diagram Acura RDX 2007 Owner's Manual

To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the inf ormation display or multi-
inf ormation display (depending on
models). Move the tires to the
positions shown in the diagram each
time they are rotated. If you
purchase directional tires, rotate
only f ront-to-back.Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.
TheABSworksbycomparingthe
speed of the wheels. When replacing
tires, use the same size originally
supplied with the vehicle. Tire size
and construction can affect wheel
speed and may cause the system to
activate.
It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
If you ever replace a wheel, make
sure the new one matches the
specif ications of the original.
Replacement wheels are available at
your dealer.
Tires
T ire Rotation
Replacing T ires and Wheels
Maint enance
375
Front Front
(For Non-directional
Tires and Wheels) (For Directional
Tires and Wheels)
——
y
y
() yy

If something electrical in your
vehicle stops wo rking, check for a
blown fuse first. Determine from the
chart on pages and , or the
diagram on the f use box lid, which
f use or f uses control that device.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is the cause. Replace any
blown f uses, and check if the device
works.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Remove the cover f rom the f use
box. Check each of the large f uses in
the under-hood f use box by
looking through the side window
atthewireinside.Removethe
screws with a Phillips-head
screwdriver.
3.
1.
2. 401 402
(Under-hood f use boxes)
Fuses
Checking and Replacing Fuses
398
FUSE BLOWN BLOWN
——
y
y
() yy

Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.................
Identif ication Numbers .406
................................
Specif ications .408
DOT Tire Quality Grading ......................
(U.S. Vehicles) .410
Unif orm Tire Quality ..................................
Grading .410
.................................
Treadwear .410
......................................
Traction .410
.............................
Temperature .411
.................................
Tire Labeling .412
Tire Pressure Monitoring System (TPMS)-Required Federal ............................
Explanation .413.......................
Emissions Controls .415
.....................
The Clean Air Act .415
Crankcase Emissions Control ....................................
System .415
Evaporative Emissions Control ....................................
System .415
Onboard Ref ueling Vapor ................................
Recovery .415
...
Exhaust Emissions Controls .416
....................
PGM-FI System .416
Ignition Timing Control ................................
System .416
Three Way Catalytic ...........................
Converter .416
....................
Replacement Parts .416
..
Three Way Catalytic Converter .417
..............
State Emissions Testing .418
T echnical Inf ormation
Technical Inf ormation
405
——
