brake fluid Acura RDX 2011 Owner's Manual

U.S. CanadaParking Brake and Brake System
Indicator (Red)
This indicator has two functions:1. It comes on when you turn the ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. Driving with
the parking brake not fully
released can damage the brakes
and tires.
If you drive without releasing the
parking brake, a beeper will sound,
and you will also see a ‘‘RELEASE
PARKING BRAKE ’’message on the
multi-information display (see page
79). 2. If it stays on after you have fully
released the parking brake while
the engine is running, or if it
comes on while driving, it can
indicate a problem in the brake
system. You will also see a
‘‘BRAKE FLUID LOW ’’or
‘‘ CHECK BRAKE SYSTEM ’’
message on the multi-information
display. For more information, see
page 467.
U.S. CanadaBrake System Indicator (Amber)
The brake system indicator (amber)
normally comes on when you turn
the ignition switch to the ON (II)
position and goes off after the engine
starts. If it comes on at any other
time, there is a problem in the brake
system including the electric vacuum
pump. If this happens, have your
vehicle checked by your dealer. For
more information, see page 468.
You will also see a ‘‘CHECK BRAKE
SYSTEM ’’message on the multi-
information display (see page 79).
CONTINUED
Instrument Panel Indicators
67
Instruments and Controls
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

This section explains why it is
important to keep your vehicle well
maintained and how to follow basic
maintenance safety precautions.
This section also includes
instructions on how to read the
maintenance minder messages on
the multi-information display, and
instructions for simple maintenance
tasks you may want to take care of
yourself.
If you have the skills and tools to
perform more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page 497 for information on how to
obtain a copy, or see your dealer.U.S. Vehicles:
Maintenance,
replacement, or repair of
emissions control devices and
systems may be done by any
automotive repair establishment
or individual using parts that are
‘‘certified’’ to EPA standards. Maintenance Safety
.....................
410
Maintenance Minder ™
................
411
Fluid Locations
...........................
419
Adding Engine Oil
......................
420
Required Engine Oil
...............
420
Changing the Engine Oil and
Filter
.......................................
422
Engine Coolant
...........................
424
Windshield Washers
...................
426
Automatic Transmission Fluid
....
427
Brake Fluid
.................................
429
Power Steering Fluid
..................
430
Lights
..........................................
431
Cleaning the Seat Belts
...............
438
Floor Mats
..................................
438
Audio Antenna
............................
439
Intercooler
..................................
439
Dust and Pollen Filter
.................
439
Wiper Blades
..............................
440
Wheels
........................................
443
Tires
...........................................
444
Checking the Battery
..................
450
Vehicle Storage
...........................
451
Interior Care
...............................
452
Maintenance
409
Maintenance
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

U.S. Vehicles:
According to state and federal
regulations, failure to perform
maintenance on the items marked
with＃will not void your emissions
warranties. However, Acura
recommends that all maintenance
services be performed in accordance
with the intervals indicated by the
multi-information display. Owner's Maintenance Checks
You should check the following
items at the specified intervals. If you
are unsure of how to perform any
check, turn to the appropriate page
listed.
●Engine oil level
－Check every
time you fill the fuel tank. See page
356.●Engine coolant level －Check the
radiator reserve tank every time
you fill the fuel tank. See page 357.●Automatic transmission －Check
the fluid level monthly. See page
427.
●Brakes －Check the fluid level
monthly. See page 429.●Tires －Check the tire pressure
monthly. Examine the tread for
wear and foreign objects. See page
445.●Lights －Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
and license plate lights monthly.
See page 431.
Maintenance Minder™
417
Maintenance
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

SymbolMaintenance Main Items
A
●Replace engine oil
ꭧ 1
B
●Replace engine oil
ꭧ1and oil filter
●Inspect front and rear brakes●Check parking brake adjustment●Inspect these items:●Tie rod ends, steering gear box, and boots●Suspension components●Driveshaft boots●Brake hoses and lines (including ABS/VSA)●All fluid levels and condition of fluids●Exhaust system
＃
●Fuel lines and connections
＃
ꭧ1: If the message ‘‘SERVICE ’’does not appear more than 12 months after
the display is reset, change the engine oil every year.
＃: See information on maintenance and emissions warranty on page 417.
NOTE:
●Independent of maintenance message in the Information Display,
replace the brake fluid every 3 years.●Inspect idle speed every 160,000 miles (256,000 km).●Adjust the valves during services A, B, 1, 2, or 3 if they are noisy. Symbol Maintenance Sub Items
1
●Rotate tires
2●Replace air cleaner element If you drive in dusty conditions, replace every 15,000
miles (24,000 km).●Replace dust and pollen filterIf you drive primarily in urban areas that have high
concentrations of soot in the air from industry and from
diesel-powered vehicles, replace every 15,000 miles
(24,000 km).●Inspect drive belt
3●Replace transmission and transfer
ꭧ 2fluid
Driving in mountainous areas at very low vehicle speeds
or trailer towing results in higher transmission and
transfer temperatures. This requires transmission and
transfer fluid changes more frequently than
recommended by the Maintenance Minder. If you
regularly drive your vehicle under these conditions, have
the transmission and transfer fluid changed at 60,000
miles (100,000 km), then every 30,000 miles (48,000 km).
4
●Replace spark plugs●Inspect valve clearance
5●Replace engine coolant
6●Replace rear differential fluid
ꭧ 2
Driving in mountainous areas at very low vehicle speeds
or trailer towing results in higher level of mechanical
(shear) stress to fluid. This requires differential fluid
changes more frequently than recommended by the
Maintenance Minder. If you regularly drive your vehicle
under these conditions, have the differential fluid
changed at 7,500 miles (12,000 km), then every 15,000
miles (24,000 km).
ꭧ2: SH-AWD only
Maintenance Minder™
Maintenance Minder
41810/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

ENGINE OIL
DIPSTICK
(Orange loop)
WASHER FLUID
(Blue cap)
POWER STEERING
FLUID
(Red cap)ENGINE
COOLANT
RESERVOIR
RADIATOR CAP BRAKE FLUID
(Black cap)
AUTOMATIC
TRANSMISSION
FLUID DIPSTICK
(Yellow loop)
ENGINE OIL
FILL CAP
Fluid Locations
419
Maintenance
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Check the fluid level in the brake
fluid reservoir monthly.
Independent of the maintenance
minder display, replace the brake
fluid every 3 years.Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 fluid, from a sealed
container, as a temporary
replacement.
Using any non-Honda brake fluid can
cause corrosion and decrease the life
of the system. Have the brake
system flushed and refilled with
Honda Heavy Duty Brake Fluid
DOT 3 as soon as possible.
Brake fluid marked DOT 5 is not
compatible with your vehicle's
braking system and can cause
extensive damage.
The fluid level should be between
the MIN and MAX marks on the side
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected for leaks or
worn brake pads.
MAX
MINBrake Fluid
429
Maintenance
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Brake System Indicator
(Red)U.S. CanadaThe brake system indicator (red)
normally comes on when you turn
the ignition switch to the ON (II)
position, and as a reminder to check
the parking brake. It will stay on if
you do not fully release the parking
brake.
If the brake system indicator (red)
comes on while driving, the brake
fluid level is probably low. Press
lightly on the brake pedal to see if it
feels normal. If it does, check the
brake fluid level the next time you
stop at a service station (see page
429).
You will also see a‘‘BRAKE FLUID
LOW ’’message on the multi-
information display (see page 79). If the fluid level is low, take your
vehicle to a dealer, and have the
brake system inspected for leaks or
worn brake pads.
However, if the brake pedal does not
feel normal, you should take
immediate action. A problem in one
part of the system's dual circuit
design will still give you braking at
two wheels. You will feel the brake
pedal go down much farther before
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
You will also see a
‘‘CHECK BRAKE
SYSTEM ’’message on the multi-
information display (see page 79). Slow down by shifting to a lower
gear, and pull to the side of the road
when it is safe. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed, and repaired as
soon as possible (see
Emergency
Towing on page 475).
If you must drive the vehicle a short
distance in this condition, drive
slowly and carefully.
If the ABS indicator and the VSA
system indicator come on with the
brake system indicator, have your
vehicle inspected by your dealer
immediately.
Brake System Indicator
467
Taking Care of the Unexpected
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

A
Accessories andModifications
..........................
362
ACCESSORY (Ignition Key Position)
.................................
125
Accessory Power Sockets
..........
157
AcuraLink
®(U.S. models
only)
.......................................
332
Additives, Engine Oil
.................
421
Adjusting the Sound
............
177, 224
Adjusting the Steering Wheel....
122
Advanced Airbags
........................
28
Airbag (SRS)
..........................
10, 24
Air Conditioning System
............
164
Usage
......................................
165
Air Pressure, Tires
..............
444, 445
Alcohol in Gasoline
....................
352
Antifreeze
...................................
424
Anti-lock Brakes (ABS) Indicator
............................
66, 388
Operation
................................
388
Anti-theft, Audio System
.............
292
Anti-theft Steering Column Lock
.......................................
125 Armrests
....................................
138
Audio Antenna
...........................
439
Audio System
......................
172, 216
Automatic Lighting Off
Feature
...................................
118
Automatic Seat Belt Tensioners...
22
Automatic Speed Control
...........
300
Automatic Transmission
............
376
Capacity, Fluid
........................
480
Checking Fluid Level
..............
427
Driving with the Paddle Shifters
................................
380
Shifting
...................................
376
Shift Lever Position Indicators
............................
376
Shift Lever Positions
...............
377
Shift Lock Release
...................
379
Auxiliary Input Jack
...................
291
B
Battery Charging System
Indicator
........................
65, 465
Jump Starting
..........................
461 Maintenance
...........................
450
Specifications
..........................
481
Before Driving
...........................
351
Belts, Seat
................................
9, 20
Beverage Holders
......................
156
Bluetooth
®Audio
................
212, 280
Bluetooth
®HandsFreeLink
®......
306
Booster Seats
...............................
54
Brakes Anti-lock Brakes (ABS)
...........
388
Break-in, New Linings
.............
352
Bulb Replacement
...................
433
Fluid
.......................................
429
Parking
...................................
150
System Design
........................
387
System Indicator (Amber)
.......
468
System Indicator (Red)
...........
467
Wear Indicators
.......................
387
Braking System
..........................
387
Break-in, New Vehicle
................
352
Brightness Control,
Instruments
............................
120
CONTINUED
Index
I
INDEX
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

EngineAdding Engine Coolant
...........
424
If it Won't Start
........................
459
Malfunction Indicator
Lamp
.............................
65, 466
Oil Life Indicator
.....................
411
Oil Pressure Indicator
.......
65, 465
Overheating
............................
463
Specifications
..........................
480
Speed Limiter
..........................
378
Starting
...................................
374
Engine Coolant
..........................
424
Engine Number
.........................
479
Ethanol in Gasoline
....................
352
Evaporative Emissions Controls
..................................
487
Exhaust Emissions Controls
......
488
Exhaust Fumes
............................
57
Expectant Mothers, Use of Seat Belts by
....................................
18
F
Fan, Interior
...............................
166
Features
.....................................
163 Filters
Dust and Pollen
.......................
439
Oil
...........................................
422
Flashers, Hazard Warning
.........
121
Flat Tire, Changing a
.................
455
Floor Mats
.................................
438
Fluids Automatic Transmission
.........
427
Brake
......................................
429
Location
..................................
419
Power Steering
........................
430
Windshield Washer
.................
426
FM/AM Radio Reception
...........
287
Fog Lights
..................................
119
Folding the Rear Seats Down
.....
138
Four-way Flashers
......................
121
Front Airbags
.........................
10, 26
Front Door Pockets
....................
155
Front Seat Heaters
...................................
141
Front Seat Power
Adjustments
...........................
134
Fuel
............................................
352
Economy
.................................
358
Fill Door and Cap
....................
353
Gauge
......................................
73 Low Fuel Indicator
...................
68
Octane Requirement
...............
352
Reserve Indicator
.....................
68
Tank, Filling the
......................
353
Tighten Fuel Cap
....................
354
Fuel Economy
............................
358
Fuses, Checking the
..................
470
G
Gas Mileage, Improving
.............
359
Gasoline
.....................................
352
Low Fuel Indicator
...................
68
Octane Requirement
...............
352
Tank, Refueling
.......................
353
Gas Station Procedures
..............
353
Gauges Fuel
..........................................
73
Speedometer
............................
73
Tachometer
..............................
73
Turbo Boost Meter
..................
73
Gearshift Lever Positions Automatic
Transmission
...............
376, 377
Glove Box
..................................
155
IndexIV10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Mirrors, Adjusting
......................
146
Modifications
.............................
363
Modifying Your Vehicle
.............
363
Moonroof
...................................
144
Multi-Information Display
............
74
N
Neutral Gear Position
.................
377
New Vehicle Break-in
.................
352
NOTICE, Explanation of
................
i
Numbers, Identification
.............
478
O
Octane Requirement, Gasoline
.................................
352
Odometer
.....................................
76
Odometer, Trip
............................
76
Off-Highway Driving Guidelines
..............................
405
Off-Road Precautions
..................
405
Oil Change, How to
......................
422
Change, When to
....................
411 Checking Engine
....................
356
Life, Engine
.............................
411
Pressure Indicator
.............
65, 465
Selecting Proper Viscosity
Chart
...................................
420
Onboard Refueling Vapor Recovery
................................
488
ON (Ignition Key Position)
........
125
Outside Mirrors
.........................
146
Outside Temperature
...................
76
Overheating, Engine
..................
463
Owner's Maintenance Checks
....
417
Oxygenated Fuels
......................
352
P
Panel Brightness Control
...........
120
Park Gear Position
.....................
377
Parking
......................................
386
Parking Brake
............................
150
Parking Brake and Brake System Indicator
.................................
467
Parking Lights
...........................
116
Parking Over Things that Burn
................................
386, 489 Passenger Airbag Off Indicator
....
33
PGM-FI System
..........................
488
Playing an iPod
®..................
197, 260
Playing a USB Flash Memory
Device
.............................
204, 270
Playing Disc
...............................
185
Playing the FM/AM Radio
...............................
174, 217
Playing the XM
®Radio
........
179, 228
Pollen Filter
...............................
439
Power Door Locks
.....................
126
Power Seat Adjustments
............
134
Power Socket Locations
.............
157
Power Steering Fluid
.................
430
Power Windows
.........................
142
Pregnancy, Using Seat Belts
........
18
Preparing to Drive
......................
373
Proper Seat Belt Usage
................
15
Protecting Adults and Teens
........
12
Additional Safety Precautions
...
19
Advice for Pregnant Women
....
18
CONTINUED
Index
VII
INDEX
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu
