xv
7“Map” switch
You can select a destination simply by
touching the location on the displayed map.
34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8“Intersection” switch
You can enter the names of two intersecting
streets. This is helpful if you do not know the
specific street address of your destination
but know the general vicinity. 35 . . . . . . . . .
9“Freeway Ent./Exit” switch
You can enter the name of a freeway (inter-
state) entrance or exit. 36 . . . . . . . . . . . . . . .
10“Phone #” switch
You can enter a destination by the telephone
number. 37 . . . . . . . . . . . . . . . . . . . . . . . . . . .
11“Coordinates” switch
You can set a destination using latitude and
longitude as coordinates. 37 . . . . . . . . . . . .
12Quick access switch
You can select one of 5 preset destinations
directly. To use this function, it is necessary
to set the “Attribute” for each memory point.
(To register a “Quick Access”, see page 70.)
22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Home switch
You can select your own home without en-
tering the address each time. To use this
function, it is necessary to set the “Attribute”
for the memory point. (To register “Home”,
see page 70.) 22 . . . . . . . . . . . . . . . . . . . . . .
14“Change” switch
To change the search area, touch this
switch. 20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5
Screen scroll operation
(onetouch scroll)
Touch any point on the map and that point
moves to the center of the screen and is
shown by the cursor mark.
If you wish to look at a point on the map which
is different to your current vehicle position,
you can bring the desired point to the center
of the screen by using the scroll feature.
If you continue to hold your finger on the
screen, the map will continue scrolling in that
direction until you lift your finger. After you scroll the screen, the map remains
centered at the selected location
until you ac-
tivate another function. The current vehicle
position mark will continue to move along
your actual route and may move off the
screen. When you touch the
“MAP/
VOICE” button, the current vehicle position
mark returns to the center of the screen and
the map moves as you proceed along the
designated route.
INFORMATION
When you use the onetouch scroll fea-
ture, the current vehicle position mark
may disappear from the screen. Move
the map with a onetouch scroll again or
push the
“MAP/VOICE” button to re-
turn to the current vehicle position map
location display.
To set the cursor position as a destina-
tion
You can set a specific point on the map as a
destination using the one −touch scroll func-
tion.
Touch the “Enter ” switch.
The screen changes and displays the map
location of the selected destination and
the route preference. (See “ — Entering
destination” on page 38.)
If there is already a preset destination, touch
the
“Add to ” switch or the “Replace
” switch.
When there is already a preset destination,
using the
“Add to ” switch to set an addi-
tional destination, will set the new one as the
first point of arrival.

7
Touch the
“Info.” switch.
Information such as the name, address, and
phone number are displayed.
If you touch the
“Enter ” switch, the posi-
tion of cursor is set as a destination.
If there is already a preset destination, the
“Add to ” switch and the “Replace
” switch are displayed.
When there is already a preset destination,
using the
“Add to ” switch to set an addi-
tional destination, will set the new one as the
first point of arrival.
To register this POI as a memory point, touch
the
“Mark” switch. (For details, see page
66.)
INFORMATION
The desired Point of Interest can be dis-
played on the map screen. (For details,
see page 49.)
MEMORY POINT INFORMATION
When the cursor is set on a memory point
icon, the name and
“Info.” switch are dis-
played on the top of screen.
Touch the “Info.” switch.
Information such as the name, location, and
phone number are displayed.
If you touch the
“Enter ” switch, the posi-
tion of cursor is set as a destination.

8
If there is already a set destination, the
“Add
to
” switch and the “Replace ”switch are displayed.
When there is already a preset destination,
using the
“Add to ” switch to set an addi-
tional destination, will set the new one as the
first point of arrival.
To edit a memory point, touch the
“Edit”switch. (For details, see page 68.)
Map scale
Touch the or switch to change
the scale of the map display. The scale bar
and indicator at the bottom of the screen indi-
cates the map scale menu. The scale ranges
150 feet (50 m) to 250 miles (400 km).
Touch the
or switch until the
scale bar changes normally. If you continue
to touch on the switch, the scale bar changes
smoothly.
You can change the scale of the map display
by touching the scale bar directly. It is not
available during driving.
The map scale is displayed under the north −
up symbol or heading −up symbol at the top
left of the screen.
INFORMATION
When the map scale is at the maximum
range of 250 miles (400 km), is not
shown. When the map scale is at the
minimum range of 150 feet (50 m),
is not shown. However, in the area
where the foot print map is contained,
when the map scale is changed to 150
feet (50 m), the switch changes to
the switch.

97
“Reset
All”: To reset the item which has sat-
isfied a condition.
Touch the
“Off” switch at the top of the
“Maintenance” screen to turn off the informa-
tion screen.
When your vehicle needs to be serviced, the
icon color will change to orange.
INFORMATION
 For scheduled maintenance informa-
tion, please refer to the “Scheduled
Maintenance Guide” or “Owner’s
Manual Supplement”.
 Depending on driving or road condi-
tions, the actual date and distance
may differ from the stored date and
distance in the system.
Information items
Oil change
Replace oil filter
Rotate tires
Replace tires
Replace battery
Replace brake linings
Replace wiper blades
Replace engine coolant
Replace brake fluid
Replace ATF
Scheduled maintenance
Replace air filter
Personal event

109
Average Speed
The Average Speed is displayed. The av-
erage
vehicle speed is calculated and dis-
played based on the total driving distance
and the total driving time after the engine
is started.
The displayed value is updated every 10 sec-
onds.
To calculate from the beginning, touch the
“Reset” switch.
Distance
The distance after engine starting is dis-
played.
When refueling, be sure to stop your vehicle
and turn the ignition switch off.
Handsfree system
Handsfree system allows you to make or
receive a call without taking your hands
off the steering wheel by connecting your
cellular phone.
This system supports the Bluetooth. Blue-
tooth is a wireless data system by which you
can call without your cellular phone connect-
ing with a cable or placing on a cradle.
If your cellular phone does not support the
Bluetooth, this system can not function.
CAUTION
While you are driving, do not use a cellu-
lar phone or connect the Bluetooth
phone.
NOTICE
Do not leave your cellular phone in the
car. The temperature indoor may be
high and damage the phone.
INFORMATION
In the following conditions, the system
may not function.
 The cellular phone is turned OFF.
 The current position is outside the
communication area.
 The cellular phone is not connected.
 The cellular phone has a low battery.

For the JBL brand audio system, “JBL” logo is provided on the panel.
7ulc001a
142
Audio system
Quick reference for your audio system
Page
1Audio operation screen display
button 143 . . . . . . . . . . . . . . . . . . . . . . . .
2Function switch display
screen 144 . . . . . . . . . . . . . . . . . . . . . . .
3Cassette tape slot 157
. . . . . . . . . . . . .
4Frequency turning knob 147 . . . . . . .
5[Radio mode] Preset tuning 148 . . . .
[Tape mode] Side change of
cassette tape 157 . . . . . . . . . . . . . . . . .
[DISC mode] Disc selection 161 . . . .
6SCAN button 148, 162
. . . . . . . . . . . . . .
7Mode selectors 144
. . . . . . . . . . . . . . . .
8Stopping and ejecting a
cassette tape 157 . . . . . . . . . . . . . . . . .
9[Radio mode] Seek tuning 148 . . . . . .
[Tape/DISC mode] Direct access to
a desired program 158, 162 . . . . . . . . .
10Turning the system on and
adjusting volume 143. . . . . . . . . . . . . .

148
(b) Presetting a station
lxb001a
1. Tune in the desired station.
2. Touch one of the station selector
switches (16) and hold it until a beep is
heard. This sets the station to the switch
and the frequency appears on the switch.
Each switch can store FM1, FM2 and AM. To
change the preset station to a different one,
follow the same procedure.
The preset station memory is cancelled when
the power source is interrupted by battery dis-
connection or a blown fuse.
(c) Selecting a station
Your Toyota has an electronic tuning radio
(ETR). Tune in the desired station using one
of the following methods.
Preset tuning: Touch the switch (1−6) or
push the “
” or “” sid e of th e “CH” button for
the station you want. The switch (1 −6) is high-
lighted in green and station frequency ap-
pears on the display.
Manual tuning: Turn the “TUNE” knob briefly.
Each time you turn the knob, the radio will
step up or down to another frequency.
Seek tuning: Push the “
” or “” sid e of the
“SEEK” button and hold it until you hear a
beep. The radio will begin seeking up or down
for a station of the nearest frequency and will
stop on reception. Each time you push the
button, the stations will be searched out one
after another.
lxb001a
Scan tuning: Touch the “SCAN” switch brief-
ly. “SCAN” appears on the display . The radio
will find the next station up or down the band,
stay there for a few seconds, and then scan
again. To select a station, touch the “SCAN”
switch a second time.
Preset scan tuning: Touch the “SCAN”
switch and hold it until you hear a beep. “P.
SCAN” appears on the display . The radio will
tune in the next preset station up or down the
band, stay there for a few seconds, and then
move to the next preset station. To select a
station, touch the “SCAN” switch a second
time.

152
(c) Listening to the satellite radio
lc025
Push the “AM·SAT” button to choose a
SAT channel.
Besides “AM”, “SAT1”, “SAT2” or “SAT3” ap-
pears on the display.
Turn this knob to select the next or pre-
vious channel.
If you turn continuously, you can rapidly scroll
forward or down through the channels.
(d) Presetting a channel
1. Tune in the desired channel.
2. Touch one of the channel selector
switches (16) and hold it until a beep is
heard. This sets the channel to the switch
and the frequency appears on the switch.
Each switch can store three SAT channels.
To change the preset channel to a different
one, follow the same procedure.
The preset channel memory is cancelled
when the power source is interrupted by bat-
tery disconnection or a blown fuse.

153
(e) Selecting a channel
Tune in the desired channel using one of the
following methods.
Preset tuning: Touch the switch (1−6) or
push the “
” or “” button of the “CH” button
for the channel you want. The switch (1 −6) is
highlighted in green.
Manual tuning within the channel catego-
ry: Turn the “TUNE” knob. The radio will step
up or down the channel.
Manual tuning within the current channel
category: Push the “SEEK” button. The radio
will step up or down the channel within the
current channel category. Touch the “TYPE
SEEK” switch. The radio will step up the
channel within the current channel category.lc022
To scan the currently selected channel
category: Touch the “TYPE SCAN” switch or
push the “SCAN” button briefly. “SCAN” ap-
pears on the display. The radio will find the
next channel in the same channel category,
stay there for a few seconds, and then scan
again. To select a channel, push the “SCAN”
button a second time.
To scan the preset channels: Touch the
“TYPE SCAN” switch or push the “SCAN” but-
ton and hold it until you hear a beep.
“P.SCAN” appears on the display. The radio
will find the next preset channel, stay there for
a few seconds, and then move to the next pre-
set channel. To select a channel, push the
“SCAN” button a second time.
(f) Channel category
lc023
Touch either “” or “” switch to switch to the
next or previous category.
VI
