5408-2. Steps to take in an emergency
Owners Manual_USA_M42C01_en
1Locks all the doors
2 Unlocks the door
Turning the key rearward unlocks
the driver’s door. Turning the key
once again within 5 seconds
unlocks the other doors.
■Key linked functions
1 Closes the windo ws (turn and
hold)
*
2 Opens the windows (turn and
hold)
*
*
: These settings must be custom- ized at your Toyota dealer.
1 Depress the brake pedal.
2 Touch the electronic key to
the power switch.
When the electronic key is
detected, a buzzer sounds and the
power switch will turn to ON.
When the smart key system is
deactivated in customization set-
ting, the power switch will turn to
ACC.
3Firmly depress the brake
pedal and check that is
displayed on the multi-infor-
mation display.
4 Press the power switch
shortly and firmly.
In the event that the EV system still
WARNING
■When using the mechanical
key and operating the power
windows
Operate the power window after
checking to make sure that there
is no possibility of any passenger
having any of their body parts
caught in the window. Also, do not
allow children to operate the
mechanical key. It is possible for
children and other passengers to
get caught in the power window.
Starting the EV system

5458-2. Steps to take in an emergency
Owners Manual_USA_M42C01_en
8
When trouble arises1 Stop the vehicle in a safe
place and turn off the air con-
ditioning system.
2 Leave the EV system operat-
ing and carefully lift the hood.
3 Check if the cooling fan is
operating.
If the fan is operating:
Wait until the “EV System
overheated Output power
reduced” message disap-
WARNING
■When replacing the 12-volt
battery
●When the vent plug is close to
the hold down cl amp, the bat-
tery fluid (acid) may leak.
●For information regarding bat-
tery replacement, contact your
Toyota dealer.
NOTICE
■When handling jumper cables
When connecting the jumper
cables, ensure that they do not
become entangled in the cooling
fan.
If your vehicle over-
heats
When “EV System over-
heated Output power
reduced” is shown on the
multi-information display,
your vehicle may be over-
heating.
NOTICE
■Cooling system coolant
The radiator coolant is exclusive
for radiator usage. Damage may
occur when water or any other
type of coolant is used, so never
use any other fluid. When there is
no “Toyota Genuine Traction Bat-
tery Coolant”, immediately contact
your Toyota dealer.
Correction procedures

5669-2. Customization
Owners Manual_USA_M42C01_en
9-2.Customization
■Changing using the multi-
information display
1 Press or of the meter
control switches and select
.
2 Press or of the meter
control switches, select the
item.
3 To switch the function on and
off, press icon to switch
to the desired setting.
4 To perform detailed setting of
the function, press and hold and display the setting
screen.
The method of deta iled setting dif-
fers for each screen. Please refer to
the advice sentenc e displayed on
the screen.
To go back to the previous screen
or exit the customize mode, press
.
■Changing by using the mul-
timedia system
1 Select on the main menu.
2 Select “Vehicle customize”.
3 According to the display,
select the desired setting.
Various setting can be changed.
Refer to the list of settings that can
be changed for details.
■When customizing using the
multimedia system or multi-
information display
Stop the vehicle in a safe place,
apply the parking brake, and shift
the shift lever to P. Also, to prevent
12-volt battery discharge, leave the
EV system operating while custom-
izing the features.
Some function settings are changed simultaneously with other fu nc-
tions being customized. Contact y our Toyota dealer for further
details.
Customizable features
Your vehicle includes a vari-
ety of electronic features
that can be personalized to
suit your preferences. The
settings of these features
can be changed using the
multi-information display,
multimedia system, or at
your Toyota dealer.
Customizing vehicle fea-
tures
NOTICE
■During customization
To prevent 12-volt battery dis-
charge, ensure that the EV sys-
tem is operating while
customizing features.
Customizable Features

5679-2. Customization
Owners Manual_USA_M42C01_en
9
Vehicle specifications
Settings that can be changed using the multimedia system
Settings that can be changed using the multi-information displa y
Settings that can be changed by your Toyota dealer
Definition of symbols: O = Available, – =Not available
■Charging system ( P.105, 113)
■Gauges, meters and multi-information display ( P.152, 155)
FunctionDefault settingCustomized
setting
Charging currentMAX8AOO–16A
Charging limitFull
90%
OO–
80%
70%
60%
50%
DC charging powerMAX
125 kW
OO–100 kW
75 kW
50 kW
Connector lockAuto Lock
Off
OO–Auto Lock & Unlock
Battery coolerOnOffOO–
Function*1Default settingCustomized setting
LanguageEnglishFrenchOSpanish
Unitsmiles
(miles/kWh)km
(kWh/100km) km (km/kWh)
O

5689-2. Customization
Owners Manual_USA_M42C01_en
*1: For details about each function: P. 1 5 8
*2: If equipped
■Rear seat reminder ( P.169)
Power Consumption
Total average
(Average
power con-
sumption [after reset])Trip average (Average
power con-
sumption [after start])
O
Audio system linked displayOnOffO
AWD*2OnOffO
Drive Info TypeAfter StartAfter ResetO
Drive Info ItemsDistance
Average Speed
O
To t a l T i m e
Pop-up displayOnOffO
Closing displayDrive InfoCharging
ScheduleO
Suggestion functionOn
On (when the vehicle is stopped)
OO
Off
FunctionDefault settingCustomized setting
Indication to prevent mis-
placement in the rear seatOnOff—O—
Function*1Default settingCustomized setting

Owners Manual_USA_M42C01_en
595What to do if... (Troubleshooting)
Is the 12-volt battery dis-
charged? ( P.541)
 Is the window lock switch
pressed?
The power window except for
the one at the driver’s seat
cannot be operated if the win-
dow lock switch is pressed.
( P.214)
 The auto power off function
will be operated if the vehicle
is left in ACC or ON (the EV
system is not operating) for a
period of time. ( P.235)
 The seat belt reminder light is
flashing
Are the driver and the passengers
wearing the seat belts? ( P. 5 1 5
,
516)
 The parking brake indicator is
on
Is the parking brake released?
( P.245)
Depending on the situation,
other types of warning buzzer
may also sound. ( P.513, 522)
Did anyone inside the vehicle
open a door during setting the
alarm?
The sensor detects it and the
alarm sounds. ( P.69)
To stop the alarm, turn the power
switch to ON or start the EV sys-
tem.
Is the message displayed on
the multi-information display?
Check the message on the
multi-information display.
( P.522)
 When a warning light turns on
or a warning message is dis-
played, refer to P.513, 522.
 Stop the vehicle in a safe
place and replace the flat tire
with the spare tire. ( P.527)
The windows do not open
or close by operating the
power window switches
The power switch is
turned off automatically
A warning buzzer sounds
during driving
An alarm is activated and
the horn sounds (if
equipped)
A warning buzzer sounds
when leaving the vehicle
A warning light turns on
or a warning message is
displayed
When a problem has
occurred
If you have a flat tire

Owners Manual_USA_M42C01_en
597Alphabetical Index
Alphabetical Index
A
A/C ........................................... 402Air conditioning filter ............. 494
Automatic air conditioning sys-tem ..................................... 402
Front seat concentrated airflow mode (S-FLOW) ................. 408
My Room Mode .................... 129
Remote Air Conditioning System ........................................... 409
“SYNC”mode ........................ 406
ABS (Anti-lock Brake System) ............................................... 387Function ............................... 387
Warning light ........................ 514
AC charging ............................ 105
AC charging cable .................... 87 CCID (Charging Circuit Interrupt-ing Device) ........................... 89
If the AC charging connector cannot be unlocked .............. 95
Indicator ................................. 90
Maintenance........................... 92
Safety functions...................... 89
ACA (Active Cornering Assist) ............................................... 387
Acoustic Vehicle Alerting Sys- tem ........................................... 74
Active Cornering Assist (ACA) ............................................... 387
Air conditioning filter ............. 494
Air conditioning system Air conditioning filter ............. 494
Automatic air conditioning sys-tem ..................................... 402
Front seat concentrated airflow mode (S-FLOW) ................. 408
Remote Air Conditioning System ........................................... 409
“SYNC” mode ....................... 406
Airbags ...................................... 34 Airbag operating conditions ....36
Airbag precautions for your child
.............................................39
Correct driving posture ...........27
Curtain shield airbag operating conditions .............................37
Curtain shield air bag precautions
.............................................39
Front passenger occupant clas- sification system ...................44
General airbag precautions ....39
Locations of airbags ...............34
Modification and disposal of air- bags......................................42
Side airbag operating conditions .............................................37
Side airbag precautions..........39
Side and curtain shield airbags operating conditions .............37
Side and curtain shield airbags precautions ...........................39
SRS airbag instructions for Canadian owners ...............583
SRS airbags ...........................34
SRS warning light .................514
Alarm .........................................69 Alarm ......................................69
Warning buzzer ....................513
ALL AUTO (“ECO”) control....400
Anchor brackets ... ..............52, 61
Antenna (smart key system)..187
Anti-lock Brake System (ABS) Warning light.........................514
Anti-lock brake system (ABS)387 Function................................387
Approach warning ..................294
Armrest ......... ......................... ..437
Assist grips .............................438
Audio system-linked display .157
Automatic air conditioning sys- tem .........................................402Air conditioning filter .............494

Owners Manual_USA_M42C01_en
Alphabetical Index599
Charging ......................... 105, 113AC charging ......................... 105
AC charging cable .................. 87
Charging components ............ 85
Charging indicator .................. 90
Charging methods .................. 98
Charging procedure ..... 105, 113
Charging schedule function.. 118
Charging time may increase 104
Charging tips ........................ 100
DC charging ......................... 113
Display . 101, 121, 129, 131, 140
Information related to charging display 101, 121 , 129, 131, 140
Locking and unlocking the AC charging connector............... 93
My Room Mode .................... 129
Opening and closing the charging port lid s .................. 85
Power sources precautions .... 97
Power sources th at can be used
............................................. 96
Safety functions.............. 89, 102
Things to know before charging ........................................... 102
Warning messages............... 140
When AC charging cannot be performed ........................... 133
When charging schedule func- tion cannot be performed ... 138
When DC charging cannot be performed ........................... 135
Charging equipment ................ 85
Charging methods.................... 98 AC charging ......................... 105
DC charging ......................... 113
Charging ports Charging port lid ..................... 85
Locking and unlocking the AC charging connector............... 93
Opening and closing .............. 85
Charging schedule function .. 118 Setting ..................................121
Charging tips ..........................100
Charging-linked functions My Room Mode ......................98
Traction battery cooler ............99
Traction battery heater ...........99
Traction battery warming control.............................................99
Child restraint system ..............50 Fixed with a LATCH system ...59
Fixed with a seat belt..............54
Front passenger occupant clas-sification system ...................44
Points to remember ................50
Riding with children ................49
Types of child restraint system installation method ...............52
Using an anchor bracket ........61
Child safety ...............................49 12-volt battery precautions ...544
Airbag precautions .................39
Back door precautions..........172
Child restraint system .............52
Electronic sunshade .............427
How your child should wear the seat belt ................................30
Power window lock switch ....214
Power window precautions...213
Rear door child-protectors ....171
Seat belt extender precautions .............................................30
Seat belt precautions........29, 49
Child-protector........................171
Cleaning ..........................448, 451 Aluminum wheels .................449
Brake calipers.......................449
Digital Rear-view Mirror ........206
Exterior .................................448
Interior ..................................451
Radar sensor ........................261
Seat belts .............................451
Clock ................................152, 154

600Alphabetical Index
Owners Manual_USA_M42C01_en
Coat hooks .............................. 437
Console box ............................ 419
Coolant Capacity ............................... 552
Checking ...................... 465, 467
Preparing and c hecking before
winter.................................. 393
Cooling system EV system overheating ........ 545
Coussins gonflables Modification et é limination en fin
de vie des coussins gonflables ........................................... 589
Précautions avec les coussins gonflables latéraux ............. 585
Précautions avec les coussins gonflables latéraux et rideau........................................... 585
Précautions avec les coussins gonflables pour votre enfant........................................... 585
Précautions avec les coussins gonflables rideau ................ 585
Précautions générales avec les coussins gonflables ............ 585
Cruise control Dynamic radar cruise control................................... 288, 296
Warning lights....................... 517
Cup holders ............................ 419
Current Power consumption . 157
Curtain shield airbags ............. 34
Customizable features ........... 566
D
Daytime running light system248
Daytime running lights Replacing light bulbs ............ 502
DC charging ............................ 113
Deck board .............................. 422
Deck under tray ...................... 423
Defogger Outside rear view mirrors .....404
Rear window.........................404
Windshield ............................403
Digital key................................165
Digital Rear-view Mirror .........201
Dimension ...............................550
Dinghy towing .........................230
Display Charging101, 121, 129, 131, 140
Cruise control .......................297
Dynamic radar cruise control 291
Intuitive parking assist ..........312
Multi-information display.......155
Pedestrians Rear of the Vehicle ...........................................340
RCD (Rear Camera Detection) ...........................................328
Rear Camera Detection (RCD) ...........................................328
Warning message.................522
Do-it-yourself maintenance .455, 460
Door lock Back door .............................172
Side doors ............................167
Smart key system .................187
Wireless remote control........164
Door trim ornament lights .....415
Doors Automatic door locking and unlocking system ................171
Back door .............................172
Door glasses ........................212
Door lock ..............................167
Open door warning buzzer ...170
Outside rear view mirrors .....210
Rear door child-protectors ....171
Side doors ............................167
Drive distance .........................158
Drive information ....................158
Drive-start control ..................224
Driving .....................................219

Owners Manual_USA_M42C01_en
Alphabetical Index601
Battery Electric Vehicle driving tips........................................ 81
Break-in tips ......................... 220
Correct posture ...................... 27
Procedures ........................... 219
Winter drive tips ................... 393
Driving assist information Warning light ........................ 517
Driving information display ... 157
Driving range .......................... 152
Driving support system informa- tion display ........................... 157
Dynamic radar cruise control ....................................... 288, 296Approach warning ................ 294
Curve speed redu ction function
........................................... 295
Warning lights....................... 518
E
ECB (Electronically Controlled Brake System) ...................... 387Warning light ........................ 513
Eco mode ................................ 241
EDR (Event data recorder)......... 9
Elapsed time ........................... 158
Electric motor (traction motor) Location.................................. 72
Electric motor(traction motor) Identification number ............ 551
Electric Power Steering (EPS) Function ............................... 387
Warning light ........................ 515
Electric Vehicle system features ................................................. 72
Electric Vehicle system precau-
tions......................................... 76
Electronic key Battery-saving function......... 188
If the electronic key does not operate properly ................. 539
Replacing the battery ........... 497 Electronic sunshade ..............426
Operation..............................426
Electronically Controlled Brake System (ECB) ........................387Warning light.........................513
Emergency Driving Stop System ...............................................299
Emergency flashers ...............504
Emergency tire puncture repair kit ...........................................527Storage location ...................528
Emergency, in case of If a warning buzzer sounds ..513
If a warning light turns on .....513
If a warning message is dis-played .................................522
If the 12-volt battery is dis- charged ..............................541
If the electronic key does not operate properly .................539
If the EV system will not start537
If the vehicle is submerged or water on the road is rising ..506
If you have a flat tire .............527
If you lose your keys.............539
If you think something is wrong ........................................... 511
If your vehicle becomes stuck ...........................................547
If your vehicle has to be stopped in an emergency .................505
If your vehicle needs to be towed ...........................................507
If your vehicle ove rheats ......545
Engine Hood .....................................462
EPS (Electric Po wer Steering)
Function................................387
Warning light.........................515
EV system .................................72 ACC ......................................234
Acoustic Vehicle Alerting System
