Indicator Lights

Door and Brake Lamp Monitor
The appropriate light comes on in this display if the trunk or any door
is not closed tightly. If a brake light
does not work, the BRAKE LAMP
indicator comes on when you push
the brake pedal with the ignition switch ON (II).
A burned out brake light is a hazard when drivers behind you cannot tell
you are braking. Have your brake lights repaired right away.
All the lights in the monitor display come on for a few seconds when you
turn the ignition switch ON (II). Turn Signal and
Hazard Warning
Indicators
The left or right turn signal light blinks when you signal a lane changeor turn. If the light does not blink or
blinks rapidly, it usually means one of the turn signal bulbs is burned out (see page 250 ). Replace the bulb as
soon as possible, since other drivers
cannot see that you are signalling.
When you turn on the Hazard
Warning switch, both turn signal lights blink. All turn signals on theoutside of the vehicle should flash.
Low Fuel Indicator
This light comes on as a reminder that you must refuel soon. High Beam Indicator
This light comes on with the high beam headlights. See page 63 forinformation on the headlight

controls.

On Canadian models, this indicator
comes on with reduced brightness
when the Daytime Running Lights (DRL) are on (see page 65 ).
"Daytime Running
Lights" Indicator

Canadian models only

This indicator lights when you turn the ignition switch to ON (II) with
the headlight switch off and the
parking brake set. It should go off if
you turn on the headlights or release the parking brake. If it comes on at
any other time, it means there is a
problem with the DRL. There may also be a problem with the high
beam headlights.

Instruments and Controls
D R L

Lights

Check the operation of your car's
exterior lights at least once a month.
A burned out bulb can create an unsafe condition by reducing yourcar's visibility and the ability to
signal your intentions to other

drivers.

Maintenance
HIGH BEAM HEADLIGHT


LOW BEAM HEADLIGHT
FRONT FOG LIGHT
TURN SIGNAL/
PARKING LIGHT
SIDE MARKER LIGHT

Lights

Check the following: Headlights (low and high beam)
Fog lights
Parking lights
Taillights
Brake lights
Turn signals Back-up lights
Hazard light function License plate light
Side marker lights
High-mount brake light
Daytime running lights (Canadian

models)

If you find any bulbs are burned out,

replace them as soon as possible.

Refer to the chart on page 303 to

determine what type of replacement

bulb is needed.

Maintenance
HIGH-MOUNT BRAKE LIGHT
TURN SIGNAL LIGHT

LICENSE PLATE

LIGHTS

STOP/TAIL LIGHTS

BACK-UP LIGHT

Lights

Replacing a High Beam Headlight
Bulb
The low beam headlight bulbs are a type of high voltage discharge tube.
High voltage can remain in the
circuit even with the light switch off
and the key removed. Because of
this, you should not attempt to examine or change a low beam
headlight bulb yourself. If a low
beam headlight bulb fails, take the
car to your dealer to have it replaced. Halogen bulbs are used for the high
beam headlight bulbs. When replacing a high beam headlight bulb,
handle it by its base and protect the
glass from contact with your skin or
hard objects. If you touch the glass, clean it with denatured alcohol and a
clean cloth.

Halogen bulbs get very hot when lit. Oil,

perspiration, or a scratch on the glass
can cause the bulb to overheat and
shatter.
1. Open the hood.
2. Remove the electrical connector
from the bulb by pulling the connector straight back.

3. Remove the rubber weather seal

by pulling on the tab.

Maintenance
NOTICE

Lights

4. Unclip the end of the hold-down
wire from its slot. Pivot it out of
the way and remove the bulb.

5. Insert the new bulb into the hole,

making sure the bulb is right side
up and the nubs on the bulb base
fit in the indentations in the headlight assembly. Pivot the hold-
down wire back in place and clip
the end into the slot.

6. Install the rubber seal over the

back of the headlight assembly.
Make sure it is right side up; it is
marked

7. Push the electrical connector onto

the new bulb.
Turn on the headlights to test the new bulb.

Replacing a Fog Light Bulb
Your car uses halogen fog light bulbs. See page 252 for informationon replacing a halogen bulb.

CONTINUED

Maintenance

WEATHER SEAL
BULB
CONNECTOR

HOLD-DOWN WIRE

Lights

Replacing Front Turn Signal/ Parking and Side Marker Light
Bulbs
1. If you are changing the bulb on the driver's side, start the engine,
turn the steering wheel all the way
to the right, and turn off theengine. If you are changing the
bulb on the passenger's side, turn
the steering wheel to the left. 2. Use a flat-tipped screwdriver to
remove the holding clip from the
inner fender.
3. Pull the inner fender cover back.
4. Remove the socket from the headlight assembly by turning itone-quarter turn counterclockwise. 5. To remove the front turn signal/
parking light bulb, push it inslightly and turn it
counterclockwise. To remove the side marker bulb, pull it straight
out of its socket.
6. Install the new bulb into the
socket.

7. Insert the socket back into the headlight assembly. Turn itclockwise to lock it in place.
8. Test the lights to make sure the new bulb is working.
9. Put the inner fender cover in place. Install the holding clip. Lock it in
place by pushing on the center.
Maintenance

HOLDING CLIP

Specifications

Technical Information
page 236

"' Low beam headlight bulbs are a type of high voltage discharge tube
(D2R).

page 295
page 294

Index

Accessories and Modifications.... 174 Accessories................................. 174
Additional Safety Precautions.. 175Modifications............................. 175
ACCESSORY (Ignition Key
Position)........................................ 80
Accessory Power Socket.............. 115
Additives, Engine Oil..................... 218
Airbag (SRS).......................... 9, 43, 45
Air Cleaner Element...................... 231
Air Conditioning Filter.................. 242
Air Conditioning System............... 122 Maintenance............................... 241
Usage..................................124, 129
Air Outlets (Vents)........................ 122
Air Pressure, Tires........................ 243
Alarm, Anti-theft............................ 164
Alcohol in Gasoline........................ 306
Aluminum Wheels, Cleaning........ 265
Antifreeze....................................... 221
Anti-lock Brakes (ABS) Indicator................................ 56, 189Operation.................................... 188
Anti-theft, Audio System............... 164
Anti-theft Steering Column
Lock...............................................80

Anti-theft System........................... 165

Appearance Care........................... 263

Armrest............................................. 97

Ashtrays.......................................... 117

Audio Controls, Remote................ 163

Audio System................................. 136
Automatic Climate Control
System......................................... 122

Automatic Lighting.......................... 64
Automatic Seat Belt Tensioners.................................... 41
Automatic Speed Control................ 73
Automatic Transmission............... 182
Capacity, Fluid........................... 302

Checking Fluid Level................228

Shifting........................................ 182

Shift Lever Position Indicator.. 182
Shift Lever Positions................. 182
Shift Lock Release..................... 185 Battery
Charging SystemIndicator............................ 54, 286
Jump Starting............................. 280 Maintenance............................... 236
Specifications............................. 303
Before Driving............................... 167
Belts, Seat..................................... 8, 40
Beverage Holder............................ 112
Body Repair.................................... 270

Brakes
Anti-lock System (ABS)............ 188
Break-in, New Linings .............. 168
Bulb Replacement..................... 256
Fluid............................................229

Parking........................................ 109
System Indicator.................. 54, 289
Wear Indicators......................... 187
Braking System.............................. 187
Break-in, New Car......................... 168
Brightness Control, Instruments... 66
Brights, Headlights......................... 63

CONTINUED

Index
Bulb Replacement
Back-up Lights........................... 256
Brake Lights............................... 256
Ceiling Lights............................. 259
Courtesy Lights......................... 259

Fog Lights.................................. 253

Front Side Marker Lights......... 255

Headlights.................................. 252

High-mount Brake Light.......... 257
License Plate Lights.................. 258

Specifications............................. 303

Trunk Light................................ 260
Tum Signal Lights..................... 255

Bulbs, Halogen............................... 252

Cancel Button................................... 75
Capacities Chart............................. 302

Carbon Monoxide Hazard.............. 49
Carrying, Cargo............................. 176

Cassette Player
Care............................................. 156

Operation............................ 141, 153

CAUTION, Explanation of............... ii
CD Changer................... 144, 157, 159

Ceiling Lights................................. 118
Certification Label......................... 300

Chains............................................. 249
Changing Oil
How to......................................... 219

When to....................................... 208

Changing a Flat Tire..................... 273
Changing Engine Coolant............. 223
Charging System Indicator.... 54, 287
Checklist, Before Driving............. 180

Child Safety...................................... 20
Child Seats........................................ 24
Tether Anchorage Point............. 39

Childproof Door Locks................... 85
Cigarette Lighter........................... 116

Cleaner. Air.................................... 231

Cleaning
Aluminum Wheels..................... 265

Carpeting.................................... 266

Exterior....................................... 264

Fabric.......................................... 266

Interior........................................ 266
Leather........................................ 266

Seat Belts.................................... 266

Vinyl............................................ 266
Windows..................................... 267

Wood Trim................................. 267

Climate Control System................ 122
Clock, Setting the.......................... 109
Code, Audio System...................... 164

CO in the Exhaust......................... 308

Coin Box......................................... 113

Cold Weather, Starting in............. 181

Compact Spare............................... 272

Console Compartment.................. 113
Consumer Information*................ 314
Controls, Instruments and.............. 51Coolant Adding......................................... 221
Checking..................................... 172

Proper Solution.......................... 221

Replacing.................................... 223

Temperature Gauge.................... 60
CoiTosion Protection..................... 269 Courtesy Lights............................. 119
Crankcase Emissions Control
System......................................... 308

Cruise Control Operation............... 73
Customer Relations Office........... 314

Index

Fan, Interior.......................... 126, 131

Features, Comfort and
Convenience............................... 121
Filling the Fuel Tank..................... 169

Filters
Air Cleaner................................. 231

Air Conditioning........................ 242

Oil................................................ 219

Flashers, Hazard Warning.............. 70
Flat Tire, Changing a.................... 273
Fluids Automatic Transmission........... 228

Brake........................................... 229

Differential................................. 229

Power Steering........................... 230

Windshield Washer................... 227
FM Stereo Radio
Reception........................... 137, 147

Fog Lights......................................... 67
Foreign Countries, Driving in...... 307
Four-way Flashers...........................
70

Front
Airbags.............................. 9,

43

Fuel..................................................

168

Fill Door and Cap....................... 169
Gauge............................................ 60

Octane Requirement................. 168
Oxygenated................................ 306

Reserve Indicator......................... 57
Tank, Filling the......................... 169
Fuel Mileage, Improving............... 173
Fuses, Checking the...................... 292

Gasohol........................................... 306
Gasoline.......................................... 168

Fuel Reserve Indicator................ 57

Gauge............................................ 60
Octane Requirement................. 168
Tank, Filling the......................... 169

Gas Station Procedures................. 169

Gauges.............................................. 58

Engine Coolant Temperature .... 60

Fuel................................................ 60

Speedometer................................ 58

Tachometer.................................. 58

GAWR (Gross Axle Weight
Rating)........................................ 197

Gearshift Lever Positions............. 182

Glass Cleaning............................... 268

Glove Box......................................... 88
GVWR (Gross Vehicle Weight

Rating)........................................ 197

Halogen Headlight Bulbs.............. 252
Hazard Warning Flashers............... 70
Headlights Automatic Lighting..................... 64
Daytime Running Lights............. 65
High Beam Indicator................... 57Lights On Indicator..................... 55

Reminder Chime.......................... 63

Replacing Halogen Bulbs......... 252

Turning on.................................... 63

Head Restraints............................... 96
Heating and Cooling...................... 122
High Altitude, Starting at.............. 181
High-Low Beam Switch .................. 63
High-mount Brake Light............... 257
HomeLink Universal
Transmitter.................................. 89

Hood Latch..................................... 231

Hood, Opening the........................ 170

Horn................................................... 62

Hydroplaning.................................. 195
