HDS Inputs and Commands
Input:System Menu Data List Data List Indication
22-88Multiplex Integrated Control System
System Description (cont’d)
Certain inputs happen so quickly that the HDS cannot update fast enough. Hold the switch that is being tested while monitoring the Data List.
This should give the HDS time to update the signal on the Data List.
Because the HDS software is updated to support the release for newer vehicles it is not uncommon to see system function tests that are not
supported.
Make sure that the most current software is loaded.
Gauges Cruise Control Main Switch OFF/ON Cruise Control Set Switch OFF/ON
Cruise Control Resume Switch OFF/ON
Washer Fluid Level Switch OFF/ON
VSA/TCS Off Switch OFF/ON
Gauge Select/Reset Switch OFF/ON
Parking Brake Switch OFF/ON
Brake Fluid Level Switch OFF/ON
Illumination Volume Plus Switch OFF/ON
Illumination Volume Minus Switch OFF/ON
Km/h mph Select Switch OFF/ON
Fuel Sending Unit Input 1 deg
Fuel Sending Unit Input 2 VOLTAGE
VSA/TCS Active Indicator OFF/ON
VSA/TCS Indicator (Warning) OFF/ON
ABS Indicator OFF/ON
Cruise Control Main Switch Indicator OFF/ON
MIL Indicator OFF/ON
Washer Fluid Level Indicator OFF/ON
DRL Indicator OFF/ON
Low Oil Pressure Indicator OFF/ON
Charging System Indicator OFF/ON
Cruise Main Switch ON Indicator OFF/ON
Maintenance Minder Indicator OFF/ON
High Beam Indicator OFF/ON
Parking Light ON Indicator OFF/ON
Low Fuel Warning Indicator OFF/ON
Security Indicator OFF/ON
Fog Light Indicator OFF/ON
Seat Belt Indicator OFF/ON
Speed Indicator (km/h) 0 249 km/h, over 250 km/h, Fail
Speed Indicator (mph) 0 154 mph, over 155 mph, Fail
Low Tire Pressure Indicator OFF/ON
TPMS Indicator OFF/ON
A/TGearPositionSwitch(R) OFF/ON
A/TGearPositionSwitch(P) OFF/ON
08/08/21 14:24:09 61SNR030_220_0090
ProCarManuals.com
DYNOMITE -2009-

´µ

The Indicator Drive Circuit Check
Switch Input Check
The Beeper Drive Circuit Check
The LCD Segment Check
The Gauge Drive Circuit Check
22-242Gauges
Self-diagnostic Function (cont’d)
OFF ON
OFF ON
OFF ON
OFF ON
Gauge needles
Beeper
5sec.
Self-diagnostic
mode
SEL/RESET
SWITCH
When entering the self-diagnostic mode, the following indicators blink:
A/T gear position indicator, ABS indicator, brake system indicator, charging system indicator, cruise control indicator,
cruise main indicator, door indicator, DRL indicator, EPS indicator, fog light indicator , high beam indicator,
immobilizer indicator, lights-on indicator, low fuel indicator, low oil pressure indicator, low tire pressure indicator ,
maintenance minder indicator, malfunction indicator lamp (MIL), REV limit indicator (TYPE S model), seat belt
reminder indicator, security indicator, side airbag cutoff indicator, SRS indicator, TPMS indicator , trunk indicator,
VSA activation indicator , VSA indicator , and washer fluid level indicator.
1: ’07 TYPE S and ’08-09 models
2: ’08-09 models
3: TYPE S and ’08 Premium and ’09 models
At the initial stage of the self-diagnostic function, the beep sounds intermittently, the beeper sounds continuously
when any of the following switch inputs are switched from OFF to ON:
Cruise control main, dash lights brightness controller volume ( ), ( ) button, mph km/h switch, parking brake switch,
SEL/RESET switch, SET, RESUME, CANCEL switches, and VSA OFF switch . : ’07 TYPE S and ’08-09 models
When entering the self-diagnostic mode, the beeper sounds five times.
When entering the self-diagnostic mode, all the segments blink five times.
When entering the self-diagnostic mode, the tachometer needle sweeps from the minimum position to maximum
position, then returns to the minimum position.
NOTE:
After the beeper stops sounding and the gauge needle returns to the minimum position, pushing the SEL/RESET
switch starts the Beeper Drive Circuit Check (one beep) and the Gauge Drive Circuit Check again.
The check cannot be started again until the gauge needle returns to the minimum position.
If the needle fails to sweep, or the beeper does not sound, replace the gauge control module (tach).
3 2
2
11
The needle sweeps from the
minimum position to the
maximum position, then return
to the minimum position.
08/08/21 14:35:12 61SNR030_220_0244
ProCarManuals.com
DYNOMITE -2009-

Î
µ´µ
22-254Gauges
Circuit Diagram - Gauge Control Module (Tach) (cont’d)
GAUGE CONTROL MODULE (TACH)
D
MAIN CIRCUIT
INDICATOR DRIVE CIRCUIT
DRL
INDICATOR
(LED)
DOOR
INDICATOR
(LED)TRUNK
INDICATOR
(LED)
MAINTENANCE
MINDER
INDICATOR
(LED) *
LOW TIRE
PRESSURE
INDICATOR
(LED) TPMS
INDICATOR
(LED)
G5014
3 6
7
1
2
5
BLK
PUR
7
BLU 6
YEL 5
4
BRN
GRY
RED ILLUMI
()
ILLUMI
()SEL/
RESETkm/h
mph
LIGHTS
(LED)
GAUGE CONTROL
MODULE (TACH) No. 14 (7.5 A) FUSE
(UNDER-DASH
FUSE/RELAY BOX)
DASH LIGHTS BRIGHTNESS CONTROLLER and
ODOMETER SELECT/RESET SWITCH
C
