The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
regulations to disconnect, reset, or
alter the odometer with the intent to
change the number of miles or
kilometers indicated.
This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it. There
are two trip meters: Trip A and Trip
B. Each trip meter works
independently, so you can keep track
of two dif f erent distances.When you reset Trip A, AVG.
FUEL A is reset at the same time.
When you reset Trip B, AVG.
FUEL B is reset.
The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
To reset a trip meter, display it, then
press and hold the SEL/RESET
button until the number resets to
‘‘0.0’’. You can customize the Trip A and
AVG. FUEL A reset condition on the
multi-inf ormation display (see page
).
You can adjust the outside
temperature display (see page ).
This shows the outside temperature
in Fahrenheit (U.S. models), or in
Celsius (Canadian models).
91
89
Odometer
Trip Meter
Outside Temperature Display
Multi-Inf ormation Display
74
\f—\f—

y

y
() \fy\f\fy
2009 RDX

This shows the estimated distance
you can travel on the fuel remaining
in the f uel tank. This distance is
estimated f rom the f uel economy
you received over the last several
miles(U.S.) or kilometers (Canada),
so it will vary with changes in speed,
traf f ic, etc.
This shows the time passed traveled
since you last reset it. When you turn
the ignition switch to the ON (II)
position, ELAPSED TIME is reset.
You can customize the ELAPSED
TIME reset condition on the multi-
inf ormation display (see page ).This shows your vehicle’s average
f uel economy in mpg (U.S. models)
or liter/100 km (Canadian models)
since you last reset the Trip A or
Trip B.
When you reset Trip A, AVG.
SPEED is also reset.
This shows the average speed you
are traveling in miles per hour (mph)
forU.S.modelsorkilometersper
hour (km/h) f or Canadian models.
When the battery is disconnected, or
you ref uel, RANGE is also reset.
The multi-inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.
This shows your current f uel
mileage.
When you turn of f the engine, INST.
MPG or INST. L/100 km is also
reset.
The average f uel mileage will be
reset when you reset the trip meter,
or if the vehicle’s battery goes dead
or is disconnected.
You can customize the Trip A and
AVG. FUEL A reset condition on the
multi-inf ormation display (see page).
327
91
93
RANGE
EL A PSED T IME
AVG. FUEL A/B
A VG. SPEED
Maintenance Minder
INST.MPG(U.S.models)/INST.
L /100km (Canadian models)
Multi-Inf ormation Display
Inst rument s and Cont rols
75
\f—\f—

y

y
() \fy\f\f\fy
2009 RDX

This monitor shows how much
torque is being delivered to each
wheel. For more inf ormation, see
page .
You can see the pressure of each tire
in this monitor. If one or more tire
pressure are low, inflate them to the
correct pressure. For more
inf ormation, see page .This shows the temperature of the
engine’s coolant. During normal
operation, the reading should rise
f rom the ‘‘C (Cold)’’ mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the reading may rise to near
the ‘‘H (Hot)’’ mark of the gauge. If
it reaches the ‘‘H’’ mark, pull saf ely
to the side of the road. See page
f or instructions and precautions
on checking the engine’s coolant
system. You can receive or make phone calls
f rom your cell phone through your
vehicle’s Bluetooth
HandsFreeLink(HFL) system
without touching your cell phone.
To use the system, your cell phone
and the HFL system must be linked.
Not all cell phones are compatible
with this system. Ref er to page for instructions on how to link
your cell phone to the HFL and how
to receive or make phone calls, or
visit the handsf reelink.com website.
301
308379 257
SH-AWD T orque Distribution
Monitor
Tire Pressure Monitor
Temperature Gauge Bluetooth
HandsFreeL ink
Multi-Inf ormation Display
76
\f—\f—

y


y
() \fy\f\f
y
2009 RDX

If there is a problem with your
vehicle, f or example, the engine oil
level is low or a door is not f ully
closed, the multi-inf ormation display
will show you the problem. It does
this by interrupting the current
display with one or more messages.
Here is a list of messages shown on
the multi-information display:See page
19
See page 11
See page 65
See page 383
See pages 383,384 See page
310
See page 309
See page 381
See page 381
See page 382
CONT INUED
System Messages
Multi-Inf ormation Display
Inst rument s and Cont rols
77
U.S. Canada
Canada
U.S.
Canada
U.S.
——

y

y
() yy
2009 RDX

Youshouldhavereceivedakey
number tag with your keys. You will
need this key number if you ever
have to get a lost key replaced. Use
only Acura-approved key blanks.
These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Donotdropthekeysorsetheavy
objects on them.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
The valet key does not contain a
battery. Do not try to take it apart. The master key can be retracted into
theremotetransmitter.Tousethe
key, push the release button to
release the key f rom the transmitter.
The key should be f ully extended.
To retract the key, push the release
buttonandatthesametimepushthe
key into the remote transmitter until
it is securely latched.Always use the f ully-extended key
when you insert it to the ignition
switch. If the key does not f ully
extend, the immobilizer system may
not operate properly and may
prevent the engine f rom starting.
Thekeymaycomeincontactwith
your f inger while being retracted or
extended. Make sure your f ingers do
not touch the pivot of the key when
retracting or extending the key.Retractable Master Key
Keys and Locks
120
RELEASE BUTTON
Push
\f—\f—

y


y
() \fy\f
y
2009 RDX

As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
When you turn the ignition switch to
the ON (II) position, the immobilizer
system indicator should come on
brief ly, then go of f . If the indicator
starts to blink, it means the system
does not recognize the coding of the
key. Turn the ignition switch to the
LOCK (0) position, remove the key,
reinsert it, and turn the ignition
switch to the ON (II) position again. If you have lost your key and cannot start the engine, contact your dealer.
Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle inoperable.
If the system repeatedly does not
recognize the coding of your key,
contact your dealer.
The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
f ob) is near the ignition switch when
you insert the key.
The immobilizer system protects
your vehicle f rom thef t. If an
improperly-coded key (or other
device) is used, the engine’s f uel
system is disabled.
Immobilizer System
Inst rument s and Cont rols
121
Always take the ignition key with you
whenever you leave the vehicle alone.
\f—\f—

y

y
() \fy\f
y
2009 RDX

µµ
µ
µ
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III).
You can insert or
remove the key only in this position.
To turn the key, the shift lever must
be in Park, and you must push the
key in slightly. If the f ront wheels are turned, the
anti-theft lock may make it difficult
to turn the key. Firmly turn the
steering wheel to the lef t or right as
you turn the key.
You can
operate the audio system and the
accessory power sockets in this
position.
This is the normal key
position when driving. Several of the
indicators on the instrument panel
come on as a test when you turn the
ignition switch f rom the
ACCESSORY (I) to the ON (II)
position.
Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the key. You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or the
ACCESSORY (I) position and open
the driver’s door. Remove the key to
turn of f the beeper.
You will also see a ‘‘REMOVE KEY’’
message on the multi-information
display (see page ).
TheshiftlevermustbeinPark
bef ore you can remove the key f rom
the ignition switch.
78
Ignition Switch
LOCK (0) A CCESSORY (I)
ON (II)
ST A RT (III)
122
\f—\f—

y

y
() \fy\f
y
2009 RDX

Follow these precautions whenever
you use the seat heaters:Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters, even on the LO
setting. It can weaken the battery,
causing hard starting.
In the LO setting, the heater runs
continuously. It does not cycle with
temperature changes.
In the HI setting, the heater turns off
when the seat gets warm, and turns
back on after the seat’s temperature
drops.
Both f ront seats are equipped with
seat heaters. The passenger seat is
only heated in the seat bottom
because of the side airbag cutof f
system. The ignition switch must be in the
ON (II) position to use seat heaters.
Push the top of the switch, HI, to
rapidly heat up the seat. Af ter the
seat reaches a comfortable
temperature, select LO by pushing
the bottom of the switch. This will
keep the seat warm.
Seat Heaters
138
SEAT HEATER SWITCHES
Passenger’s Seat
Driver’s Seat
HEATERS
\f—\f—

y
\fy
() \fy\f
y
2009 RDX

Û
Ý
Proper use of the climate control
system can make the interior dry
and comfortable, and keep the
windows clear f or best visibility.
For the climate control system to
provide heating and cooling, the
engine must be running.
You can adjust the temperatures of
thedriver’ssideandthepassenger’s
side independently (see page ). The automatic climate control
system adjusts the f an speed and
airflow levels to maintain the interior
temperature you select.
Set the desired temperature by
pushing the driver’s side
temperature control buttons ( or
). The selected temperature will
show in the display.
The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature to your pref erence.
When you push the passenger’s side
temperature control buttons, the
indicator in the DUAL button comes
on and the driver’s side and
passenger’s side temperature can be
controlled independently (see page ).
The climate control system f or your
vehicle can also be operated by voice
control. See the navigation section in
your quick start guide f or an
overview of this system, and the
navigation system manual f or
complete details. In AUTO mode, the vehicle’s interior
temperature is independently
regulated f or the driver and
passenger, based on inputs f rom
sunlight and temperature sensors
(see page ). If one side of the
vehicle is getting too much sun, the
system lowers the temperature only
on that side.
Press the AUTO button. You will
see AUTO on the display. The
indicator in the button also comes
on as a reminder.
1. 2.
165 165
167
CONT INUED
On RDX with Technology Package
model On RDX with Technology Package
model
Voice Control System Automatic Operation
Climate Control System
Features
161
\f—\f—

y
y
() \fy\f
y
2009 RDX

You can make calls using any phone
number, or by using a name in the
HFL phonebook. You can also redial
the last number called. During a call,
theHFLallowsyoutotalkupto30
minutes af ter you remove the key
f rom the ignition switch. Continuing
a call without running the engine
may discharge and weaken the
vehicle’s battery.With your phone on and the
ignition in the ACCESSORY (I) or
ON (II) position, press and release
the Talk button. After the beep,
say ‘‘Call’’ or ‘‘Dial.’’ The HFL
response is, ‘‘What name or
number would you like to call/
dial?’’
Press and release the Talk button.
Af ter the beep, say the number
you want to call. For example, say
‘‘123 456 7891.’’ The HFL response
is ‘‘123 456 7891. Say call, dial, or
continue to add numbers.’’Press and release the Talk button.
Af ter the beep, say ‘‘Call’’ or ‘‘Dial.’’
The HFL response is ‘‘Calling’’ or
‘‘Dialing.’’ Once connected, you
will hear the person you called
through the audio speakers. To
change the volume, use the audio
system volume knob, or the
steering wheel volume controls.
To end the call, press the Back
button.
3.
1.
2. 4.
To make a call using a phone number,
do this:
CONT INUED
Making a Call
BluetoothHandsFreeL ink
Features
261
\f—\f—

y
y
() \fy\fy
2009 RDX
