steering Acura MDX 2006 Owner's Guide

Your vehicle has higher ground
clearance that allows you to travel
over bumps, obstacles, and rough
terrain. It also provides good
visibility so you can anticipate
problems earlier.
Because your vehicle rides higher
of f the ground, it has a high center
of gravity that can cause it to roll
over if you make abrupt turns. Utility
vehicles have a signif icantly higher
roll over rate than other types of
vehicles.
To prevent rollovers or loss of
control:Take corners at slower speeds
than you would with a passenger
vehicle.
Avoid sharp turns and abrupt
maneuvers whenever possible. Do not modif y your vehicle in any
way that would raise the center of
gravity.
Do not carry heavy cargo on the
roof .
Youshoulddothefollowingchecks
and adjustments bef ore you drive
your vehicle. Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice. Make sure the doors and tailgate
are securely closed and locked. Check the steering wheel
adjustment (see page ). Check the adjustment of the
inside and outside mirrors (see
page ). Check the seat adjustment (see
page ). Check that any items you may be
carrying are stored properly or
f astened down securely.
When you start the engine, check
the gauges and indicators in the
instrument panel (see page ).
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure. Fasten your seat belt. Check that
your passengers have f astened
their seat belts (see page ).
1.
2. 3.
4.
5.
6.
7.
8.
9.
95
1659
86
78
See page f or of f -highway drivingguidelines. 224
Driving Guidelines, Preparing to Drive
Driving Guidelines
Preparing to Drive
200

Check the brakes after driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious in your driving.
Your vehicle is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The anti-lock
brake system (ABS) helps you retain
steering control when braking very
hard.
The hydraulic system that operates
the brakes has two separate circuits.
Each circuit works diagonally across
the vehicle (the lef t-f ront brake is
connected with the right-rear brake,
etc.). If one circuit should develop a
problem, you will still have braking
at two wheels.If the brake pads need replacing, you
will hear a distinctive, metallic
screeching sound when you apply
the brake pedal. If you do not have
the brake pads replaced, they will
screech all the time. It is normal f or
the brakes to occasionally squeal or
squeak when you apply them.
Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear. Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, and reduces their ef f ectiveness.
It also keeps your brake lights on all
the time, conf using drivers behind
you. Braking System DesignBrake Wear Indicators
Braking System
210

The anti-lock brake system (ABS)
helps prevent the brakes f rom
locking up, and helps you retain
steering control by pumping the
brakes rapidly, much f aster than a
person can do it.
The ABS also balances the f ront-to-
rear braking distribution according
to vehicle loading.
Let the ABS work f or you by always
keeping f irm, steady pressure on the
brake pedal. This is sometimes
ref erred to as ‘‘stomp and steer.’’If this indicator comes on, the anti-
lock f unction of the braking system
has shut down. The brakes still work
like a conventional system, but
without anti-lock. You should have
your dealer inspect your vehicle as
soon as possible.
You will f eel a pulsation in the brake
pedal when the ABS activates, and
may hear some noise. This is normal:
it is the ABS rapidly pumping the
brakes. On dry pavement, you will
need to press on the brake pedal
very hard before the ABS activates.
However, you may f eel the ABS
activate immediately if you are trying
to stop on snow or ice.
If the indicator comes on while
driving, test the brakes as instructed
on page .274
You should never pump the brake pedal.
Anti-lock Brakes (ABS)
ABS Indicator
Driving
211

on loose or
uneven surf aces, such as gravel or
snow, than a vehicle without anti-
lock.
If the ABS indicator and the brake
system indicator come on together
and the parking break is f ully
released, the front-to-rear braking
distribution system may also shut
down.
It only helps with steering
control during braking.
such as trying to take a
corner too f ast or making a sudden
lane change.
Always steer moderately
when you are braking hard. Severe
or sharp steering wheel movement
can still cause your vehicle to veer
into oncoming traffic or off the road. Important Saf ety Reminders A vehicle with A BS may require a longer distance to stop
A BS does not reduce the time or
distance it takes to stop the
vehicle.
A BS will not prevent a skid that
results f rom changing direction
abruptly,
A BS cannot prevent a loss of
stability.
Anti-lock Brakes (ABS)
212

Your vehicle has been designed to
primarily carry passengers and their
cargo. You can also use it to tow a
trailer if you caref ully observe the
load limits, use the proper equipment,
and f ollow the guidelines in this
section.The weight that the tongue of a f ully
loaded trailer puts on the hitch
shouldbe5to10percentof thetotal
trailer weight f or boat trailers, and 8
to 15 percent of total trailer weight
f or all other trailers. (See pagef or limits f or your towing
situation). Too much tongue load
reduces front-tire traction and
steering control. Too little tongue
load can make the trailer unstable
and cause it to sway.
The maximum allowable weight of
the trailer and everything in or on it
depends on the number of occupants
inyourvehicleandthetypeof trailer
being towed (see page ).
Towing a trailer that is too heavy can
seriously af f ect your vehicle’s
handling and perf ormance. It can
also damage the engine and driven.
Be sure to read the
sectiononpage
if you plan to tow of f paved
surf aces.
217
217
224
Towing Weight Limits
Load Limit
Off-Highway
Driving Guidelines
T ot al T railer Weight Tongue Load
Driving
215
Exceeding any load limit or
improperly loading your vehicle
and trailer can cause a crash in
which you can be seriously hurt
or killed.
Check the loading of your
vehicle and trailer carefully
beforestartingtodrive.

Î
Î
ÎNumber of
Occupants 2
3
4
5
6
7 Equipped with transmission cooler and power steering f luid cooler.
Max. T railer Weight Max. T ongue Load
T owing is Not Recommended
Number of
Occupants 2
3
4
5
6
7 Equipped with transmission cooler and power steering f luid cooler.
Max. T railer Weight Max. T ongue Load
T owing is Not Recommended
Towing Weight Limits
Driving
217
4500 lbs (2045 kg)
4500 lbs (2045 kg)
4500 lbs (2045 kg)
4000 lbs (1820 kg) 1700 lbs (770 kg) 450 lbs (205 kg)
410 lbs (185 kg)
310 lbs (140 kg)
215 lbs (100 kg)
90 lbs (40 kg)
3500 lbs (1590 kg)
3500 lbs (1590 kg)
3000 lbs (1365 kg) 2000 lbs (910 kg)
1000 lbs (455 kg) 450 lbs (205 kg)
410 lbs (185 kg)
310 lbs (140 kg)
215 lbs (100 kg)
90 lbs (40 kg)
The corresponding weight limits assume occupants fill seats from the front of the vehicle to the back, each occupant weighs 150 lbs (70 kg) and each has 1 5lbs(7
kg) of luggage in the cargo area.
Total Trailer Weight and Tongue Load Limits: BOAT TRAILERS
OTHER TYPES OF TRAILERS

Towing generally requires a variety
of supplemental equipment. To
ensure the best quality, we
recommend that you purchase Acura
equipment whenever possible.
Your dealer of f ers a trailer package
that includes a hitch, a ball mount, a
wiring harness, a heavy-duty
transmission f luid cooler.
Discuss any additional needs with
your trailer sales or rental agency,
and make sure all equipment is
properly installed, maintained, and
also meets state, f ederal, province,
and local regulations.We strongly recommend that you
have your dealer install an Acura
hitch and use the required f luid
coolers. Using non-Acura equipment
may result in serious damage to your
vehicle.
To help prevent overheating, a
heavy-duty transmission f luid cooler
and a heavy-duty power steering
f luid cooler are required f or trailer
towing. These coolers are available
only f rom your dealer.
A weight distributing hitch is not
recommended f or use with your
vehicle, as an improperly adjusted
weight distributing hitch may reduce
handling, stability, and braking
perf ormance.
Check the weight of the unhitched
trailer. Limit: See page .
Calculate the tongue load.
Subtract the weight in Step
5f rom
the
weight in step 6.
Limit: See page .
Range: 5-10% f or boat trailers 8-15% f or other trailers
6.
7.
217
217
CONT INUED
Towing a Trailer
T owing Equipment and
A ccessoriesHitch
T ransmission Fluid Cooler andPower St eering Fluid Cooler
Weight Distributing Hitch
Driving
219

When climbing hills, closely watch
your temperature gauge. If it nears
the red (hot) mark, turn the air
conditioning of f , reduce speed and, if
necessary, pull to the side of the
road to let the engine cool.
If the transmission shif ts f requently
while going up a hill, shif t to D3.
If you must stop when f acing uphill,
use the f oot brake or parking brake.
Do not try to hold the vehicle in
placebypressingontheaccelerator,
as this can cause the automatic
transmission to overheat.
When driving down hills, reduce
your speed and shif t down to D . Do
not ‘‘ride’’ the brakes.Crosswinds and air turbulence
caused by passing trucks can disrupt
your steering and cause trailer to
sway. When being passed by a large
vehicle, keep a constant speed, and
steer straight ahead. Do not try to
make quick steering or braking
corrections.
Always drive slowly and have
someone guide you when backing up.
Grip the of the steering wheel,
then turn the wheel to the left to get
the trailer to move to the lef t. Turn
the wheel to the right to move the
trailer to the right.
Follow all normal precautions when
parking, including putting the
transmission in Park and f irmly
setting the parking brake. Also, place
wheel chocks at each of the trailer’s
tires.If the vehicle’s tires slip when
retrieving a boat f rom the water,
shif t to f irst gear, and turn on VTM-4
Lock (see page ). Disengage
VTM-
4Lock as soon as the boat is
out of the water to prevent damage
to the VTM- 4system. 206
3
bottom
Towing a Trailer
Driving on Hills
Handling Crosswinds and Buf f et ing
Backing UpParking Ret rieving a Boat
Remember, it
takes longer to slow down and
stop when towing a trailer.
Driving
223

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
This section also includes
Maintenance Schedules f or normal
driving and severe driving conditions,
a Maintenance Record, and instruc-
tions f or simple maintenance tasks
you may want to take care of
yourself .
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.......................
Maintenance Saf ety .228
.................
Maintenance Schedule . 229
....................
Maintenance Record .233
..............................
Fluid Locations .236
........................
Adding Engine Oil .237
.........
Changing the Oil and Filter . 238
..............................
Engine Coolant .240
....................
Windshield Washers .241
....
Automatic Transmission Fluid . 242
....................................
Brake Fluid .243
....................
Power Steering Fluid . 244
....................................
Timing Belt .244
.............................................
Lights .245
..................
Dust and Pollen Filter . 248
................
Cleaning the Seat Belts . 249
.....................................
Floor Mats .249
.................................
Wiper Blades .250
...............................................
Tires .252
...................
Checking the Battery . 257
.............................
Vehicle Storage .258
299
Maintenance
Maint enance
227

Î
ÎÌ
Ì
Ì
Î
Î Î
231
Service the items listed at the indicated distance (or time, if given).
miles x 1,000
km x 1,000 Check oil and coolant at each fuel stop
Check inflation and condition once a month
Every 7,500 miles (12,000 km)
Every 3 years (independent of mileage)
At 120,000 miles (192,000 km) or 10 years, then every 60,000 miles (96,000 km) or 5 years
( (
O
O r
re
ev
ve
er
ry
y 7
7y
ye
ea
ar
rs
s, , w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
(
(
O
O r
re
ev
ve
er
ry
y 1
1y
ye
ea
ar
r,
, w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
(
( O
O r
re
ev
ve
er
ry
y 2
2y
ye
ea
ar
rs
s, , w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
Every 7,500 miles (12,000 km) or every 1 year, whichever comes first
At every 15,000 miles (24,000 km) up to 30,000 miles (48,000 km) or every 1 year, then every 30,000 miles (48,000 km) or 2 years. At 45,000 miles (72,000 km) or 3 years, then every 30,000 miles (48,000 km) or 2 years.
See information on maintenance and emissions warranty, middle column, page .
( ( O
O t
th
h e
er
rw
w i
is
se e a
ad
d j
ju
u s
stt o
o n
nl
ly
y i
if
f n
n o
oi
is
sy y )
)
120
192 135
216150
240
90
144
75
120
60
96
45
72
30
48
15
24 105
168
Check engine oil and coolant
Check tires
Replace engine oil
Rotate tires (follow pattern on page 254)
Replace engine oil filter
Check front and rear brakes
Check parking brake adjustment
Inspect the following items: Tie-rod ends, steering gearbox, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Exhaust system
Fuel lines and connections
Inspect drive belts
Replace dust and pollen filter
Replace air cleaner element
Inspect valve clearance
Replace automatic transmission fluid
Replace transfer fluid
Replace VTM-4 rear differential fluid
Inspect idle speed
Replace spark plugs
Replace timing belt and inspect water pump
Replace engine coolant
Replace brake fluid
1:
2:: 230
1
1 2
Maintenance Schedule for Normal Conditions
