Page 54 of 426
3-1
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-3.frame
EL
EBU00032
DESCRIPTION AND MACHINE
IDENTIFICATION
1. Rear spring preload
adjusting ring
2. Storage box and tool kit
3. Spark plug
4. Rear brake fluid
reservoir
5. Radiator cap
6. Front spring preload
adjusting ring
7. V-belt case
8. Rear brake pedal
9. Front spring preload
adjusting ring
10. Fuel cock
11. Air filter case
12. Fuses13. V-belt cooling duct
check hose
14. Coolant reservoir
15. Oil filter cartridge
16. Engine oil dipstick
17. Rear brake lever
18. Left handlebar switches
19. Starter (choke)
20. Horn switch
21. Drive select lever
22. Speedometer
23. Main switch
24. Fuel tank cap
25. Auxiliary DC jack
26. Right handlebar switch
27. Throttle lever
28. Front brake lever
NOTE:
The machine you have purchased may differ
slightly from those shown in the figures of this
manual.
Page 114 of 426
5-1
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-5.frame
EL
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Brakes
• Check operation, free play, fluid level and fluid leakage.
• Fill with DOT 4 brake fluid if necessary.5-7 ~ 5-9,
8-91 ~ 8-95
Fuel
• Check fuel level.
• Fill with fuel if necessary.5-11 ~ 5-13
Engine oil
• Check oil level.
• Fill with oil if necessary.5-15 ~ 5-17,
8-31 ~ 8-41
Coolant reservoir
• Check coolant level.
• Fill with coolant if necessary.8-53 ~ 8-63
Final gear oil/
Differential gear oil
• Check for leakage. 5-19, 8-41 ~ 8-51
Throttle
• Check for proper throttle cable operation. 5-21, 8-87
Wheels and tires
• Check tire pressure, wear and damage.5-25 ~ 5-31,
8-107 ~ 8-109
Fittings and Fasteners
• Check all fittings and fasteners. 5-21
Lights
• Check for proper operation. 5-23, 8-121 ~ 8-127
Front axle boots
• Check for damage. 8-63
Page 310 of 426
8-53
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
EBU00703
Cooling system
1. Check the coolant level in the reservoir
tank when the engine is cold as the cool-
ant level will vary with engine tempera-
ture. The coolant level should be between
the maximum and minimum marks.
2. If the level is low, remove panel D. (See
pages 8-17 ~ 8-19 for panel removal and
installation procedures.)
1. Coolant reservoir tank cap
2. Maximum level mark
3. Minimum level mark
1. Bouchon du vase d’expansion
2. Repère de niveau maximum
3. Repère de niveau minimum
1. Tapa del depósito de refrigerante
2. Marca de nivel máximo
3. Marca de nivel mínimo
Page 312 of 426
8-55
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
3. Remove the reservoir tank cap and add
coolant or distilled water to raise it to the
specified level.
4. Install the panel.CAUTION:Hard water or salt water is harmful to the en-
gine. You may use soft water if you can’t getdistilled water. NOTE:l
If water is added, have a Yamaha dealer
check the antifreeze content of the coolant
as soon as possible.
l
The radiator fan operation is completely
automatic. It is switched on or off accord-
ing to the coolant temperature in the radi-ator.
If your ATV overheats, see page 4-3 for details.Reservoir tank capacity:
0.25 L
1. Coolant reservoir drain hose
1. Flexible de vidange du vase d’expansion
1. Manguera de drenaje del depósito de refrigerante
Page 316 of 426
8-59
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
5. Remove the radiator cap.
6. Remove the reservoir tank cap.
7. Disconnect the hose on the reservoir tank
side and drain the coolant from the reser-
voir tank.
8. After draining the coolant, thoroughly
flush the cooling system with clean tap
water.
9. Replace the coolant drain bolt washer if it
is damaged and tighten the coolant drain
bolt to the specified torque.
Tightening torque:
Coolant drain bolt:
10 Nm (1.0 m.kg)
1. Coolant reservoir drain hose
1. Boulon de vidange du liquide de refroidissement
1. Manguera de drenaje del depósito de refrigerante1. Radiator cap
1. Bouchon du radiateur
1. Tapa del radiador
Page 318 of 426
8-61
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
10. Install the reservoir tank hose.
11. Pour the recommended coolant into the
radiator until it is full.CAUTION:Hard water or salt water is harmful to the en-
gine. You may use distilled water if you can’tget soft water. Recommended antifreeze:
High quality ethylene glycol antifreeze
containing corrosion inhibitors for alumi-
num engines.
Antifreeze and water mixing ratio:
1:1
Total amount:
1.1 L
Reservoir tank capacity:
0.25 L
Page 320 of 426
8-63
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
12. Install the radiator cap.
13. Run the engine several minutes. Stop the
engine and recheck the coolant level in
the radiator. If it is low, add more coolant
until it reaches the top of the radiator.
14. Fill the reservoir tank with coolant up to
maximum level.
15.Install the reservoir tank cap and check for
coolant leakage.NOTE:If any leakage is found, ask a Yamaha dealer toinspect the cooling system.
16. Install the panel and the front carrier.
EBU00283
Front axle boots
Check the protective boots for holes or tears. If
any damage is found, have them replaced by a
Yamaha dealer.
1. Front axle boot (´ 2 each side)
1. Soufflet d’axe avant (´ 2 de chaque côté)
1. Guardapolvo de eje delantero (´ 2 en cada lado)
Page 389 of 426
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
ER
8-132
Engine overheatingNOTE:If it is difficult to get the recommended coolant, tap water can be temporarily used, provided that itis changed to the recommended coolant as soon as possible.
WARNING
Wait for the engine and radiator to cool before removing the radiator cap. You could be burned by
hot fluid and steam blown out under pressure. Always put a thick rag over the cap when opening.Allow any remaining pressure to escape before completely removing the cap. Wait until the
engine has cooled.
Check the coolant level in the
reservoir tank and/or radiator.
Level is OK.Level is low, check the
cooling system for leakage.
No
leakage.Leakage.
Ask a Yamaha dealer to inspect
and repair the cooling system.Add coolant. (See NOTE.)
Restart the engine. If the engine overheats again, ask a
Yamaha dealer to inspect and/or repair the cooling system.
