CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
After it finishes heating up, it automati-
cally pops out ready for use.
If the engine is not running, the key must
be in the “ACC” position.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.
ASHTRAYS
Front: To use the ashtray, pull it out.
Rear: To use the ashtray, raise the lid.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
Front—To remove the ashtray, press down
on the lock spring plate and pull out.
Rear—To remove the ashtray, pull it out.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always completely close
the ashtray after use.
Instrument panel
Rear console box
Luggage compartment
The power outlets are designed for
power supply for car accessories.
The key must be in the “ACC” or “ON”
position for the power outlet to be used.
NOTICE
To prevent the fuse from being
blown, do not use the electricity
over the total vehicle capacity of
12V/120W.
 To prevent the battery from being
discharged, do not use the power
outlets longer than necessary when
the engine is not running.
Power outlets (12 VDC)

04_SEQUOIA_U (L/O 0309)
389
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
If the headlights or other electrical
components do not work, check the
fuses. If any of the fuses are blown,
they must be replaced.
See “Fuse locations” on page 365 in Sec-
tion 7−1 for locations of the fuses.
Turn the ignition switch and inoperative
component off. Pull a suspected fuse
straight out and check it.
Determine which fuse may be causing the
problem. The lid of the fuse box shows
the name of the circuit for each fuse. See
page 402 in Section 8 of this manual for
the functions controlled by each circuit.
Type A fuses can be pulled out by using
the pull −out tool. The location of the pull −
out tool is shown in the illustration.
If you are not sure whether the fuse has
blown, try replacing the suspected fuse
with one that you know is good.
If the fuse has blown, push a new fuse
into the clip.
Only install a fuse with the amperage rat-
ing designated on the fuse box lid.
If you do not have a spare fuse, in an
emergency you can pull out the “DOME”
or “RAD” fuse, which may be dispensable
for normal driving, and use it if its amper-
age rating is the same. If you cannot use one of the same amper-
age, use one that is lower, but as close
as possible to the rating. If the amperage
is lower than that specified, the fuse
might blow out again but this does not
indicate anything wrong. Be sure to get
the correct fuse as soon as possible and
return the substitute to its original clip.
It is a good idea to purchase a set of
spare fuses and keep them in your ve-
hicle for emergencies.
If a new fuse immediately blows out, there
is a problem with the electrical system.
Have your Toyota dealer correct it as
soon as possible.
CAUTION
Never use a fuse with a higher am-
perage rating, or any other object, in
place of a fuse. This may cause ex-
tensive damage and possibly a fire.
If any washer does not work or low
windshield washer fluid level warning
light comes on, the washer tank may be
empty. Add washer fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer ’s directions for how much to
mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.
Adding washer fluid

04_SEQUOIA_U (L/O 0309)
405
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
41. OBD 7.5 A: On−board diagnosis sys-
tem
42. PANEL 7.5 A: Instrument panel lights,
glove box light, lights of seat heaters,
cigarette lighter, ashtrays, multi −infor-
mation display, car audio/video system,
gauge and meters, air conditioning sys-
tems
43. PWR NO.1 25 A: Driver ’s door lock
system
44. WIP 25 A: Wiper and washers
45. IGN 1 10 A: Charging system
46. SUN ROOF 25 A: Electric moon roof
47. PWR NO.2 25 A: Front passengers’
door lock system
48. HTR 10 A: Air conditioning systems,
electric cooling fan, back window de-
fogger, outside rear view mirror heater
49. FOG 15 A: Front fog lights
50. GAUGE 15 A: Back−up lights, seat
heaters, gauge and meters, air condi-
tioning systems
51. PWR OUTLET 15 A: Power outlets
52. SEAT HTR 15 A: Seat heaters Fuses (type B)
53. RR HEATER 30 A: Rear air condition-
ing system
54. HEATER 40 A: Front air conditioning
system
55. DEFOG 40 A: Back window defogger
56. MAIN 40 A: Starting system, “H −LP
RH”, “H− LP LH” and “STA” fuses
57. DOOR NO.2 30 A: Multiplex commu-
nication system (power door lock sys-
tem, security system, auto −door locking
system)
58. PWR SEAT 30 A: Power front seats
59. AM1 40 A: “HTR”, “CIG”, “GAUGE”,
“RAD NO.2”, “ECU −IG”, “WIPER”,
“WSH” and “4WD” fuses
60. PWR NO.5 30 A: Power door lock sys-
tem, back door lock system Fuses (type C)
61. ALT 140 A: “AM1”, “PWR SEAT”,
“TAIL”, “STOP”, “SUN ROOF”, “PANEL”,
“OBD”, “FOG”, “PWR NO.1”, “PWR
NO.2”, “PWR NO.5”, “PWR NO.3”,
“PWR NO.4”, “PWR OUTLET” and
“SEAT HTR” fuses
62. ABS 60 A: Anti−lock brake system,
vehicle stability control system, traction
control system (two −wheel drive mod-
els), active traction control system
(four −wheel drive models)
