length YAMAHA YFZ450R 2017 Owners Manual

8-32
8
Cable length “A” should measure 47–51 mm
(1.85–2.01 in). Adjust the parking brake free play
as follows.
1. Release the parking brake by moving the parking brake lever to the right.
2. Fully loosen the locknut and the adjusting bolt at the rear brake caliper.
3. Slide the rubber cover back at the brake ca- ble.
4. Loosen the locknut. 5. Turn the parking brake free play adjusting nut
in direction (a) to increase the cable length,
and in direction (b) to decrease it.
TIPIf the cable length cannot be adjusted to specifi-
cation, consult a Yamaha dealer. 6. Tighten the locknut on the brake cable.
7. Slide the rubber cover to its original position.
8. Turn in the adjusting bolt at the rear brake cal-iper until it feels tight, then turn it out 1/8 turn
and tighten its locknut to the specified torque.
1. Adjusting bolt
2. Cable length “A”
3. Locknut
1
2
3
1. Locknut
2. Parking brake free play adjusting nut
3. Rubber cover
1
2
3
(b)
(a)
UBW260E0.book Page 32 Thursday, May 12, 2016 2:28 PM

8-35
8
EBU26865Drive chain slackThe drive chain slack should be checked before
each ride and adjusted if necessary.
To check the drive chain slack1. Place the ATV on a level surface.TIPWhen checking and adjusting the drive chain
slack, there should be no weight on the ATV and
all tires must be touching the ground. 2. Move the ATV back and forth to locate the tightest portion of the drive chain, and then
measure the drive chain slack as shown. 3. If the drive chain slack is incorrect, adjust it as
follows.
To adjust the drive chain slack 1. Place the ATV on a level surface.
2. Loosen the rear wheel axle pinch bolts.
3. Insert a rod of a diameter of 8 mm (0.3 in) and a length of 10 cm (4 in) into one of the holes in
the drive chain tensioner as shown.
Drive chain slack:
25.0–35.0 mm (0.98–1.38 in)
1. Drive chain slack
1
UBW260E0.book Page 35 Thursday, May 12, 2016 2:28 PM

10-1
10
EBU25962
SPECIFICATIONS
Dimensions:Overall length:1795 mm (70.7 in)
Overall width: 1240 mm (48.8 in)
Overall height:
1065 mm (41.9 in)
Seat height: 810 mm (31.9 in)
Wheelbase: 1270 mm (50.0 in)
Ground clearance:
235 mm (9.3 in)
Minimum turning radius: 3600 mm (142 in)Weight:Curb weight:
184.0 kg (406 lb)Noise and vibration level:Noise level (77/311/EEC):85.9 dB(A) at 3750 r/min (YFZ45YSSH,
YFZ45YSXH_EUR/FRA/GBR)
Uncertainty of measurement: 3.0 dB(A) (YFZ45YSSH, YFZ45YSXH_EUR/FRA/GBR)
A-weighted sound power level:
99.0 dB(A) at 3750 r/min (YFZ45YSSH,
YFZ45YSXH_EUR/FRA/GBR) Uncertainty of measurement:
3.0 dB(A) (YFZ45YSSH, YFZ45YSXH_EUR/FRA/GBR)
Vibration on seat (EN1032, ISO5008): Will not exceed 0.5 m/s² (YFZ45YSSH,
YFZ45YSXH_EUR/FRA/GBR)
Uncertainty of measurement: 0.1 m/s² (YFZ45YSSH, YFZ45YSXH_EUR/FRA/GBR)
Vibration on handle (EN1032, ISO5008): Will not exceed 2.5 m/s² (YFZ45YSSH,
YFZ45YSXH_EUR/FRA/GBR)
Uncertainty of measurement: 0.8 m/s² (YFZ45YSSH, YFZ45YSXH_EUR/FRA/GBR)
Engine:Engine type:Liquid cooled 4-stroke, DOHC
Cylinder arrangement: Single cylinder
Displacement:
449 cm³
Bore × stroke:
95.0 × 63.4 mm (3.74 × 2.50 in)
Compression ratio: 11.8 : 1
Starting system:
Electric starter
Lubrication system: Dry sump
