technical data VAUXHALL VIVA 2015.75 Owner's Manual

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
ContentsIntroduction . . . . . . . . . . . . . . . . . . . . . . 2
In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keys, Doors, and Windows . . . . . 18
Seats and Restraints . . . . . . . . . . . 31
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 52
Instruments and Controls . . . . . . . 59
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . 85
Infotainment System . . . . . . . . . . . . 92
Climate Controls . . . . . . . . . . . . . . 129
Driving and Operating . . . . . . . . . 138
Vehicle Care . . . . . . . . . . . . . . . . . . 159
Service and Maintenance . . . . . 198
Technical Data . . . . . . . . . . . . . . . . 205
Customer Information . . . . . . . . . 210
Index . . . . . . . . . . . . . . . . . . . . 213

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Introduction 3
Vehicle specific data
Please enter your vehicle's data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service
and maintenance" and "Technical
data" as well as on the identification
plate.
Introduction
Your vehicle is a designed
combination of advanced
technology, safety, environmental
friendliness and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of
accident and injury which may result
from improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in
this Owner's Manual.When this Owner's Manual refers to
a workshop visit, we recommend
your Vauxhall Authorised workshop.
For gas vehicles, we recommend a
Vauxhall Authorised workshop
licensed to service gas vehicles.
All Vauxhall Authorised workshops
provide first-class service at
reasonable prices. Experienced
mechanics trained by Vauxhall work
according to specific Vauxhall
instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this Manual
.
This manual describes all
options and features available
for this model. Certain
descriptions, including those for
display and menu functions, may
not apply to your vehicle due to
model variant, country
specifications, special equipment
or accessories.
. The "In brief" section will give
you an initial overview. .
The table of contents at the
beginning of this manual and
within each section shows where
the information is located.
. The index will enable you to
search for specific information.
. This Owner's Manual depicts
left-hand drive vehicles.
Operation is similar for
right-hand drive vehicles.
. The Owner's Manual uses the
factory engine designations.
The corresponding sales
designations can be found in the
section "Technical data".
. Directional data, e.g. left or right,
or front or back, always relate to
the direction of travel.
. The vehicle display screens may
not support your specific
language.
. Display messages and interior
labelling are written in bold
letters.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
58 Storage
.The load must not obstruct the
operation of the pedals, parking
brake and gear selector lever,
or hinder the freedom of
movement of the driver. Do not
place any unsecured objects in
the interior.
. Do not drive with an open load
compartment.
{Warning
Always make sure that the load in
the vehicle is securely stowed.
Otherwise objects can be thrown
around inside the vehicle and
cause personal injury or damage
to the load or car. .
The payload is the difference
between the permitted gross
vehicle weight (see identification
plate
0Vehicle Identification
Number (VIN) 0205) and the
kerb weight. For the kerb weight
in detail, refer to the technical
data section.
The kerb weight includes
weights for the driver (68 kg),
luggage (7 kg) and all fluids
(tank 90% full).
Optional equipment and
accessories increase the kerb
weight. .
Driving with a roof load
increases the sensitivity of the
vehicle to cross-winds and has a
detrimental effect on vehicle
handling due to the vehicle's
higher centre of gravity.
Distribute the load evenly and
secure it properly with retaining
straps. Adjust the tyre pressure
and vehicle speed according to
the load conditions. Check and
retighten the straps frequently.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Technical Data 205
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . 205
Engine Identification . . . . . . . . . . 205
Identification Plate . . . . . . . . . . . . 206
Vehicle Data
Engine Data . . . . . . . . . . . . . . . . . . 207
Performance . . . . . . . . . . . . . . . . . 207
Vehicle Weight . . . . . . . . . . . . . . . 208
Vehicle Dimensions . . . . . . . . . . 208
Capacities and Specifications . . . . . . . . . . . . . . . 209
Tyre Pressure . . . . . . . . . . . . . . . . 209
Vehicle Identification
Vehicle Identification
Number (VIN)
The Vehicle Identification Number is
located in the engine compartment.
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the
windscreen.
Engine Identification
The technical data tables show the
engine identifier code. Engine data
0Engine Data 0207.
To identify the respective engine,
refer to the engine power in the
EEC Certificate of Conformity
provided with your vehicle or other
national registration documents.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
206 Technical Data
Identification Plate
The identification plate is on the left
side door frame.
Information on identification label:
1 = Manufacturer
2 = Type approval number
3 = Vehicle Identification Number
4 = Permissible gross vehicle
weight rating in kg
5 = Permissible gross train
weight in kg
6 = Maximum permissible front axle
load in kg
7 = Maximum permissible rear axle
load in kgThe combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight.
For example, if the front axle is
bearing its maximum permissible
load, the rear axle can only bear a
load that is equal to the gross
vehicle weight minus the front
axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Technical Data 207
Vehicle Data
Engine Data
Sales designation1.0
Engine identifier code L5Q
Number of cylinders 3
Piston displacements [cm³] 999
Engine Power [kW] at rpm 55
Torque [Nm] at rpm 95
Octane rating RON
recommended 95
possible 98
possible 91
Fuel type Petrol
Performance
Engine 1.0
Top speed [km/h] ([mph])
Manual gearbox 106 mph
Automatic transmission -

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
208 Technical Data
Vehicle Weight
Kerb weight, Basic model without any optional equipment
Engine4 seater 5 seater
Without/without air
conditioning [kg] L5Q
938/947 939/945
Optional equipment and accessories increase the Kerb weight.
Loading information.
Vehicle Dimensions
Length [mm] 3675
Width without exterior mirrors [mm] 1595
Width with two exterior mirrors [mm] 1876
Height (without aerial) [mm] w/o roof rack 1485
Length of load compartment floor [mm] 486
Length of load compartment with folded rear seats [mm] 1109
Load compartment width [mm] 978
Load compartment height [mm] 522
Height of load compartment opening [mm] 608
Wheelbase [mm] 2385
Turning circle diameter [m] 9.6(14"), 10.4(15")

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Technical Data 209
Capacities and Specifications
Engine oil1.0
including Filter [l] 4.5 L
between MIN and MAX [l] 1
Fuel tank
petrol, nominal capacity [l] 32
Tyre Pressure
TypeFront[kPa/bar] ([psi])
Rear[kPa]
Comfort ECO Full load Comfort ECO Full load
165/65R14 220/2.2 (32) 270/2.7 (39) 260/2.6 (38) 210/2.1 (30) 250/2.5 (36) 300/3.0 (43)
185/55R15 220/2.2 (32) 270/2.7 (39) 260/2.6 (38) 210/2.1 (30) 250/2.5 (36) 300/3.0 (43)
195/45R16 220/2.2 (32) 270/2.7 (39) 260/2.6 (38) 210/2.1 (30) 250/2.5 (36) 300/3.0 (43)
T105/70D14 (Spare) 420/4.2 (60)

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
210 Customer Information
Customer
Information
Customer Information
Declaration of Conformity . . . . . 210
Vehicle Data Recording and
Privacy
Event Data Recorders . . . . . . . . 211
Radio FrequencyIdentification (RFID) . . . . . . . . . 212
Customer Information
Declaration of Conformity
Transmission systems
This vehicle has systems that
transmit and/or receive radio waves
subject to Directive 1999/5/EC.
These systems are in compliance
with the essential requirements and
other relevant provisions of
Directive 1999/5/EC. Copies of the
original Declarations of Conformity
can be obtained on our website.
Jack
Translation of the original
declaration of conformity
Declaration of conformity according
to EC Directive 2006/42/EC
We declare that the product:
Product designation: Jack
Type/GM part number: 13584087
is in compliance with the provisions
of Directive 2006/42/EC.
Applied technical standards:
GMN9737: Jacking GMW14337: Standard Equipment
Jack
–Hardware Tests
GMN5127: Vehicle Integrity –
Hoisting and Service Station
Jacking
GMW15005: Standard Equipment
Jack and Spare Tyre, Vehicle Test
ISO TS 16949: Quality management
systems
The signatory is authorised to
compile the technical
documentation.
Rüsselsheim, 31st January 2014
signed by
Hans-Peter Metzger
Engineering Group Manager
Chassis & Structure
Adam Opel AG
D-65423 Rüsselsheim

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Customer Information 211
Vehicle Data
Recording and
Privacy
Event Data Recorders
Data storage modules in the
vehicle
A large number of electronic
components of your vehicle contain
data storage modules temporarily or
permanently storing technical data
about the condition of the vehicle,
events and errors. In general, this
technical information documents the
condition of parts, modules, systems
or the environment:
.Operating conditions of system
components (e.g. filling levels)
. Status messages of the vehicle
and its single components (e.g.
number of wheel revolutions /
rotational speed, deceleration,
lateral acceleration) .
Dysfunctions and defects in
important system components
. Vehicle reactions in particular
driving situations (e.g. inflation of
an airbag, activation of the
stability regulation system)
. Environmental conditions (e.g.
temperature)
This data is exclusively technical
and helps identify and correct errors
as well as optimise vehicle
functions.
Motion profiles indicating travelled
routes cannot be created with
these data.
If services are used (e.g. repair
works, service processes, warranty
cases, quality assurance),
employees of the service network
(manufacturer included) are able to
read out this technical information
from the event and error data
storage modules applying special
diagnostic devices. If required, you
will receive further information at
these workshops. After an error has been corrected, the data is deleted
from the error storage module or
constantly overwritten.
When using the vehicle, situations
may occur in which these technical
data related to other information
(accident report, damages on the
vehicle, witness statements etc.)
may be associated with a specific
person - possibly, with the
assistance of an expert.
Additional functions contractually
agreed upon with the client (e.g.
vehicle location in emergency
cases) allow the transmission of
particular vehicle data from the
vehicle.
