Page 171 of 330
Do not remove any original
equipment or modif y your car in any
way that would alter its design or
operation. This could make your car
unsaf e and illegal to drive.
Such modif ications can adversely
af f ect handling, and interf ere with
the operation of the car’s anti-lock
brakes and other systems.Covering the outside edge of a
f ront seat-back, with a non-Acura
seat cover for example, could
prevent the airbag from inflating
properly.
For example, do not make any
modif ications that would change the
ride height of your car, or install
wheels and tires with a dif f erent
overall diameter.
In addition, any modif ications that
decrease ground clearance increase
the chance of undercarriage parts
striking a curb, speed bump, or other
raised object, which could cause
your airbags to deploy. Do not modif y your steering wheel
or any other part of your
Supplemental Restraint System.
Modif ications could make the
system inef f ective.
Any object
attached to or placed on the covers
marked ‘‘SRS AIRBAG,’’ in the
center of the steering wheel and
on top of the dashboard, could
interf ere with the proper operation
of the airbags. Or, if the airbags
inf late, the objects could be
propelled inside the car and hurt
someone. If a side airbag
inflates,acupholderorotherhard
object attached on or near the
door could be propelled inside the
car and hurt someone.
Modif ications
Additional Saf ety Precautions
Do not place any object s over t heoutsideedgeof afront seat-back.
Do not at t ach or place object s on
the f ront airbag covers. Do not at t ach hard object s on or
near a door.
A ccessories and Modif ications
Bef ore Driving168
Page 211 of 330
µ
Ì
Ì
Ì
Follow the Normal Conditions
Maintenance Schedule if the
severe driving conditions
specif ied in the Severe
Conditions Maintenance
Schedule do not apply.
NOTE: If you onlydrive under a
‘‘severe’’ condition, you should
f ollow the Normal Conditions
Maintenance Schedule.
Follow the Maintenance
Schedule f or Severe Conditions.
OCCASIONALLY
Maint enance
U.S. Owners
Canadian Owners
208
Visually inspect the following items:
Service at the indicated
distance or time whichever
comes first.
miles x 1,000
km x 1,000
months
Replace every 7,500 miles (12,000 km) or 12 months
Check oil and coolant at each fuel stop
Replace engine oil
Replace engine oil filter
Check engine oil and coolant
Replace air cleaner element
Inspect valve clearance
Replace spark plugs
Replace timing belt, and inspect water pump
Inspect and adjust drive belts
Inspect idle speed
Replace engine coolant
Replace transmission fluid
Inspect front and rear brakes
Replace brake fluid
Check parking brake adjustment
Replace air conditioning filter
Rotate tires (Check tire inflation and condition
at least once per month) 15
24
12
30
48
2445
72
3660
96
4875
120 60 90
144 72 120
192
96
105
168
84
Rotate tires every 7,500 miles (12,000 km)
Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Cooling system hoses and connections Exhaust system
Fuel lines and connections
See information on maintenance and emissions warranty, last column, page .
: Adjust only if noisy
207
Maintenance Schedule for Normal Conditions
Page 213 of 330
µ
µ
Ì
Î
Î
ÌÎ
Î
ÌÌ
Follow the Severe Conditions
Maintenance Schedule if you
drive your car under
one or more of the f ollowing
conditions: Driving less than 5 miles (8
km) per trip or, in f reezing
temperatures, driving less
than 10 miles (16 km) per trip.
Driving in extremely hot
[over 90°F (32°C)] conditions.
Extensive idling or long
periods of stop-and-go driving.
Trailer towing, driving with a
roof rack, or driving in
mountainous conditions.
Driving on muddy, dusty, or
de-iced roads.
Follow the Maintenance
Schedule f or Severe Conditions.
MAINLY
Maint enance
U.S. Owners
Canadian Owners
210
Visually inspect the following items: Replace every 3,750 miles (6,000 km) or 6 months
Check oil and coolant at each fuel stop
Service at the indicated
distance or time whichever
comes first.
miles x 1,000
km x 1,000
months
Replace engine oil and oil filter
Check engine oil and coolant
Clean ( ) or replace ( ) air
cleaner element Use normal schedule except in
dusty conditions
Inspect valve clearance
Replace spark plugs Replace timing belt , and inspect water pump
Inspect and adjust drive belts
Inspect idle speed
Replace engine coolant
Replace transmission fluid
Inspect front and rear brakes
Replace brake fluid
Check parking brake adjustment
Replace air conditioning filter
Lubricate all hinges, locks, and latches
Rotate tires (Check tire inflation and condition
at least once per month)
Every 7,500 miles (12,000 km) or 6 months
Tie rod ends, steering gear box, and boots
Suspension components, Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Cooling system hoses and connections
Exhaust system, Fuel lines and connections
Lights and controls, Vehicle underbody Rotate tires every 7,500 miles (12,000 km)
Inspect every 7,500 miles (12,000 km) or 6 months
15
24
12
30
48
2445
72
3660
96
4875
120 60 90
144 72 105
168
84 120
192
96
Refer to page for replacement information under special driving conditions. Refer to page for replacement information under special driving conditions.
See information on maintenance and emissions warranty, last column, page .
:
1:
2: Adjust only if noisy
242 243 207
Type S
Premium model
1
2
Maintenance Schedule for Severe Conditions
Page 246 of 330
µµWe recommend that you visually
check your tires every day. If you
think a tire might be low, check it
immediately with a tire gauge.
To saf ely operate your car, your tires
must be the proper type and size, in
good condition with adequate tread,
and correctly inf lated. The f ollowing
pages give more detailed inf ormation
on how and when to check air
pressure, how to inspect your tires
for damage and wear, and what to do
when your tires need to be replaced.
Keeping the tires properly inf lated
provides the best combination of
handling, tread lif e and riding
comf ort. Underinf lated tires wear
unevenly, adversely af f ect handling
and f uel economy, and are more
likely to f ail f rom being overheated.
Overinf lated tires can make your car
ride more harshly, are more prone to
damage f rom road hazards, and wear
unevenly.
The timing belt should normally be
replaced at the intervals shown in
the maintenance schedule.
Replace this belt at 60,000 miles (U.S.)
or 100,000 km (Canada) if you
regularly drive your car in one or
more of these conditions:
In very high temperatures
(over 110°F, 43°C).
In very low temperatures
(under 20°F, 29°C).
CONT INUED
Inf lation
Tires
Timing Belt
Timing Belt, Tires
Maint enance243
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
Page 274 of 330
This section covers the more-
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your car towed.......................
Compact Spare Tire . 272
....................
Changing a Flat Tire . 273
..........
If Your Engine Won’t Start . 278
Nothing Happens or theStarter Motor Operates ........................
Very Slowly . 278
The Starter Operates ................................
Normally . 279
................................
Jump Starting . 280
............
If Your Engine Overheats . 282
.........
Low Oil Pressure Indicator . 284
..........
Charging System Indicator . 285
.......
Malf unction Indicator Lamp . 286
...............
Brake System Indicator . 287
..................
Closing the Moonroof . 288
..............................................
Fuses . 289
..........
Checking and Replacing . 290
......................
Emergency Towing . 295
Taking Care of the Unexpected
T aking Care of t he Unexpect ed271
Page 276 of 330
If you have a f lat tire while driving,
stop in a saf e place to change it.
Stopping in traf f ic or on the shoulder
of a busy road is dangerous. Drive
slowly along the shoulder until you
gettoanexitoranareatostopthat
is far away from the traffic lanes.Park the car on f irm, level, and
non-slippery ground away f rom
traf f ic. Put the transmission in
Park. Apply the parking brake. Turn on the hazard warning lights
and turn the ignition switch to
LOCK (0). Have all the
passengers get out of the car while
you change the tire.
Open the trunk. Raise the trunk
f loor lid by pulling up on the
handle. To keep the lid out of the
way, hook the handle on the upper
f rame of the trunk opening.The tools are in the tool box on
the right side of the trunk. Take
the tools out of the tool box.
Unscrew the wing bolt and take
the spare tire out of its well.
5. 4.
3. 2.
1.
CONT INUED
Changing a Flat T ire
T aking Care of t he Unexpect ed273
T T R
RU UN NKK F
FLLOOO ORR
S
SP PA
A R
REE T
TI
IRRE E T
TO
OO OLL B
BOOX X
H
H
A
AN
ND DL
LEE
H
H A
AN
ND DL
LEE
J
JAA C
CKK
The car can easily roll off the
jack, seriously injuring anyone
underneath.
Follow the directions for
changing a tire exactly, and
never get under the car when it
is supported only by the jack.
Page 278 of 330
Ú
CONT INUED
Remove the wheel nuts and f lat
tire. Temporarily place the f lat tire
on the ground with the outside
surf ace of the wheel f acing up.
You could scratch the wheel if you
putitfacedown.
Use the extension and wheel
wrench as shown to raise the
vehicle until the f lat tire is of f the
ground.
Locate the jacking point nearest
thetireyouneedtochange.Itis
pointed to by a mark molded
into the underside of the body.
Place the jack under the jacking
point. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
restinginthejacknotch.
9.
10.
11.
Changing a Flat T ire
T aking Care of t he Unexpect ed275
E EX
X T
TE
EN
NS SIIOON N
J
JA A C
CKKIINNG G P
PO
OI INNT T W
WH
HE
EE
EL
L
W
WR REEN
NC CHH
Page 279 of 330
Lower the car to the ground and
remove the jack.
Put on the spare tire. Put the
wheel nuts back on f inger-tight,
then tighten them in a crisscross
pattern with the wheel wrench
until the wheel is f irmly against
the hub. Do not try to tighten
them f ully.
Bef ore mounting the spare tire,
wipeanydirtoff themounting
surface of the wheel and hub with
a clean cloth. Wipe the hub
carefully,itmaybehotfrom
driving.
12.
13.14.
T aking Care of t he Unexpect ed
Changing a Flat T ire
276
B BRRAA K
KEE H
HU
UB B
Page 280 of 330
CONT INUED
Remove the center cap before
storing the f lat tire in the trunk
well.Place the flat tire face down in the
sparetirewell.
Tighten the wheel nuts securely in
the same crisscross pattern. Have
the wheel nut torque checked at
the nearest automotive service
f acility.
Tighten the wheel nuts to: Remove the spacer cone f rom the
wing bolt, turn it over, and put it
back on the bolt.
Securetheflattirebyscrewing
the wing bolt back into its hole.
16.
15.
17.
18.
19.
Changing a Flat T ire
T aking Care of t he Unexpect ed277
C CEEN
NT TE
ER
R C
CAA P
P W
WI
INNG G B
BOOL LTT S
SPPA
A C
CEER
R C
COON NEE
80 lbf·ft (108 N·m , 11 kgf·m)
Page 281 of 330
Diagnosing why your engine won’t
start f alls into two areas, depending
on what you hear when you turn the
key to START (III):You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. When you turn the ignition switch to
START (III), you do not hear the
normal noise of the engine trying to
start. You may hear a clicking sound
or series of clicks, or nothing at all.
Check these things:
Check the transmission interlock.
The transmission must be in Park
orNeutralorthestarterwillnot
operate. Your car has the Immobilizer
System. You should use a
properly-coded master or valet key
to start the engine (see page ).
A key that is not properly coded
will cause the immobilizer system
indicator in the dash panel to blink
rapidly.
Store the jack in its holder. Turn
the jack’s end bracket to lock it in
place. Replace the cover. Store the
tools.
Store the center cap in the trunk.
Make sure it does not get scratch-
ed or damaged.
Unhook the handle f rom the trunk
opening and lower the f loor lid.
Close the trunk lid.
78
20.
21.
22.
23.
Changing a Flat Tire, If Your Engine Won’t Start
T aking Care of t he Unexpect ed
If Your Engine Won’t Start Nothing Happens or the Starter Motor Operates Very Slowly
278
Loose items can fly around the
interior in a crash and could
seriously injure the occupants.
Store the wheel, jack and tools
securely before driving.
