dimensions Acura RDX 2011 Owner's Manual

Contents
A convenient reference to the
sections in this manual.
Your Vehicle at a Glance
A quick reference to the main
controls in your vehicle.
Driver and Passenger Safety
Important information about the
proper use and care of your vehicle's
seat belts, an overview of the
supplemental restraint system, and
valuable information on how to
protect children with child restraints.
Instruments and Controls
Explains the purpose of each
instrument panel indicator and
gauge, and how to use the controls
on the dashboard and steering
column.
Features
How to operate the climate control
system, the audio system, and other
convenience features.Before Driving
What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
Driving
The proper way to start the engine,
shift the transmission, and park; plus
what you need to know if you're
planning to tow a trailer.
Maintenance
The Maintenance Minder
TM
shows
you when you need to take your
vehicle to the dealer for maintenance
service. There is also a list of things
to check and instructions on how to
check them.
Taking Care of the Unexpected
This section covers several problems
motorists sometimes experience, and
details how to handle them. Technical Information
ID numbers, dimensions, capacities,
and technical information.
Warranty and Client Relations
(U.S. and Canada only)
A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual for detailed
information.
Index
Service Information Summary
A summary of the information you
need when you pull up to the fuel
pump.
Overview of Contents210/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

When you store a large item like a
briefcase, lift the shelves up to create
a large space.
The maximum dimensions of the
item you can store in the console
compartment are:
Length: 16.9 in (430 mm)
Height: 12.2 in (310 mm)
Width: 5.5 in (140 mm)Cargo Area Cover
Your vehicle has a cargo area cover
to conceal your luggage and protect
them from direct sunlight.
Do not put any items on top of the
cargo area cover. They can block
your view and be thrown around the
vehicle during a crash.
The cargo area cover may be
removed to give you more cargo
space.
To remove it:
1. Open the tailgate. Remove the
hook from the tab on the tailgate.
Make sure you use both hands to
prevent the cargo area cover from
falling accidentally.
2. Lift and pull the rear edge of the cargo area cover slightly to unlock
it from the hanger bars, then
remove it straight out.
CARGO
AREA
COVER
HOOK TAB
HANGER BAR
Interior Convenience Items16010/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

The diagrams in this section give you
the dimensions and capacities of
your vehicle and the locations of the
identification numbers. It also
includes information you should
know about your vehicle's tires and
emissions control systems.Identification Numbers
...............
478
Specifications
..............................
480
DOT Tire Quality Grading (U.S. Vehicles)
.............................
482
Uniform Tire Quality Grading
...............................
482
Treadwear
...............................
482
Traction
..................................
482
Temperature
...........................
483
Tire Labeling
..............................
484
Tire Pressure Monitoring System
(TPMS) －Required Federal
Explanation
.........................
485
Emissions Controls
.....................
487
The Clean Air Act
....................
487
Crankcase Emissions Control System
................................
487
Evaporative Emissions Control
System
................................
487
Onboard Refueling Vapor
Recovery
.............................
488
Exhaust Emissions
Controls
..............................
488
Replacement Parts
..................
488 Three Way Catalytic
Converter
................................
489
Emissions Testing
.......................
490
Technical Information
477
Technical Information
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

DimensionsLength182.5 in (4,635 mm)
Width 73.6 in (1,870 mm)
Height 65.2 in (1,655 mm)
Wheelbase 104.3 in (2,650 mm)
Track Front 61.9 in (1,572 mm)
Rear 62.6 in (1,590 mm)WeightsGross vehicle weight rating See the certification label attached to
the driver's doorjamb.EngineType Water cooled 4-stroke DOHC i-VTEC
4 cylinder gasoline engine with turbo charger, intercooler
Bore x Stroke 3.39 x 3.90 in (86.0 x 99.0 mm)
Displacement 140.3 cu-in (2,300 cm
3)
Compression ratio 8.8
Spark plugs SILKR8A-S (NGK)
Seating CapacitiesTotal 5
Front 2
Rear 3
CapacitiesFuel tankApprox.
18.0 US gal (68 L)
Engine oil Change
ꭧ 1
Including
filter 5.0 US qt (4.7 L)
Without filter 4.8 US qt (4.5 L)
Total 6.1 US qt (5.8 L)
Engine coolant Change
ꭧ 2
1.85 US gal (7.0 L)
Total 2.22 US gal (8.4 L)
Automatic
transmission fluid Change
2WD 3.0 US qt (2.8 L)
4WD 3.1 US qt (2.9 L)
Total 2WD 8.8 US qt (8.3 L)
4WD 8.2 US qt (7.8 L)
Rear differential
fluid (4WD) Change
2.67 US qt (2.53 L)
Total 2.93 US qt (2.77 L)
Transfer assembly
fluid (4WD) Change
0.45 US qt (0.43 L)
Total 0.48 US qt (0.45 L)
Windshield
washer reservoir U.S. Vehicles 2.6 US qt (2.5 L)
Canada
Vehicles 4.8 US qt (4.5 L)
ꭧ1: Excluding the oil remaining in the engine
ꭧ2: Including the coolant in the reserve tank and that remaining in the engine Reserve tank capacity:
0.18 US gal (0.7 L)
Specifications48010/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Customized Settings
....................
82
D
DANGER, Explanation of
.............
iii
Dashboard
...............................
3, 62
Daytime Running Lights
............
119
Dead Battery
..............................
461
Defects, Reporting Safety
...........
496
Defogger, Rear Window
.............
121
Defrosting the Windows
............
167
Dimensions
................................
480
Dimming the Headlights
............
116
Dipstick
Automatic Transmission
.........
427
Engine Oil
...............................
356
Directional Signals
...............
69, 116
Disc Brake Wear Indicators.......
387
Disc Care
...................................
257
Disc Changer
......................
185, 239
Disc Changer Error Messages
........................
195, 255
Disc Player
..........................
185, 239
Disposal of Used Oil
...................
423 Doors
Childproof Door Locks
............
127
Locking and Unlocking
...........
126
Power Door Locks
..................
126
DOT Tire Quality Grading (U.S. Vehicles)
................................
482
Driver and Passenger Safety
..........
5
Driving
.......................................
371
Economy
.................................
358
Driving Guidelines
.....................
372
Driving Position Memory System
...................................
148
Driving with the Paddle Shifters
...................................
380
Dust and Pollen Filter
................
439
E
Economy, Fuel
...........................
358
Emergencies on the Road
..........
453
Battery, Jump Starting
.............
461
Brake System Indicator
...
467, 468
Changing a Flat Tire
...............
455
Charging System Indicator
........................
65, 465 Checking the Fuses
................
470
Driving with a Flat Tire
...........
454
Hazard Warning Flashers
.......
121
Jump Starting
..........................
461
Low Oil Pressure Indicator
........................
65, 465
Malfunction Indicator Lamp
.............................
65, 466
Overheated Engine
.................
463
Towing
....................................
475
Emergency Brake
......................
150
Emergency Flashers
..................
121
Emergency Towing
....................
475
Emissions Controls
....................
487
Emissions Testing
......................
490
CONTINUED
Index
III
INDEX
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

TransmissionChecking Fluid Level
..............
427
Fluid Selection
........................
427
Identification Number
.............
478
Shifting the Automatic
.............
376
Treadwear
..................................
482
Trip Meter
...................................
76
Turbo Boost Meter
......................
73
Turn Signals
.................................
69
Turn Signals and Headlights
......
116
U
Unexpected, Taking Care of the
..........................................
453
Uniform Tire Quality Grading (U.S. only)
..............................
482
Unleaded Gasoline
.....................
352
USB Flash Memory Device Error Messages
........................
211, 279
Used Oil, How to Dispose of......
423
V
Vanity Mirror
.............................
158 Vehicle Capacity Load
................
365
Vehicle Dimensions
...................
480
Vehicle Identification Number
...
478
Vehicle Stability Assist (VSA)
System
................................
395
VSA Activation Indicator
..........
69
VSA System Indicator
..............
68
Vehicle Storage
..........................
451
VIN
............................................
478
Viscosity, Oil
..............................
420
W
WARNING, Explanation of
...........
iii
Warning Labels, Location of
.........
58
Warranty Coverages (U.S. only)
.......................................
495
Washer, Windshield Checking the Fluid Level
........
426
Operation
................................
114
Wheels
.......................................
443
Adjusting the Steering
.............
122
Alignment and Balance
...........
447
Compact Spare
........................
454
Wrench, Nut
...........................
455 Windows
Auto Reverse
...........................
143
Operating the Power
...............
142
Rear, Defogger
........................
121
Windshield Cleaning
..................................
114
Defroster
.................................
167
Washers
..........................
114, 426
Wipers, Windshield Changing Blades
.....................
440
Operation
................................
114
Rear Windshield Wiper and
Washer
................................
115
Worn Tires
.................................
445
Wrecker, Emergency Towing
....
475
X
XM
®Radio
..........................
179, 228Index
XI
INDEX
