Acura MDX 2013 Owner's Manual

Independent of the Maintenance
Midner information, replace the
brake fluid every 3 years.
Check the fluid level in the brake
fluid reservoir monthly.Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 fluid, from a sealed
container, as a temporary
replacement.
Using any non-Honda brake fluid can
cause corrosion and decrease the life
of the system. Have the brake
system flushed and refilled with
Honda Heavy Duty Brake Fluid DOT
3 as soon as possible.
Brake fluid marked DOT 5 is not
compatible with your vehicle's
braking system and can cause
extensive damage.
The fluid level should be between
the MIN and MAX marks on the side
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected for leaks or
worn brake pads.
MIN MAX
Brake Fluid
525
Maintenance
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Power Steering FluidCheck the level on the side of the
reservoir when the engine is cold.
The fluid should be between the
UPPER LEVEL and LOWER LEVEL.
If not add power steering fluid to the
UPPER LEVEL mark.
Pour the fluid slowly and carefully so
you do not spill any. Clean up any
spills immediately; it could damage
components in the engine
compartment.Always use Acura Power Steering
Fluid. You may use another power
steering fluid as an emergency
replacement, but have the power
steering system flushed and refilled
with Acura PSF as soon as possible.
A low power steering fluid level can
indicate a leak in the system. Check
the fluid level frequently, and have
the system inspected as soon as
possible.
If you are not sure how to add fluid,
contact your dealer.
Turning the steering wheel to full left or
right lock and holding it there can
damage the power steering pump.Timing Belt
The timing belt should be replaced at
the intervals shown in the
Maintenance Minder schedule.
Replace the timing belt every 60,000
miles (U.S.) or every 100,000 km
(Canada) if you regularly drive your
vehicle in any of the following
conditions:
●In very high temperatures
(over 110°F, 43°C).●In very low temperatures
(under－20°F,－29°C).●Frequently tow a trailer.
UPPER LEVEL
LOWER LEVEL
Power Steering Fluid, Timing Belt52612/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Headlight Aiming
The headlights were properly aimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area or pull a trailer,
readjustment may be required.
Adjustments should be done by your
dealer or another qualified
technician.
Low Beam Headlight Bulb
Replacement
The low beam headlight bulbs are a
type of high voltage discharge tube.
High voltage can remain in the
circuit even with the light switch off
and the key removed. Because of
this, you should not attempt to
examine or change a low beam
headlight bulb yourself. If a low
beam headlight bulb fails, take the
vehicle to your dealer to have it
replaced.Replacing a High Beam Headlight
Bulb
Your vehicle has halogen headlight
bulbs. When replacing a bulb, handle
it by its base, and protect the glass
from contact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean
cloth.
Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
1. Open the hood.
2. Remove the front bulkhead cover
(see page 516).
(Passenger's side)
Remove the power steering
reserve tank from the stay
brackets.STAY BRACKETS
POWER STEERING FLUID
CONTINUED
Lights
527
Maintenance
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

(Passenger's side)
Use a flat-tip screwdriver to
remove the holding clip from the
engine coolant reserve tank, and
then remove the engine coolant
reserve tank.
Remove the cap from the engine
coolant reserve tank (use towel to
wipe fluid).
Unclip hose from the stay brackets
on the engine coolant reserve
tank.
3. Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
4. Remove the bulb by turning it
about one-quarter turn
counterclockwise.5. Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
6. Push the electrical connector onto
the new bulb.
7. Turn on the headlights to test the
new bulb.
8. (Passenger's side)
Install the engine coolant reserve
tank and power steering reserve
tank.
HOLDING CLIP
CAP
ENGINE COOLANT
RESERVOIR
BULB
CONNECTOR
Lights52812/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Replacing Front Turn Signal/
Parking and Side Marker Light
Bulbs1. Open the hood.
2. Remove the front bulkhead cover
(see page 516).
3. Remove the socket by turning it
one-quarter turn counterclockwise.
4. Pull the bulb straight out of its
socket.
5. Push the new bulb straight into
the socket until it bottoms.
6. Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
7. Turn on the lights to make sure
the new bulb is working.
FRONT TURN SIGNAL LIGHT
BULB
SOCKET
BULB PARKING LIGHT
SOCKET
SIDE MARKER LIGHT
BULB
SOCKET
CONTINUED
Lights
529
Maintenance
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Replacing Front Fog/Daytime
Running Light Bulbs
Your vehicle uses halogen light
bulbs. When replacing a bulb, handle
it by its plastic case, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.Halogen bulbs get very hot when lit.
Oil, perspiration, or a scratch on the
glass can cause the bulb to overheat
and shatter.
1. To change the bulb on the driver's
side, start the engine, turn the
steering wheel all the way to the
right, then turn off the engine. To
change the bulb on the
passenger's side, turn the steering
wheel to the left.
2. Remove the bolt and use the flat-
tip screwdriver to remove the
holding clips located under the
front bumper.
3. Use a flat-tip screwdriver to
remove the holding clip from the
inner fender, and remove the
screw with a Phillips-head
screwdriver.
4. Pull the inner fender cover away
from the fender and bumper.
BOLT
HOLDING
CLIP
HOLDING
CLIP
SCREW
Lights53012/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

5. Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
6. Remove the bulb from the fog light
assembly by turning it one-quarter
turn counterclockwise.Replacing Rear Bulbs
(in Rear Pillar)
1. Open the tailgate. Put a cloth on
the edge of the cover to prevent
scratches. Remove the covers by
prying the edge with a flat-tip
screwdriver.
2. Remove the two bolts, and remove
the rear light assembly from the
rear pillar.
3. Determine which of the two bulbs
is burned out: turn signal/hazard
lights or side marker light.
COVER
BOLT
BOLT
CONTINUED
Lights
531
Maintenance
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

4. Remove the socket by turning it
one-quarter turn counterclockwise.
5. Pull the bulb straight out of its
socket.6. Push the new bulb straight into
the socket until it bottoms.
7. Turn on the lights to make sure
the new bulb is working.
8. Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
9. Install the rear light assembly in
the rear pillar. Tighten the two
bolts. Snap the bolt covers into
position.Replacing a Back-up Light Bulb
1. Open the tailgate. Place a cloth on
the edge of the light assembly
cover to prevent scratches.
Remove the cover by carefully
prying in the notch on its middle
edge with a flat-tip screwdriver.
BULB SOCKET
COVER
Lights53212/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

2. Remove the socket by turning it
one-quarter turn counterclockwise.
3. Pull the bulb straight out of its
socket.
4. Push the new bulb straight into
the socket until it bottoms.
5. Turn on the lights to make sure
the new bulb is working.6. Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
7. Place the cover back into the light
assembly. Push it up until it locks
in place.Side Turn Signal Light
Each outside mirror has side turn
signal lights. The lights should be
replaced by your dealer.
High-mount Brake Light
The high-mount brake light should
be replaced by your dealer.
Rear License Plate Bulb
The license plate has two lights
above it. The bulbs should be
replaced by your dealer.
BULB
SOCKET
Lights
533
Maintenance
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Dust and Pollen Filter
This filter removes the dust and
pollen that is brought in from the
outside through the climate control
system.
Have your dealer replace the filter
when this service is indicated by a
maintenance message on the multi-
information display. It should be
replaced every 15,000 miles (24,000
km) if you drive primarily in urban
areas that have high concentrations
of soot in the air, or if the flow from
the climate control system becomes
less than usual.Cleaning the Seat Belts
If your seat belts get dirty, use a soft
brush with a mixture of mild soap
and warm water to clean them. Do
not use bleach, dye, or cleaning
solvents. Let the belts air-dry before
you use the vehicle.Dirt build-up around the openings of
the seat belt anchors can cause the
belts to retract slowly. Wipe the
openings with a clean cloth
dampened in mild soap and warm
water or isopropyl alcohol.
OPENING
Dust and Pollen Filter, Cleaning the Seat Belts53412/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu
