This spreads the f orces of a crash
over the strongest bones in your
upper body.
If the seat belt touches or crosses
your neck, or if it crosses your arm
instead of your shoulder, you need to
adjust the seat belt anchor height.
Position the lap part of the belt as
low as possible across your hips,
then pull up on the shoulder part of
the belt so the lap part f its snugly.
This lets your strong pelvic bones
take the force of a crash and reduces
the chance of internal injuries.
If necessary, pull up on the belt again
to remove any slack, then check that
the belt rests across the center of
your chest and over your shoulder.
Insert the latch plate into the buckle,
then tug on the belt to make sure the
belt is securely latched. Check that
the belt is not twisted, because a
twisted belt can cause serious
injuries in a crash.
Protecting A dults and Teens
Fasten and Position the Seat
Belts
5.
16
Improperly positioning the seat
belts can cause serious injury
or death in a crash.
Make sure all seat belts are
properly positioned before
driving.
——
y

y
() y
y

CONTINUED
After all occupants have adjusted
their seats and put on seat belts, it is
very important that they continue to
sit upright, well back in their seats,
with their feet on the floor, until the
vehicle is parked and the engine is
off.
Sitting improperly can increase the
chance of injury during a crash. For
example, if an occupant slouches,
lies down, turns sideways, sits
forward, leans forward or sideways,
or puts one or both feet up, the
chance of injury during a crash is
greatly increased.
This could cause
very serious injuries in a crash.
See page f or additional
inf ormation about your seat belts
and how to take care of them. Using a seat
belt that is not working properly can
result in serious injury or death.
Have your dealer check the belt as
soon as possible. If a seat belt does not seem to work
properly, it may not protect the
occupant in a crash.
The front seats have adjustable seat
belt anchors. To adjust the height of
an anchor, press and hold the release
button and slide the anchor up or
down as needed (it has f our
positions). 20
Protecting A dults and Teens
Maintain a Proper Sitting
Position
6.Never place t he shoulder port ion of a
lap/shoulder belt under your arm orbehind your back.
No one should sit in a seat wit h aninoperat ive seat belt .
Driver and Passenger Saf ety
17
RELEASE
BUTTON
——
y

y
() yy

An inf ant must be properly
restrained in a rear-f acing, reclining
child seat until the child reaches the
seat maker’s weight or height limit
f or the seat, and the child is at least
one year old.A rear-f acing child seat can be placed
in any seating position in the back
seat, but not in the f ront.
If the passenger’s front airbag
inflates, it can hit the back of the
child seat with enough f orce to kill or
seriously injure an inf ant.
If placed
f acing f orward, an inf ant could be
very seriously injured during a
f rontal collision. Two types of seats may be used: a
seat designed exclusively f or inf ants,
or a convertible seat used in the rear-
f acing, reclining mode. Only a rear-f acing child seat provides
proper support f or a baby’s head,
neck, and back.
When properly installed, a rear-
f acing child seat may prevent the
driver or a f ront passenger f rom
moving their seat as far back as
recommended, or f rom locking their
seat-back in the desired position.
It can also interf ere with proper
operation of the passenger’s
advanced front airbag system.
Child Seat T ype Rear-f acing Child Seat Placement
Never put a
rear-f acing child seat in t he f ront seat .
Do not put a rear-f acing child seat in a f orward-f acing position.
Protecting Inf ants
Protecting Inf ants and Small Children
42
——
y
y
() yy

In any of these situations, we
strongly recommend that you install
the child seat directly behind the
f ront passenger’s seat, move the seat
as far forward as needed, and leave it
unoccupied. Or, you may wish to get
a smaller rear-f acing child seat.A child who is at least one year old,
and who fits within the child seat
maker’s weight and height limits,
should be restrained in a f orward-
f acing, upright child seat.Of the different seats available, we
recommend those that have a f ive-
point harness system as shown.
We also recommend that a small
child use the child seat until the child
reaches the weight or height limit
for the seat.
CONT INUED
Protecting Small Children
Child Seat T ype
Protecting Inf ants and Small Children
Driver and Passenger Saf ety
43
Placing a rear-facing child seat
in the front seat can result in
serious injury or death during a
collision.
Always place a rear-facing child
seat in the back seat, not the
front.
——
y
y
() yy

When a child reaches the
recommended weight or height limit
for a forward-facing child seat, the
child should sit in a back seat on a
booster seat and wear a lap/shoulder
belt.
The f ollowing pages give
instructions on how to check proper
seat belt f it, what kind of booster
seat to use if one is needed, and
important precautions f or a child
who must sit in f ront.To determine if a lap/shoulder belt
properly f its a child, have the child
put on the seat belt, then ask
yourself :Does the child sit all the way back
against the seat?
Do the child’s knees bend
comf ortably over the edge of the
seat?
1.
2. Checking Seat Belt Fit
Protecting L arger Children
54
Allowing a child age 12 or under
to sit in front can result in injury
or death if the passenger’s front
airbag inflates.
If a child must ride in front,
move the vehicle seat as far
back as possible, use a booster
seat if needed, have the child
sit up properly and wear the
seat belt properly.
——
y
y
() yy

If a child who uses a booster seat
must ride in front, move the vehicle
seat as far back as possible and be
sure the child is wearing the seat
belt properly.
A child may continue using a booster
seat until the tops of their ears are
even with the top of the vehicle’s or
booster’s seat-back. A child of this
height should be tall enough to use
the lap/shoulder belt without a
booster seat. The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
ag
ed 12 and under be p roperly
restrained in a back seat.
If the passenger’s front airbag
inflates in a moderate to severe
frontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses ri sks. If any
part of a larger child’s body is in the
path of a deploying side ai rbag, the
child could receive possibly serious
injuries. Of course, children vary widel
y. And
while age m ay be one indicator of
when a child can safely ride in front,
there are other important factors you
should consider.
Physically, a child must be large
enough for the lap/shoulder belt to
properly fit (see pages and ). If
the seat belt does not f it properly,
with or without the child sitting on a
booster seat, the child should not sit
in f ront.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride. 16 54
When Can a L arger Child Sit in
Front
Physical Size
Maturity
Protecting L arger Children
56
——
y
y
() y
y

See page for important safety
inf ormation and a warning about how to properly position the head restraints. 15
Your vehicle is equipped with head
restraints in all seating positions to
help protect you and your
passengers f rom whiplash and other
injuries.
Theyaremosteffectivewhenyou
adjust them so the back of the
occupant’s head rests against the
center of the restraint.
To remove a head restraint f or
cleaning or repair, pull it up as f ar as
it will go. Push the release button,
then pull the restraint out of the seat-
back.
Make sure the removed head
restraints are securely stored.
The f ront and rear head restraints
adjust f or height. You need both
hands to adjust the restraint. Do not
attempt to adjust it while driving. To
raise it, pull upward. To lower the
restraint, push the release button
and push the restraint down.
Head Restraints
Seats
146
RELEASE BUTTON
RELEASE BUTTON
Front
Rear
——
y
y
() y

y

You can use the inside of the lid f or a
pen holder, a coin holder and a card
holder.The console compartment has two
shelves to divide it into two levels.
To store small items, you can use the
upperhalfofthespacebyputting
the shelves down until they latch.
The f ront and rear shelves can be
used separately.When you store a large item like a
brief case, lif t the shelves up to
create a large space.
The console compartment light
comes on when the parking lights
are on. The items on each shelves should
not exceed 11 lbs (5 kg). Heavy
items may damage the shelves.The maximum dimensions of the
item you can store in the console
compartment are:
Length: 16.9 in (430 mm)
Height: 12.2 in (310 mm)
Width: 5.5 in (140 mm)
Interior Convenience Items
166
LID
CARD HOLDER PEN HOLDER
COIN
HOLDER
SHELVES
——
y
y
() y

y

When climbing hills, closely watch
your temperature gauge (see pages
and ). If it nears the H (Hot)
mark, turn the A/C of f , reduce
speed and, if necessary, pull to the
side of the road to let the engine cool.
When driving down hills, reduce
your speed, and shif t down to S
position, or use the puddle shif t to
the lower gear (3, 2 or 1)in the S
position. When towing a trailer, do
not ‘‘ride’’ the brakes, and remember,
it will take longer to slow down and
stop when towing a trailer.
Drive slower than normal in all
driving situations, and obey posted
speed limits f or vehicles with trailers.
Use the D position when towing a
trailer on level roads. See ‘‘
’’ in the next column f or
additional gear inf ormation. Do not
exceed 55 mph (88 km/h). At higher
speeds, the trailer may sway or
af f ect vehicle handling.
Make turns more slowly and wider
than normal. The trailer tracks a
smaller arc than your vehicle, and it
canhitorrunoversomethingthe
vehicle misses. Allow more time and
distance f or braking. Do not brake or
turn suddenly as this could cause the
trailer to jackknif e or turn over.
The added weight, length, and
height of a trailer will af f ect your
vehicle’s handling and perf ormance,
so driving with a trailer requires
some special driving skills and
techniques.
Foryoursafetyandthesafetyof
others,taketimetopracticedriving
maneuvers bef ore heading f or the
open road, and f ollow the guidelines
in this section.
8378
Driving on Hills
T owing Speeds and Gears
Driving on
Hills
Making T urns and BrakingDriving Saf ely With a T railer
Towing a Trailer
322
——
y

y
() yy

ÎÎ
Î
Î
Specif ications
408
Dimensions
Weights
Engine
Capacities
Capacities
1.66 US gal (6.3)
8.1 US qt (7.7
)
2.6 US qt (2.5
)
2.9 US qt (2.7)
Length
Width
Height
Wheelbase
Track
65.2 in (1,655 mm)
104.3 in (2,650 mm)
61.9 in (1,572 mm)
62.6 in (1,590 mm)
Gross vehicle weight rating See the certification label attached to the driver’s doorjamb.
Type
BorexStroke
Displacement
Compression ratio
Spark plugs Water cooled 4-stroke DOHC
i-VTEC 4-cylinder gasoline engine with turbo charger
3.39 x 3.90 in (86.0 x 99.0 mm) 140.4 cu-in (2,300 cm
)
8.8 : 1
Fuel tank
Engine oil 18.0 US gal (68
)
5.0 US qt (4.7
)
4.6 US qt (4.4)
6.1 US qt (5.8) Excluding the oil remaining in the engine
Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity:
0.190 US gal (0.72
)
180.7 in (4,590 mm)
73.6 in (1,870 mm)
2.40 US gal (9.1
)
3.5 US qt (3.3)
2.6 US qt (2.5
)
4.8 US qt (4.5)
Engine
coolant
Automatic
transmission
fluid
Rear
differential
fluid
Windshield
washer
reservoir
SILKR8A-S
Approx.
Front
Rear
Change
Without filter
Total Change
Total
Change
Total
Change
Total
U.S. Vehicles
Canada
Vehicles
1:
2:
(NGK)
1 2
Including filter
——
y
y
() y
y
