwards when the vehicle
is reversing in order to give a better view of the ground.
To disable this function, select neither “L” nor “R” of the mirror select
switch.
■Adjusting the mirror angle when the vehicle is reversing
With the shift lever in R, adjust the mirror angle at a desired posi-
tion.
The adjusted angle will be memorized and the mirror will automati-
cally tilt to the memorized angle whenever the shift lever is shifted
to R from next time.
The memorized downward tilt position of the mirror is linked to the nor-
mal position (angle adjusted with the shift lever in other than R). There-
fore, if the normal position is changed after adjustment, the tilt position
will also change.
When the normal position is changed, readjust the angle in reversing.
■Mirror angle can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode.
■When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. ( P. 324)
■Automatic adjustment of the mirror angle (vehicles with driving position
memory)
A desired mirror face angle can be entered to memory and recalled automati-
cally by the driving position memory. (P. 146)
■Auto anti-glare function (driver’s side only) (if equipped)
When the anti-glare inside rear view mirror is set to automatic mode, the out-
side rear view mirrors will activate in conjunction with the anti-glare inside
rear view mirror to reduce reflected light. (P. 155)
■Customization
Some functions can be customized. (P. 505)
Linked mirror function when reversing (vehicles with driving
position memory)

4417-2. Steps to take in an emergency
7
When trouble arises
WARNING
■If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact your To y o t a
dealer. The vehicle will become extremely unstable during braking, and the
ABS system may fail, which could cause an accident resulting in death or
serious injury.
■When the electric power steering system warning light comes on
When the light comes on yellow, the assist to the power steering is
restricted. When the light comes on red, the assist to the power steering is
lost and handling operations of the steering wheel become extremely
heavy. When steering wheel operations are heavier than usual, grip the
steering wheel firmly and operate it using more force than usual.
■
If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could
cause a loss of vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire
inflation pressure immediately.
●If the tire pressure warning light comes on even after tire inflation pres-
sure adjustment, it is probable that you have a flat tire. Check the tires.
If a tire is flat, change it with the spare tire and have the flat tire
repaired by the nearest Toyota dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

543Alphabetical index
Seats ................................. 142, 144
Adjustment .................... 142, 144
Adjustment
precautions ................. 143, 145
Child seats/child restraint
system installation ................ 63
Cleaning................................ 369
Driving position memory ....... 146
Folding down the rear
seatbacks ........................... 144
Front seat heaters................. 329
Head restraints ..................... 151
Power easy access
system ................................ 146
Properly sitting in the seat ...... 28
Rear seat heaters ................. 329
Seat ventilators ..................... 329
Secondary Collision Brake ..... 310
Sensor
Automatic headlight
system ................................ 204
Automatic High Beam
system ................................ 206
Camera sensor ..................... 219
Inside rear view mirror .......... 156
Intuitive parking assist .......... 276
LDA (Lane Departure Alert
with steering control) .......... 237
Radar sensor ........................ 219
Service reminder
indicators ................................. 84
Shift lever ................................. 189
Automatic transmission......... 189
If the shift lever cannot
be shifted from P ................ 193
S mode ................................. 190Shift lock system ..................... 192
Side airbags ............................... 37
Side marker lights ................... 202
Light switch ........................... 202
Replacing light bulbs ............ 421
Side mirrors ............................. 157
Adjusting and folding ............ 157
BSM (Blind Spot Monitor) ..... 260
Heaters ................................. 324
Side turn signal lights
Replacing light bulbs ............ 421
Turn signal lever ................... 195
Smart key system .................... 135
Antenna location ................... 135
Entry functions .............. 125, 131
Starting the engine ............... 184
Snow tires ................................ 319
Spare tire .................................. 449
Inflation pressure .................. 486
Storage location.................... 450
Spark plug ................................ 483
Specifications .......................... 478
Speedometer.............................. 90
Sport mode .............................. 305
Steering lock
Column lock release ............. 186
Steering wheel ......................... 153
Adjustment............................ 153
Heated steering wheel .......... 329
Meter control switches ............ 94
Power easy access
system ................................ 146
Stoplights
Replacing light bulbs ............ 421
Storage feature ........................ 335
Storage precautions................ 335
