Following are the steps f or
determining the correct cargo and
luggage load limit.
The resulting f igure equals the
available amount of cargo and
luggage load capacity.
The maximum load limit f or your
vehicle is 1,158 lbs (525 kg). This
f igure includes the total weight of all
occupants, cargo, accessories, and
the tongue weight if you are towing a
trailer.
Locate the statement, ‘‘the
combined weight of occupants and
cargo should never exceed 1,158
lbs (525 kg)’’ on your vehicle’s
placard (on the driver’s doorjamb).
Determine the combined weight
of the driver and passengers that
will be riding in your vehicle.
(Seven is the seating capacity of
your vehicle.) Subtract the combined weight of
the driver and passengers f rom
1,158 lbs (525 kg).
For example, if there will be f ive 150
lbs (70 kg) occupants in your vehicle,
the amount of available cargo and
luggage load capacity is 408 lbs (175
kg).
5 150 lbs (70 kg) = 750 lbs (350
kg)
1,158 lbs (525 kg) 750 lbs (350 kg)
= 408 lbs (175 kg) If your vehicle will be towing a
trailer, load f rom your trailer will
be transf erred to your vehicle.
Consult this manual to determine
how this reduces the available
cargo and luggage load capacity of
your vehicle.
Determine the combined weight
of accessories, luggage, and cargo
beingloadedinthevehicle.The
weight may not saf ely exceed the
available cargo and luggage load
capacity calculated in step 4 [408
lbs(175kg)inthisexample].
1.
2. 3.
4.
5.
6.
Load Limit
Bef ore Driving
Carrying Cargo
246
Overloading or improper
loading can affect handling and
stability and cause a crash in
which you can be hurt or killed.
Follow all load limits and other
loading guidelines in this
manual.

Steering Wheel..................................
Adjustment .89
.............
Anti-theft Column Lock . 92
...
Stereo Sound System . 145,163,183
....................
Storing Your Vehicle .349
........................
Sunglasses Holder .124
........................................
Sun Visor .124
Supplemental Restraint System ......................................
Servicing .61
.........................
SRS Indicator .56 ,68
...................
System Components . 50
..................................
Synthetic Oil .308
.....................
Underside, Cleaning .357
Unexpected, Taking Care ..........................................
of the .359
....
Unif orm Tire Quality Grading . 392
........................
Unleaded Gasoline .236
.....................
Upholstery Cleaning .354
.......
Used Oil, How to Dispose of . 310
................................
Vanity Mirror .125
.................
Vehicle Capacity Load . 246
......................
Vehicle Dimensions .390
....
Vehicle Identif ication Number . 388
.....................................
Tachometer .74
......
Taillights, Changing Bulbs in . 344
.
Taking Care of the Unexpected . 359
...................
Tape Player . 151,177,191
Technical Descriptions ......
DOT Tire Quality Grading . 392
.....
Emissions Control Systems . 397
.....................
Oxygenated Fuels .395
Three Way Catalytic ...............................
Converter .399
.......................
Temperature Gauge .75 ...................
Tensioners, Seat Belts . 48
............................
Thef t Protection .182
..
Three Way Catalytic Converter . 399
....................................
Timing Belt .332
....................................
Tire Chains .338
.........
Tire, How to Change a Flat . 361
...........................
Tire Inf ormation .394
...............................................
Tires .332
..............................
Air Pressure .332
...................................
Balancing .335
.........................
Checking Wear .334
..........................
Compact Spare .360
......
DOT Tire Quality Grading . 392
......................................
Inf lation .332
..................................
Inspection .334
...................................
Replacing .336
......................................
Rotating .335
...........................................
Snow .338
............................
Specif ications .391
................................
Tire Chains .338
Towing .....................................
A Trailer .271
................
Emergency Wrecker . 385
Your Vehicle Behind a ............................
Motorhome .283
.............
Transf er Assembly Fluid . 318Transmission
...............
Checking Fluid Level . 317
...........................
Fluid Selection .317
..............
Identif ication Number . 388
.............
Shif ting the Automatic . 253
.....................................
Treadwear .392
.......................................
Trip Meter .75
....................................
Turn Signals .83
...................
Tools, Tire Changing . 361
Index
T U
V
VIII
