spark plugs replace Acura MDX 2013 Owner's Manual

Symbol Maintenance Main Items
A
●Replace engine oil
1
B
●Replace engine oil
1and oil filter
●Inspect front and rear brakes●Check parking brake adjustment●Inspect these items:●Tie rod ends, steering gear box, and boots●Suspension components●Driveshaft boots●Brake hoses and lines (including ABS/VSA)●All fluid levels and condition of fluids●Exhaust system
＃
●Fuel lines and connections
＃
1: If the message‘‘SERVICE DUE NOW’’does not appear more than
12 months after the display is reset, change the engine oil every
year.
＃: See information on maintenance and emissions warranty in the
first column on page 512.
NOTE:
●Independent of the Maintenance Midner information, replace
the brake fluid every 3 years.●Inspect idle speed every 160,000 miles (256,000 km).●Adjust the valves during services A, B, 1, 2, or 3 if they are
noisy.Symbol Maintenance Sub Items
1
●Rotate tires
2●Replace air cleaner element
If you drive in dusty conditions, replace every 15,000
miles (24,000 km).●Replace dust and pollen filter
If you drive primarily in urban areas that have high
concentrations of soot in the air from industry and from
diesel-powered vehicles, replace every 15,000 miles
(24,000 km).●Inspect drive belt
3●Replace transmission and transfer fluid
4●Replace spark plugs●Replace timing belt and inspect water pump
If you drive regularly in very high temperatures (over
110°F, 43°C), in very low temperatures (under－20°F,－
29°C), or towing a trailer, replace every 60,000 miles (U.
S.)/100,000 km (Canada).●Inspect valve clearance
5●Replace engine coolant
6●Replace rear differential fluid
Driving in mountainous areas at very low vehicle
speeds or trailer towing results in higher level of
mechanical (shear) stress to fluid. This requires
differential fluid changes more frequently than
recommended by the Maintenance Minder. If you
regularly drive your vehicle under these conditions,
have the differential fluid changed at 7,500 miles (12,000
km), then every 15,000 miles (24,000 km).
Maintenance Minder
TM
Maintenance Minder
51412/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Lights
Headlights High 60 W (HB3)
Low
ᤳ1
35 W (D2S)
Daytime running lights 60 W (HB3)
Front side marker lights 3 CP
Front turn signal lights 21 W (Amber)
Parking lights 3 CP
Stop/Tail lights LED
ᤳ2
Side turn signal lights LED
ᤳ2
Fog lights 55 W (H11)
Rear turn signal lights 21 W
Rear side marker lights 3 CP
Backup lights 18 W
High-mount brake light LED
ᤳ2
License plate lights 3 CP
Tailgate lights 5 W
Vanity mirror lights 2 W
Door lights 3.4 W
Glove box light 1.4 W
Foot light 3.4 W
ᤳ1: The low beam headlights are high voltage discharged type.
Replacement of a low beam headlight bulb should be performed by
your dealer.
ᤳ2: Replacement of a light bulb should be done by your dealer.Battery
Capacity 12 V－65AH/5 HR
12 V－76AH/20 HR
Fuses
Interior See page 571 or the fuse label attached
to the inside of the fuse box lid.
Rear See page 570 or the fuse label attached
to the inside of the fuse box lid.
Under-hood See page 569 and 570 or the fuse box
cover.
Engine
Type Water-cooled, 4-stroke SOHC VTEC V6
gasoline engine
Bore x Stroke 3.54 x 3.78 in (90.0 x 96.0 mm)
Displacement 223.5 cu-in (3,664 cm
3)
Compression ratio 11.2 : 1
Spark plugs DENSO:
NGK:SXU22HCR11S
ILZKR7B11S
Alignment
Toe-in Front 0.00 in (0.0 mm)
Rear 0.08 in (2.0 mm)
Camber Front－0°30’
Rear－0°30’
Caster Front 4 ° 12’
Specifications
579
Technical Information
12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu

Side Curtain Airbags
....................
35
How Your Side Curtain Airbags
Work
....................................
35
Side Marker Lights, Bulb
Replacement in
.......................
529
Signaling Turns
............................
71
Snow Tires
.................................
546
Sound System
.....................
192, 212
Spare Tire
..................................
550
Inflating
...........................
540, 550
Specifications
..........................
580
Spark Plugs
................................
579
Specifications
.............................
578
Speed Control
............................
345
Speed Limiter
.............................
446
Speedometer
................................
78
SRS, Additional Information
.........
27
Additional Safety Precautions
...
39
Airbag Service
..........................
38
Airbag System Components
.....
27
How the Side Airbag Off
Indicator Works
...................
36
How the SRS Indicator Works..36
How Your Front Airbags
Work
....................................
30
How Your Side Airbags Work..33How Your Side Curtain Airbags
Work
....................................
35
SRS Indicator
.........................
36, 70
START (Ignition Key
Position)
.................................
139
Starting the Engine
....................
442
Auto Control Mode
.................
442
In Cold Weather at High
Altitude
................................
442
With a Dead Battery
................
558
State Emissions Testing
.............
590
Steam Coming from Engine
.......
560
Steering Wheel
Adjustments
............................
134
Anti-theft Column Lock
...........
139
Buttons
...........................
305, 345
Position Memory
....................
168
Stereo Sound System
..........
192, 212
Storage Compartment
................
175
Storing Your Vehicle
..................
548
Sunglasses Holder
.....................
176
Sun Visor
...................................
176
Super Handling-All Wheel Drive™
(SH-AWD
®) System
................
452Supplemental Restraint
System
............................
10, 27
Servicing
..................................
38
SRS Indicator
......................
36, 70
System Components
................
27
Synthetic Oil
..............................
518
T
Tachometer
..................................
78
Tailgate
......................................
141
Open Indicator
.........................
76
Opening the
............................
141
Power
......................................
142
Taillights, Changing Bulbs in
.....
531
Taking Care of the
Unexpected
............................
549
Technical Descriptions
DOT Tire Quality Grading (U.S.
Vehicles)
.............................
581
Emissions Control Systems
.....
587
Three Way Catalytic
Converter
............................
589
Tire Labeling
...........................
583
IndexX12/07/17 18:10:57 13 ACURA MDX MMC North America Owner's M 50 31STX660 enu
