TPMS Acura RDX 2009 User Guide

The vehicle stability assist (VSA)
system helps to stabilize the vehicle
during cornering if the vehicle turns
more or less than desired. It also
assists you in maintaining traction
while accelerating on loose or
slippery road surf aces. It does this
by regulating the engine’s output and
by selectively applying the brakes.When VSA activates, you will see the
VSA activation indicator blink (see
page ).
If this indicator comes on while
driving, pull to the side of the road
when it is saf e, and turn of f the
engine. Reset the system by
restarting the engine. If the VSA
system indicator stays on or comes
back on while driving, have the VSA
system inspected by your dealer.
When VSA activates, you may notice
that the engine does not respond to
the accelerator in the same way it
does at other times. There may also
be some noise f rom the VSA
hydraulic system. You will also see
the VSA activation indicator blink.
The VSA system cannot enhance the
vehicle’s driving stability in all
situations and does not control your
vehicle’s entire braking system. It is
still your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety. If the indicator does not come on
when the ignition switch is turned to
the ON (II) position, there may be a
problem with the VSA system. Have
your dealer inspect your vehicle as
soon as possible.
If the low tire pressure/TPMS
indicator comes on (see page ),
or the multi-information display
shows a ‘‘CHECK TPMS SYSTEM’’
message with the indicator flashing
(see page ), the VSA system
automatically turns on even if the
VSA system is turned off with the
VSA OFF switch. In this case, you
cannot turn the VSA system of f by
pressing the VSA OFF switch again.
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display if there is a
problem with the VSA system.
The main f unction of the
VSA system is generally known as
Electronic Stability Control (ESC).
The system also includes a traction
control f unction. 67
307
310
VSA A ctivation Indicator
Vehicle Stability Assist
(VSA ) System Indicator
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
312
NOTE:
\f—\f—

y
y
() \fy\f
y
2009 RDX

To saf ely operate your vehicle, your
tires must be the proper type and
size, in good condition with adequate
tread, and correctly inf lated.
The f ollowing pages give more
detailed inf ormation on how to take
care of your tires and what to do
when they need to be replaced.Keeping the tires properly inf lated
provides the best combination of
handling, tread lif e, and riding
comf ort.
Underinf lated tires wear unevenly,
adversely affect handling and fuel
economy, and are more likely to
fail from being overheated.
Overinf lated tires can make your
vehicleridemoreharshly,are
more prone to damage f rom road
hazards, and wear unevenly.
The tire pressure monitoring system
(TPMS)willwarnyouwhenatire
pressure is low. See page f or
inf ormation on the TPMS. Even though your vehicle is
equipped with TPMS, we
recommend that you visually check
your tires every day. If you think a
tire might be low, check it
immediately with a tire gauge.
Use a gauge to measure the air
pressure in each tire at least once a
month. Even tires that are in good
condition may lose 1 to 2 psi (10 to
20 kPa, 0.1 to 0.2 kgf /cm ) per
month. Remember to check the
sparetireatthesametime.
Check the air pressures when the
tires are cold. This means the
vehicle has been parked f or at least 3
hours, or driven less than 1 mile (1.6
km). Add or release air, if needed, to
match the recommended cold tire
pressures.
307
Tires
Inf lation Guidelines
360
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
\f—\f—

y
\fy
() \fy\fy
2009 RDX

Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the multi-information display. Move
the tires to the positions shown in
the illustration each time they are
rotated. If you purchase directional
tires, rotate only front-to-back. The ABS and VSA system work by
comparing the speed of the wheels.
When replacing tires, use the same
size originally supplied with the
vehicle. Tire size and construction
can af f ect wheel speed and may
cause the ABS or VSA system to
activate.If you ever replace a wheel, make
sure that the wheel’s specif ications
match those of the original wheels.
Also be sure you use only TPMS
specif ic wheels. If you do not, the
tire pressure monitoring system will
not work.
Replacement wheels are available at
your dealer.
Tires
T ire Rotation Replacing T ires and Wheels
Maint enance
363
Front Front
(For Non-directional
Tires and Wheels) (For Directional
Tires and Wheels)
\f—\f—

y


y
() \fy\fy
2009 RDX

´
Tires marked ‘‘M S’’ or ‘‘All
Season’’ on the sidewall have an all-
weather tread design suitable for
most winter driving conditions.
For the best perf ormance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions.
Wheels:
Tires:
See page f or inf ormation about
DOT Tire Quality Grading, and page
f or tire size and labeling
inf ormation.
If you mount snow tires on your
vehicle, make sure they are radial
tires of the same size and load range
as the original tires. Mount snow
tires on all f our wheels. The traction
provided by snow tires on dry roads
maybelowerthanyouroriginaltires.
Check with the tire dealer f or
maximum speed recommendations.
398
400 Winter Driving
Wheel and T ire Specif ications
Snow T ires
Tires
364
18x71/2J
P235/55R18 99V(TPMS)
Installing improper tires on your
vehicle can affect handling and
stability. This can cause a crash
in which you can be seriously
hurt or killed.
Always use the size and type of
tires recommended in this
owner’s manual.
\f—\f—

y

y
() \fy\fy
2009 RDX

Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.
Check the inf lation pressure of the
compact spare tire every time you
check the other tires. It should be
inf lated to:Replace the tire when you can see
the tread wear indicator bars. The
replacement should be the same size
and design tire, mounted on the
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed f or mounting a regular tire.
Follow these precautions:
Never exceed 50 mph (80 km/h).
This tire gives a harsher ride and
less traction on some road
surf aces. Use greater caution
while driving.
Do not mount snow chains on the
compact spare tire.
Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel.
After the flat tire is replaced with
the spare tire, the low tire
pressure/TPMS indicator stays on.
Af ter several miles (kilometers)
driving with the spare, this
indicator begins to f lash, then
stays on again. You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display (see page ). 310
Compact Spare Tire
370
INDICATOR LOCATION MARKS
TREAD WEAR INDICATOR
60 psi (420 kPa , 4.2 kgf/cm)
\f—\f—

y
\fy
() \fy\fy
2009 RDX

µ
µ
µ
µ
No. No. Circuits ProtectedNo.
Circuits Protected
Amps. Amps. Amps. Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15 RR Wiper
OPDS
Meter
SRS
Right Headlight High
Left Headlight High
Small Lights (Interior)
Small Lights (Exterior) 16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
SH-AWD
Fuel Pump
ACG
ABS/VSA
Heated Seat
FR Fog Lights
Driver’s Power Seat Lumbar
Support
7.5 A
20 A
15 A
7.5 A 15 A
20 A
7.5 A 10 A
7.5 A
7.5 A 10 A
10 A
10 A
7.5 A 15 A 15 A
15 A
20 A
20 A
7.5 A 30 A
20 A
20 A
20 A
15 A
15 A
20 A
20 A
20 A
20 A
7.5 A 10 A
7.5 A 30 A Right Headlight Low
Left Headlight Low
Headlight High Main
Small Lights Main
TPMS
Headlight Low Main
Not Used
Not Used
Moonroof
Door Lock
Driver’s Power Window
Not Used
Accessory Socket (Console
Compartment)
ACC
Passenger’s Power Window
Radio Amplifier
Right Rear Power Window
Left Rear Power Window
Not Used
Radio
HAC
Daytime Running Light
FR Wiper
Fuse Locations
T aking Care of t he Unexpect ed
389
INTERIOR FUSE BOX
\f—\f—

y
y
() \fy\fy
2009 RDX

µ
Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.
................
Identif ication Numbers .394
................................
Specif ications .396
DOT Tire Quality Grading
......................
(U.S. Vehicles) .398
Unif orm Tire Quality ..................................
Grading .398
.................................
Treadwear .398
......................................
Traction .398
.............................
Temperature .399
.................................
Tire Labeling .400
Tire Pressure Monitoring System
(TPMS) Required Federal ............................
Explanation .401 .......................
Emissions Controls .403
.....................
The Clean Air Act .403
Crankcase Emissions Control
....................................
System .403
Evaporative Emissions Control ....................................
System .403
Onboard Ref ueling Vapor ................................
Recovery .403
...
Exhaust Emissions Controls .404
....................
PGM-FI System .404
Ignition Timing Control
................................
System .404
Three Way Catalytic ...........................
Converter .404
....................
Replacement Parts .404
..
Three Way Catalytic Converter .405
........................
Emissions Testing .406
T echnical Inf ormation
Technical Inf ormation
393
\f—\f—

y
y
() \fy\fy
2009 RDX

µ
µ
µ
CONT INUED
As an added safety feature, your
vehicle has been equipped with a tire
pressure monitoring system (TPMS)
that illuminates a low tire pressure
telltale
when one or more of your tires is
signif icantly under-inf lated.
Accordingly, when the low tire
pressure telltale illuminates, you
should stop and check your tires as
soon as possible, and inflate them to
the proper pressure.
Each tire, including the spare (if
provided), should be checked
monthly when cold and inf lated to
the inf lation pressure recommended
by the vehicle manuf acturer on the
vehicle placard or tire inf lation
pressure label.
(If your vehicle has tires of a
dif f erent size than the size indicated
on the vehicle placard or tire
inf lation pressure label, you should
determine the proper tire inf lation
pressure f or those tires.)
Max Press The maximum air
pressurethetirecanhold.
Max Load The maximum load the
tire can carry at maximum air
pressure.
Tire Labeling, Tire Pressure Monitoring System (TPMS) Required Federal Explanation
Tire Pressure Monitoring System
(T PMS)Maximum T ire Pressure
Maximum T ire L oad
Technical Inf ormation
401
\f—\f—

y
y
() \fy\f\fy
2009 RDX

µ
Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is combined
with the low tire pressure telltale.
When the system detects a
malf unction, the telltale will f lash f or
approximately one minute and then
remain continuously illuminated.
This sequence will continue upon
subsequent vehicle start-ups as long
as the malfunction exists.
Driving on a signif icantly under
inf lated tire causes the tire to
overheat and can lead to tire failure.
Underinf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Please note that the TPMS is not a
substitute for proper tire
maintenance, and it is the driver’s
responsibility to maintain correct tire
pressure, even if under-inf lation has
not reached the level to trigger
illumination of the TPMS low tire
pressure telltale.
When the malf unction indicator is
illuminated, the system may not be
able to detect or signal low tire
pressure as intended.TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly.
Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
402
\f—\f—

y
y
() \fy\f\fy
2009 RDX

CONT INUED
GaugesEngine Coolant .....................
Temperature .73,76
...............................................
Fuel .71
.................................
Tachometer .71
.....................
Turbo Boost Meter .71
...............................
Speedometer .71
............
Gearshif t Lever Positions .293
......................................
Glove Box .152
Gross Vehicle Weight Rating
.....................................
(GVWR) .315
.............
Halogen Headlight Bulbs .347
..................................
Hanger Bars .287
......
HandsFreeLink
, Bluetooth.250
............
Hazard Warning Flashers .118
Headlights
........................................
Aiming .347
.........
Daytime Running Lights .116
..................
High Beam Indicator .67
High-Intensity Discharge
......................................
Lamp .347
.........................
Reminder Tone .114
........
Replacing Halogen Bulbs .347 .................................
Turning on .114
.............
Headlight Auto Of f Timer .98
............................
Head Restraints .132
.............................
Heated Mirrors .144
.................................
Heaters, Seat .138
..........................
High Beam Lever .114
HomeLink
Universal
................................
Transceiver .247
.......................
Hood, Opening the .275
...........................................
Horn.4,111
...
Identif ication Number, Vehicle .394
Ignition
............................................
Keys .119
.........................................
Switch .122
............
Timing Control System .404
......................
Immobilizer System .121
.........
Important Safety Precautions .6
Indicators
......
ABS (Anti-Lock Brake) .64,305
.......................
A/T Temperature .63
...................
Brake (Amber) .65,384
.........................
Brake (Red) .65,383
................
Charging System .63,381 .............................
Cruise Control .67
.................................
Cruise Main .67
.....................................
Fog Light .68
...................................
High Beam .67
........
Key (Immobilizer System) .64
......................................
Low Fuel .66
................
Low Oil Pressure .63,381
.....................................
Lights On .68
Low Tire Pressure/
...............................
TPMS .69,307
..................
Maintenance Minder .70
...
Malf unction Indicator Lamp .382
.................
Passenger Airbag Of f .32
..................
Security System .68,233
......................................
SH-AWD .68
.....................
Side Airbag Of f .31,64
.........................................
SRS .31,63
.........................
System Message .70
.
TPMS, Low Tire Pressure .69,307
Turn Signal and Hazard
...................................
Warning .67
VSA (Vehicle Stability ..............................
Assist) .66,312
....................
VSA Activation .67,312
Index
INDEX
H I
V
\f—\f—

y

y
() \fy\fy
2009 RDX
