INSTRUMENT AND CONTROL FUNCTIONS
3-7
3
EAU01601
Digital speedometerThis speedometer is equipped with:l
an odometer
l
two trip odometers
l
a fuel reserve trip meter
l
a clock
NOTE:@ For UK and USA models only:
To change the speedometer display
from kilometers to miles, press the
“SELECT” button for at least two sec-
onds. @
Odometer and trip meter modes
Use the trip meters to estimate how far
you can ride on a tank of fuel.
Use the fuel reserve trip meter to see
the distance traveled from when the
fuel level dropped to the reserve level.
Selecting a modePush the “SELECT” button to change
between the odometer mode “ODO”
and the trip odometer modes “TRIP 1”
and “TRIP 2” in the following order:
“ODO”
® “TRIP 1”
® “TRIP 2”
®
“ODO”
If the fuel level indicator light comes on
(see page 3-2), the odometer display
will automatically change to the fuel re-
serve trip meter mode “TRIP F” and
start counting the distance traveled
from that point. Push the “SELECT”
button to change between the fuel
odometer, trip odometer and odometer
modes in the following order:
“TRIP F”
® “TRIP 1”
® “TRIP 2”
®
“ODO”
® “TRIP F”Resetting a meter
To reset a trip odometer to 0.0, select it
by pushing the “SELECT” button and
push the “RESET” button for at least
one second. To reset the fuel reserve
trip meter, select it by pushing the
“SELECT” button and push the
“RESET” button for at least one sec-
ond. The display will return to “TRIP 1”.
If you do not reset the fuel reserve trip
meter manually, it will automatically re-
set and return to “TRIP 1” after refuel-
ing and the motorcycle has traveled
both 5 km and for approximately 3 min-
utes.NOTE:@ After the fuel reserve trip meter is reset,
the display always returns to the
“TRIP 1” mode. If “TRIP 2” was being
used before the fuel reserve trip meter
is reset, be sure to push the “SELECT”
button to change back to the “TRIP 2”
mode. @
1. Speedometer
2. Clock, odometer
3. “SELECT” button
4. “RESET” buttonE_5eb_Functions.fm Page 7 Thursday, November 18, 1999 4:03 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-8
3 Clock mode
To change the display to the clock
mode, push both the “SELECT” and
“RESET” buttons.
To change the display back to the
odometer mode, push the “RESET”
button.
To set the clock
1. Push both the “SELECT” and
“RESET” buttons for at least two
seconds.
2. When the hour digits start flashing,
push the “RESET” button to set
the hours.
3. Push the “SELECT” button to
change the minutes.
4. When the minute digits start flash-
ing, push the “RESET” button to
set the minutes.
5. Push the “SELECT” button to start
the clock.
NOTE:@ After setting the clock, be sure to push
the “SELECT” button before turning the
main switch to “OFF”, otherwise the
clock will not be set. @
EAU00101
TachometerThis model is equipped with an electric
tachometer so the rider can monitor the
engine speed and keep it within the
ideal power range.
EC000003
CAUTION:@ Do not operate in the red zone.
Red zone: 15,500 r/min and above @1. Tachometer
2. Red zone
