engine coolant VAUXHALL INSIGNIA 2018 User Guide

284Service and maintenanceDexos is the newest engine oil quality
that provides optimum protection for
petrol and diesel engines. If it is
unavailable, engine oils of other listed qualities must be used.
Recommendations for petrol engines
are also valid for Compressed Natural
Gas (CNG), Liquified Petroleum Gas
(LPG) and Ethanol (E85) fuelled
engines.
Select the appropriate engine oil based on its quality and on the
minimum ambient temperature
3 288.
Topping up engine oilCaution
In case of any spilled oil, wipe it up and dispose it properly.
Engine oils of different manufacturersand brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oils for all petrol
engines with only ACEA quality is
prohibited, since it can cause engine
damage under certain operating
conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 288.
Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.
Engine oil viscosity grades
The SAE viscosity grade gives
information on the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates the low temperature viscosity and the
second figure the high temperature viscosity.
Select the appropriate viscosity grade depending on the minimum ambient
temperature 3 288.All of the recommended viscosity
grades are suitable for high ambient
temperatures.
Coolant and antifreeze
Use only organic acid type-long life
coolant (LLC) antifreeze approved for
the vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -28 °C. In
cold regions with very low
temperatures the factory filled coolant
provides frost protection down to
approx. -37 °C. This concentration
should be maintained all year round.
The use of additional coolant
additives that intend to give additional corrosion protection or seal against
minor leaks can cause function
problems. Liability for consequences
resulting from the use of additional
coolant additives will be rejected.

317Child restraints.............................. 62
Child restraint systems ................62
Climate control ............................. 15
Clock............................................. 91
Collision damage repair ..............310
Control indicators........................ 105
Control of the vehicle .................161
Controls ........................................ 87
Convex shape .............................. 35
Coolant and antifreeze ...............283
Cruise control ....................111, 186
Cupholders .................................. 71
Curtain airbag system .................. 60
Curve lighting.............................. 138
D Danger, Warnings and Cautions ...4
Daytime running lights ...............138
Declaration of conformity ............306
DEF ............................................ 170
Diesel exhaust fluid ....................170
Diesel fuel system bleeding .......244
Diesel particle filter ....................168
Door open .................................. 111
Doors ............................................ 27
Driver assistance systems ..........186
Driver Information Centre ...........112
Driving characteristics and towing tips .............................. 234
Driving hints ................................ 161E
Electric adjustment ......................35
Electrical system......................... 255
Electric parking brake .........107, 179
Electric parking brake fault .........107
Electronic climate control system 151
Electronic key system ...................19
Electronic Stability Control.......... 182
Electronic Stability Control and Traction Control system ..........108
Electronic Stability Control off..... 108
End-of-life vehicle recovery .......238
Engine compartment fuse box ...256
Engine coolant ........................... 241
Engine coolant temperature ......109
Engine coolant temperature gauge ..................................... 104
Engine data ............................... 291
Engine exhaust .......................... 168
Engine identification ...................287
Engine oil ................... 240, 283, 288
Engine oil pressure ....................109
Entry lighting .............................. 145
Event data recorders ..................313
Exit lighting ................................ 145
Exterior care .............................. 279
Exterior light ............................... 110
Exterior lighting ....................12, 134
Exterior mirrors ............................. 35F
First aid kit ................................... 82
Fixed air vents ........................... 158
Fog light ..................................... 110
Fog lights ................................... 247
Folding mirrors ............................. 36
Following distance ......................108
Following distance indication ......200
Forward collision alert................. 197
Front airbag system .....................59
Front fog lights ........................... 142
Front pedestrian protection ........204
Front seats.................................... 45
Front storage ................................ 72
Fuel............................................. 230
Fuel for diesel engines ..............231
Fuel for petrol engines ...............230
Fuel gauge ................................. 103
Funnel......................................... 231
Fuses ......................................... 255
G Gauges ....................................... 101
Gear shifting ............................... 108
General information ...................233
Glovebox ..................................... 71
H Halogen headlights ....................245
Hand brake ................................. 178
Hazard warning flashers ............141
