’07Camry_U (L/O 0608)
316
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
1. Check the area around the vehicle be-
fore entering it.
2. Adjust seat position, seatback angle,
seat cushion height, head restraint
height, steering wheel angle and length.
3. Adjust the inside and outside rear view
mirrors.
4. Lock all doors.
5. Fasten seat belts.Once you press “ENGINE START STOP”
switch (engine switch) and release it, the
cranking hold function continues to crank
the engine until it starts.
The function stops cranking the engine
after about 25 seconds maximum if the
engine has not started yet. When you
crank the engine again, wait a few sec-
onds and restart it.
If you press and hold the “ENGINE
START STOP” switch, the function will
keep cranking for about 30 seconds maxi-
mum.1. Apply the parking brake firmly.
2. Turn off unnecessary lights and acces-
sories.
3.Manual transmission: Press the clutch
pedal to the floor and shift the trans-
mission into neutral. Hold the clutch
pedal to the floor until the engine is
started. A starter safety device will pre-
vent the starter from operating if the
clutch pedal is not fully depressed.
Automatic transmission: Put the se-
lector lever in “P”. If you need to re-
start the engine while the vehicle is
moving, put the selector lever in “N”.
A starter safety device will prevent the
starter from operating if the selector
lever is in any drive position.
4.Automatic transmission only: De-
press the brake pedal and hold it to
the floor until driving off.
Before starting the engineHow to start the engine—
—Cranking hold function(vehicle with smart key system)(a) Before cranking

’07Camry_U (L/O 0608)
318
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
With the brake pedal firmly depressed, the
indicator light on the “ENGINE START
STOP” switch will turn green. Check that
the automatic transmission selector lever
is in the “P” position. Pressing the
“ENGINE START STOP” switch once
starts the engine.
Press the “ENGINE START STOP” switch
slowly and firmly.
Engine should be warmed up by driving,
not in idle. For warming up, drive with
smoothly turning engine until engine cool-
ant temperature is within normal range.
If the engine stalls...
Simply restart it, using the correct proce-
dure given in normal starting.
If the engine will not start...
In the following cases, the engine will not
start.
If a buzzer sounds from the vehicle,
and the “KEY IS NOT DETECTED”
message appears on the multi−informa-
tion display and the master warning
light comes on when pressing the
“ENGINE START STOP” switch, this
indicates that the key is not in the
vehicle.
If the key is placed in the trunk, the
engine cannot be started.
There are instances in which the en-
gine will not start, even if the key is
in the vehicle (e.g. on the floor, in the
cup holder or glove box).
When the push button start function
does not operate properly, the following
may be causes:
The key battery may be discharged if
the electronic key does not work.
You can start the engine by touching
the Toyota logo side of the electronic
key to the “ENGINE START STOP”
switch. For details, see “Smart key
system” on page 30 in Section 1−2.
Replace the key battery as soon as
possible. (See “—Replacing battery” on
page 28 in Section 1−2.)
The engine was repeatedly turned on
and off over a short period.
Wait 10 seconds and then start the
engine.

’07Camry_U (L/O 0608)
319
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
If the green indicator light on the
“ENGINE START STOP” switch flashes,
and the “S/T IS NOT UNLOCKED”
message appears on the multi−informa-
tion display and the master warning
light comes on, the steering wheel is
locked.
To free it, rotate the steering wheel
slightly while pressing the “ENGINE
START STOP” switch.
If the amber indicator light on the
“ENGINE START STOP” switch flashes,
and the “CHECK S/T LOCK” message
appears on the multi−information dis-
play and the master warning light
comes on, there is a problem in the
steering lock function.
Contact your Toyota dealer, and have
your vehicle and all keys inspected.
If the amber indicator light on the
“ENGINE START STOP” switch flashes,
and no message appears on the multi−
information display, there is a problem
in the push button start function.
Contact your Toyota dealer, and have
your vehicle and all keys inspected.
In addition to the above, there are
instances in which the smart key sys-
tem does not operate properly because
of the circumstances of use. For de-
tails, see “Smart key system” on page
30 in Section 1−2.
In cases other than those described
above, it is possible that a problem has
occurred in an area other than the start
system. See “If your vehicle will not start”
on page 336 in Section 4.When the battery is disconnected or
run down, the push button start function
memorizes the current mode. After you
reconnect, replace, or recharge the bat-
tery, the memorized mode is selected au-
tomatically. In any of these cases, turn off
the engine if the engine comes on.
Wait 10 seconds to start the engine after
the battery has been reconnected. The
engine may not start on the first try. This
does not indicate a malfunction.
NOTICE
Do not race a cold engine.
If the engine becomes difficult to
start or stalls frequently, have the
engine checked immediately.

’07Camry_U (L/O 0608)
320
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
TIPS FOR USING SMART KEY SYSTEM
When using the smart key system, it is
possible to start or stop the engine as
long as the key is on your person.
For this reason, it is possible that a pas-
senger may remove the key from the ve-
hicle without the driver being aware of the
fact. In such a case, it is not possible to
restart the engine after having turned it
off. In addition, it is possible that one may
get out of the vehicle without being aware
that the ignition switch has not been
turned off completely.
When driving or getting in or out of the
vehicle, drivers should make sure that
they are carrying the key.
CAUTION
Do not touch the “ENGINE START
STOP” switch (engine switch) while
driving.
If you have to make an emergency stop,
press and hold the “ENGINE START
STOP” switch for more than 3 seconds.
Master warning light and multiinforma-
tion display
SYSTEM FUNCTION REMINDERS
Follow the instructions described below if
any of the following warnings occur:
(A) A warning buzzer sounds once from
the instrument cluster when the igni-
tion switch is turned on
This indicates that the driver has gotten
into the vehicle without the key. The “KEY
IS NOT DETECTED” message will also
appear on the multi−information display
and the master warning light will come on.
Operate the ignition switch only after tak-
ing care that the key is in the vehicle.If the warning light is still lit when the key
is in the vehicle, the key battery is dis-
charged. Check that the indicator light on
the key comes on by pushing the lock
button on the key. When the indicator light
does not come on, change the key battery
so that smart key system works properly.
(B) A warning buzzer sounds once from
the instrument cluster, accompanied
by three warning sounds from the
vehicle when the driver gets out of
the vehicle and closes the door
This indicates that the driver is attempting
to leave the vehicle carrying the key with
ignition switch not set at OFF although the
transmission selector lever has been set
in the “P” position. The “KEY IS NOT
DETECTED” message will also appears on
the multi−information display and the mas-
ter warning light will come on.
Get out of the vehicle only after turning
off the engine by pressing the “ENGINE
START STOP” switch and checking that
the ignition switch indicator light has gone
off. If the driver returns to the vehicle
without carrying the key and begins driv-
ing, a warning buzzer will sound once
more.
Driving and parking using
smart key system

’07Camry_U (L/O 0608)
321
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
(C) A warning buzzer sounds from the
vehicle for two seconds after locking
the door with the door handle switch
This indicates that the driver is attempting
to lock the doors while carrying the key,
neglecting to follow the instructions for
case (B) above.
Lock the doors only after turning off the
engine by pressing the “ENGINE START
STOP” switch and checking that the igni-
tion switch indicator light has gone off.
A warning buzzer that sounds even though
the engine has been turned off indicates
that driver is attempting to lock the ve-
hicle with the keys still in the vehicle.
Leave the vehicle only after making sure
that you are carrying the key.(D) A warning buzzer sounds continu-
ously from the instrument cluster
when opening the driver ’s door
This indicates that the transmission selec-
tor lever is in a position other than “P”
and that the ignition switch is not set at
OFF. The “SHIFT TO P RANGE” message
will also appears on the multi−information
display.
Get out of the vehicle only after setting
the transmission selector lever in the “P”
position, turning off the engine by pressing
the “ENGINE START STOP” switch and
checking that the ignition switch indicator
light has gone off.(E) A warning buzzer sounds continu-
ously from the instrument cluster
and from the vehicle when closing
the door after getting out of the ve-
hicle
This indicates that the driver is attempting
to leave the vehicle carrying the key, ne-
glecting to follow the instructions for case
(D) above. The messages, “SHIFT TO P
RANGE” and “KEY IS NOT DETECTED”,
will also appear alternately on the multi−
information display and the master warn-
ing light will come on.
Get out of the vehicle only after setting
the transmission selector lever in the “P”
position, turning off the engine by pressing
the “ENGINE START STOP” switch and
checking that the ignition switch indicator
light has gone off.

’07Camry_U (L/O 0608)
322
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
(F) A warning buzzer sounds once from
the instrument cluster and three
times from the vehicle when a pas-
senger is getting out of the vehicle
This indicates that the passenger is at-
tempting to leave the vehicle carrying the
key, without the ignition switch set at OFF.
The “KEY IS NOT DETECTED” message
will also appear on the multi−information
display and the master warning light will
come on.
When passengers get out of the vehicle,
care should be taken to leave the key
with the driver. If the driver begins driving
after a passenger gets out of the vehicle
carrying the key, a warning buzzer will
sound once more.
(G) A warning buzzer sounds from the
vehicle for two seconds when lock-
ing the vehicle from the outside with
the door handle switch
This indicates that the driver is attempting
to lock the door with the key still in the
vehicle.
Leave the vehicle only after making sure
that you are carrying the key.(H) A warning buzzer sounds once from
the instrument cluster when turning
off the ignition switch
This indicates that the key battery is low.
(This warning buzzer sounds only when
the engine has been on or the ignition
switch has been set at ON for 20 minutes
or more.) The “LOW KEY BATTERY” mes-
sage will also appear on the multi−infor-
mation display.
Change the key battery ahead of time in
order to ensure that the smart key system
properly.
(I) A warning buzzer sounds repeatedly
from the instrument cluster when
opening the driver ’s door with the
ignition switch turned off
This indicates that the steering wheel is
not locked. Turn the engine off and then
open the door in order to lock the steering
wheel.(J) The “ENGINE START STOP” switch
flashes green once every second
This indicates that the steering lock is
stuck. The “S/T IS NOT UNLOCKED”
message will also appear on the multi−in-
formation display.
To free it, rotate the steering wheel slight-
ly while pressing the “ENGINE START
STOP” switch.
(K) The “ENGINE START STOP” switch
flashes amber once every 2 seconds
When “CHECK S/T LOCK” is displayed on
the multi−information display—
This indicates a problem with the steering
lock function. Have your vehicle checked
at your Toyota dealer.
When no message is displayed on the
multi−information display—
This indicates a problem with the push
button start function. Have your vehicle
checked at your Toyota dealer.

’07Camry_U (L/O 0608)
323
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
THEFT PREVENTION FUNCTION
When the engine is turned off, the en-
gine immobilizer system is automatical-
ly set. (See “Engine immobilizer sys-
tem” on page 18 in Section 1−2.)
When the driver ’s door is opened after
turning off the engine, the steering
wheel will lock.
When the vehicle’s battery is dis-
charged, the steering lock function may
not operate properly.
Always slow down in gusty crosswinds.
This will allow you much better control.
Drive slowly onto curbs and, if pos-
sible, at a right angle. Avoid driving
onto high, sharp−edged objects and
other road hazards. Failure to do so
can lead to severe tire damage such
as a tire burst.
Drive slowly when passing over bumps
or travelling on a bumpy road. Other-
wise, the impact could cause severe
damage to the tires and/or wheels.
When parking on a hill, turn the front
wheels until they touch the curb so
that the vehicle will not roll. Apply the
parking brake, and place the transmis-
sion in “P” (automatic) or in first or
reverse (manual). If necessary, block
the wheels.
Washing your vehicle or driving through
deep water may get the brakes wet. To
see whether they are wet, check that
there is no traffic near you, and then
press the pedal lightly. If you do not
feel a normal braking force, the brakes
are probably wet. To dry them, drive
the vehicle cautiously while lightly
pressing the brake pedal with the park-
ing brake applied. If they still do not
work safely, pull to the side of the road
and call a Toyota dealer for assistance.
CAUTION
Before driving off, make sure that
the parking brake is fully released
and the parking brake reminder
light is off.
Do not leave your vehicle unat-
tended while the engine is running.
Do not rest your foot on the brake
pedal while driving. It can cause
dangerous overheating, needless
wear, and poor fuel economy.
To drive down a long or steep hill,
reduce your speed and downshift.
Remember, if you ride the brakes
excessively, they may overheat and
not work properly.
Tips for driving in various
conditions

’07Camry_U (L/O 0608)
329
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
HITCHES
Use only a hitch which is recom-
mended by the hitch manufacturer and
conforms to the total trailer weight re-
quirement.
Follow the directions supplied by the
hitch manufacturer. Lubricate the hitch
ball with a light coat of grease.
Toyota recommends removing the trail-
er hitch whenever you are not towing
a trailer to reduce the possibility of
additional damage caused by the hitch
if your vehicle is struck from behind.
NOTICE
Do not use axlemounted hitches as
they can cause damage to the axle
housing, wheel bearings, wheels or
tires. Also, never install a hitch which
may interfere with the normal function
of an Energy Absorbing Bumper, if so
equipped.
BRAKES AND SAFETY CHAINS
Toyota recommends trailers with
brakes that conform to any applica-
ble federal and state/provincial regu-
lations.
A safety chain must always be used
between the towing vehicle and the
trailer. Leave sufficient slack in the
chain for turns. The chain should
cross under the trailer tongue to
prevent the tongue from dropping to
the ground in case it becomes dam-
aged or separated. For correct safety
chain procedures, follow the hitch or
trailer manufacturer ’s recommenda-
tions.
CAUTION
Never tap into your vehicle’s hy-
draulic system as it would lower its
braking effectiveness.
Never tow a trailer without using a
safety chain securely attached to
both the trailer and the vehicle. If
damage occurs to the coupling unit
or hitch ball, there is danger of the
trailer wandering over into another
lane.
TIRES
Ensure that your vehicle’s tires are
properly inflated. See page 385 in Sec-
tion 7−2 and page 411 in Section 8 for
instructions.
The trailer tires should be inflated to
the pressure recommended by the trail-
er manufacturer in respect to the total
trailer weight.
TRAILER LIGHTS
Trailer lights must comply with federal,
state/provincial and local regulations.
See your local recreational vehicle
dealer or rental agency for the correct
type of wiring and relays for your trail-
er. Check for correct operation of the
turn signals and stop lights each time
you hitch up. Direct splicing may dam-
age your vehicle’s electrical system
and cause a malfunction of your lights.
BREAKIN SCHEDULE
Toyota recommends that you do not
tow a trailer with a new vehicle or a
vehicle with any new power train com-
ponent (engine, transmission, differen-
tial, wheel bearing, etc.) for the first
800 km (500 miles) of driving.

’07Camry_U (L/O 0608)
330
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
MAINTENANCE
If you tow a trailer, your vehicle will
require more frequent maintenance due
to the additional load. For this informa-
tion, please refer to the scheduled
maintenance information in the “Sched-
uled Maintenance Guide” or “Owner ’s
Manual Supplement”.
Retighten all fixing bolts of the towing
ball and bracket after approximately
1000 km (600 miles) of trailer driving.
PRETOWING SAFETY CHECK
Check that your vehicle remains level
when a loaded or unloaded trailer is
hitched. Do not drive if the vehicle has
an abnormal nose−up or nose−down
condition, and check for improper
tongue load, overload, worn suspension
or other possible causes.
Make sure the trailer cargo is securely
loaded so that it can not shift.
Check that your rear view mirrors con-
form to any applicable federal, state/
provincial or local regulations. If not,
install the rear view mirrors required
for towing purpose.TRAILER TOWING TIPS
When towing a trailer, your vehicle will
handle differently than when not tow-
ing. The three main causes of vehicle
trailer accidents are driver error, exces-
sive speed and improper trailer loading.
Keep these in mind when towing:
Before starting out, check operation of
the lights and all vehicle−trailer connec-
tions. After driving a short distance,
stop and recheck the lights and con-
nections. Before actually towing a trail-
er, practice turning, stopping and back-
ing with a trailer in an area away from
traffic until you learn the feel.
Backing with a trailer is difficult and
requires practice. Grip the bottom of
the steering wheel and move your hand
to the left to move the trailer to the
left. Move your hand to the right to
move the trailer to the right. (This pro-
cedure is generally opposite to that
when backing without a trailer.) Also,
just turn the steering wheel a little at
a time, avoiding sharp or prolonged
turning. Have someone guide you when
backing to reduce the risk of an acci-
dent.
Because stopping distance may be in-
creased, vehicle−to−vehicle distance
should be increased when towing a
trailer. For each 16 km/h (10 mph) of
speed, allow at least one vehicle and
trailer length between you and the ve-
hicle ahead. Avoid sudden braking as
you may skid, resulting in jackknifing
and loss of control. This is especially
true on wet or slippery surfaces.
Avoid jerky starts or sudden accelera-
tion. If your vehicle has a manual
transmission, prevent excessive clutch
slippage by keeping engine rpm low
and not racing the engine. Always start
out in first gear.
Avoid jerky steering and sharp turns.
The trailer could hit your vehicle in a
tight turn. Slow down before making a
turn to avoid the necessity of sudden
braking.
Remember that when making a turn,
the trailer wheels will be closer than
the vehicle wheels to the inside of the
turn. Therefore, compensate for this by
making a larger than normal turning
radius with your vehicle.

’07Camry_U (L/O 0608)
336
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Before making these checks, make sure
you have followed the correct starting pro-
cedure given in “How to start the engine”
on page 316 in Section 3 and that you
have sufficient fuel. If your vehicle is
equipped with the engine immobilizer sys-
tem, also check whether the other keys
will start the engine. If they work, your
key may be broken. Have the key
checked at your Toyota dealer. If none of
your keys work, there may be a malfunc-
tion in the immobilizer system. Call your
Toyota dealer. (See “Keys” on page 14 or
16 in Section 1−2.)If the engine is not turning over or is
turning over too slowly—
1. Check that the battery terminals are
tight and clean.
2. If the battery terminals are O.K., switch
on the interior light.
3. With smart key system—If the light is
on, you may try emergency start. See
“(b) Emergency start” on page 337 for
further instructions.
4. If the light is out, dim or goes out
when the starter is cranked, the battery
is discharged. You may try jump start-
ing. See “(d) Jump starting” on page
338 for further instructions.
5. With smart key system—If the engine
does not start even after the battery
has been recharged or replaced, see
“(e) Starting the engine after a battery
discharge” on page 341 for further in-
struction.
If the light is O.K., but the engine still will
not start, it needs adjustment or repair.
Call a Toyota dealer or qualified repair
shop.NOTICE
Do not pull or pushstart the ve-
hicle. It may damage the vehicle or
cause a collision when the engine
starts. Also the threeway catalytic
converter may overheat and become a
fire hazard.
If the engine turns over at its normal
speed but will not start—
1. Set the ignition switch to ACC or off
and try starting the engine again.
2. If the engine will not start, the engine
may be flooded because of repeated
cranking. See “(c) Starting a flooded
engine” on page 337 for further instruc-
tions.
3. If the engine still will not start, it needs
adjustment or repair. Call a Toyota
dealer or qualified repair shop.
If your vehicle will not start—
(a) Simple checks
