clock YAMAHA BEAR TRACKER 250 2002 Manuale de Empleo (in Spanish)

4-19 1. Recoil starter
1. Lanceur à réenroulement
1. Arranque por tracción de cable
1. Fuel tank cap
1. Bouchon de réservoir de carburant
1. Tapón del depósito de combustible
EBU00591
Recoil starter
Firmly grasp the handle and pull slightly until en-
gagement can be felt. Then pull forcefully, being
careful not to pull the rope all the way out.
WARNING
Put the transmission in neutral and set the
parking brake before starting the engine or the
ATV could start to move unexpectedly, which
could cause an accident.
EBU00092
Fuel tank cap
Remove the fuel tank cap by turning it counter-
clockwise.
EE.book Page 19 Monday, June 25, 2001 2:27 PM

8-61 1. Locknut 2. Adjusting bolt
1. Contre-écrou 2. Boulon de réglage
1. Contratuerca 2. Perno de ajuste
EBU00346
Clutch adjustment
1. Loosen the locknut.
2. Slowly turn the adjusting bolt counterclock-
wise until resistance is felt. Then, turn it 1/8
turn clockwise.
3. Tighten the locknut to specification.NOTE:Turn the adjusting bolt counterclockwise to de-
crease the clutch free play and turn it clockwise to
increase the free play.
Tightening torque:
15 Nm (1.5 m·kgf)
EE.book Page 61 Monday, June 25, 2001 2:27 PM

8-81 1. Headlight cover
1. Cache de phare
1. Carenado del faro
1. Cover (× 2) 2. Bulb holder
1. Cache (× 2) 2. Fixation d’ampoule
1. Cubierta (× 2) 2. Portalámparas
EBU00400
Replacing the headlight bulb
If the headlight bulb burns out, replace the bulb as
follows:
1. Remove the headlight cover.
2. Remove the cover and turn the bulb holder
counterclockwise to remove the defective
bulb.
WARNING
The headlight bulb is hot when it is on and im-
mediately after it is turned off. Wait for the bulb
to cool before touching or removing it. You can
be burned or a fire could start if the bulb touch-
es something flammable.
EE.book Page 81 Monday, June 25, 2001 2:27 PM

8-83 1. Adjusting screw (× 2)
1. Vis de réglage (× 2)
1. Tornillo de ajuste (× 2)
3. Put a new bulb into position and secure it in
place with the bulb holder.
4. Reinstall the cover and headlight cover. Ad-
just the headlight beam if necessary.
EBU00409
Headlight beam adjustmentCAUTION:
It is advisable to have a Yamaha dealer make
this adjustment.1. Vertical adjustment:
To raise the beam, turn the adjusting screw
clockwise.
To lower the beam, turn the screw counter-
clockwise.
EE.book Page 83 Monday, June 25, 2001 2:27 PM

8-85 1. Storage box 2. Nut (× 2)
1. Compartiment de rangement 2.Écrou (× 2)
1. Caja portaobjetos 2. Tuerca (× 2)
1. Bulb holder
1. Fixation d’ampoule
1. Portabombilla
EBU00945
Tail/brake light bulb replacement
1. Open the storage box. (See page 4-29.)
2. Remove the nuts together with washers.
3. Remove the bulb holder (together with the
bulb) by turning it counterclockwise.
EE.book Page 85 Monday, June 25, 2001 2:27 PM

8-87 1. Bulb holder 2. Bulb
1. Fixation d’ampoule 2. Ampoule
1. Portabombilla 2. Lámpara
4. Remove the defective bulb from the bulb
holder by pushing it inward and turning it
counterclockwise.
5. Install a new bulb in the bulb holder by push-
ing it inward and turning it clockwise.
6. Install the bulb holder (together with the
bulb).
7. Install the washers, and then install the nuts.
EE.book Page 87 Monday, June 25, 2001 2:27 PM
