NAVIGATION SYSTEM: DESTINATION SEARCH
74

SECTION 3
NAVIGATION SYSTEM: ROUTE GUIDANCE
75
NAVIGATION SYSTEM:
ROUTE GUIDANCE
Navigation system: Route guidance
Route guidance screen 76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Typical voice guidance prompts 79
. . . . . . . . . . . . . . . . . . . . . . . . . .
 Distance and time to destination 81
. . . . . . . . . . . . . . . . . . . . . . . . .
 Setting and deleting destinations 82
. . . . . . . . . . . . . . . . . . . . . .
Adding destinations 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reordering destinations 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting destinations 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Setting route 84
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Detour setting 84
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Route overview 85
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Route preference 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pausing and resuming guidance 89
. . . . . . . . . . . . . . . . . . . . . . .
 Show on map 90
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
Display POI
∗ icons 90
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Route trace 94
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
 XM  NavTraffic 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
∗: Point of Interest

NAVIGATION SYSTEM: ROUTE GUIDANCE
76
During route guidance, various types of
guidance screens can be displayed de-
pending on conditions.
Screen layout
1Distance to the next turn and the
arrow indicating turning direction
2Current street name
3Distance and travel/arrival time to
the destination
4Current position
5Guidance route
INFORMATION
If the vehicle goes off the guidance
route, the route is searched again.
 For some areas, the roads have not
been completely digitized in our
database. For this reason, the
route guidance may select road
that should not be traveled on.
 When you arrive at your destina-
tion, the destination name will be
displayed on the top of the screen.
Touching “ Off” clears the dis-
play.
During freeway driving
During freeway driving, the freeway exit in-
formation screen will be displayed.
This screen displays the distance to the
next junction and exit, or POIs in the vicin-
ity of the freeway exit.
1Current position
2Points of Interest that are close to
a freeway exit
3Exit number and junction name
4Distance from the current position
to the exit or junction
5Current street name
“Map”: To display the selected map of the
exit vicinity.
:To scroll for farther junctions or exits.
:To scroll for closer junctions or exits.
:To scroll for the closest 3 junctions or
exits.
Route guidance screen

NAVIGATION SYSTEM: ROUTE GUIDANCE
77

When
approaching a freeway exit or
junction
When the vehicle approaches an exit or
junction, the guidance screen for the free-
way will be displayed.
1Next street name
2Distance from the current position
to the exit or junction
3Current position
“Off”: The guidance screen on freeway
disappears and the map screen appears.
When touching
or push-
ing the “MAP/VOICE” button, the guid-
ance screen on freeway reappears.
When approaching an intersection
When the vehicle approaches an intersec-
tion, the intersection guidance screen will
be displayed.
1Next street name
2Distance to the intersection
3Current position
“Off”: The intersection guidance screen
disappears and the map screen appears.
When touching
or push-
ing the “MAP/VOICE” button, the inter-
section guidance screen reappears.

NAVIGATION SYSTEM: ROUTE GUIDANCE
78

Other screens
TURN LIST SCREEN
On this screen, the list of turns on the guid-
ance route can be viewed.
Touching
during guid-
ance displays the turn list.
1Next street name or destination
name
2Turn direction
3Distance between turns
4Current street name ARROW SCREEN
On this screen, information about next
turns on the
guidance route can be viewed.
Touching
during guid-
ance displays the arrow screen.
1Exit number, street name contain-
ing number or next street name
2Turn direction
3Distance to the next turn
4Current street name

NAVIGATION SYSTEM: ROUTE GUIDANCE
79
The voice guidance provides various mes-
sages as you approach an intersection, or
other point where you need to maneuver
the vehicle.
4.7 miles
0.5
miles
1“Proceed about 5 miles to Main
street.”
2“In half of a mile, right turn onto
Main street.”
3“Right turn.”
4(Beep sound only)
INFORMATION
 The street names may not be pro-
nounced correctly or clearly due to
texttospeech function.
 On freeways, interstates or other
highways with higher speed limits,
the voice guidance will be made at
earlier points than on city streets in
order to allow time to maneuver.
4.2 miles
0.5 miles
1“Proceed about 4 miles to the
traffic circle.”
2“In half of a mile, traffic circle
ahead, and then 3rd exit ahead
onto Main street.”
3“The 3rd exit ahead.”
4“The exit ahead.”
5(Beep sound only)
Typical voice guidance
prompts

NAVIGATION SYSTEM: ROUTE GUIDANCE
80
One−way road
One −way road
∗: The system indicates a U −turn if the dis-
tance between two one −way roads (of op-
posite directions) is less than 50 feet (15
m) in residential areas or 164 feet (50 m)
in non −residential areas.
1“In half of a mile, make a legal
U−turn.”
2“Make a legal U −turn ahead.”
3(Beep sound only)
The system announces the approach to
the final destination.
1“Your destination is ahead.”
2“You have arrived at your des-
tination. The route guidance is
now finished.”
INFORMATION
 If the system cannot determine the
current vehicle position correctly
(in cases of poor GPS signal recep-
tion), the voice guidance may be
made early or delayed.
 If you did not hear the voice guid-
ance command, push the “MAP/
VOICE” button to hear it again.
 To adjust the voice guidance vol-
ume, see “
 Voice volume” on
page 277.

NAVIGATION SYSTEM: ROUTE GUIDANCE
81
When the vehicle is on the guidance route,
the distance and the estimated travel/arriv-
al time to the destination are displayed.
When the vehicle is not on the guidance
route, the distance and the direction of the
destination are displayed.
When driving on the guidance route and
more than one destination is set, the dis-
tance and the estimated travel/arrival time
from the current position to each destina-
tion are displayed.
1. Touch this button to display the fol-
lowing screen.
2. Touch the number button to display
the desired destination. The distance, the estimated travel time
and the estimated arrival time from the cur-
rent position to the selected destination
are displayed.
Estimated travel time is dis-
played.
Estimated arrival time is dis-
played.
To switch to estimated arrival
time.
To switch to estimated travel
time.
Displayed while driving off the
guidance route. The destina-
tion direction is indicated by
an arrow.
INFORMATION
When the vehicle is on the guidance
route, the distance measured along
the route is displayed. Travel time
and arrival time is calculated based
on the set vehicle speed information.
(See page 280.) However, when the
vehicle is not on the guidance route,
the distance is the linear distance be-
tween the current position and the
destination.
Distance and time to
destination

NAVIGATION SYSTEM: ROUTE GUIDANCE
82
You can add destinations and search
again for the routes.
1. Touch “Route”.
2. Touch “Add”.
3. Input an additional destination in
the same way as the destination
search. (See “Destination search” on
page 50.)
4. Touch the desired “Add Destination
Here” to determine the arrival order of
the additional destination. When more than one destination is set,
you can change the arrival order of the
destinations.
1. Touch “Route”.
2. Touch “Reorder”.
3. Select the desired destination and
press “Move Up” or “Move Down” to
change the arrival order.
4. Touch “OK”.
5. After selecting the destinations,
touch “OK”.
The system searches for the guidance
route again, and displays the entire route.
Setting and deleting
destinations —
— Adding destinations
— Reordering destinations

NAVIGATION SYSTEM: ROUTE GUIDANCE
83
A set destination can be deleted.
1. Touch “Route”.
2. Touch “Delete”.
When more than one destination is set, a
list will be displayed on the screen.
3. Touch the destination for deletion.
“Select All”: To select all destinations on
the list.
“Unselect All”: To unselect all of the se-
lected destinations.
A message appears to confirm the request
to delete. 4. To delete the destination(s), touch
“Yes”.
If
“Yes” is touched, the data cannot be re-
covered.
If “No” is touched, the previous screen will
return.
The system searches for the guidance
route again, and displays the entire route.
— Deleting destinations
