The three way catalytic converters
contain precious metals that serve as
catalysts, promoting chemical
reactions to convert the exhaust
gasses without affecting the metals.
The catalytic converters are referred
to as three-way catalysts, since they
act on HC, CO, and NOx.
Replacement units must be original
Acura parts or their equivalent.
The three way catalytic converter
must operate at a high temperature
for the chemical reactions to take
place. It can set on fire any
combustible materials that come
near it. Park your vehicle away from
high grass, dry leaves, or other
flammables.
A defective three way catalytic
converter contributes to air pollution,
and can impair your engine's
performance. Follow these
guidelines to protect your vehicle's
three way catalytic converter.●Always use unleaded gasoline.
Even a small amount of leaded
gasoline can contaminate the
catalyst metals, making the three
way catalytic converter ineffective.
●Keep the engine well maintained.●Have your vehicle diagnosed and
repaired if it is misfiring,
backfiring, stalling, or otherwise
not running properly.
THREE WAY CATALYTIC CONVERTERS
Three Way Catalytic Converter
489
Technical Information
09/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX

Testing of Readiness Codes
If you take your vehicle for an
emissions test shortly after the
battery has been disconnected or
gone dead, it may not pass the test.
This is because of certain‘‘readiness
codes ’’that must be set in the on-
board diagnostics for the emissions
systems. These codes are erased
when the battery is disconnected,
and set again only after several days
of driving under a variety of
conditions. If the testing facility determines that
the readiness codes are not set, you
will be requested to return at a later
date to complete the test. If you must
get the vehicle retested within the
next two or three days, you can
condition the vehicle for retesting by
doing the following.
1. Make sure the gas tank is nearly,
but not completely, full (around
3/4).
2. Make sure the vehicle has been parked with the engine off for 6
hours or more.
3. Make sure the ambient temperature is between 40° and
95°F (4° and 35°C). 4. Without touching the accelerator
pedal, start the engine, and let it
idle for 20 seconds.
5. Keep the vehicle in Park. Increase the engine speed to 2,000 rpm, and
hold it there until the temperature
gauge rises to at least 1/4 of the
scale (about 3 minutes).
6. Without touching the accelerator pedal, let the engine idle for 20
seconds.
7. Drive your vehicle for 30 seconds while accelerating.Emissions Testing49009/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX

8. Select a nearby lightly traveledmajor highway where you can
maintain a speed of 50 to 60 mph
(80 to 100 km/h) for at least 20
minutes. Drive on the highway in
D. Do not use the cruise control.
When traffic allows, drive for 90
seconds without moving the
accelerator pedal. (Vehicle speed
may vary slightly; this is okay.) If
you cannot do this for a continuous
90 seconds because of traffic
conditions, drive for at least 30
seconds, then repeat it two more
times (for a total of 90 seconds). 9. Then drive in city/suburban traffic
for at least 10 minutes. When
traffic conditions allow, let the
vehicle coast for several seconds
without using the accelerator pedal
or the brake pedal.
10. Make sure the vehicle has been parked with the engine off for 30
minutes.
If the testing facility determines the
readiness codes are still not set, see
your dealer.
Emissions Testing
491
Technical Information
09/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX

Purchasing Factory Authorized Manuals (U.S. only)The publications shown below can be purchased from Helm
Incorporated. You can order by phone or online:●Call Helm Inc. at 1-800-782-4356 (credit card orders only)●Go online at
www.helminc.com
If you are interested in other years or models, contact Helm Inc.
at 1-800-782-4356.
Publication
Form Number Form Description
61STK03 2007-2010 Acura RDX Service Manual
61STK03EL 2010 Acura RDX
Electrical Troubleshooting Manual
61STK30 2007 Model series Acura RDX
Body Repair Manual
31STK630 2010 Acura RDX Owner's Manual
31STK830 2010 Acura RDX Navigation System Manual
31STKM30 2010 Acura RDX Maintenance Journal
31STKQ30 2010 Acura RDX Advanced Technology Guide
ACU-R Order Form for Previous Years-
Indicate Year and Model Desired
Service Manual:
Covers maintenance and recommended procedures for
repair to engine and chassis components. It is written
for the journeyman mechanic, but it is simple enough
for most mechanically inclined owners to understand.
Electrical Troubleshooting Manual:
Complements the Service Manual by providing in-depth
troubleshooting information for each electrical circuit in
your vehicle.
Body Repair Manual:
Describes the procedures involved in the replacement
of damaged body parts.
Authorized Manuals
497
Warranty and Client Relations
ProCarManuals.com
2010 RDX

A
Accessories andModifications
..........................
362
ACCESSORY (Ignition Key Position)
.................................
125
Accessory Power Sockets
..........
157
AcuraLink
®(U.S. models
only)
.......................................
332
Additives, Engine Oil
.................
421
Adjusting the Sound
............
177, 224
Adjusting the Steering Wheel....
122
Advanced Airbags
........................
28
Air Conditioning System
............
164
Usage
......................................
165
Air Pressure, Tires
..............
444, 445
Airbag (SRS)
..........................
10, 24
Alcohol in Gasoline
....................
352
Anti-lock Brakes (ABS) Indicator Light
..................
66, 388
Operation
................................
388
Anti-theft Steering Column Lock
.......................................
125
Anti-theft, Audio System
.............
292
Antifreeze
...................................
424 Armrests
....................................
138
Audio Antenna
...........................
439
Audio System
......................
172, 216
Automatic Lighting Off
Feature
...................................
118
Automatic Seat Belt Tensioners...
22
Automatic Speed Control
...........
300
Automatic Transmission
............
376
Capacity, Fluid
........................
480
Checking Fluid Level
..............
427
Driving with the Paddle Shifters
................................
380
Shift Lever Position Indicators
............................
376
Shift Lever Positions
...............
377
Shift Lock Release
...................
379
Shifting
...................................
376
Auxiliary Input Jack
...................
291
B
Battery Charging System
Indicator
........................
65, 465
Jump Starting
..........................
461 Maintenance
...........................
450
Specifications
..........................
481
Before Driving
...........................
351
Belts, Seat
................................
9, 20
Beverage Holders
......................
156
Bluetooth
®Audio
................
212, 280
Bluetooth
®HandsFreeLink
®......
306
Booster Seats
...............................
54
Brakes Anti-lock Brakes (ABS)
...........
388
Break-in, New Linings
.............
352
Bulb Replacement
...................
433
Fluid
.......................................
429
Parking
...................................
150
System Design
........................
387
System Indicator (Amber)
.......
468
System Indicator (Red)
...........
467
Wear Indicators
.......................
387
Braking System
..........................
387
Break-in, New Vehicle
................
352
Brightness Control,
Instruments
............................
120
CONTINUED
Index
I
INDEX
09/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX

D
DANGER, Explanation of
.............
iii
Dashboard
...............................
3, 62
Daytime Running Lights
............
119
Dead Battery
..............................
461
Defects, Reporting Safety
...........
496
Defogger, Rear Window
.............
121
Defrosting the Windows
............
167
Dimensions
................................
480
Dimming the Headlights
............
116
Dipstick Automatic Transmission
.........
427
Engine Oil
...............................
356
Directional Signals
...............
69, 116
Disc Brake Wear Indicators.......
387
Disc Care
...................................
257
Disc Changer
......................
185, 239
Disc Changer Error Messages
........................
195, 255
Disc Player
..........................
185, 239
Disposal of Used Oil
...................
423
Doors Childproof Door Locks
............
127
Locking and Unlocking
...........
126 Power Door Locks
..................
126
DOT Tire Quality Grading (U.S. Vehicles)
................................
482
Driver and Passenger Safety
..........
5
Driving
.......................................
371
Economy
.................................
358
Driving Guidelines
.....................
372
Driving Position Memory System
...................................
148
Driving with the Paddle Shifters
...................................
380
Dust and Pollen Filter
................
439
E
Economy, Fuel
...........................
358
Emergencies on the Road
..........
453
Battery, Jump Starting
.............
461
Brake System Indicator
...
467, 468
Changing a Flat Tire
...............
455
Charging System Indicator
........................
65, 465
Checking the Fuses
................
470
Driving with a Flat Tire
...........
454
Hazard Warning Flashers
.......
121 Jump Starting
..........................
461
Low Oil Pressure Indicator
........................
65, 465
Malfunction Indicator
Lamp
.............................
65, 466
Overheated Engine
.................
463
Towing
....................................
475
Emergency Brake
......................
150
Emergency Flashers
..................
121
Emergency Towing
....................
475
Emissions Controls
....................
487
Emissions Testing
......................
490
Engine Adding Engine Coolant
...........
424
If it Won't Start
........................
459
Malfunction Indicator Lamp
.............................
65, 466
Oil Life Indicator
.....................
411
Oil Pressure Indicator
.......
65, 465
Overheating
............................
463
Specifications
..........................
480
Speed Limiter
..........................
378
Starting
...................................
374
Engine Coolant
..........................
424
Engine Number
.........................
479
CONTINUED
Index
III
INDEX
09/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX

Numbers, Identification
.............
478
O
Octane Requirement, Gasoline
.................................
352
Odometer
.....................................
76
Odometer, Trip
............................
76
Off-Highway Driving Guidelines
..............................
405
Off-Road Precautions
..................
405
Oil Change, How to
......................
422
Change, When to
....................
411
Checking Engine
....................
356
Life, Engine
.............................
411
Pressure Indicator
.............
65, 465
Selecting Proper Viscosity Chart
...................................
420
ON (Ignition Key Position)
........
125
Onboard Refueling Vapor Recovery
................................
488
Outside Mirrors
.........................
146
Outside Temperature
...................
76
Overheating, Engine
..................
463 Owner's Maintenance Checks
....
417
Oxygenated Fuels
......................
352
P
Panel Brightness Control
...........
120
Park Gear Position
.....................
377
Parking
......................................
386
Parking Brake
............................
150
Parking Brake and Brake System Indicator
.................................
467
Parking Lights
...........................
116
Parking Over Things that Burn
................................
386, 489
Passenger Airbag Off Indicator
....
33
PGM-FI System
..........................
488
Playing a USB Flash Memory Device
.............................
204, 270
Playing an iPod
...................
197, 260
Playing the FM/AM Radio
...............................
174, 217
Playing the XM
®Radio
........
179, 228
Pollen Filter
...............................
439
Power Door Locks
.....................
126
Power Seat Adjustments
............
134 Power Socket Locations
.............
157
Power Steering Fluid
.................
430
Power Windows
.........................
142
Pregnancy, Using Seat Belts
........
18
Preparing to Drive
......................
373
Proper Seat Belt Usage
................
15
Protecting Adults and Teens
........
12
Additional Safety Precautions
...
19
Advice for Pregnant Women
....
18
Protecting Children
......................
36
General Guidelines
..................
36
Protecting Infants
.....................
41
Protecting Larger Children
......
53
Protecting Small Children
........
42
Using Child Seats with Tethers
.................................
51
Using LATCH
..........................
46
R
Radiator Overheating
.................
463
Radio Theft Protection
...............
292
Radio/CD Sound System
...........
172
Readiness Codes
........................
490
CONTINUED
Index
VII
INDEX
09/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX

Rear Lights, BulbReplacement
...........................
433
Rear Seat Folding Down
.............
138
Rear Window Defogger
..............
121
Rear Window Wiper and Washer
...................................
115
Rearview Mirror
.........................
146
Rearview Mirror with Rearview Camera Display
......................
348
Reclining the Seat Backs
............
134
Refueling
....................................
353
Reminder Indicators
.....................
64
Remote Audio Controls
..............
289
Remote Transmitter
...................
130
Replacement Information Dust and Pollen Filter
.............
439
Engine Oil and Filter
...............
422
Fuses
......................................
469
Light Bulbs
.............................
431
Schedule
.................................
418
Spark Plugs
.............................
480
Tires
.......................................
447
Wiper Blades
..........................
440
Replacing Seat Belts After a Crash
........................................
23 Reporting Safety Defects (U.S.
only)
.......................................
496
Required Engine Oil
..................
420
Reserve Tank, Engine
Coolant
............................
357, 424
Restraint, Child
............................
36
Reverse Gear Position
................
377
Reverse Tilt Door Mirror
...........
147
Rotation, Tire
.............................
447
S
Safety Belts
..............................
9, 20
Safety Defects, Reporting (U.S.
only)
.......................................
496
Safety Features
..............................
8
Airbags
...............................
10, 24
Door Locks
..............................
12
Head Restraints
........................
15
Seat Belts
........................
9, 15, 20
Seats & Seat-Backs
..............
13, 14
Safety Labels, Location of
.............
58
Safety Messages
..........................
iii
Seat Belts
.................................
9, 20
Additional Information
.............
20 Advice for Pregnant Women
....
18
Automatic Seat Belt Tensioners
...........................
22
Cleaning
..................................
438
Lap/Shoulder Belt
..............
15, 21
Maintenance
............................
23
Reminder Indicator and Beeper
.............................
20, 64
System Components
................
20
Use During Pregnancy
.............
18
Wearing a Lap/Shoulder Belt
..................................
15, 21
Seats
..........................................
134
Armrest
...................................
138
Head Restraints
.......................
135
Heaters
...................................
141
Position Memory
....................
148
Seats, Adjusting the
...................
134
Security System
.........................
294
Security System Indicator
............
70
Sensors
Driver's Seat Position Sensor
...
28
Front Passenger's Weight Sensors
................................
28
Impact Sensors
........................
24
Serial Number
............................
478
IndexVIII09/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX

Service Intervals
.........................
411
Service Station Procedures
........
353
Setting the Clock
........................
293
SH-AWD
®...................................
384
Indicator
...................................
70
Torque Distribution Monitor
...
384
Shift Lever Position Indicators
...
376
Shift Lock Release
......................
379
Shifting the Automatic Transmission
..........................
376
Side Airbags
.................................
30
How the Side Airbag Off
Indicator Works
...................
32
How Your Side Airbags Work..30
Side Curtain Airbags
....................
31
How Your Side Curtain Airbags Work
....................................
31
Side Marker Lights, Bulb Replacement in
.......................
432
Signaling Turns
............................
69
Snow Tires
.................................
448
Sound System
.....................
172, 216
Spare Tire
..................................
454
Inflating
...........................
444, 454
Specifications
..........................
481
Spark Plugs
................................
480 Specifications
.............................
480
Speed Control
............................
300
Speed Limiter
.............................
378
Speedometer
................................
73
SRS Indicator
.........................
32, 65
SRS, Additional Information
.........
24
Additional Safety Precautions
...
35
Airbag Service
..........................
34
Airbag System Components
.....
24
How the Side Airbag Off Indicator Works
...................
32
How the SRS Indicator Works..32
How Your Front Airbags Work
....................................
26
How Your Side Airbags Work..30
How Your Side Curtain Airbags Work
....................................
31
START (Ignition Key Position)
.................................
125
Starting the Engine
....................
374
Auto Control Mode
.................
375
In Cold Weather at High Altitude
................................
374
With a Dead Battery
................
461
State Emissions Testing
.............
490
Steam Coming from Engine
.......
463 Steering Wheel
Adjustments
............................
122
Anti-theft Column Lock
...........
125
Buttons
...........................
289, 300
Position Memory
....................
148
Stereo Sound System
..........
172, 216
Storing Your Vehicle
..................
452
Sun Visor
...................................
157
Super Handling-All Wheel Drive ™
(SH-AWD
®) System
................
384
Supplemental Restraint System
............................
10,24
Servicing
..................................
34
SRS Indicator
......................
32, 65
System Components
................
24
System Messages
........................
79
T
Tachometer
..................................
73
Tailgate
......................................
128
Open Monitor
..........................
12
Opening the
............................
128
Taillights, Changing Bulbs in
.....
433
CONTINUED
Index
IX
INDEX
09/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX

Gasoline:
Premium unleaded gasoline, pump
octane number of 91 or higher.Avoid driving with an extremely low
fuel level. Running out of fuel could
cause the engine to misfire, damaging
the catalytic converter.
Fuel Tank Capacity:18.0 US gal (68 L)
Required Engine Oil;
Always use Mobil 1
®5W-30 or an
equivalent oil that meets the
Acura HTO-06 standard.
Oil change capacity (including
filter):
5.0 US qt (4.7 L) Automatic Transmission Fluid:
Acura ATF-Z1
(automatic transmission fluid)
(see page
427).
On models with SH-AWDRear Differential Fluid:
Use Acura ATF-Z1
(automatic transmission fluid)
only.
Capacity:
SH-AWD differential case
2.67 US qt (2.53 L)On models with SH-AWDTransfer Assembly Fluid:
SAE 90 or SAE 80W-90 viscosity
hypoid gear oil, API service
classified GL4 or GL5 only. Power Steering Fluid:
Acura Power Steering Fluid
preferred, or another brand of
power steering fluid as a
temporary replacement. Do not
use ATF (see page
430).
Brake Fluid:
Honda Heavy Duty Brake Fluid
DOT 3 preferred, or a DOT 3 or
DOT 4 brake fluid as a temporary
replacement (see page 429).
Tire Pressure (measured cold):
Front/Rear:
32 psi (220 kPa , 2.2 kgf/cm
2)
Spare Tire Pressure:
60 psi (420 kPa , 4.2 kgf/cm2)
Service Information Summary09/07/07 15:02:04 10 ACURA RDX MMC North America Owner's M 50 31STK630 enu
ProCarManuals.com
2010 RDX
