Number Maintenance Sub Items
3-8
Maintenance Minder
Maintenance Sub Items
1 Rotate tires, and check tire inflation and condition.
Follow the pattern shown in the Owner’s Manual.


2 Replace air cleaner element (see page 11-346).
Replace every 15,000 miles (24,000 km) if the vehicle is driven in dusty conditions.
Replace dust and pollen filter (see page 21-75). If the vehicle is driven mostly in urban areas that have high concentrations of dust, pollen, or soot in
the air, replace every 15,000 miles (24,000 km).
Replace the filter whenever airflow from the heating and air c onditioning system is less than normal.
Inspect drive belt (see page 4-30). Look for cracks and damage, then check the position of the drive belt auto-tensioner indicator.
3 Replace automatic transmission fluid (see page 14-232). Capacity:2.9L(3.1USqt);useAcuraATF-Z1.
Replace manual transmission fluid. 5M/T (see page 13-5), 6M/T (see page 13-82)
Capacity:1.5L(1.6USqt);useAcuraMTF.




4 Replace spark plugs (see page 4-21).
K20Z2: Use SKJ20DR-M11 (DENSO).
K20Z3: Use SK22PR-M11S (DENSO).
Inspect valve clearance (cold). K20Z2 (see page 6-12)
Intake: 0.21 0.25 mm (0.008 0.010 in.), Exhaust: 0.28 0.32 mm (0.011 0.013 in.)
K20Z3 (see page 6-14)
Intake: 0.21 0.25 mm (0.008 0.010 in.), Exhaust: 0.25 0.29 mm (0.010 0.011 in.)


5 Replace engine coolant (see page 10-8).
Capacity (including the reservoir):
K20Z2: M/T 4.3 L (1.14 US gal), A/T 4.2 L (1.11 US gal)
K20Z3: 4.5 L (1.19 US gal)
Use Honda Long Life Antifreeze/Coolant Type 2.
08/08/21 14:08:32 61SNR030_030_0008
ProCarManuals.com
DYNOMITE -2009-

ÃŽ
 ÃŽ
ÃŽ
Specified Torque:
8x1.25mm
27 N·m (2.8 kgf·m, 20 lbf·ft)
13-59
Liquid gasket
D
39 N·m
(4.0 kgf·m,
29 lbf·ft)
C
B
A
B
6x1.0mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft)
B
44 N·m
(4.5 kgf·m, 33 lbf·ft)
G
H
F
A
39 N·m
(4.0 kgf·m,
33 lbf·ft)
6x1.0mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft) D
E
C
C
15. Tighten the 8 mm flange bolts in a crisscross pattern in several steps.
16. Clean any dirt or oil from the mating surface of the change lever assembly and the transmission
housing. Apply liquid gasket, P/N 08718-0001
evenly to the mating surface of the change lever
assembly and the transmission housing. Install the
component within 5 minutes of applying the liquid
gasket.
NOTE:  If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes.
 If too much time has passed after applying the liquid gasket, remove the old liquid gasket and
residue, then reapply new liquid gasket. 17. Installthe8x14mmdowelpins(B)andthechange
lever assembly (C) with harness bracket A.
18. Apply liquid gasket, P/N 08718-0001, evenly to the threads of the inter lock bolt (D). Install the
component within 5 minutes of applying the liquid
gasket.
NOTE: If you apply liquid gasket P/N 08718-0012, the component must be installed within 4 minutes.
 If too much time has passed after applying the liquid gasket, remove the old liquid gasket and
residue, then reapply new liquid gasket.
19. Install the drain plug (A) and the 10 mm flange bolt (B) with new washers (C). Install the filler plug (D)
finger-tight with new sealing washer (E).
20. Apply MTF to a new O-ring (F). Then install the output shaft (countershaft) speed sensor (G) with
the O-ring and the plain washer (H).
(cont’d)
Replace.Replace.
Replace.
Replace.
