VOLKSWAGEN JETTA GLI 2014 1B / 6.G Owners Manual
Manufacturer: VOLKSWAGEN, Model Year: 2014, Model line: JETTA GLI, Model: VOLKSWAGEN JETTA GLI 2014 1B / 6.GPages: 357, PDF Size: 5.56 MB
Page 1 of 357
Side view
Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Roof antenna
(3) Outside door handles
(4) Outside mirror
– Additional turn signal light
(5) Lift points for the jack
Page 2 of 357
Front view
Fig. 2 Vehicle front overview.
Key to fig. 2:
(1) Inside mirror
(2) Windshield wipers
(3) Engine hood release
(4) Headlights (on both left and right)
(5) Fog lights/static cornering lights (on both left and right)
(6) Threaded hole for the front towing eye (behind cover)
(7) Side marker lights (on both left and right)
Page 3 of 357
Rear view
Fig. 3 Vehicle rear overview.
Key to fig. 3:
(1) Rear window
– Rear window defroster
(2) High-mounted brake light
(3) Taillights (on both left and right)
(4) Area for:
– Luggage compartment release
– Rear Assist camera (if equipped)
(5) License plate lights
(6) Threaded hole for the rear towing eye (behind cover)
(7) Roof antenna
