high beam Acura RDX 2011 Owner's Manual

The U.S. instrument panel is shown. Differences for the Canadian models are noted in the text.
VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATOR
(P. 68)HIGH BEAM INDICATOR (P. 69)
LOW TIRE PRESSURE/TPMS INDICATOR
(P. 71, 390)
VEHICLE STABILITY ASSIST (VSA)
ACTIVATION INDICATOR (P. 69) BRAKE SYSTEM INDICATOR (AMBER) (P. 67, 468)
LIGHTS ON INDICATOR
(P. 70)
IMMOBILIZER
SYSTEM
INDICATOR (P. 66)
LOW OIL PRESSURE
INDICATOR
(P. 65, 465)
CHARGING SYSTEM INDICATOR
(P. 65, 465) A/T TEMPERATURE INDICATOR
(P. 65) MALFUNCTION INDICATOR LAMP
(P. 65, 466) SYSTEM MESSAGE INDICATOR
(P. 72)
FOG LIGHT INDICATOR (P. 70)
LOW FUEL INDICATOR (P. 68)SEAT BELT REMINDER INDICATOR (P. 20, 64)
SECURITY SYSTEM INDICATOR (P. 70) SH-AWD INDICATOR
ꭧ
(P. 70)PARKING BRAKE AND
BRAKE SYSTEM
INDICATOR (RED)
(P. 67, 467)
SIDE AIRBAG OFF
INDICATOR (P. 32, 66)
SUPPLEMENTAL RESTRAINT
SYSTEM (SRS) INDICATOR
(P. 32, 65)
CRUISE CONTROL INDICATOR
(P. 69)
CRUISE MAIN INDICATOR (P. 69)
ANTI-LOCK BRAKE SYSTEM (ABS)
INDICATOR (P. 66, 388)
ꭧ : If equippedInstrument Panel
63
Instruments and Controls
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

VSA Activation Indicator
This indicator has three functions: 1. It comes on as a reminder that you have turned off the vehicle stability
assist (VSA) system.
2. It flashes when VSA is active (see page 395).
3. It comes on along with the VSA system indicator if there is a
problem with the VSA system.
You will also see a ‘‘CHECK VSA
SYSTEM ’’message on the multi-
information display (see page 80).
This indicator normally comes on for
a few seconds when you turn the
ignition switch to the ON (II)
position. For more information, see
page 395.
Cruise Main Indicator
This indicator comes on when you
turn on the cruise control system by
pressing the CRUISE button (see
page 300).Cruise Control Indicator
This indicator comes on when you
set the cruise control. See page 300
for information on operating the
cruise control.High Beam Indicator
This indicator comes on with the
high beam headlights. For more
information, see page 117.
This indicator also comes on with
reduced brightness when the
daytime running lights (DRL) are on
(see page 119).
Turn Signal and Hazard Warning
Indicators
The left or right turn signal indicator
blinks when you signal a lane change
or turn. If an indicator does not blink
or blinks rapidly, it usually means
one of the turn signal bulbs is burned
out (see pages 432 and 434). Replace
the bulb as soon as possible, since
other drivers cannot see that you are
signaling.
When you press the hazard warning
button, both turn signal indicators
and all turn signals on the outside of
the vehicle flash.
CONTINUED
Instrument Panel Indicators
69
Instruments and Controls
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

1. Turn signal
2. Off
3. Parking and interior lights
4. AUTO
5. Headlights on
6. High beams
7. Flash high beams
8. Fog lights off
9. Fog lights onTurn Signal
－Push down on the
lever to signal a left turn and up to
signal a right turn. To signal a lane
change, push lightly on the lever,
and hold it. The lever will return to
center when you release it or
complete a turn. Headlights
－Turning the switch to
the
position turns on the parking
lights, taillights, instrument panel
lights, side-marker lights, and rear
license plate lights.
Turning the switch to the
position
turns on the headlights.
When the light switch is in the
or
position, the lights on indicator
comes on as a reminder. This
indicator stays on if you leave the
light switch on and turn the ignition
switch to the ACCESSORY (I) or the
LOCK (0) position.
If you leave the lights on with the key
removed from the ignition switch,
you will hear a reminder beeper
when you open the driver's door.
Turn Signals and Headlights11610/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

High Beams－Push the lever
forward and the high beam indicator
will come on (see page 69). Pull it
back to return to low beams.
To flash the high beams, pull the
lever back lightly, then release it.
The high beams will stay on as long
as you hold the lever back. AUTO
－The automatic lighting
feature turns on the headlights and
all other exterior lights when it
senses low ambient light.
To turn on automatic lighting, turn
the light switch to AUTO. The lights
will come on automatically when the
outside light level becomes low (at
dusk, for example). The lights on
indicator comes on as a reminder.
The lights and indicator will turn off
automatically when the system
senses high ambient light. The lights will remain on when you
turn off the ignition switch. They will
turn off automatically when you
remove the key and open the driver's
door. To turn them on again, either
turn the ignition switch to the ON
(II) position or turn the light switch
to the
position.
CONTINUED
Turn Signals and Headlights
117
Instruments and Controls
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

If you remove the key from the
ignition switch with the headlight
switch on, but do not open the door,
the lights will turn off after 10
minutes.
The lights will turn on again when
you unlock or open the driver's door.
If you unlock the door, but do not
open it within 15 seconds, the lights
will go off. With the driver's door
open, you will hear a lights on
reminder beeper.
You can change the‘‘HEADLIGHT
AUTO OFF TIMER ’’setting on the
multi-information display (see page
100). Daytime Running Lights
With the headlight switch off or in
the
position, the high beam
headlights and the high beam
indicator come on with reduced
brightness when you turn the
ignition switch to the ON (II)
position and release the parking
brake. They remain on until you turn
the ignition switch off, even if you set
the parking brake.
The headlights revert to normal
operation when you turn them on
with the switch.
If you see a ‘‘CHECK DRL SYSTEM ’’
message on the multi-information
display, there is a problem with the
daytime running light system. Take
your vehicle to a dealer to have it
checked. Fog Lights
Turn the fog lights on and off by
turning the switch next to the
headlight switch.
You can use the fog lights only when
the headlights are on low beam.
They will go off when the headlights
are turned off.
Turn Signals and Headlights
119
Instruments and Controls
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Headlight Aiming
The headlights were properly aimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area or pull a trailer,
readjustment may be required.
Adjustments should be done by your
dealer or another qualified
technician.
Low Beam Headlight Bulb
Replacement
The low beam headlight bulbs are
high voltage discharge tube. High
voltage can remain in the circuit even
with the light switch off and the key
removed. Because of this, you should
not attempt to examine or change a
low beam headlight bulb yourself. If
a low beam headlight bulb fails, take
the vehicle to your dealer to have it
replaced.Replacing a High Beam Headlight
Bulb
Your vehicle has halogen headlight
bulbs. When replacing a bulb, handle
it by its base, and protect the glass
from contact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean
cloth.
Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
1. Open the hood.
Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
2. Remove the bulb by turning it about one-quarter turn
counterclockwise.
3. Insert the new bulb into the hole,and turn it one-quarter turn
clockwise to lock it in place.
4. Push the electrical connector onto the new bulb.
5. Turn on the headlights to test the new bulb.
BULB CONNECTOR
CONTINUED
Lights
431
Maintenance
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

LightsHeadlights High12 V－60 W (HB3)
Low
ꭧ
12 V －35 W (D2S)
Front turn signal/parking lights 12 V －24/2.2 CP (Amber)
Front fog lights 12 V －55 W (H11)
Front side marker lights 12 V －3CP
Rear turn signal lights 12 V －21 W
Brake/Taillights (in fenders) 12 V －21/5 W
Taillights (in tailgate) 12 V －3CP
Back-up lights 12 V －21 W
Rear side marker lights 12 V －2CP
License plate lights 12 V －3CP
High-mount brake light 12 V －16 W
Front ceiling lights/Spotlights 12 V －4CP
Rear ceiling light 12 V －8W
Glove box light 14 V －1.4 W
Console compartment light 14 V －1.4 W
Vanity mirror lights 12 V －2W
Door courtesy lights 12 V －2CP
Cargo area light 12 V －5W
ꭧ : The low beam headlights are high voltage discharged type.
Replacement of a low beam headlight bulb should be performed by
your dealer.
Air ConditioningRefrigerant type HFC-134a (R-134a)
Charge quantity 15.9－17.6 oz (450 －500 g)
Lubricant type SP-10BatteryCapacity12 V－52 AH/5 HR
12 V －65 AH/20 HRFusesInterior See page 473 or the fuse label
attached to the dashboard.
Under-hood See page 474 or the fuse box
covers.AlignmentToe-in Front 0.0 in (0 mm)
Rear 0.10 in (2.5 mm)
Camber Front 0 ° 10’
Rear －1°
Caster Front 2 ° 57’TiresSize Front/Rear P235/55R18 99V
Spare T165/80D17 104M
Pressure Front/Rear 32 psi (220 kPa , 2.2 kgf/cm
2)
Spare 60 psi (420 kPa , 4.2 kgf/cm2)
Specifications
481
Technical Information
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu

Gross Axle Weight Rating(GAWR)
.................................
398
Gross Vehicle Weight Rating (GVWR)
.................................
398
H
HandsFreeLink
®........................
306
Hazard Warning Flashers
..........
121
Headlights Aiming
....................................
431
Automatic Lighting Off
............
118
Automatic Lighting On
............
117
Daytime Running Lights
.........
119
High Beam Indicator
................
69
High Beams, Turning on
.........
116
Lights On Indicator
..................
70
Low Beams, Turning on
..........
116
Reminder Chime
.....................
116
Turning on
..............................
116
Head Restraints
..........................
135
Heated Mirrors
..........................
147
Heaters, Seats
............................
141
Heating and Cooling
..................
164
High Altitude, Starting at
............
374 High-Low Beam Switch
..............
117
HomeLink
®Universal
Transceiver
............................
303
Hood, Opening and Closing
the
..........................................
355
Horn
......................................
4, 113
I
Identification Number, Vehicle
...................................
478
Ignition Keys
........................................
122
Switch
.....................................
125
Timing Control System
...........
488
Immobilizer System
...................
124
Important Safety Precautions
.........
6
Indicators, Instrument Panel
........
63
ABS (Anti-lock Brake)
.......
66, 388
A/T Temp
................................
65
Brake (Amber)
..................
67, 468
Brake (Red)
......................
67, 467
Charging System
..............
65, 465
Cruise Control
..........................
69
Cruise Main
.............................
69 Fog Lights
................................
70
High Beam
...............................
69
Key (Immobilizer System)
.......
66
Lights On
.................................
70
Low Fuel
..................................
68
Low Oil Pressure
..............
65, 465
Low Tire Pressure/ TPMS
............................
71, 390
Maintenance Minder ™
............
411
Malfunction Indicator Lamp
.............................
65, 466
Passenger Airbag Off
...............
33
Seat Belt Reminder
.............
20, 64
Security System
.......................
70
SH-AWD
®.................................
70
Side Airbag Off
....................
32, 66
SRS
.....................................
32, 65
System Message
......................
72
TPMS/Tire Pressure Monitor
.........................
71, 390
Turn Signal and Hazard
Warning
...............................
69
VSA Activation
.........................
69
VSA System
.............................
68
Individual Map Lights
................
152
CONTINUED
Index
V
INDEX
10/06/08 17:42:32 11 ACURA RDX MMC North America Owner's M 50 31STK640 enu
