Page 10 of 219
High beams
Illuminates when the high beam
headlamps are turned on.
Anti-theft system (if equipped)
Refer toPerimeter alarm system
in theControls and features
chapter.
Charging system
Momentarily illuminates when the
ignition is turned ON and the
engine is off. The light also
illuminates when the battery is not
charging properly, requiring
electrical system service.
Oil pressure/Engine coolant
This light will come on when the
key is in the ON position and the:
²engine coolant temperature is
very high
²engine oil pressure is low
The light serves as a notice that a
system needs your attention and to
check the engine coolant
temperature gauge and the engine
oil pressure gauge.
Refer toEngine coolant
temperature gaugeandEngine
THEFT
Instrumentation
10
Page 11 of 219
oil pressure gaugein this chapter
for more information.
Four wheel drive low (if
equipped)
Illuminates when four-wheel drive
low is selected.
Four wheel drive indicator (if
equipped)
Illuminates when 4x4 range is
selected.
Check air suspension (if
equipped)
Illuminates briefly when the
ignition is turned to the ON
position and the engine is OFF.
The light also illuminates when the
air suspension system requires
servicing.
For information, refer toAir
suspension systemin theDriving
chapter.
Door ajar
Illuminates when the ignition
switch is in the ON or START
position and any door is open.
LOW
RANGE
4x4
CHECK
SUSP
DOOR
AJAR
Instrumentation
11
Page 16 of 219
Battery voltage gauge
This gauge shows the battery
voltage when the ignition is in the
ON position. If the pointer moves
and stays outside the normal
operating range (as indicated),
have the vehicle's electrical system
checked as soon as possible.
Engine oil pressure gauge
This shows the engine oil pressure
in the system. Sufficient pressure
exists as long as the needle
remains in the normal range (the
area between the ªHº and ªLº).
If the gauge indicates low
pressure, switch off the engine
immediately. Check the oil level.
Add oil if needed (refer to
Checking and adding engine oil
in theMaintenance and care
chapter). If the oil level is correct,
have your vehicle checked at your
dealership or by a qualified
technician.
818
L
H
Instrumentation
16
Page 190 of 219
parts in performance and
durability.
Do not park, idle, or drive
your vehicle in dry grass
or other dry ground cover. The
emission system heats up the
engine compartment and exhaust
system, which can start a fire.
Watch for fluid leaks, strange
odors, smoke, loss of oil pressure,
the charging system warning light,
the ªCheck Engineº light or the
temperature warning light. These
events could indicate that the
emission control system is not
working properly.
If you smell exhaust fumes
of any kind inside your
vehicle, have the dealer inspect
and fix your vehicle immediately.
Do not drive if you smell exhaust
fumes. These fumes are harmful
and could kill you.
Do not make any unauthorized
changes to your vehicle or engine.
By law, vehicle owners and anyone
who manufactures, repairs,
services, sells, leases, trades
vehicles, or supervises a fleet of
vehicles are not permitted to
intentionally remove an emission
control device or prevent it from
working. Information about your
vehicle's emission system is on the
Vehicle Emission Control
Information Decal located on or
near the engine. This decal
Maintenance and care
190
Page 217 of 219
Fuse panels
instrument panel ....................133
power distribution box ...........138
Fuses ...................................132,133
Gauges, Mechanical ....................13
engine coolant temperature
gauge .........................................14
Hazard flashers .........................131
Headlamps
autolamp system .......................18
flashing ......................................35
high beam .................................35
turning on and off ....................17
Heating ........................................20
High beams
indicator light ...........................10
Hood
release lever ............................154
Ignition
positions of the ignition ...........27
removing the key ......................98
Instrument panel
lighting up panel and
interior .......................................18
Jump-starting your
vehicle .................................147,149
attaching cables ......................148
disconnecting cables ..............149
Keyless entry system
autolock .....................................44
Keys
key in ignition chime ...............12
Lamps
interior lamps ...........................36
map lamps .................................36
parking lamps .........................195
Lights, warning and indicator
air bag ..........................................8
anti-lock brakes (ABS) ..............9
anti-theft ...................................10
brake ............................................9
charging system ........................10check engine ............................6,7
door ajar ....................................11
engine oil pressure ...................10
four-wheel drive ........................11
fuel reset ................................6,12
safety belt ...................................9
turn signal indicator ...................9
Load limits
trailer towing ..........................110
Lubricant specifications ....205,208
Manual transmission ...................92
shift speeds .....................94,96,97
Mirrors
side view mirrors (power) .......38
Odometer .....................................15
Off road driving, 4-wheel drive 104
Overdrive ................................35,36
Panic alarm feature, remote
entry system ................................43
Parking brake ..............................85
Parts (see Motorcraft parts) ....205
Power door locks ........................38
Power steering
fluid, checking and adding ....169
Recreational towing, all wheels
on the ground ...........................123
Relays ........................................132
Remote entry system .................42
illuminated entry ......................47
locking/unlocking doors ...........43
replacement/additional
transmitters ...............................46
replacing the batteries .............45
Reporting safety defects ..........215
Safety restraints
automatic locking mode
(retractor) .......................54,55,56
extension assembly ..................57
for children ...............................68
lap and shoulder belts ........53,54
maintenance ..............................58
proper use .................................51
Index
217
Page 219 of 219
Recommended fuel Unleaded fuel only - 87 octane
Fuel tank capacity-4 x 4 regular
cab92.7L (24.5 gallons)
Fuel tank capacity-4 x 2 vehicles
and4x4SuperCab94.6L (25 gallons)
Fuel tank capacity-Long wheelbase 113.6L (30 gallons)
Engine oil (with filter change) Use Motorcraft 5W30 Super
Premium Motor Oil, Ford
Specification WSS-M2C153-G
Tire size and pressure Refer to Tire Pressure Decal on
passenger's door panel
Hood release Pull handle under the left side of
the instrument panel
Oil capacity (with filter change) 5.7L (6.0 quarts)
Coolant capacity-4.2L without A/C 14.9L (15.7 quarts)
Coolant capacity-4.2L with A/C 16.4L (17.3 quarts)
Coolant capacity-4.6L and 5.4L
without A/C16.9L (17.9 quarts)
Coolant capacity-4.6L and 5.4L
with A/C18.4L (19.4 quarts)
Power steering fluid capacity Fill to line in reservoir
Automatic transmission fluid
capacity-4R70W13.1L (13.9 quarts)
Automatic transmission fluid
capacity-E4OD (4 x 2)15.0L (15.9 quarts)
Automatic transmission fluid
capacity-E4OD (4 x 4)15.5L (16.4 quarts)
Filling station information
