2005 MDX Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through\
this reference.
For a printed owner's manual, click on authorized manuals or go to www.h\
elminc.com.
Contents

Introduction ........................................................................\
............................................................... i
A Few Words About Safety........................................................................\
........................................ ii
Your Vehicle at a Glance........................................................................\
........................................... 4
Driver and Passenger Safety ........................................................................\
.................................... 7
Seat belts, SRS, and child protection.
Instruments and Controls........................................................................\
......................................... 57
Indicators, gauges, dashboard, and steering column.
Features ........................................................................\
..................................................................... 105
Climate, audio, rear entertainment, steering wheel, secruity, cruise con\
trol, HomeLink and Onstar
Before Driving........................................................................\
.......................................................... 185
Fuel, vehicle break-in, and cargo loading.
Driving ........................................................................\
..................................................................... . 197
Engine and transmission operation.
Maintenance........................................................................\
............................................................. 227
Schedules, fluid checking, minor services, and vehicle storage.
Taking Care of the Unexpected........................................................................\
.............................. 259
Flat tire, dead battery, overheating, fuses.
Technical Information........................................................................\
............................................ . 281
Vehicle specifications, tires, fuels, and emissions controls.
Warranty and Customer Relations (U.S. and Canada)................................................................ 295
Warranty and contact information.
Authorized Manuals (U.S. only)........................................................................\
.............................. 299
How to order.
Index........................................................................\
........................................................................\
..... I
Service Information Summary
Fluid capacities and tire pressures.
Important Handling Information. ........................................................................\
................... iii

µ
This section gives you important
inf ormation about how to protect
yourself and your passengers. It
shows you how to use seat belts
properly. It explains how your
airbags work, and it tells you how to
properly restrain infants and
children in your vehicle.
.........
Important Safety Precautions . 8
.......
Your Vehicle’s Saf ety Features . 9
.........
Protecting Adults and Teens . 13
.....
1. Close and Lock the Doors . 13
...........
2. Adjust the Front Seats . 13
............
3. Adjust the Seat-Backs . 14
...
4. Adjust the Head Restraints . 15
5. Fasten and Position the Seat .....................................
Belts .16
6. Maintain a Proper Sitting ................................
Position .18
.....
Advice f or Pregnant Women . 18
...
Additional Safety Precautions . 19Additional Inf ormation About Your
.................................
Seat Belts .21
..
Seat Belt System Components . 21
......................
Lap/Shoulder Belt .21
........ 22
...............
Seat Belt Maintenance . 23
Additional Inf ormation About Your .....................................
Airbags .24
......
Airbag System Components . 24
......... 26
........................
Advanced Airbag .28
...
How Your Side Airbags Work . 29
How Your Side Curtain Airbag .........................................
Work .31
How the SRS Indicator Light .......................................
Works .32
How The Side Airbag Of f ......................
Indicator Works .32
How the Passenger Airbag ...............
Of f Indicator Works . 33
.............................
Airbag Service .33
...
Additional Safety Precautions . 34
Protecting Children General ................................
Guidelines .35
All Children Must Be ...............................
Restrained .35 All Children Should Sit in a Back
...........................................
Seat .36
The Passenger’s Front Airbag Can Pose Serious Risks to ...............................
Children .36
If You Must Drive with Several ...................................
Children .38
If a Child Requires Close ..................................
Attention .38
...
Additional Safety Precautions . 38
Protecting inf ants and .........................
Small Children .40
.......................
Protecting Inf ants .40
.........
Protecting Small Children . 41
.....................
Selecting a Child Seat .43
....................
Installing a Child Seat .44
...............................
With LATCH .45
..........................
With a Seat Belt .47
..............................
With a Tether .48
...........
Protecting Larger Children . 50
...................
Checking Seat Belt Fit . 51
......................
Using a Booster Seat .51
......
When Can a Child Sit in Front . 52
.............
Carbon Monoxide Hazard . 54
...................................
Saf ety Labels .55
Automatic Seat Belt Tensioners
How Your Front Airbags Work
Driver and Passenger Saf ety
Driver and Passenger Saf ety
7

If nooneisridinginthefrontseat,
the airbag will be automatically shut
of f , but the indicator will not come
on.
However, if the indicator comes on
with no passenger in the f ront, or
with an adult in the seat, there may
be a problem with the advanced
airbag system. Have the vehicle
checked by the dealer as soon as
possible.
The Passenger Airbag Of f indicator
mayalsocomeonandgooff
repeatedly if total weight on the seat
is near the airbag cutof f threshold.Your airbag systems are virtually
maintenance f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:
Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. Any
seat belt tensioner that activates
must also be replaced.
Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by your dealer or a
knowledgeable body shop.
Take your vehicle to an
authorized dealer as soon as
possible. If you ignore this
indication, your airbags may not
operate properly.
This indicator alerts you that the
passenger’s f ront airbag has been
shut of f because weight sensors
detect the weight of an inf ant or
small child on the f ront passenger’s
seat. It does there is a
problem with the airbag.
If this happens, have the passenger
ride properly restrained in a back
seat. If the passenger must ride in
front, move the seat as far to the
rear as possible, have the passenger
sit upright, and wear the seat belt
properly.
How the Passenger Airbag Of f
Indicator Works
Airbag Service
not mean
Additional Inf ormation About Your Airbags
An airbag ever inf lates. T he SRS indicat or alert s you t o aproblem.
Driver and Passenger Saf ety
33
PASSENGER AIRBAG OFF INDICATOR

This indicator normally comes on f or
a f ew seconds when you turn the
ignition to ON (II).
This indicator normally comes on f or
a f ew seconds when you turn the
ignition to ON (II).
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are extremely low on
pressure.
If this happens, pull to the side of the
road when it is saf e, check which tire
has lost the pressure on the Tire
Pressure Monitor, and determine the
cause. If it is because of a f lat tire,
replace the flat tire with the compact
spare (see page ), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service
(see page ). Ref er to page
f or more inf ormation. The appropriate tire indicator will
come on along with the Low Tire
Pressure Indicator if a tire is
extremely under inf lated or has
suddenly lost pressure. See Low Tire
Pressure Indicator f or what to do if
this indicator comes on.
If this indicator comes on and stays
on at any other time, or it does not
come on when you turn the ignition
switch to ON (II), there is a problem
with the TPMS. With this indicator
on, the low tire pressure indicator
and the tire pressure monitor will not
come on when a tire loses pressure.
Take the vehicle to your dealer to
have the system checked.
261
274
205
Instrument Panel Indicators
Tire Pressure Monitoring
System (T PMS) Indicator
Low Tire Pressure
Indicator Tire Pressure Monitor
66

The OnStarsystem in your vehicle
gives you access to a wide range of
services and information with the
touch of a button. An OnStar advisor
is available 24 hours a day, 7 days a
week.
The Saf e and Sound Plan provides
these f eatures: Roadside Assistance
Emergency Services
Automatic Notif ication of Airbag
Deployment
Accident Assist
Remote Door Locking/Unlocking
Stolen Vehicle Tracking
Misplaced Vehicle Assistance
Online Concierge Services. The Directions and Connections
Plan provides these additional
f eatures:
Route Support
Ride Assist
Inf ormation and Convenience
Services
The Luxury and Leisure Plan adds
personal concierge services.
The OnStar buttons and indicator
are located on the ceiling near the
f ront map lights.
U.S. Touring model with NavigationSystemOnStar Control Panel
OnSt ar
Features
173
EMERGENCY BUTTON SYSTEM
STATUS
INDICATOR
CALL ANSWER/
CALL END BUTTON
OnStar
BUTTON
VOICE
ACTIVATED
KEYPAD

µµ
µ
µ
µ
µ
µ
µ If you are ever in an
accident that causes the airbags to
deploy, the OnStar system
automatically places a call (provided
the OnStar system and your vehicle’s
electrical system are still intact). The
advisor will attempt to speak to you
to evaluate the situation, and contact
the nearest emergency services
provider.
The OnStar
advisor can help you if you are ever
in a minor accident by asking you f or
inf ormation about the accident.
Complete, detailed inf ormation will
make it easier to complete accident
reports and insurance claims.
The OnStar system uses the Global
Positioning System (GPS) to locate
your vehicle whenever you place a
call. This allows the advisor to
quickly contact the nearest services
without requiring you to provide
detailed directions.
Contact
the OnStar advisor if you need
assistance with a problem (f lat tire,
out of f uel, etc.) while traveling. The
advisor will contact an appropriate
agency to come and assist you.
Contact an
OnStar advisor if you have an
emergency situation. The advisor
will contact the nearest emergency
services provider (ambulance, f ire
department, etc.) and advise them of
your situation.
This indicator shows you the status
of the system.
The system is ready
for use.
Acallisin
progress.
There is a problem
with the system. Press the OnStar
button to contact an advisor. If the
call connects, the advisor will assist
you with verif ying the system’s
operation. If you are not able to
contact an advisor, take your vehicle
to an Acura dealer to have the
system diagnosed.
There is a problem
with the system while a call is in
progress. A utomatic Notif ication of A irbag
Deployment
A ccident A ssist
Saf e and Sound Plan Features
Roadside Assistance
Emergency Services
System Status Indicator
Solid Green
Blinking Green
Solid Red
Blinking Red
OnSt ar
176

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Avoid full-throttle starts and rapid
acceleration.
Do not change the oil until the
scheduled maintenance time. Avoidhardbrakingforthefirst
200 miles (300 km).
Do not tow a trailer.
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced. Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the Malfunction Indicator
Lamp on your instrument panel to
come on. If this happens, contact
your authorized Acura dealer f or
service.
Some gasoline today is blended with
oxygenates such as ethanol or
MTBE. Your vehicle is designed to
operate on oxygenated gasoline
containing up to 10 percent ethanol
by volume and up to 15 percent
MTBE by volume. Do not use
gasoline containing methanol.
If you notice any undesirable
operating symptoms, try another
service station or switch to another
brand of gasoline.
For f urther important f uel-related
inf ormation, please ref er to your
Quick Start Guide.
Use of a gasoline with a pump octane
less than 86 can lead to engine
damage.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT. Your vehicle is designed to operate
on premium unleaded gasoline with a
pump octane number of 91 or higher.
Useof aloweroctanegasolinecan
cause occasional metallic knocking
noises in the engine and will result in
decreased engine perf ormance.
We recommended using a quality
gasoline containing detergent
additives that help prevent fuel
system and engine deposits.
Break-in Period
Fuel Recommendation
Break-in Period, Fuel Recommendation
186

Screw the fuel fill cap back on
until it clicks at least three times.
If you do not properly tighten the
cap, the Malf unction Indicator
Lampmaycomeon(seepage).
Push the f uel f ill door closed until
it latches.
Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower lef t corner of the dashboard.
The hood will pop up slightly.Put your f ingers under the f ront
edge of the hood near the center.
Slide your hand to your lef t until
you f eel the hood latch handle.
Push this handle up until it
releases the hood. Lif t the hood.
If the hood latch handle moves stif f ly,
or if you can open the hood without
lifting the handle, the mechanism
should be cleaned and lubricated.
1.
5.
6.
2.
273
Service Station Procedure
Opening and Closing the Hood
188
HOOD RELEASE HANDLE
LATCH

Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure indicator and the
appropriate tire on the tire pressure
monitor to come on. Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.When the tire pressure monitoring
system warning light is lit, one or
more of your tires is signif icantly
under-inf lated. You should stop and
check your tires as soon as possible.
If you think you can saf ely drive a
short distance to a service station,
proceed slowly, and inf late the tire to
the recommended pressure shown
on the driver’s doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire.Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Although your tire pressure is
monitored, each tire should be
checked monthly, including the
spare.
Check the pressure with the tires
cold, af ter the vehicle has been
parked f or at least 2 hours.
Set to the recommended inf lation
pressure as specif ied on the vehicle
placard and in the owner’s manual
(see page ).
252
Tire Pressure Monitoring System (TPMS)
Low Tire Pressure
Indicator
Driving
205

The appropriate tire indicator and
low tire pressure indicator comes on
if a tire becomes signif icantly
underinf lated. Follow the
instructions under ‘‘Low Tire
Pressure Indicator’’.The indicator comes on and stays on
if there is a problem with the tire
pressure monitoring system.
Af ter you replace the f lat tire, the
Low Tire Pressure indicator stays on.
This is normal; the system is not
monitoring the spare tire pressure.
Manually check the spare tire
pressure to be sure it is correct.
If this happens, the system will shut
of f and no longer monitor tire
pressures. Have the system checked
by your dealer as soon as possible. Each wheel is equipped with a tire
pressure sensor mounted inside the
tire behind the valve stem. You must
use TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
qualif ied technician.
Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.
If you have a f lat tire, the low tire
pressure and tire monitor indicators
will come on. Replace the indicated
flat tire with the compact spare tire
(see page ).
261
Tire Pressure Monitoring System (TPMS)
Tire Pressure Monitor Tire Pressure Monitoring
System (T PMS) Indicator
Changing a T ire with T PMS
206
