3758-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
8
When trouble arises
WARNING
■Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly
when cold and inflated to the inflation pressure recommended by the
vehicle manufacturer on the vehicle placard or tire inflation pressure
label (tire and load information label). (If your vehicle has tires of a dif-
ferent size than the size indicated on the vehicle placard or tire inflation
pressure label [tire and load information label], you should determine
the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire
pressure monitoring system (TPMS-ti re pressure warning system) that
illuminates a low tire pre ssure telltale (tire pressure warning light) when
one or more of your tires is significantly under-inflated. Accordingly,
when the low tire pressure telltale (tire pressure warning light) illumi-
nates, you should stop and check your tires as soon as possible, and
inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure.
Under-inflation also reduces fuel effi ciency and tire tread life, and may
affect the vehicle’s hand ling and stopping ability.
Please note that the TPMS (tire pres sure warning system) is not a sub-
stitute for proper ti re maintenance, and it is the driver’s responsibility to
maintain correct tire pressure, even if under-inflation has not reached
the level to trigger illumina tion of the TPMS low tire pressure telltale (tire
pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warn-
ing system) malfunction indicator to indicate when the system is not
operating properly. The TPMS (tire pressure warning system) malfunc-
tion indicator is combined with the lo w tire pressure telltale (tire pressure
warning light). When the system dete cts a malfunction, the telltale will
flash for approximately one minute and then remain continuously illumi-
nated. This sequence will continue up on subsequent vehicle start-ups
as long as the malfunction exists. When the malfunction indicator is illu-
minated, the system may not be able to detect or signal low tire pres-
sure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a vari-
ety of reasons, including the installati on of replacement or alternate tires
or wheels on the vehicle that prevent the TPMS (tire pressure warning
system) from functioning properly. Always check the TPMS (tire pres-
sure warning system) malfunction te lltale after replacing one or more
tires or wheels on your vehicle to ensure that the replacement or alter-
nate tires and wheels allow the TPMS (tire pressure warning system) to
continue to function properly.

3788-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U■
If “Press Brake When Vehicle is St opped FC System may Overheat” is
displayed
Message is displayed when the accelerator pedal is depressed to maintain
the vehicle position when stopped on an upward slope, etc.
If this continues, the fuel cell system may overheat.
Release the accelerator pedal and depress the brake pedal.
■ If “Accelerator Pedal is Pressed Ch eck The Accelerator Pedal” is dis-
played
The accelerator pedal may be stuck.
If the message does not disappear even when the foot has been removed
from the accelerator pedal, check that the accelerator pedal is not stuck.
■ If “Ion Filter Maintenance Require d Visit Your Dealer” is displayed
Ion filter replacement is necessary. Contact your Toyota dealer.
■ If “Shift System Malfunction Stop Your Vehicle in a Safe Place then See
Owner's Manual” is displayed
The shift position may not be able to be shifted. Stop the vehicle in a safe
place.
Contact your Toyota dealer immediately.
■ If “Shift System Malfunction Shifting Unavailable See Owner’s Manual”
is displayed
The shift position may not be able to be shifted from P to a position other than
P.
Contact your Toyota dealer immediately.
■ If “Shift System Malfunction When Parking, Apply Parking Brake
Securely then See Owner’s Manual” is displayed
●The parking lock mechanism may not operate.
● The automatically P position selection function ( P. 177) may not operate.
● The power switch may not turn off. In that case, engage the parking brake
and the switch can be turned to off.
● The fuel cell system may not be able to be started.
When parking, choose a flat surface and be sure to engage the parking
brake.
Have the vehicle inspected by your Toyota dealer immediately.

3808-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U■
If “Shifting to [D] or [R] Position Unavailable Try to Shift after FC System
has Started” is displayed
When the power switch is in ON mode (“READY” indicator switched off), a
warning message is displayed when trying to shift the shift position to R or D,
or shift to Br mode.
After starting the fuel cell system, shift the shift position to R or D, or shift to Br
mode.
■ If “Shifting Unavailable Press Brake Pedal before Shifting” is displayed
A warning message is displayed when attempting to shift the shift position
without depressing the brake pedal.
Depress the brake pedal and shift the shift position when changing it from P.
■ If “Shifted to [N] Position Stop Your Vehicle before Shifting to [D]” is dis-
played
While the vehicle is moving backward, a warning message is displayed when
attempting to shift the shift position to D.
The shift position is changed to N.
Shift the shift position after stopping the vehicle.
■ If “Shifted to [N] Position Stop Your Vehicle before Shifting to [R]” is dis-
played
When the vehicle is moving forward, a warning message is displayed when
attempting to shift the shift position to R.
The shift position is changed to N.
Shift the shift position after stopping the vehicle.
■ If “Shifted to [N] Position To Shift to [P], Stop Your Vehicle and Press [P]
Switch” is displayed
When the vehicle is moving, a warning message is displayed when the P
position switch is operated and attempting to shift the shift position to P.
The shift position is changed to N.
Operate the P position switch after the vehicle has been brought to a com-
plete stop.
■ If “Smart Entry & Start System Malf unction See Owner’s Manual” is dis-
played
P. 133
■ Warning buzzer
P. 374

4008-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
■Stopping the fuel cell system
Shift the shift position to P and press the power switch as you normally do
when stopping the fuel cell system.
■ Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
( P. 353)
■ Alarm
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set,
the alarm may be triggered. ( P. 75)
■ When the electronic key does not work properly
●Make sure that the smart key system has not been deactivated in the cus-
tomization setting. If it is off, turn the function on.
(Customizable features P. 436)
● Check if battery-saving mode is set. If it is set, cancel the function.
(P. 133)
■ Changing power switch modes
Release the brake pedal and press the power switch in step above.
The fuel cell system does not start and modes will be changed each time the
switch is pressed. ( P. 174)
WARNING
■When using the mechanical key an d operating the power windows
Operate the power window after checking to make sure that there is no pos-
sibility of any passenger having any of their body parts caught in the win-
dow.
Also, do not allow children to operate the mechanical key. It is possible for
children and other passengers to get caught in the power window.
3

4108-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
Start the fuel cell system and turn the air conditioning system on
to check that the radiator coo ling fans operate and to check for
coolant leaks from th e radiator or hoses.
The fans operate when the air conditioning system is turned on immedi-
ately after a cold start. Confirm that the fans are operating by checking
the fan sound and air flow. If it is difficult to check these, turn the air con-
ditioning system on and off repeatedly.
(The fans may not operate in freezing temperatures.)
If the fans are not operating:
Stop the fuel cell system immediately and contact your Toyota
dealer.
If the fans are operating:
Have the vehicle inspected at the nearest Toyota dealer.
WARNING
■When inspecting under the hood of your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
●If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The motor compartment may be very hot.
● After the fuel cell system has been turned off, check that the “READY”
indicator is off.
When the fuel cell system is operating, the cooling fans may suddenly
operate even if the fuel cell system stops. Do not touch or approach rotat-
ing parts such as the fans, which may lead to fingers or clothing (espe-
cially a tie, a scarf or a muffler) getting caught, resulting in serious injury.
● Do not loosen the coolant reservoir caps or radiator cap, while the fuel cell
system and radiator are hot.
High temperature steam or coolant could spray out.
6
7

4128-2. Steps to take in an emergency
MIRAI_OM_USA_OM62004U
If the vehicle becomes stuck
Set the parking brake and stop the fuel cell system.
Remove the mud, snow or sand from around the front wheels.
Place wood, stones or some other material under the front wheels
to help provide traction.
Restart the fuel cell system.
Shift the shift position to D or R and release the parking brake.
Then, while exercising caution, depress the accelerator pedal.
■ When it is difficult to free the vehicle
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
1
2
3
4
5
Press to turn off TRAC.
WARNING
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the
surrounding area is clear to avoid striking other vehicles, objects or people.
The vehicle may also lunge forward or lunge back suddenly as it becomes
free. Use extreme caution.
■ When shifting the shift position
Be careful not to shift the shift position with the accelerator pedal
depressed.
This may lead to unexpected rapid acceleration of the vehicle that may
cause an accident resulting in death or serious injury.

448What to do if... (Troubleshooting)
MIRAI_OM_USA_OM62004U
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 371)
●The brake system warning light is on
Is the parking brake released? (P. 186)
Depending on the situation, other types of warning buzzer may also sound.
(  P. 369, 376)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 74)
To stop the alarm, turn the power switch to ON mode or start the fuel cell sys-
tem.

●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. ( P. 376)
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 369, 376.
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. (P. 381)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 412)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
An alarm is activated and the horn sounds
A warning light turns on or a warning message or indicator
is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

452Alphabetical index
MIRAI_OM_USA_OM62004U
DrivingBreak-in tips .......................... 160
Correct driving posture ........... 28
Driving advice ......................... 94
Fuel cell vehicle driving
tips ........................................ 94
Procedures ........................... 158
Winter drive tips .................... 253
Driving position memory ........ 140 Memory recall function.......... 142
Dynamic radar cruise
control .................................... 203
ECB (Electronically Controlled Brake System) ...................... 232
Eco drive mode ........................ 181
EDR (Event data recorder) .......... 9
Electric motor (traction motor) Location ............................ 78, 83
Specification ......................... 418
Electric Power Steering (EPS)....................................... 233
Function ................................ 233
Warning light ......................... 370
Electronic key Battery-saving function ......... 133
If the electronic key does not
operate properly ................. 398
Replacing the battery ............ 353
Electronically Controlled Brake System (ECB) ............. 232
Emergency flashers ................ 360 Emergency, in case of
If a warning buzzer sounds... 369
If a warning light turns on ..... 369
If a warning message is displayed ............................ 376
If the 12-volt battery is discharged.......................... 401
If the electronic key does not
operate properly ................. 398
If the fuel cell system will not start ........................ 396
If you have a flat tire ............. 381
If you lose your keys ..... 117, 119
If you think something is wrong ................................. 368
If your vehicle becomes stuck ................................... 412
If your vehicle has to be stopped in an emergency ... 361
If your vehicle needs to be
towed.................................. 362
If your vehicle overheats....... 406
Emergency shut off system ..... 84
Emergency tire puncture
repair kit ................................. 381
Energy monitor ........................ 108
Enhanced VSC ......................... 232
EPS (Electric Power Steering) ..... 233Function ................................ 233
Warning light......................... 370
Event data recorder (EDR).......... 9
E

453Alphabetical index
MIRAI_OM_USA_OM62004U
Flat tire...................................... 381
Floor mats .................................. 26
FluidBrake .................................... 420
Transmission ........................ 420
Washer ................................. 327
Front interior lights ................. 270 Wattage ................................ 421
Front passenger occupant classification system .............. 49
Front seats ............................... 138
Adjustment ............................ 138
Cleaning................................ 310
Correct driving posture ........... 28
Driving position memory ....... 140
Head restraints ..................... 145
Power easy access system ......... ....................... 140
Seat heaters ......................... 268
Seat position memory ........... 140
Front side marker lights.......... 187 Light switch ........................... 187
Replacing light bulbs............. 358
Front turn signal lights ........... 185 Replacing light bulbs............. 358
Turn signal lever ................... 185
Fuel
Capacity ................................ 418
Fuel gauge ............................ 102
Hydrogen station information.......................... 464
Refueling............................... 198
Type .............................. 198, 418
Warning light ......................... 371
Fuel cell stack ............................ 86
Fuel cell stack coolant Capacity ................................ 419
Checking ............................... 324 Fuel cell system
Characteristics ........................ 78
Cold temperatures ................ 175
Coolant type ......................... 419
Indicators .............................. 100
Multi-information display ....... 107
Precautions............................. 82
Starting the system ............... 172
Stopping the system ............. 173
Warning lights ......................... 99
Fuel cell system indicator ...... 110
Fuel cell vehicles
Characteristics ........................ 78
Charging the traction battery .................................. 81
Driving advice ......................... 94
Emergency shut off system .... 84
Emergency start function ...... 397
Emergency stops .................. 361
Fuel....................................... 418
Handling hydrogen gas........... 90
High-voltage components ....... 83
Hydrogen gas ......................... 89
Hydrogen-related components.......................... 82
If the 12-volt battery is discharged.......................... 401
If the fuel cell system will not start ........................ 396
Maintenance, repair,
recycling, and disposal ......... 81
F

454Alphabetical index
MIRAI_OM_USA_OM62004U
Opening the fuel door ........... 198
Overheating .......................... 406
Power output restriction .......... 88
Power switch......................... 172
Precautions ............................. 82
Regenerative braking.............. 81
Road accident cautions .......... 92
Running out of fuel.................. 85
Service plugs .......................... 91
Sounds and vibrations ............ 80
Starting the system ............... 172
Traction battery air intake vent....................................... 85
Vehicle proximity notification
system ......... ......................... 84
Warning message ................. 376
Water release ....................... 173
Fuel consumption............ 111, 112
Fuel door .................................. 198 Refueling............................... 198
Fuses ........................................ 355
Garage door opener ................ 292
Gauges ..................................... 102
Glove box ................................. 273
Grocery bag hooks .................. 277 H
2O switch ............................... 173
Hands-free system
(for cellular phone)
*
Head restraints ........................ 145
Headlights ................................ 187 Automatic High Beam system .......... ...................... 190
Light switch ........................... 187
Replacing light bulbs ............ 358
Heated steering wheel ............ 267
Heaters Automatic air conditioning system .......... ...................... 258
Heated steering wheel .......... 267
Outside rear view mirrors ..... 261
Seat heaters ......................... 268
High mounted stoplight
Replacing light bulbs ............ 358
High-voltage components ........ 83
Hill-start assist control ........... 232
Hood ......................................... 320 Warning message................. 376
Hooks
Coat hooks ........................... 281
Grocery bag hooks ............... 277
Retaining hooks (floor mat) .... 26
Horn .......................................... 147
Hydrogen detectors .................. 87
Hydrogen-related components............................. 82
Hydrogen tanks ......................... 86 Capacity................................ 418
Location ............................ 78, 82
G
H
