flat tire Acura Integra 2000 Hatchback User Guide

Compac
t Spar e Tir e

Your car has a compact spare tire that takes up less space. Use thisspare tire as a temporary replace-
ment only. Get your regular tirerepaired or replaced and put back on
your car as soon as you can.
Check the inflation pressure of the
compact spare tire every time you
check the other tires. It should be

inflated to:

60 psi (420 kPa , 4.20 kgf/cm2)

Follow these precautions whenever
you are using the compact spare tire:
Do not exceed 50 mph (80 km/h)
under any circumstances.
This tire gives a harsher ride and
less traction on some road sur-
faces than the regular tire. Use greater caution while driving on
this tire. Do not mount snow chains on the

compact spare.

The wheel of the compact spare tire is designed especially to fit
your car. Do not use your spare tire on another vehicle unless it is

the same make and model.

Type-R model only
Do not drive with the compactspare tire mounted on the front
wheels for a long period; it will damage the Limited Slip Differential. The compact spare tire has a shorter

tread life than a regular tire. Replace
it when you can see the tread wear

indicator bars. The replacement
should be the same size and design

tire, mounted on the same wheel.

The compact spare tire is not
designed to be mounted on a regular

wheel, and the compact wheel is not
designed for mounting a regular tire.

Takin g Car e o f th e Unexpecte d INDICATO
R LOCATIO N MAR K
TREA D WEA R INDICATO R BA R

Changin
g a Fla t Tir e
If you have a flat tire while driving, stop in a safe place to change it.
Stopping in traffic or on the shoulderof a busy road is dangerous. Drive
slowly along the shoulder until you
get to an exit or an area to stop that is far away from the traffic lanes.
1. Park the car on firm, level and
non-slippery ground away from
traffic. Put the transmission in Park (automatic) or Reverse (manual). Apply the parking brake.

2. Turn on the hazard warning lights

and turn the ignition switch to
LOCK (0). Have all the
passengers get out of the car while
you change the tire.

3. Open the hatch. Pull up the floor

mat and remove the spare tire
cover.

4. Take the tool kit out of the spare

tire well.

5. Unscrew the wing bolt and take

the spare tire out of its well.

CONTINUED

Takin g Car e o f th e Unexpecte d

The car can easily roll off the

jack, seriously injuring anyone
underneath.

Follow the directions for

changing a tire exactly, and never get under the car when it
is supported only by the jack. JAC
K
SPAR E TIR E
TOOL KI T

Changin
g a Fla t Tir e
9. Use the extension and wheelwrench as shown to raise the
vehicle until the flat tire is off the
ground.
10.Remove the wheel nuts and flat
tire. Temporarily place the flat tire on the ground with the outside
surface of the wheel facing up.
You could scratch the wheel if you put it face down.
11.Before mounting the spare tire,
wipe any dirt off the mountingsurface of the wheel and hub with
a clean cloth. Wipe the hub
carefully, it may be hot from driving.

CONTINUED

Takin g Car e o f th e Unexpecte d

EXTENSIO
N
WHEE L WRENC H BRAK
E HU B

Changin
g a Fla t Tire , I f You r Engin e Won' t Star t
15.Remove the wheel cover or center
cap.

Place the flat tire face down in the
spare tire well.
16.Remove the spacer cone from the
wing bolt, turn it over, and put it back on the bolt.

17.Secure the flat tire by screwing

the wing bolt back into its hole.
18.Store the jack in its holder with
the end bracket facing to the right.
Turn the jack's end bracket to lock i t in place. Store the tool kit.

19.Store the wheel cover or center
cap in the cargo area. Make sure it
will not get scratched or damaged. I
f You r Engin e Won' t Star t

Diagnosing why your engine won't
start falls into two areas, depending

on what you hear when you turn the
key to START (III):

You hear nothing, or almostnothing. The engine's starter

motor does not operate at all, or

operates very slowly.
You can hear the starter motor

operating normally, or the starter

motor sounds like it is spinning

faster than normal, but the engine

does not start up and run.

Takin g Car e o f th e Unexpecte d

Loose items can fly around the
interior in a crash and could
seriously injure the occupants.
Store the wheel, jack and tools
securely before driving.

WIN
G BOL T

SPACER

CON E

Emergenc
y Towin g

If your vehicle needs to be towed,
call a professional towing service or,
if you belong to one, an organization
that provides roadside assistance. Never tow your vehicle behind
another vehicle with just a rope or
chain. It is very dangerous.
There are three popular types of professional towing equipment:

Flat-bed Equipment — The operator

loads your vehicle on the back of a

truck. Thi s i s th e best way o f trans -
portin g you r Acura .

Wheel-Lift Equipment — The tow

truck uses two pivoting arms that go
under the tires (front or rear) and lift
them off the ground. The other two
tires remain on the ground. Thi s is
a n acceptabl e wa y t o to w you r
Acura .
Sling-type Equipment — The tow

truck uses metal cables with hooks on the ends. These hooks go around
parts of the frame or suspension and
the cables lift that end of the vehicle off the ground. Your vehicle's sus-
pension and body can be seriously damaged. Thi s metho d o f towin g
i s unacceptable .
If your Acura cannot be transported
by flat-bed, it should be towed by
wheel-lift equipment with the front
wheels off the ground. If, due to damage, your car must be towed
with the front wheels on the ground, do the following.

5-speed Manual Transmission
Release the parking brake.
Shift the transmission to Neutral.
Automatic Transmission:
Release the parking brake.
Start the engine.
Shift to D4, then to N.
Turn off the engine.

Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shift the transmission or start the engine, your vehicle must be trans-
ported with the front wheels off the
ground.

With the front wheels on the ground, it is best to tow the vehicle no farther
than 50 miles (80 km), and keep the speed below 35 mph (55 km/h).

CONTINUED

Takin g Car e o f th e Unexpecte d

NOTIC
E

DO
T Tir e Qualit y Gradin g (U.S . Cars )
Temperatur e
The temperature grades are A (the highest), B, and C, representing the
tire's resistance to the generation of heat and its ability to dissipate heat
when tested under controlled conditions on a specified indoor
laboratory test wheel. Sustained high
temperature can cause the material of the tire to degenerate and reduce
tire life, and excessive temperature can lead to sudden tire failure. The
grade C corresponds to a level of
performance which all passenger car
tires must meet under the Federal Motor Vehicle Safety Standard No.109. Grades B and A represent
higher levels of performance on the
laboratory test wheel than the minimum required by law. Warning: The temperature grade for
this tire is established for a tire thatis properly inflated and not over-
loaded. Excessive speed, underinfla-
tion, or excessive loading either separately or in combination, can
cause heat build-up and possible tire
failure.
Technical Informatio n

Inde
x

Brakes Anti-lock System (ABS)............ 146Break-in, New Linings.............. 123

Fluid............................................ 183
Light, Burned-out...................... 210

Parking.......................................... 87

System Indicator.................. 54, 238
Wear Indicators......................... 145
Brakes, ABS Operation.................................... 146
System Indicator.................. 55, 148
Braking System.............................. 145
Break-in, New Car......................... 123
Brightness Control, Instruments... 63 Brights, Headlights......................... 62
Bulb Replacement Back-up Lights........................... 210
Brake Lights............................... 210
Cargo Area Light....................... 212
Ceiling Lights............................. 212
Front Parking Lights................. 208
Front Side Marker Lights......... 208
Headlights.................................. 207
High-mount Brake Light.......... 209
License Plate Light.................... 212
Rear Side Marker Lights.......... 210 Specifications............................. 251
Spotlights.................................... 212
Turn Signal Lights..................... 208
Bulbs, Halogen............................... 207
Cables, Jump Starting With.......... 231
Capacities Chart.................... 250, 251
Carbon Monoxide Hazard.............. 49
Cargo Area Cover............................ 83
Carrying Cargo.............................. 132
Cassette Player Care............................................. 118
Operation.................................... 115
CAUTION, Explanation of............... ii
CD Changer.................................... 111

CD Player........................................ 109
Certification Label......................... 248
Chains............................................. 202
Change Oil
How to......................................... 173

When to....................................... 162

Changing a Flat Tire..................... 225
Changing Engine Coolant............. 178
Charging System Indicator.... 54, 236 Checking
Automatic Transmission
Fluid........................................ 182
Battery Condition...................... 189
Brake Fluid................................. 184
Clutch Fluid................................ 184

Drive Belts.................................. 195
Engine Coolant........................... 128

Engine Oil................................... 127

Fuses........................................... 241
Manual Transmission Fluid..... 183
Power Steering Fluid................. 185
Checklist, Before Driving............. 136
Child Safety...................................... 21 Cleaner Element, Air..................... 186

Cleaning
Aluminum Wheels..................... 217

Antenna...................................... 216
Carpeting.................................... 218

Exterior....................................... 216

Fabric.......................................... 218

Interior........................................ 218
Leather........................................ 218

Seat Belts.................................... 218

Vinyl............................................ 218
Windows..................................... 219

Inde
x

Clock, Setting the............................ 88

Clutch Fluid.................................... 183

Code, Audio System...................... 119
CO in the Exhaust......................... 256

Cold Weather, Starting in............. 137

Compact Spare............................... 224

Console Compartment.................... 90
Consumer Information*................ 260
Controls, Instruments and............. 51
Coolant
Adding......................................... 176

Checking..................................... 128

Proper Solution.......................... 176

Replacing.................................... 178

Temperature Gauge.................... 59

Corrosion Protection..................... 220

Crankcase Emissions Control
System......................................... 256

Cruise Control Operation............... 67
Customer Relations Office........... 260
DANGER, Explanation of................
ii
Dashboard.................................... 2, 52
Daytime Running Lights................. 62 Dead Battery, What to Do............ 231
Defects, Reporting Safety............. 263
Defog and Defrost......................... 100
Defogger, Rear Window................. 65
DEXRON ®
III Automatic
Transmission Fluid.................... 182
Dimensions..................................... 250
Dimming the Headlights................ 62
Dipstick Automatic Transmission........... 182
Engine Oil................................... 127
Directional Signals........................... 63
Disabled, Towing Your Car
If......
245
Disc Brake Wear Indicators......... 145 Disposal of Used Oil...................... 175
Doors Locking and Unlocking............... 75
Power Door Locks....................... 75
DOT Tire Quality Grading........... 252
Downshifting, 5-speed Manual Transmission.............................. 138
Drive Belts...................................... 195
Driver and Passenger Safety............ 5
Driving............................................ 135 Economy..................................... 129
In Bad Weather.......................... 149 In Foreign Countries................. 255

Economy, Fuel............................... 129

Emergencies on the Road............. 223 Battery, Jump Starting.............. 231
Brake System Indicator............ 238
Changing a Flat Tire................. 225
Charging System Indicator...... 236
Checking the Fuses................... 241
Low Oil Pressure Indicator...... 235
Malfunction Indicator Lamp.... 237
Manually Closing Moonroof.... 239 Overheated Engine................... 233
Emergency Brake............................ 87
Emergency Flashers....................... 65
Emergency Towing....................... 241
Emissions Controls........................ 256

CONTINUED

Inde
x

Engine
Coolant Temperature Gauge..... 59
Drive Belts.................................. 195 Malfunction Indicator Lamp................................ 54, 237
Oil Pressure Indicator........ 54, 235
Oil, What Kind to Use............... 171
Overheating................................ 233
Specifications............................. 250
Engine Speed Limiter........... 139, 142
Ethanol in Gasoline ....................... 254
Evaporative Emissions Controls.. 256
Exhaust Fumes................................ 49
Expectant Mothers, Use of Seat Belts by......................................... 19
Exterior, Cleaning the................... 216
Fabric, Cleaning............................. 218

Fan, Interior...................................... 94

Features, Comfort and
Convenience................................. 93

Filling the Fuel Tank..................... 124
Filters Air Cleaner................................. 186
Oil................................................ 173

First Gear, Shifting........................ 142

5-speed Manual Transmission
Checking Fluid Level................ 183
Shifting the................................. 138
Flashers, Hazard Warning.............. 65
Flat Tire, Changing a.................... 225
Fluids Automatic Transmission........... 182Brake........................................... 183

Clutch.......................................... 183

Manual Transmission............... 183
Power Steering........................... 185
Windshield Washer................... 181
FM Stereo Radio Reception.................................... 103
Folding Rear Seat............................ 83
Foreign Countries, Driving in...... 255
Four-way Flashers........................... 65
Front End, Towing by Emergency Wrecker................. 245

Fuel.................................................. 123
Fill Door and Cap....................... 124
Gauge............................................ 59

Octane Requirement................. 123

Oxygenated................................ 254
Reserve Indicator......................... 54
Tank, Filling the......................... 124
Fuses, Checking the...................... 240
Gas Mileage, Improving................ 129

Gasohol........................................... 254

Gasoline.......................................... 123 Fuel Reserve Indicator................ 54
Gauge............................................ 59
Octane Requirement................. 123
Tank, Filling the......................... 124
Gas Station Procedures................. 124
Gauges
Engine Coolant Temperature.... 59
Fuel............................................... 59

Gearshift Lever Positions
Automatic Transmission
........... 140

5-speed Manual
Transmission.......................... 138
Glass Cleaning............................... 219

Glove Box......................................... 78

Inde
x

Halogen Headlight Bulbs.............. 207

Hatch................................................. 76
Opening the................................. 76

Open Monitor Light.................... 56

Hazard Warning Flashers.............. 65

Headlights
Aiming......................................... 205Daytime Running Lights............. 62
High Beam Indicator................... 57
High Beams, Turning on............ 62
Low Beams, Turning on............. 62
Reminder Chime.......................... 62
Replacing Halogen Bulbs......... 207

Turning on................................... 62

Head Restraints...............................
82

Heating and Cooling........................ 94

High Altitude, Starting at.............. 137

High-Low Beam Switch.................. 62

High-mount Brake Light............... 209

Hood Latch.....................................
187

Hood, Opening the........................
125
Horn..................................................
61

Hot Coolant, Warning About........
176

Hydraulic Clutch............................ 184
Hydroplaning.................................. 150

Identification Number, Vehicle.... 248
If Your Car Has to be Towed....... 245
Ignition Keys............................................... 71
Switch............................................ 71
Timing Control System............. 257
Immobilizer System......................... 72
Important Safety Precautions.......... 6
Indicator Lights, Instrument
Panel.............................................. 53

Infant Restraint................................ 21
Inflation, Proper Tire .................... 196
Inside Mirror.................................... 86

Inspection, Tire.............................. 197

Instrument Panel......................... 2, 52
Instrument Panel Brightness......... 63
Interior Cleaning............................ 218
Interior Lights.................................. 92
Introduction......................................... i
Jacking up the Car......................... 226

Jack, Tire....................................... 226
Jump Starting................................. 231

Keys................................................... 71

Label, Certification........................ 248
Lane Change, Signaling.................. 63
Lap/Shoulder Belts......................... 42
Leaking of Exhaust into Car.......... 49
Leather, Cleaning.......................... 218
Lighter, Cigarette............................ 90
Lights Bulb Replacement..................... 207

Indicator........................................ 53

Parking.......................................... 62

Turn Signal................................... 63

Limited Slip Differential............... 148
LOCK (Ignition Key Position)....... 74
CONTINUED
