Page 10 of 518
ᤳ1: To use the horn, press the center pad of the steering wheel.
ᤳ 2: On models without navigation system.
ᤳ 3: Only on vehicles equipped with navigation system. Refer to the navigation system manual.HEADLIGHTS/TURN
SIGNAL/FOG LIGHTS
(P. 116/119)
REMOTE AUDIO
CONTROL BUTTONS
(P. 289)VEHICLE STABILITY
ASSIST (VSA) OFF SWITCH
(P. 396)
MIRROR CONTROLS
(P. 146)
VOICE CONTROL
BUTTONS
ᤳ 3
BLUETOOTH HANDSFREELINK
BUTTONS (P. 306)
STEERING WHEEL ADJUSTMENTS
(P. 122) HORN
ᤳ
1
MULTI-INFORMATION
BUTTONS (P. 74) CRUISE CONTROL
BUTTONS (P. 300)SEAT HEATER SWITCHES
(P. 141)ACCESSORY POWER
SOCKET
(P. 157)
AUXILIARY INPUT JACK
(P. 291) REAR WINDOW
DEFOGGER/
HEATED MIRROR
BUTTON
(P. 121/147)PASSENGER AIRBAG
OFF INDICATOR
(P. 33)
NAVIGATION SYSTEM
ᤳ
3/
CENTER DISPLAY
ᤳ 2
(P. 172)
HAZARD WARNING BUTTON
(P. 121)
PADDLE SHIFTERS
(P. 380) WINDSHIELD
WIPERS/WASHERS/
REAR WINDOW
WIPER/WASHER
(P. 114/115) UPPER DISPLAY
ᤳ
3
(P. 173)
Vehicle with navigation system is shown.
Your Vehicle at a Glance411/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 67 of 518
This section gives information about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach.
Control Locations
..........................
62
Instrument Panel
..........................
63
Instrument Panel Indicators
..........
64
Gauges
..........................................
73
Turbo Boost Meter
...................
73
Fuel Gauge
...............................
73
Multi-Information Display
.............
74
System Messages
.....................
79
Customized Settings
.................
82
Controls Near the Steering
Wheel
.....................................
113
Windshield Wipers and
Washers
..............................
114
Rear Window Wiper and Washer
...............................
115 Turn Signals and Headlights
.......
116
Instrument Panel Brightness
......
120
Rear Window Defogger
...............
121
Hazard Warning Button
..............
121
Steering Wheel Adjustments
.......
122
Keys and Locks
...........................
122
Immobilizer System
....................
124
Ignition Switch
............................
125
Door Locks
.................................
126
Power Door Locks
..................
126
Childproof Door Locks
............
127
Tailgate
.......................................
128
Remote Transmitter
....................
130
Seats
...........................................
134
Front Seat Power
Adjustments
........................
134
Head Restraints
.......................
135
Armrests
.................................
138
Folding the Rear Seats Down
..................................
138
Seat Heaters
................................
141
Power Windows
..........................
142
Moonroof
....................................
144 Mirrors
.......................................
146
Adjusting the Power
Mirrors
...............................
146
Reverse Tilt Door Mirror
........
147
Heated Mirrors
.......................
147
Driving Position Memory
System
....................................
148
Parking Brake
.............................
150
Interior Lights
.............................
151
Ceiling Lights
.........................
151
Individual Map Lights
.............
152
Courtesy Lights
......................
153
Cargo Area Light
.....................
153
Interior Convenience Items
.........
154
Glove Box
...............................
155
Front Door Pockets
.................
155
Beverage Holders
...................
156
Accessory Power Sockets
.......
157
Sun Visor
................................
157
Vanity Mirror
..........................
158
Console Compartment
............
158
Cargo Area Cover
...................
160
Coat Hook
...............................
161
Instruments and Controls
61
Instruments and Controls
11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 119 of 518
ᤳ1: To use the horn, press the center pad of the steering wheel.
ᤳ 2: On models without navigation system.
ᤳ 3: Only on vehicles equipped with navigation system. Refer to the navigation system manual.BLUETOOTH HANDSFREELINK
BUTTONS (P. 306) HORN
ᤳ
1
STEERING WHEEL
ADJUSTMENTS (P. 122) MULTI-INFORMATION
BUTTONS (P. 74)CRUISE CONTROL
BUTTONS (P. 300)SEAT HEATER SWITCHES
(P. 141)
HEADLIGHTS/TURN
SIGNAL/FOG LIGHTS
(P. 116/119)
REMOTE AUDIO CONTROL
BUTTONS (P. 289) VEHICLE STABILITY
ASSIST (VSA) OFF
SWITCH
(P. 396)MIRROR CONTROLS
(P. 146)
VOICE CONTROL
BUTTONS
ᤳ 3
HAZARD WARNING BUTTON
(P. 121)
PADDLE SHIFTERS
(P. 380)
WINDSHIELD
WIPERS/WASHERS/
REAR WINDOW
WIPER/WASHER
(P. 114/115) NAVIGATION SYSTEM
ᤳ
3/
CENTER DISPLAY
ᤳ 2
(P. 172)
PASSENGER AIRBAG
OFF INDICATOR (P. 33)
REAR WINDOW
DEFOGGER/
HEATED MIRROR
BUTTON
(P. 121/147)
AUXILIARY INPUT JACK
(P. 291)
ACCESSORY POWER
SOCKET
(P. 157)
UPPER DISPLAY
ᤳ
3
(P. 173)
Vehicle with navigation system is shown.
Controls Near the Steering Wheel
113
Instruments and Controls
11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 127 of 518
Rear Window DefoggerThe rear window defogger clears fog,
frost, and thin ice from the window.
Push the defogger button to turn it on
and off. The indicator in the button
comes on to show the defogger is on. If
you do not turn it off, the defogger will
shut itself off within about 5 to 30
minutes according to the outside
temperature. It also shuts off when you
turn off the ignition switch. You have to
turn it on again when you restart the
vehicle.
In cold weather, the defogger will not
automatically shut itself off. You must
manually shut off the rear window
defogger when it is no longer
needed.
Make sure the rear window is clear
and you have good visibility before
starting to drive.
The defogger wires on the inside of
the rear window can be accidentally
damaged. When cleaning the glass,
always wipe side-to-side.
Pushing this button also turns the
mirror heaters on or off. For more
information, see page 147.Hazard Warning Button
Push the button between the center
vents to turn on the hazard warning
lights (four-way flashers). This
causes all outside turn signals and
both indicators in the instrument
panel to flash. Use the hazard
warning lights if you need to park in
a dangerous area near heavy traffic,
or if your vehicle is disabled.
Rear Window Defogger, Hazard Warning Button
121
Instruments and Controls
11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 139 of 518
Recalling a Memorized Driving
PositionWhen you unlock the driver's door
with your remote, each remote
activates the keyless memory
settings related to that remote. The
driver's ID (MEMORY 1 or
MEMORY 2) is shown on the back of
each remote.Here is the setting activated with the
remote;
●Driving position memory
(see page 148).
When you unlock and open the
driver's door with the remote
transmitter, the driver's seat (except
the power lumbar feature) and
outside mirrors start to move to the
positions stored in memory. The
indicator in the related memory
button to the remote comes on. To turn off this feature, press and
hold the LOCK and UNLOCK
buttons at the same time. Once the
remote LED blinks twice, release the
buttons. Keyless memory settings for
that remote are canceled.
To turn the keyless memory settings
back on, repeat this procedure. The
LED blinks once to indicate the
feature has been turned on.
Remote Transmitter
133
Instruments and Controls
11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 153 of 518
3. Push the appropriate edge of theadjustment switch to move the
mirror right, left, up, or down.
4. When you finish, move the selector switch to the center (off)
position. This turns the adjustment
switch off to keep your setting. Outside mirror positions can be
stored in the driving position
memory system (see page 148).
Reverse Tilt Door Mirror
The passenger's outside mirror has a
reverse tilt feature. When in reverse,
the mirror will tilt down slightly to
improve your view as you parallel
park. Shifting out of reverse will
return the mirror to its original
position.
●To tilt the passenger mirror, place
the selector switch in the right
position.●To turn the feature off, place the
switch in the center or left
position.
Heated Mirrors
The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off. Pressing this button also
turns the rear window defogger on
and off.
ADJUSTMENT SWITCH
HEATED MIRROR BUTTON
CONTINUEDMirrors
147
Instruments and Controls
11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 155 of 518
3. Press and release the SET buttonon the driver's door. You will hear
a beep. Immediately press and
hold one of the memory buttons (1
or 2) until you hear two beeps. The
indicator in the memory button
will come on. The current
positions of the driver's seat and
outside mirrors are now stored. To cancel the storing procedure after
pressing the SET button, do any of
the following:
●Fail to press a memory button
within 5 seconds.●Readjust the seat position.●Readjust the outside mirror
position.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button's memory. If
you want to add a new position while
retaining the current one, use the
other memory button. Selecting a Memorized Position
To select a memorized position, do
this:
1. Make sure the vehicle is parked.
2. Press the desired memory button
(1 or 2) until you hear a beep, then
release the button.
The system will move the seat and
outside mirrors to the memorized
positions. The indicator in the
selected memory button will flash
during movement. When the
adjustments are complete, you will
hear two beeps, and the indicator will
remain on.
SET BUTTON
MEMORY BUTTONS
CONTINUED
Driving Position Memory System
149
Instruments and Controls
11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 169 of 518
The climate control system in your vehicle
provides a comfortable driving
environment in all weather conditions.
The standard audio system has many
features. This section describes those
features and how to use them.
Your vehicle has an anti-theft audio system
that requires a code number to enable it.
The security system helps to discourage
vandalism and theft of your vehicle.On models with navigation systemThe climate control system and the audiosystem have a voice control feature. Referto the navigation system manual for more
information.Climate Control System
....................
164
Dual Temperature Control
.............
169
Climate Control Sensors
................
171
Audio System
..................................
172
Playing the FM/AM Radio (Models without navigation system)
........
174
To Play the Radio
.........................
174
Adjusting the Sound
.....................
177
Playing the XM
®Radio (Models
without navigation system)
............
179
Playing Discs (Models without navigation system)
.......................
185 Disc Changer Error Messages
(Models without navigationsystem)
..................................
195
Playing an iPod
®(Models without
navigation system)
.......................
197
iPod
®Error Messages (Models
without navigation system)
............
203
Playing a USB Flash Memory Device (Models without navigationsystem)
..................................
204
USB Flash Memory Device Error Messages (Models without
navigation system)
...................
211
Bluetooth
®Audio System (Models
without navigation system)
............
212
Audio System (Models with navigation system)
..................................
216
Interface Dial
..............................
216
Playing the FM/AM Radio (Models
with navigation system)
.............
217
Adjusting the Sound
.....................
224
Playing the XM
®Radio (Models with
navigation system)
.......................
228
Playing Discs (Models with navigation system)
......................................
239
Disc Changer Error Messages
(Models with navigationsystem)
..................................
255 Protecting Your Discs
.......................
257
Playing an iPod
®(Models with
navigation system)
.......................
260
iPod
®Error Messages (Models with
navigation system)
.......................
269
Playing a USB Flash Memory Device (Models with navigation
system)
..................................
270
USB Flash Memory Device Error Messages (Models with navigation
system)
..................................
279
Bluetooth
®Audio System (Models with
navigation system)
.......................
280
FM/AM Radio Reception
..................
287
Remote Audio Controls
.....................
289
Auxiliary Input Jack
..........................
291
Radio Theft Protection
......................
291
Setting the Clock
.............................
293
Security System
...............................
294
Compass
........................................
295
Compass Operation
....................
295
Cruise Control
.................................
300
HomeLink
®Universal Transceiver
......
303
Bluetooth
®HandsFreeLink
®..............
306
AcuraLink
®(U.S. models only)
...........
332
Rearview Mirror with Rearview
Camera Display
...........................
348
Features
163
Features
11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 510 of 518
Instrument Panel Brightness
.....
120
Instruments and Controls
.............
61
Intercooler
.................................
439
Interface Dial
.............................
216
Interior Care
..............................
452
Interior Lights
............................
151
Introduction
...................................
i
iPod
®...................................
197, 260
iPod
®Error Messages
.........
203, 269
J
Jacking up the Vehicle
...............
455
Jack, Tire
...................................
455
Jump Starting
.............................
461
K
Keys
...........................................
122
L
Label, Certification
.....................
478
Lane Change, Signaling
.............
116 Lap/Shoulder Belt
.................
15, 21
LATCH Anchorage System
..........
46
Lights Indicator
...................................
63
Interior
....................................
151
Parking
...................................
116
Turn Signal
.............................
116
Load Limit
...........................
366, 397
LOCK (Ignition Key Position)....
125
Locks Anti-theft Steering Column
......
125
Childproof Door
......................
127
Fuel Fill Door
..........................
354
Glove Box
...............................
155
Lockout Prevention
.................
127
Power Door
.............................
126
Tailgate
...................................
128
Low Coolant Level
......................
358
Lower Anchors
.............................
46
Low Fuel Indicator
.......................
68
Low Oil Pressure
Indicator
...........................
65, 465
Low Tire Pressure/TPMS Indicator
...........................
71, 390
Lubricant Specifications Chart...
480
Luggage, Storing (cargo)
...........
365 M
Maintenance
..............................
409
Main Items and Sub Items
......
415
Minder
....................................
411
Owner's Maintenance Checks
................................
417
Safety
......................................
410
Schedule
.................................
418
Malfunction Indicator Lamp
................................
65, 466
Memory, Driving Position
..........
148
Meters, Gauges
............................
73
Methanol in Gasoline
.................
352
Mirrors, Adjusting
......................
146
Modifications
.............................
363
Modifying Your Vehicle
.............
363
Moonroof
...................................
144
Multi-Information Display
............
74
N
Neutral Gear Position
.................
377
New Vehicle Break-in
.................
352
NOTICE, Explanation of
................
i
IndexVI11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
Page 512 of 518
Readiness Codes
........................
490
Rear Lights, Bulb Replacement
...........................
433
Rear Seat Folding Down
.............
138
Rearview Mirror
.........................
146
Rearview Mirror with Rearview Camera Display
......................
348
Rear Window Defogger
..............
121
Rear Window Wiper and Washer
...................................
115
Recalling a Memorized Driving Position
..................................
133
Reclining the Seat Backs
............
134
Refueling
....................................
354
Reminder Indicators
.....................
64
Remote Audio Controls
..............
289
Remote Transmitter
...................
130
Replacement Information Dust and Pollen Filter
.............
439
Engine Oil and Filter
...............
422
Fuses
......................................
469
Light Bulbs
.............................
431
Schedule
.................................
418
Spark Plugs
.............................
480
Tires
.......................................
447
Wiper Blades
..........................
440 Replacing Seat Belts After a
Crash
........................................
23
Reporting Safety Defects
............
496
Required Engine Oil
..................
420
Reserve Tank, Engine Coolant
............................
358, 424
Restraint, Child
............................
36
Reverse Gear Position
................
377
Reverse Tilt Door Mirror
...........
147
Rotation, Tire
.............................
447
S
Safety Belts
..............................
9, 20
Safety Defects, Reporting
...........
496
Safety Features
..............................
8
Airbags
...............................
10, 24
Door Locks
..............................
12
Head Restraints
........................
15
Seat Belts
........................
9, 15, 20
Seats & Seat-Backs
..............
13, 14
Safety Labels, Location of
.............
58
Safety Messages
..........................
iii
Seat Belts
.................................
9, 20
Additional Information
.............
20 Advice for Pregnant Women
....
18
Automatic Seat Belt Tensioners
...........................
22
Cleaning
..................................
438
Lap/Shoulder Belt
..............
15, 21
Maintenance
............................
23
Reminder Indicator and Beeper
.............................
20, 64
System Components
................
20
Use During Pregnancy
.............
18
Wearing a Lap/Shoulder Belt
..................................
15, 21
Seats
..........................................
134
Armrest
...................................
138
Head Restraints
.......................
135
Heaters
...................................
141
Position Memory
....................
148
Seats, Adjusting the
...................
134
Security System
.........................
294
Security System Indicator
............
70
Sensors
Driver's Seat Position Sensor
...
28
Front Passenger's Weight Sensors
................................
28
Impact Sensors
........................
24
Serial Number
............................
478
IndexVIII11/06/16 17:42:51 12 ACURA RDX MMC North America Owner's M 50 31STK650 enu
