display TOYOTA SEQUOIA 2009 2.G Navigation Manual

ROUTE GUIDANCE
84
3U5046F
:To indicate the next destination.
:To preview the route to the next
destination.
: To preview the route to the next
destination in fast −forward mode.
: To stop the preview.
:To review the route to the previous
destination or starting point.
: To review the route to the previous
destination or starting point in fast −
forward mode.
: To indicate the previous destina-
tion or starting point. It is possible to store the traveled route up
to 124 miles (200 km) and retrace the route
on the display.
INFORMATION
This feature is available on the map
with
more detailed map scale than 30
miles (50 km).
3U5047F
Touch “Map View”.
3U5048F
“Record”: To start recording the route
trace.
“Stop”: To stop recording the route trace.
If you touch “Stop” to display the following
screen.
— Route trace

ROUTE GUIDANCE
85
3U5049F
Touching “Yes” stops recording and the
route trace remains displayed on the
screen.
Touching “No” stops recording and the
route trace is erased.

ADVANCED FUNCTIONS
88
The “Menu” screen allows effective use of the navigation system. To display the “Menu”
screen, push the “MENU” button.
0U5087X
1“Suspend Guidance” and
“Resume Guidance”
Suspends or resumes guidance 90 . . . .
2“Volume”
Sets the volume for voice guidance. 91
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3“?”
Function help for the “Menu” screen can be
viewed on this screen. 30 . . . . . . . . . . . .
4“Map DVD”
Displays information regarding the disc
version or covered area. NO TAG . . . . . .
5“Select User”
Up to 3 different settings for dif ferent users
can be memorized. 92 . . . . . . . . . . . . . . .
6“Setup”
Enables various settings for the navigation
system. 89,108 . . . . . . . . . . . . . . . . . . . . . .
7“My Places”
Enables changes to “Memory points”,
“Home” and “Areas to avoid”. Enables
deletion of the previous point. 94 . . . . . .
Quick reference (“Menu” screen)

ADVANCED FUNCTIONS
89
The items shown on the “Setup” screen can be set. To display the “Setup” screen, push
the “MENU” button and touch “Setup”.
0U5079X
1“Distance”
The distance units “km” or “miles” can be
selected. 109 . . . . . . . . . . . . . . . . . . . . . . .
2“Estimated Travel Time”
The system to display the travel time and
the arrival time to the destination on the
route guidance screen can be set. 109
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3“Keyboard Layout”
Key layout can be changed. 110 . . . . . . .
4“Time Zone”
The desired time zone can be selected. 111
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5“ Function”
The choice whether to display each touch −
screen button and current street name on
the map screen can be set. 112 . . . . . . .
6“Display POI Icons”
A selection of 6 icons displayed on the
“Display POI Icons” top screen is possible.
11 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7“Display Building Shapes”
Selection of either ON or OFF to display
the building shape on the map screen is
possibl 113 . . . . . . . . . . . . . . . . . . . . . . . . .
8“Traffic Restrict. Notification”
Notification of seasonal restrictions can be
selected. 114
. . . . . . . . . . . . . . . . . . . . . . .
Quick reference (“Setup” screen)

ADVANCED FUNCTIONS
90
9“Voice Recognition Guidance”
Voice recognition guidance can be set. 11 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10“Voice Guidance in All Modes”
Voice guidance can be set in all modes. 11 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11“Auto Voice Guidance”
Automatic voice guidance can be set. 11 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12“Popup Message”
Selection of either ON or OFF to display
the pop− up message is possible.
11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13“Calibration”
Adjustment of the current vehicle position
mark can be done manually, or mis −cal-
culation by changing tire will be adjusted.
11 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14“Default”
This touch−screen button initializes all of
the settings. 108
. . . . . . . . . . . . . . . . . . . .
15“?”
Function help for the “Setup” screen can
be viewed. 30 . . . . . . . . . . . . . . . . . . . . . .
To suspend guidance
XS00301
1. Push the “MENU” button.
4U5001aF
2. Touch “Suspend Guidance”.
INFORMATION
Without route guidance, “Suspend
Guidance” cannot be used.
4U5002F
The screen will return to the current posi-
tion map without route guidance.
Suspending and resuming
guidance

ADVANCED FUNCTIONS
93

To register
4U5008F
1. Touch “Memorize”.
The confirmation screen will be displayed.
4U5009F
2. To register
, touch “Yes”. To return to
the previous screen, touch “No” or
.
When a touch−screen button that is al-
ready registered is touched, the following
screen appears.
4U5010F
To replace, touch “Yes” . To cancel the re-
placement, touch “No” or
.
To change user
4U5011F
Touch “User number”.
4U5012F
The above message appears, then the
map screen will be displayed.

ADVANCED FUNCTIONS
94

To delete user
4U5013F
1. Touch “Delete”.
The confirmation screen will be displayed.
4U5014F
2. To delete, touch “Yes”. To return to
the previous screen, touch “No” or
.
Points or areas on the map can be regis-
tered.
The registered points can be used on the
“Destination”
screen. (See “ — Destination
search by Home” on page 46 and “ —
Destination search by Quick access” on
page 46.)
Registered areas are avoided at the time of
route search.
XS00301
1. Push the “MENU” button.
4U5015aF
2. Touch “My Places”.
My places —

ADVANCED FUNCTIONS
95
4U5016F
On this screen, the following operations
can be performed.
1Registers memory points. (See “ —
Registering memory points” on page
95.)
2Edits memory points. (See “ —
Editing memory points” on page 96.)
3Deletes memory points. (See “ —
Deleting memory points” on page
101.)
4Registers or deletes home. (See “
— Registering home” or “ — Deleting
home” on pages 102 or 103.)
5Registers areas to avoid. (See “ —
Registering area to avoid” on page
103.)
6Edits areas to avoid. (See “ —
Editing area to avoid” on page 104.)
7Deletes areas to avoid. (See “ —
Deleting area to avoid” on page 107.)
8Deletes previous points. (See “ —
Deleting previous points” on page
108.)
9Number of remaining memory
points
10Number of remaining areas to
avoid 1. Push the “MENU” button.
2. Touch “My Places”.
4U5017F
3. Touch “Register”.
4U5018F
4. Enter the location in the same way
as for a destination search. (See
“Destination search” on page 43.)
After memory point registration is com-
pleted, the “Memory Point” screen will be
displayed.
— Registering memory
points

ADVANCED FUNCTIONS
97
4U5022F
5. Touch the touchscreen button to
be edited.
“Icon”: To select icons to be displayed on
the map. (See page 97.)
“Quick Access”: To set an attribute.
Memory points with a set attribute can be
used as a “Quick access” or “Home” but-
ton. (See page 98.)
“Name”: To edit memory point names.
The names can be displayed on the map.
(See page 99.)
“Location”: To edit location information.
(See page 100.)
“Phone #”: To edit telephone numbers.
(See page 101.)
6. Touch “OK”.
To change “Icon”
1. Touch “Icon” on the “Memory
Point” screen.
4U5023F
2. Touch the desired icon.
Turn the page by touching “Page 1”,
“Page 2” or “with Sound”.

ADVANCED FUNCTIONS
99
DELETING “Quick Access”
4U5028F
1. Touch “Del.”.
4U5029F
2. To delete an attribute, touch “Yes”.
To return to the previous screen, touch
“No” or
.
To change “Name”
1. Touch “Name” on the “Memory
Point” screen.
4U5030F
2. Enter the name using the alphanu-
meric keys.
Up to 24 letters can be entered.
3. Touch “OK”.
The previous screen will be displayed.
