5-1
EAU15943
OPERATION AND IMPORTANT RIDING POINTS
EAU15943
OPERATION AND IMPORTANT RIDING POINTS
EAU15951
Read the Owner’s Manual carefully
to become familiar with all controls.
If there is a control or function you
do not understand, ask your Yamaha
dealer.
EWA10271
WARNING
Failure to familiarize yourself with
the controls can lead to loss of
control, which could cause an ac-
cident or injury.
EAU45310
TIPThis model is equipped with a lean
angle sensor to stop the engine in
case of a turnover. To start the en-
gine after a turnover, be sure to turn
the main switch to “OFF” and then to
“ON”. Failing to do so will prevent the
engine from starting even though the
engine will crank when pushing the
start switch.
EAUT1864
Starting the engine
ECA10250
NOTICESee page 5-3 for engine break-in
instructions prior to operating the
vehicle for the rst time.
In order for the ignition circuit cut-off
system to enable starting, the sides-
tand must be up.
See page 3-12 for more information.
1. Turn the key to “ON”.
2. Close the throttle completely.
3. Start the engine by pushing the
start switch while applying the
front or rear brake.
If the engine does not start, re-
lease the start switch, wait a few
seconds, and then try again.
Each starting attempt should be
as short as possible to preserve
the battery. Do not crank the en-
gine more than 5 seconds on any
one attempt. If the engine does
not start with the starter motor, try
using the kickstarter.
ECA11042
NOTICEFor maximum engine life, never ac-
celerate hard when the engine is
cold!
4P9-F8199-E5_CS.indd 5-14P9-F8199-E5_CS.indd 5-1
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black

1
2
3
4
5
6
7
8
9
5-4
EAU15943
OPERATION AND IMPORTANT RIDING POINTS
EAU17213
ParkingWhen parking, stop the engine, and
then remove the key from the main
switch.
EWA10311
WARNING
● Since the engine and exhaust
system can become very hot,
park in a place where pedestri-
ans or children are not likely to
touch them and be burned.● Do not park on a slope or on
soft ground, otherwise the ve-
hicle may overturn, increasing
the risk of a fuel leak and re.● Do not park near grass or other
flammable materials which
might catch re.
4P9-F8199-E5_CS.indd 5-44P9-F8199-E5_CS.indd 5-4
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black

1
2
3
4
5
6
7
8
9
6-25
EAU1722A
PERIODIC MAINTENANCE AND ADJUSTMENT
dangerous since it contains
sulfuric acid, which causes se-
vere burns. Avoid any contact
with skin, eyes or clothing and
always shield your eyes when
working near batteries. In case
of contact, administer the fol-
lowing FIRST AID.
• EXTERNAL: Flush with plen-
ty of water.
• INTERNAL: Drink large quan-
tities of water or milk and im-
mediately call a physician.
• EYES: Flush with water for
15 minutes and seek prompt
medical attention.
● Batteries produce explosive
hydrogen gas. Therefore, keep
sparks, ames, cigarettes, etc.,
away from the battery and pro-
vide suf cient ventilation when
charging it in an enclosed
space.● KEEP THIS AND ALL BATTER-
IES OUT OF THE REACH OF
CHILDREN.
To charge the battery
Have a Yamaha dealer charge the
battery as soon as possible if it seems
to have discharged. Keep in mind that
the battery tends to discharge more
quickly if the vehicle is equipped with
optional electrical accessories.
ECA16521
NOTICETo charge a VRLA (Valve Regu-
lated Lead Acid) battery, a special
(constant-voltage) battery charger
is required. Using a conventional
battery charger will damage the
battery.
To store the battery
1. If the vehicle will not be used for
more than one month, remove
the battery, fully charge it, and
then place it in a cool, dry place.
NOTICE:
When removing the
battery, be sure the key is
turned to “OFF”, then discon-
nect the negative lead before
disconnecting the positive
lead.
[ECA16302]
2. If the battery will be stored for
more than two months, check it
at least once a month and fully
charge it if necessary.
3. Fully charge the battery before
installation.
NOTICE:
When in-
stalling the battery, be sure the
key is turned to “OFF”, then
connect the positive lead be-
fore connecting the negative
lead.
[ECA16840]
4. Before installation, make sure
that the battery leads are properly
connected to the battery termi-
nals.
ECAT1053
NOTICE● Always keep the battery
charged. Storing a discharged
battery can cause permanent
battery damage.● After installing the battery, be
sure to turn the main switch
from “ON” to “OFF” three
times in 3 seconds intervals to
initialize the idle speed control
system.
4P9-F8199-E5_CS.indd 6-254P9-F8199-E5_CS.indd 6-25
2011/09/06 14:18:412011/09/06 14:18:41
Process BlackProcess Black

1
2
3
4
5
6
7
8
9
6-26
EAU1722A
PERIODIC MAINTENANCE AND ADJUSTMENT
EAUT1915
Replacing the fusesThe main fuse box is located above
the battery.ZAUM00**
1
1. Main fuseThe fuse box, which contains the fus-
es for the individual circuits, is located
in the storage compartment. (See
page 3-10.)
ZAUM00**
1
234
5
6
1. Lid
2. Backup fuse
3. Ignition fuse
4. Signaling system fuse
5. Taillight fuse
6. Headlight fuseIf a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off
the electrical circuit in question.
2. Remove the blown fuse, and then
install a new fuse of the specifi ed
amperage. WARNING! Do not
use a fuse of a higher amper-
age rating than recommended
to avoid causing extensive
damage to the electrical sys-
tem and possibly a fire.
[EWA15131]

NOTICE:
After removing and
installing the main fuse, be sure to turn the main switch
from “ON” to “OFF” three
times in 3 seconds intervals to
initialize the idle speed control
system.
[ECAT1062]
Speci ed fuses:
Main fuse:
20 A
Headlight fuse:
15 A
Signaling system fuse:
15 A
Ignition fuse:
7.5 A
Backup fuse:
7.5 A
Taillight fuse:
7.5 A3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
4P9-F8199-E5_CS.indd 6-264P9-F8199-E5_CS.indd 6-26
2011/09/06 14:18:412011/09/06 14:18:41
Process BlackProcess Black

INDEXAAcceleration and deceleration ................... 5-2
Air fi lter and V-belt case air fi lter
elements ............................................... 6-13
Auxiliary light bulb, replacing .................. 6-29BBattery ..................................................... 6-24
Brake fl uid, changing .............................. 6-20
Brake fl uid level, checking ...................... 6-19
Brake lever, front ....................................... 3-6
Brake lever, rear ....................................... 3-6
Brake levers, lubricating .......................... 6-21
Brake lever free play, checking ............... 6-18
Brake pads and shoes, checking ............ 6-19
Braking ...................................................... 5-2CCables, checking and lubricating ............ 6-21
Care .......................................................... 7-1
Catalytic converters .................................. 3-9
Centerstand and sidestand, checking and
lubricating ............................................. 6-22DDimmer switch .......................................... 3-6EEngine break-in ......................................... 5-3
Engine oil and oil strainer ........................ 6-10
Engine trouble warning light ...................... 3-2FFinal transmission oil .............................. 6-12
Front fork, checking ................................ 6-23
Fuel ........................................................... 3-7
Fuel consumption, tips for reducing .......... 5-3
Fuel tank cap ............................................ 3-7
Fuses, replacing ...................................... 6-26
HHandlebar switches ................................... 3-5
Headlight bulb, replacing ........................ 6-27
High beam indicator light .......................... 3-2
Horn switch ............................................... 3-6IIdentifi cation numbers ............................... 9-1
Ignition circuit cut-off system ................... 3-12
Indicator and warning lights ...................... 3-2KKeyhole cover ........................................... 3-2
Kickstarter ................................................. 3-9MMaintenance, emission control system ..... 6-3
Maintenance and lubrication, periodic ...... 6-4
Main switch/steering lock .......................... 3-1
Matte color, caution ................................... 7-1
Model label ................................................ 9-1
Multi-function display ................................ 3-3PPanels, removing and installing ................ 6-7
Parking ...................................................... 5-4
Part locations ............................................ 2-1RRear brake lever free play, adjusting ...... 6-18SSafe-riding points ...................................... 1-5
Safety information ..................................... 1-1
Seat ......................................................... 3-10
Sidestand ................................................ 3-11
Spark plug, checking ................................. 6-8
Specifi cations ............................................ 8-1
Speedometer ............................................ 3-3
Starting off ................................................. 5-2Starting the engine .................................... 5-1
Start switch ............................................... 3-6
Steering, checking .................................. 6-23
Storage ..................................................... 7-4
Storage compartments ............................ 3-10
TTail/brake light bulb or rear turn signal light
bulb, replacing ...................................... 6-28
Throttle grip and cable, checking and
lubricating ............................................. 6-21
Throttle grip free play, checking .............. 6-15
Tires ........................................................ 6-16
Tool kit ...................................................... 6-2
Troubleshooting ...................................... 6-29
Troubleshooting chart ............................. 6-31
Turn signal indicator light .......................... 3-2
Turn signal light bulb (front), replacing .... 6-28
Turn signal switch ..................................... 3-6VValve clearance ...................................... 6-15
Vehicle identifi cation number .................... 9-1WWheels .................................................... 6-17
Wheel bearings, checking ....................... 6-24
