tire pressure reset TOYOTA SEQUOIA 2013 2.G Owners Manual

18
Pictorial indexInstrument panel
Headlight switch
Turn signal lever
Fog light switch

P. 188
P. 166
P. 194
Windshield wipers and
washer switch
P. 196
Parking brake pedal
P. 167
Gauges and meters
P. 169
Hood lock release
lever
P. 564
Tire pressure warning
reset switch
P. 581
Rear window wiper and
washer switch
P. 200
SRS knee air-
bags
P. 114

582 4-3. Do-it-yourself maintenance
Push and hold the tire pressure
warning reset switch until the tire
pressure warning light blinks
slowly 3 times.
Wait for several minutes with the engine switch on, and then
turn the engine switch to the ACC or LOCK position.
Registering ID codes
The tire pressure warning valve and transmitter is equipped with a
unique ID code. When replacing a tire pressure warning valve and
transmitter, it is necessary to regi ster the ID code of tire pressure
warning valve and transmitter. Have the ID code registered by your
Toyota dealer.
■When to replace your vehicle’s tires
Tires should by replaced if:
●You have tire damage such as cuts, splits, cracks deep enough to
expose the fabric or bulges indicating internal damage
●A tire goes flat repeatedly or c annot be properly repaired due to the
size or location of a cut or other damage
If you are not sure, consult with your Toyota dealer.

584 4-3. Do-it-yourself maintenance
3Snow tiresFor driving on snow-covered roads or icy roads, we recommend using
snow tires. If you need snow tires, select tires of the same size, con-
struction and load capacity as the or iginally installed tires. Since your
vehicle has radial tires as original equipment, make sure your snow
tires also have radial construction. Do not install studded tires without
first checking local regulations for possible restriction. Snow tires
should be installed on all wheels. ( P. 275)
■Initializing the tire pr essure warning system
Initialize the tires with the tire inflati on pressure adjusted to the specified
level.
■If you push the tire pressure warning reset switch accidentally
If initialization is performed, adjust the tire in flation pressure to the speci-
fied level and initialize the tire pressure warning system again.
■When the initialization of the tire pressure warning system has
failed
Initialization can be completed in se veral minutes. However, in the fol-
lowing cases, the settings have not been recorded and the system will
not operate properly. If repeated attempts to record tire inflation pressure
settings are unsuccessful, have the vehicle inspected by your Toyota
dealer.
●When operating the tire pressure warning reset switch, the tire pres-
sure warning light does not blink 3 times.
●After carrying out the initialization procedure, the tire pressure warn-
ing light blinks for 1 minute and then stays on after driving for about
20 minutes.
■Routine tire inflation pressure checks
The tire pressure warning system doe s not replace routine tire inflation
pressure checks. Make sure to check tire inflation pressure as part of
your routine of daily vehicle checks.

586 4-3. Do-it-yourself maintenance
CAUTION
■When initializing the tire pressure warning system
Do not push the tire pressure warnin g reset switch without first adjusting
the tire inflation pressure to the spec ified level. Otherwise, the tire pres-
sure warning light may not come on ev en if the tire inflation pressure is
low, or it may come on when the tire inflation pressure is actually normal.
NOTICE
■Repairing or replacing tires, wheels, tire pressure warning valves,
transmitters and tire valve caps
●When removing or fitting the wheels, tires or the tire pressure warning
valve and transmitter, contact your Toyota dealer as the tire pressure
warning valve and transmitter may be damaged if not handled cor-
rectly.
●When replacing tire valve caps, do not use tire valve caps other than
those specified. The cap may become stuck.
■To avoid damage to the tire pressure warning valves and transmit-
ters
When a tire is repaired with liquid se alants, the tire pressure warning
valve and transmitter may not operate properly. If a liquid sealant is
used, contact your Toyota dealer or other qualified service shop as soon
as possible. Make sure to replace the tire pressure warning valve and
transmitter when replacing the tire. ( P. 581)
■Driving on rough roads
Take particular care when driving on roads with loose surfaces or pot-
holes.
These conditions may cause losses in tire inflation pressure, reducing
the cushioning ability of the tires. In addition driving on rough roads may
cause damage to the tires themselves, as well as the vehicle’ s wheels
and body.
■If tire inflation pressures become low while driving
Do not continue driving, or your tires and/or wheels may be ruined.

5
When trouble arises
639
5-2. Steps to take in an emergency
■
Four-wheel drive system warning buzzer
The buzzer indicated that the transfer mode is not selected correctly.
■ Key reminder buzzer
The buzzer indicates that the key has not been removed (with the engine
switch in the ACC or LOCK position and the driver’s door opened).
■ Open moon roof reminder buzzer
The buzzer indicate that the moon roof is still opened (with the engine switch
in the ACC or LOCK position and the driver’s door opened).
■ If the malfunction indicator lamp comes on while driving
First check the following:
● Is your vehicle low on gas?
If it is, refuel the vehicle immediately.
● Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after taking several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.
■ Front passenger detection sensor and passenger seat belt reminder
If luggage or other load is placed on the front passenger seat, depending on
its weight, the reminder light to flash and buzzer to sound.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.
Pushing the tire pressure warning reset switch does not turn off the tire
pressure warning light.
■The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such
as natural air leaks or tire inflation pressure changes caused by temper-
ature. In this case, adjusting the ti re inflation pressure will turn off the
warning light (after several minutes).

5
When trouble arises
657
5-2. Steps to take in an emergency
■After completing the tire change
The tire pressure warning
system must be reset. (P. 581)
■When using the temporary spare tire
As the temporary spare tire is not equipped with the tire pressure warn-
ing valve and transmitter, low inflation pressure of the temporary spare
tire will not be warned. Also, if you re place the temporary spare tire after
the tire pressure warning light comes on, the light remains on.
CAUTION
■Using the jack
Improper use of the jack may lead to death or serious injuries due to the
vehicle suddenly falling off the jack.
●Do not use the jack for any purpose other than replacing tires or install-
ing and removing tire chains.
●Only use the jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, an d do not use other jacks for replac-
ing tires on this vehicle.
●Always check that the jack is securely set to the jack point.
●Do not put any part of your body under the vehicle supported by a jack.
●Do not start or run the engine while your vehicle is supported by the
jack.
●Do not raise the vehicle while someone is in it.
●When raising the vehicle, do not put an object on or under the jack.
●Do not raise the vehicle to a hei ght greater than that required to
replace the tire.
●Use a jack stand if it is necessary to get under the vehicle.
Take particular care when lowering the vehicle to ensure that no one
working on or near the vehicle will be injured.
■Using the jack handle
Insert the square head securely until you hear a click to prevent the
extension parts from coming apart unexpectedly.

734 Alphabetical index
Rear view mirrorAnti-glare ...........................84, 89
Compass ............................... 541
Indicator ................................ 236
Rear view monitor system ...... 228
Rear window defogger ............ 314
Rear window wiper .................. 200
Replacing
Fuses .................................... 599
Key battery ............................ 597
Light bulbs ............................. 611
Tires ...................................... 650
Reporting safety defects for U.S. owners ............................ 710
Reset the maintenance data ... 554
Roll sensing of curtain shield airbags off switch....... 126
Roof luggage carrier ..................91
Seatback table ....................52, 526
Seat belts Adjusting the seat belt .............72
ALR .........................................77
Automatic Locking Retractor ...............................77
Child restraint system installation ........................... 136
Cleaning and maintaining
the seat belts ...................... 551
Comfort guide..........................75
ELR .........................................77
Emergency Locking Retractor ...............................77
How to wear your seat belt......72
How your child should wear
the seat belt ..........................78
Pregnant women, proper seat
belt use .................................77
Reminder light ....................... 635
Seat belt extenders .................78
Seat belt pretensioners ...........76 Seat heaters ............................. 518
Seating capacity ...................... 273
Seats
Adjustment ........................ 50, 54
Adjustment precaution ...... 53, 64
Child seats/child restraint system installation .............. 136
Cleaning ................................ 550
Climate control seat .............. 521
Driver’s seat position memory................................. 65
Head restraint ......................... 68
Properly sitting in the seat..... 112
Seat heaters.................. 518, 521
Seat heaters and ventilators ........................... 521
Service reminder
indicators .............................. 174
Shift lever Automatic
transmission ....................... 162
If the shift lever cannot be shifted from P ................ 663
Shift lock system ..................... 663
Shopping bag hooks ............... 532
Side airbags ............................. 114
Side marker lights Replacing .............................. 611
Switch ................................... 188
Wattage................................. 686
Side mirrors Adjusting and folding............... 87
Spare tire Inflation pressure .................. 685
Storage location .................... 650
Spark plug ................................ 682
Specifications .......................... 676
Speedometer ............................ 169
Steering Column lock release ............. 160
S
