EBU25720Troubleshooting Although Yamaha ATVs receive a thorough in-
spection before shipment from the factory, trouble
may occur during operation. Any problem in the fu-
el, compression, or ignition systems, for example,
can cause poor starting and loss of power.
The following troubleshooting chart represents a
quick and easy procedure for checking these vital
systems yourself. However, should your ATV re-
quire any repair, take it to a Yamaha dealer, whose
skilled technicians have the necessary tools, expe-
rience, and know-how to service the ATV properly.
Use only genuine Yamaha replacement parts. Im-
itation parts may look like Yamaha parts, but they
are often inferior, have a shorter service life and
can lead to expensive repair bills.
WARNING
EWB02280Do not smoke when checking the fuel system.
Fuel can ignite or explode, causing severe inju-
ry or property damage. Make sure there are no
open flames or sparks in the area, including pi-
lot lights from water heaters or furnaces.
Tightening torques:Front wheel nut:45 Nm (4.5 m·kgf, 33 ft·lbf)
Rear wheel nut: 45 Nm (4.5 m·kgf, 33 ft·lbf)
U1BS63E0.book Page 45 Tuesday, March 13, 2012 11:43 AM
10-1
10
EBU25961
SPECIFICATIONS
Dimensions:Overall length:1780 mm (70.1 in)
Overall width: 1095 mm (43.1 in)
Overall height:
1080 mm (42.5 in)
Seat height: 820 mm (32.3 in)
Wheelbase: 1210 mm (47.6 in)
Ground clearance:
115 mm (4.5 in)
Minimum turning radius: 3100 mm (122 in)Weight:With oil and fuel:
180.0 kg (397 lb)Noise and vibration level:Noise level (77/311/EEC):YFM35RD 84.3 dB(A)@3500 r/min
A-weighted sound power level:
YFM35RD 94.0 dB(A)@3500 r/min
Vibration on seat (EN1032, ISO5008): YFM35RD Will not exceed 0.5 m/s²
Vibration on handlebar (EN1032, ISO5008): YFM35RD Will not exceed 2.5 m/s²
Engine:Engine type:Air cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement:
349 cm³
Bore × stroke:
83.0 × 64.5 mm (3.27 × 2.54 in)
Compression ratio: 9.20 : 1
Starting system:
Electric starter
Lubrication system: Wet sumpEngine oil:Recommended brand:
YAMALUBE
U1BS63E0.book Page 1 Tuesday, March 13, 2012 11:43 AM
