TOYOTA VENZA 2016 Owners Manual

5
When trouble arises
5615-1. Essential information
VENZA_OM_OM73030U_(U) If you think something is wrong If you notice any of the followin g symptoms, your vehicle probably
needs adjustment or repair. Contact your Toyota dealer as soon as
possible.
■ Visible symptoms
● Fluid leaks under the vehicle
(Water dripping from the air cond itioning after use is normal.)
● Flat-looking tires or uneven tire wear
● Engine coolant temperature g auge needle continually points
higher than normal
■ Audible symptoms
● Changes in exhaust sound
● Excessive tire squeal when cornering
● Strange noises related to the suspension system
● Pinging or other noises related to the engine

5625-1. Essential information
VENZA_OM_OM73030U_(U) ■ Operational symptoms
● Engine missing, stumbling or running rough
● Appreciable loss of power
● Vehicle pulls heavily to one side when braking
● Vehicle pulls heavily to one side when driving on a level road
● Loss of brake effectiveness, s pongy feeling, pedal almost
touches the floor

5
When trouble arises
5635-1. Essential information
VENZA_OM_OM73030U_(U) Fuel pump shut off system Follow the procedure below to restart the engine after the system is
activated.
Vehicles with smart key system
Turn the “ENGINE START STOP” switch to ACCESSORY mode
or off.
Restart the engine.
Vehicles without smart key system
Turn the engine switch to the “ACC” or “LOCK” position.
Restart the engine.
NOTICE■ Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked on to the ground, the fuel system has been
damaged and is in need of repair. Do not restart the engine.To minimize the risk of fuel leakage when the engine stalls or an air-
bag inflates upon collision, the fuel pump shut off system stops sup-
plying fuel to the engine. STEP 1
STEP 2
STEP 1
STEP 2

564
VENZA_OM_OM73030U_(U) 5-2. Steps to take in an emergency
If a war ning light turns on or a war ning buzzer sounds... Stop the vehicle immediately. C ontinuing to drive the vehicle
may be dangerous.
The following warning indicates a possible problem in the brake sys-
tem. Immediately stop the vehicle in a safe place and contact your
Toyota dealer.
* : Parking brake engaged warning buzzer:
A buzzer will sound if the vehicle is driven at a speed of approximately 3 mph
(5 km/h) or more. Warning light Warning light/Details

(U.S.A.)

(Canada) Brake system warning light (warning buzzer)
*• Low brake fluid
• Malfunction in the brake system
This light also comes on when the parking brake is not
released. If the light turns off after the parking brake is
fully released, the system is operating normally.Calmly perform the following actions if any of the warning lights turn
on or flash. If a light turns on or flashes, but then tu rns off, this does
not necessarily indicate a malfunction in the system.

5
When trouble arises
5655-2. Steps to take in an emergency
VENZA_OM_OM73030U_(U) Stop the vehicle immediately.
The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Toyota dealer.
Have the vehicle inspected immediately.
Failing to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your Toyota dealer immediately.Warning light Warning light/Details
Charging system warning light
Malfunction in the vehicle’s charging system.
Low engine oil pressure warning light
Abnormal level of engine oil pressure.
This warning light may turn on if the level of engine oil
declines. The light should turn off after checking the oil
and adding oil if necessary.
Warning light Warning light/Details
Malfunction indicator lamp
Malfunction in:
• The emission control system;
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control system.

5665-2. Steps to take in an emergency
VENZA_OM_OM73030U_(U) Warning light Warning light/Details
SRS warning light
Malfunction in:
• The SRS airbag system;
• The front passenger occupant classification system; or
• The seat belt pretensioner system.

(U.S.A.)

(Canada) ABS warning light
Malfunction in:
• The ABS; or
• The brake assist system.
Slip indicator light
Indicates a malfunction in:
• The VSC system;
• The TRAC system; or
• The hill-start assist control system.
The light will flash when the VSC, the TRAC or the hill-
start assist control system is operating.

(if equipped) Automatic headlight leveling system warning light
Malfunction in the automatic headlight leveling system.
Electric power steering system warning light
Indicates a malfunction in the EPS (Electric Power
Steering) system.
(Flashes) Cruise control indicator
Indicates a malfunction in the cruise control system.
(Flashes) Automatic High Beam indicat or light (if equipped)
Indicates a malfunction in the Automatic High Beam
system

5
When trouble arises
5675-2. Steps to take in an emergency
VENZA_OM_OM73030U_(U) Follow the correction procedures.
After taking the specified steps to correct the suspected problem,
check that the warning light turns off. Warning light Warning light/Details Correction procedure
Open door warning light
(warning buzzer)
* 1
A door is not fully closed. Check that all doors are
closed.
Driver’s seat belt
reminder light (warning
buzzer)
* 2
Warns the driver to fasten
his/her seat belt. Fasten the seat belt.
(On the center
display) Front passenger’s seat
belt reminder light (warn-
ing buzzer)
* 2
Warns the front passen-
ger to fasten his/her seat
belt. Fasten the seat belt.
Tire pressure warning
light
When the light comes on:
Low tire inflation pressure
such as
• Natural causes (  P. 573)
• Flat tire (  P. 579) Adjust the tire inflation
pressure to the specified
level.
The light will turn off after
a few minutes. In case
the light does not turn off
even if the tire inflation
pressure is adjusted,
have the system checked
by your Toyota dealer.
When the light comes on
after blinking for 1 minute:
Malfunction in the tire
pressure warning system.
(  P. 575) Have the system checked
by your Toyota dealer.

5685-2. Steps to take in an emergency
VENZA_OM_OM73030U_(U) Warning light Warning light/Details Correction procedure
Low fuel level warning
light
Indicates that remaining
fuel is about 4.0 gal. (15.0
L, 3.3 Imp. gal.) or less Refuel the vehicle.

(if equipped) Master warning light
A buzzer sounds and the
warning light comes on
and flashes to indicate that
the master warning system
has detected a malfunc-
tion. Take appropriate action in
accordance with the mes-
sage displayed on the multi-
information display.
Low windshield washer
fluid level warning light
Indicates that the wind-
shield washer fluid level is
too low. Add washer fluid.

(AWD models) Active Torque Control
4WD system warning light
When the light blinks:
The system has been over-
loaded and front-wheel
drive has been automati-
cally engaged. Drop your speed or stop the
vehicle until the light stops
blinking. (Do not stop the
engine.)
When the light comes on:
Malfunction in the Active
Torque Control 4WD sys-
tem. Have the system checked
by your Toyota dealer.

5
When trouble arises
5695-2. Steps to take in an emergency
VENZA_OM_OM73030U_(U) * 1
: Open door warning buzzer:
The open door warning buzzer sounds to alert one or more of the doors is
not fully closed (with the vehicle hav ing reached a speed of 3 mph [5 km/h]).
* 2
: Driver’s and front passenger’s seat belt reminder buzzer:
The driver’s and front passenger’s seat belts reminder sounds to alert the
driver and front passenger that his/her
seat belt is not fastened. The buzzer
sounds intermittently for 10 seconds after the vehicle had reached a speed
of at least 12 mph (20 km/h). Then, if the seat belt is still unfastened, the
buzzer will sound in a different tone for 20 more seconds.
* 3
: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual
Supplement” for the maintenance interval applicable to your vehicle.Warning light Warning light/Details Correction procedure
(U.S.A.) Maintenance required
reminder light
Indicates that mainte-
nance is requires accord-
ing to the driven distance
on the maintenance
schedule.
* 3
Illuminates for about 3 sec-
onds and then flashes for
about 15 seconds approxi-
mately 4500 miles
(7200 km) after the
reminder light has been
reset. If necessary, perform main-
tenance.
Comes on and remains on if
the distance driven exceeds
5000 miles (8000 km) after
the reminder light has been
reset. (The indicator will not
work property unless the
reminder light has been
reset.) Perform the necessary
maintenance.
Please reset the reminder
light is performed.
(
 P. 4 7 7 )

5705-2. Steps to take in an emergency
VENZA_OM_OM73030U_(U) Follow the correction procedures. (smart key system)
After taking the specified steps to correct the suspected problem,
check that the warning light turns off. Interior
buzzer Exterior
buzzer Warning
light Warning light/Details Correction
procedure
Once —
(Comes on
for 8 sec-
onds.) Smart key system
warning light
Indicates that the
electronic key is not
present when
attempting to start
the engine. Confirm the
location of
the elec-
tronic key
* .
Once 3 times Smart key system
warning light
Indicates that a
door other than the
driver’s door has
been opened or
closed with the
“ENGINE START
STOP” switch in
any mode other
than off and the
electronic key out-
side of the detec-
tion area. Confirm the
location of
the elec-
tronic key.
