TOYOTA HIGHLANDER HYBRID 2018 Owners Manual (in English)

461
6
Interior features
HIGHLANDER_HV_U (OM0E032U)
6-4. Using the other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover.
The vanity light turns on.
■ To prevent 12-volt battery discharge
If the vanity lights remain on for 20 minutes while the hybrid system is off, the
lights will turn off automatically.
Other interior features
Sun visors
1
2
3
Vanity mirrors

4626-4. Using the other interior features
HIGHLANDER_HV_U (OM0E032U)
Push the lid.
Push the lid back up half way.
■To use the overhead console from the conversation mirror state
Fully close the lid, then open it again. ( →P. 454)
The clock can be adjusted by pressing the buttons.
Adjusts the hours
Adjusts the minutes
Conversation mirror
1
2
Clock
1
2

4636-4. Using the other interior features
6
Interior features
HIGHLANDER_HV_U (OM0E032U)
■The clock is displayed when
The power switch is in ACCESSORY or ON mode.
■ When the 12-volt battery is disconnected
The time display will automatically be set to 1:00.
The temperature display shows
temperatures within the range of -
40
°F (-40°C) to 122°F (50°C).
■The outside temperatur e is displayed when
The power switch is in ON mode.
■ Display
In the following situations, the correct outside temperature may not be \
dis-
played, or the display may take longer than normal to change:
●When the vehicle is stopped, or moving at low speeds (less than 15 mph
[25 km/h]).
● When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
■ When the outside temperature display flashes
If the outside temperature is 37 °F (3°C) or less, the ice warning indicator
flashes 10 times, and then illuminates.
■ When “--” or “E” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
Outside temperature display

4646-4. Using the other interior features
HIGHLANDER_HV_U (OM0E032U)
The power outlet can be used for the following components:
12 V: Accessories that run on less than 10 A
120 VAC: Accessories that use less than 100 W
■12 V
Front
Open the lid.
Console box
Open the console box lid
(
→P. 450) and open the lid.
■120 VAC (if equipped)
Open the lid.
Power outlets

4656-4. Using the other interior features
6
Interior features
HIGHLANDER_HV_U (OM0E032U)
■The power outlets can be used when
12 V: The power switch is in ACCESSORY or ON mode.
120 VAC: The power switch is in ON mode.
NOTICE
■To avoid damaging the power outlets
Close the power outlet lids when the power outlets are not in use.
Foreign objects or liquids that enter the power outlets may cause a short cir-
cuit.
■ To prevent blown fuses
12 V
Do not use an accessory that uses more than 12 V 10 A.
120 VAC
Do not use a 120 VAC appliance that requires more than 100 W.
If a 120 VAC appliance that consumes more than 100 W is used, the protec-
tion circuit will cut the power supply.
■ To prevent 12-volt battery discharge
Do not use the power outlet longer than necessary when the hybrid system
is off.
■ Appliances that may not operate properly (120 VAC)
The following 120 VAC appliances may not operate properly even if their
power consumption is under 100 W:
● Appliances with high initial peak wattage
● Measuring devices that process precise data
● Other appliances that require an extremely stable power supply

4666-4. Using the other interior features
HIGHLANDER_HV_U (OM0E032U)
The USB charging ports are used to supply 2.1 A of electricity at 5 V
to external devices.
The USB charging ports are for charging only. They are not designed
for data transfer or other purposes.
Depending on the external device, it may not charge properly. Refer to
the manual included with the dev ice before using a USB charging
port.
■ Using the USB charging ports
Open the lid.
■The USB charging ports can be used when
The power switch is in ACCESSORY or ON mode.
■ Situations in which the USB chargi ng ports may not operate correctly
● If a device which consumes more than 2.1 A at 5 V is connected
● If a device designed to communicate with a personal computer, such as a
USB memory device, is connected
● If the connected external device is turned off (depending on device)
● If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun
■ About connected external devices
Depending on the connected external device, charging may occasionally be
suspended and then start again. This is not a malfunction.
USB charging ports
FrontRear

4676-4. Using the other interior features
6
Interior features
HIGHLANDER_HV_U (OM0E032U)
NOTICE
■To prevent damage to the USB charging ports
● Do not insert foreign objects into the ports.
● Do not spill water or other liquids into the ports.
● When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.
● Do not apply excessive force to or impact the USB charging ports.
● Do not disassemble or modify the USB charging ports.
■ To prevent damage to external devices
● Do not leave external devices in the vehicle. The temperature inside the
vehicle may become high, resulting in damage to an external device.
● Do not push down on or apply unnecessary force to an external device or
the cable of an external device while it is connected.
■ To prevent 12-volt battery discharge
Do not use the USB charging ports for a long period of time with the hybrid
system stopped.

4686-4. Using the other interior features
HIGHLANDER_HV_U (OM0E032U)
Pull the tab up.
Hook the sunshade on to the
anchors.
To lower the sunshade, pull the tab
up slightly to unhook the shade
from the anchors, and lower it
slowly.
Rear sunshades (if equipped)
1
2
NOTICE
To ensure normal operation of the rear sunshades, observe the following
precautions.
●Do not place anything where it may hinder the opening/closing of a sun-
shade.
● Do not place anything on the rear sunshades.

4696-4. Using the other interior features
6
Interior features
HIGHLANDER_HV_U (OM0E032U)
Ty p e A
Fold down the armrest for use.
Ty p e B
Lower the armrest from the
highest position to the lowest
position.
Raise the armrest to the
desired angle.
To unlock the armrest, lift the arm-
rest to raise it to the highest posi-
tion.
Armrest
1
2
NOTICE
To prevent damage to the armrest, do not apply too much load on the arm-
rest.

4706-4. Using the other interior features
HIGHLANDER_HV_U (OM0E032U)
Coat hooks are provided on the
rear assist grips.
An assist grip installed on the ceil-
ing can be used to support your
body while sitting on the seat.
Coat hooks
WARNING
Do not hang coat hangers or other hard or sharp objects on the hook. If the
SRS curtain shield airbags deploy, these items may become projectiles,
causing death or serious injury.
Assist grips
WARNING
Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.
NOTICE
To prevent damage to the assist grip, do not hang any heavy object or put a
heavy load on the assist grip.
