engine Acura MDX 2008 Owner's Manual

2008 MDX Online Reference Owner's Manual
Contents

Owner's Identification Form

Introduction .......................................................................................................................................................... i A Few Words About Safety .............................................................................................................................. iii Important Handling Information .................................................................................................................... iv
Your Vehicle at a Glance (main controls) .................................................................................................... 3
Driver and Passenger Safety (seat belts, SRS, and child protection) .................................................... 5
Instruments and Controls
(indicators, gauges, multi-information display, dashboard, and steering column)
..... 61
Features (
climate control,audio,rear entertainment,steering wheel,security,cruise control,and other convenience items
)
......... 169
Before Driving (fuel, vehicle break- in, and cargo loading) ..................................................................... 321
Driving (engine and transmission operation) ................................................................................................ 337
Maintenance (minder, fluid checking, minor services, and vehicle storage)........................................... 381
Taking Care of the Unexpected (flat tire, dead battery, overheating, and fuses) ............................... 423
Technical Information (vehicle specifications, tires, and emissions controls) ....................................... 449
Warranty and Customer Relations (U. S. and Canada only) (warranty and contact information) ... 465
Authorized Manuals (U. S. only) (how to order) ......................................................................................... 469
Index ............................................................................................................................... ........................................ I

Service Information Summary ( fluid capacities and tire pressures)
1 00X31-STX-6102

A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
Explains the purpose of each
instrument panel indicator and gauge,
and how to use the controls on the
dashboard and steering column.What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
The proper way to start the engine,
shif t the transmission, and park; plus
what you need to know if you’re
planning to tow a trailer.
ID numbers, dimensions, capacities,
and technical information.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.
How to operate the climate control
system, the audio system, rear
entertainment system, and other
convenience f eatures. The maintenance minder shows you
when you need to take your vehicle
to the dealer for maintenance service.
There is also a list of things to check
and instructions on how to check
them.
This section covers several problems
motorists sometimes experience,
and details how to handle them.A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump.
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls
Features Bef ore Driving
Driving
Maintenance
T echnical Inf ormation
T aking Care of the Unexpected Warranty and Client Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
Overview of Contents
2
\f—\f—\fy\f
y
()-
\fy\f\f\fy
2008 MDX

After all occupants have adjusted
their seats and head restraints, and
put on their seat belts, it is very
important that they continue to sit
upright, well back in their seats, with
their feet on the floor, until the
vehicle is parked and the engine is
off.In addition, an occupant who is out of
position in the f ront seat can be
seriously or f atally injured in a crash
by striking interior parts of the
vehicle or being struck by an
inflating front airbag.
Sitting improperly can increase the
chance of injury during a crash. For
example, if an occupant slouches,
lies down, turns sideways, sits
forward, leans forward or sideways,
or puts one or both f eet up, the
chance of injury during a crash is
greatly increased. Maintain a Proper Sitting
Position
6.
Protecting A dults and Teens
Driver and Passenger Saf ety
17
Sitting improperly or out of
position can result in serious
injury or death in a crash.
Always sit upright, well back in
the seat, with your feet on the
floor.
\f—\f—\fy\f
y
()-
\fy\f\fy
2008 MDX

When you turn the ignition switch to
the ON (II) position, this indicator
comes on brief ly then goes of f . This
tells you the system is working
properly.This indicator
alerts you that the
passenger’s side airbag has been
automatically shut off. It does
mean there is a problem with your
side airbags.
The SRS indicator alerts
you to a potential problem
with your airbags or seat belt
tensioners.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:
If the SRS indicator does not come
on after you turn the ignition
switch to the ON (II) position.
If the indicator stays on after the
engine starts.
If the indicator comes on or
flashesonandoff whileyoudrive. You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display (see page
).
If you see any of these indications,
the airbags and seat belt tensioners
may not work properly when you
need them. When you turn the ignition switch to
the ON (II) position, the indicator
should come on brief ly and then go
out (see page ). If it does not
come on, stays on, or comes on while
driving without a passenger in the
f ront seat, you will also see a
‘‘PASSENGER SIDE AIRBAG OFF’’
message on the multi-information
display. Have the system checked
(see page ).
81
66
81
How the Side Airbag Of f
Indicator Works
How the SRS Indicator Worksnot
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
33
U.S.
Canada
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.
\f—\f—\fy\f\fy
()-
\fy\f\fy
2008 MDX

Your vehicle’s exhaust contains
carbon monoxide gas. Carbon
monoxide should not enter the
vehicle in normal driving if you
maintain your vehicle properly and
f ollow the inf ormation on this page.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the
underside.
Have the exhaust system inspected
f or leaks whenever:
With the tailgate open, airflow can
pull exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
tailgate open, open all the windows,
and set the climate control system as
shown below.
If you must sit in your parked vehicle
with the engine running, even in an
unconfined area, adjust the climate
control system as f ollows:
Select the f resh air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
1.
2.
3.
4.
Carbon Monoxide Hazard
58
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
\f—\f—\fy\fy
()-
\fy\f\fy
2008 MDX

If it stays on after you have fully
released the parking brake while
the engine is running, or if it
comes on while driving, it can
indicate a problem in the brake
system. You will also see a ‘‘LOW
BRAKE FLUID’’ or ‘‘CHECK
BRAKE SYSTEM’’ message on
the multi-information display (see
pages).For more inf ormation,
see page .
If this indicator comes on when
the engine is running, the battery
is not being charged, and you will
also see a ‘‘CHECK CHARGING
SYSTEM’’ message on the multi-
inf ormation display. For more
inf ormation, see page .
The engine can be severely
damaged if this indicator f lashes
or stays on when the engine is
running, or if a ‘‘CHECK ENGINE
OIL LEVEL’’ message is on the
multi-inf ormation display. For
more information, see page .
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display. For
more information, see page . This indicator has two f unctions:
Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. Driving with
the parking brake not f ully
released can damage the rear
brakes, axles, and tires.
If you drive without releasing the
parking brake, a beeper will sound,
and you will also see a ‘‘RELEASE
PARKING BRAKE’’ message on
the multi-information display (see
page ).
1.
2.
81
436
436 437 438
81
Instrument Panel Indicators
L ow Oil Pressure
Indicator
Charging System
Indicator
Malf unction Indicator
Lamp Parking Brake
and Brake
System
Indicator
Inst rument s and Cont rols
65
U.S. Canada
\f—\f—\fy\f\f\fy
()-
\fy\f\f\fy
2008 MDX

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator has two f unctions:This indicator monitors the
temperature of the automatic
transmission f luid. It should come on
f or a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on while driving,
it means the transmission fluid
temperature is too high. Pull to the
side of the road when it is saf e, shif t
to Park, and let the engine idle until
the indicator goes out.
You will also see an ‘‘A/T TEMP
HIGH’’ message on the multi-
inf ormation display (see page ).
If this happens, pull to the side of
the road when it is saf e, check
which tire has lost pressure on the
multi-inf ormation display, and
determine the cause. If it is
because of a flat tire, have the flat
tire repaired as soon as possible. If
two or more tires are
underinf lated, call a prof essional
towing service. For more
inf ormation, see page .
If this indicator begins to f lash,
there is a problem with the tire
pressure monitoring system
(TPMS). You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display. The indicator continues to
f lash f or a while (approximately 1
minute), then stays on. If this
happens, have your dealer check
the system as soon as possible.
For more inf ormation, see page
.
Check the tire pressure monitor on
the multi-inf ormation display and
determinethecause(seepage).
You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the multi-
inf ormation display (see page ). If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
1.
82
2.
82 446
352 354
Instrument Panel Indicators
Low Tire Pressure/
TPMS Indicator A/T Temperature
Indicator
68
Continuing to drive with the A/T
temperature indicator on may cause
serious damage to the transmission.
\f—\f—\fy\f\fy
()-
\fy\f\fy
2008 MDX

If the indicator blinks while driving,
it indicates the dif f erential
temperature is too high.
TEMP. HIGH’’ message on the
multi-inf ormation display (see page).
Pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If this indicator comes on at
any other time, there is a problem in
display (see page ). Take your
For more inf ormation, see page .
This indicator comes on when there
is a system message on the multi-
inf ormation display. Press the INFO
button on the steering wheel (see
page ) to see the message (see
page ).
Most of the time, this indicator
comes on along with other indicators
in the instrument panel such as the
seat belt reminder indicator, SRS
indicator, VSA system indicator, etc.
81
73
8282
348
Instrument Panel Indicators
Super Handling-All
Indicator
Message Indicator
Inst rument s and Cont rols
69

damage to the system.
——yy
()-
yy
vehicletoadealertohaveitchecked.
indicatorblinkingmaycauseserious
messageonthemulti-information
WheelDrive(SH-AWD®)
®theSH-AWD system. You will also
seea‘‘CHECKSH-AWD®SYSTEM’’
Youwillalsoseea‘‘SH-AWD®DIFF
ContinuingtodrivewiththeSH-AWD®
2008 MDX

This indicator comes on when you
turn on the cruise control system by
pressing the CRUISE button (see
page ).
This indicator comes on when you
set the cruise control. See pagef or inf ormation on operating the
cruise control. This indicator comes on with the
high beam headlights. For more
inf ormation, see page .
This indicator comes on when you
turn on the f og lights. For more
inf ormation, see page . This indicator reminds you that the
exterior lights are on. It comes on
when the light switch is in either the or position. This indicator
will also come on when the light
switch is in AUTO and the lights
turn on automatically. If you turn the
ignition switch to the ACCESSORY
(I) or the LOCK (0) position without
turning of f the light switch, this
indicator will remain on. A reminder
chime will also sound when you open
the driver’s door.
This indicator comes on brief ly when
you turn the ignition switch to the
ON (II) position. It will then go of f if
you have inserted a properly-coded
ignition key. If it is not a properly-
coded key, the indicator will blink,
and the engine’s f uel system will be
disabled (see page).
128
120118
270
270
Instrument Panel Indicators
Cruise Control Indicator Cruise Main Indicator High Beam Indicator
Fog L ight Indicator Lights On Indicator
Immobilizer System
Indicator
70
——yy
()-
yy
2008 MDX

This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise to
about the middle of the gauge. In
severe driving conditions, the pointer
may rise to the upper zone. If it
reaches the red (hot) mark, pull
safely to the side of the road. Forinstructions and precautions on
checking the engine’s cooling
system, see page .This shows how much f uel you
have. It may show slightly more
or less than the actual amount.
434
Gauges
Temperature Gauge Fuel Gauge
72
U.S. model is shown.SPEEDOMETER
FUEL GAUGE
TEMPERATURE
GAUGE TACHOMETER
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
\f—\f—\fy\f
\fy
()-
\fy\f\fy
2008 MDX
