Customized features Acura ILX 2013 User Guide

131Controls
Interior Lights/Interior Convenience ItemsInterior Lights
■ON
The interior lights come on regardless of
whether the doors are open or closed.■Door activated
The interior lights come on in the following
situations:
•When any of the doors are opened.
•You unlock the driver's door.
•The lights also come on when the power
mode is set to VEHICLE OFF (LOCK).■OFF
The interior lights remain off regardless of
whether the doors are open or closed.
The map lights can be turned on and off by
pressing the (map light) button.
■Interior Light Switches
1Interior Light Switches
In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after 30 seconds in the following
situations:•When you unlock the driver's door but do not open
it.•When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.
You can change the interior lights dimming time.
2Customized Features P. 83
The interior lights go off immediately in the following
situations:•When you lock the driver's door.•When you set the power mode to ON.
If you leave any of the doors open, the interior lights
go off after about 15 minutes.
Door Activated Position
Off Front
Door Activated PositionOn
Off RearOn
■Map Lights
1Map Lights
When the interior light switch is in the door activated
position and any door is open, pressing the
button does not turn off the map light.

255
uuMaintenance Minder
TMuTo Use Maintenance Minder
TM
Maintenance
Reset the engine oil life display if you have performed the maintenance service.
1.Set the power mode to ON.
2.Go to the MAINTENANCE INFO. group.
2Customized Features P. 83
3.Press the SEL/RESET button.
uThe oil life reset mode is displayed on the multi-information display.
4.Select RESET with the button, then press the SEL/RESET button.
uThe displayed maintenance items disappear, and the engine oil life display
returns to 100%.
To cancel the oil life reset mode, select CANCEL, then press the SEL/RESET button.■Resetting the Display
1Resetting the DisplayNOTICEFailure to reset the engine oil life after a maintenance
service results in the system showing incorrect
maintenance intervals, which can lead to serious
mechanical problems.
The dealer will reset the engine oil life display after
completing the required maintenance service. If
someone other than a dealer performs maintenance
service, reset the engine oil life display yourself.
Engine Oil Life Maintenance
Item Codes
SEL/RESET Button
Button

344Index
Fluid ........................................................ 272
Foot Brake ............................................... 238
Indicator ............................................ 64, 322
Parking Brake .......................................... 237
Brightness Control (Instrument Panel).... 119
Bulb Replacement..................................... 274
Back-Up Light Bulbs ................................. 282
Brake Light, Taillight, Rear Turn Signal Light
and Rear Side Marker Light Bulbs ........... 280
Fog Lights ................................................ 276
Front Turn Signal Light Bulbs ................... 278
Headlights ............................................... 274
High-Mount Brake Light .......................... 283
Parking/Side Marker Light Bulbs ............... 279
Rear License Plate Light............................ 283
Bulb Specifications............................ 330, 332CCarbon Monoxide Gas................................ 60
Carrying Cargo.................................. 211, 213
CD Player........................................... 153, 155
Certification Label.................................... 334
Changing Bulbs......................................... 274
Charging System Indicator................. 65, 320
Child Safety................................................. 48
Childproof Door Locks ............................. 100
Child Seat.................................................... 48
Booster Seats ............................................. 59
Child Seat for Infants ................................. 50
Child Seat for Small Children ..................... 51Installing a Child Seat with a Lap/Shoulder Seat
Belt ......................................................... 55
Larger Children ......................................... 58
Rear-facing Child Seat ............................... 50
Selecting a Child Seat ................................ 52
Using a Tether ........................................... 57
Childproof Door Locks............................. 100
Cleaning the Exterior............................... 300
Cleaning the Interior................................ 298
Client Service Information....................... 342
Climate Control System............................ 136
Changing the Mode ................................ 136
Defrosting the Windshield and
Windows ............................................... 137
Dust and Pollen Filter............................... 297
Recirculation/Fresh Air Mode ................... 136
Sensors ................................................... 139
Synchronized Mode................................. 138
Using Automatic Climate Control ............ 136
Clock............................................................ 92
Clutch Fluid............................................... 272
Coat Hook................................................. 134
Compact Spare Tire.................. 305, 331, 333
Console Compartment............................. 132
Controls....................................................... 91
Coolant (Engine)...................................... 268
Adding to the Radiator ............................ 269
Adding to the Reserve Tank..................... 268
Overheating ............................................ 318
Creeping (Automatic Transmission)........ 221Cruise Control.......................................... 229
Indicator ................................................... 72
Cup Holders.............................................. 133
Customized Features................................. 83
DDaytime Running Lights.......................... 117
Dead Battery............................................ 314
Defrosting the Windshield and
Windows................................................. 137
Devices that Emit Radio Waves............... 335
Dimming
Headlights .............................................. 114
Rearview Mirror ...................................... 121
Dipstick (Engine Oil)................................ 262
Directional Signals (Turn Signal)............. 114
Door Mirrors............................................. 122
Doors.......................................................... 93
Auto Door Locking.................................. 101
Auto Door Unlocking .............................. 101
Door Open Indicator ........................... 25, 69
Keys.......................................................... 93
Locking/Unlocking the Doors from
the Inside ................................................ 99
Locking/Unlocking the Doors from
the Outside ............................................. 95
Lockout Prevention System ....................... 98
DOT Tire Quality Grading........................ 289
Driving...................................................... 209
Automatic Transmission .......................... 221
